Prism Healthcare harvesthealthcare HCSAEBUMP791 Installation and operating manual

General User/Safety Guide
ANTI-ENTRAPMENT
BUMPER &
EXTENSION PIECE
BUMPERS
www.harvesthealthcare.co.uk

T+44 (0)1709 377172 F+44 (0)1709 377173
2

E[email protected] www.harvesthealthcare.co.uk 3
CONTENTS
WARNINGS & CAUTIONSWARNINGS & CAUTIONS
PRODUCT OVERVIEWPRODUCT OVERVIEW
GENERAL INFORMATIONGENERAL INFORMATION
INSTALLATIONINSTALLATION
BUMPER EXTENSION INSTALLATIONBUMPER EXTENSION INSTALLATION
CLEANING AND CARECLEANING AND CARE
4
5
6-7
8-9
10-11
12

T+44 (0)1709 377172 F+44 (0)1709 377173
4
READ THIS INSTRUCTION MANUAL CAREFULLY. PLEASE NOTE
IN PARTICULAR THAT THE SAFETY INSTRUCTIONS MUST BE
OBSERVED.
WARNING
Please ensure that this booklet is read prior to rst use.
Please refer to the information in this booklet as a guideline only.
Harvest Healthcare Ltd recommend that prior to using this product, a full risk assessment must be
completed by a qualied professional, in order to determine that the correct product is suitable for each
individual.
Do not allow sharp objects to penetrate the side rail meshing or the covering material.
Ensure this product is tted as specied in the tting instructions.
Routinely inspected this item for damage and ensure all xing straps or Hook and Loop are securely fastened.
Remove the item from service if the product is damaged or ripped.
Remove the item if the xing straps or the Hook and Loop show signs of wear and they are not effective.
Do not expose this product to open ames. We advise the user not smoke when using this product.
Facial contact with the cover may cause suffocation if used incorrectly.
WARNINGS &
CAUTIONS
SYMBOLS USED
This symbol indicates general hazards. There is a danger to life and health.
COVERS ARE
REMOVABLE AND
MACHINE WASHABLE
LOW HEAT
TUMBLE DRY
DO NOT
DRY CLEAN
DO NOT
BLEACH
DO NOT IRON CE MARK NO
SMOKING
PHENOLS
DO NOT USE
PHENOLS
UKCA MARK

E[email protected] www.harvesthealthcare.co.uk 5
PRODUCT OVERVIEW
PRODUCT DESCRIPTION
Anti-Entrapment Bumper
The Anti-Entrapment Bumper is a 2 bar bumper with net/mesh insert and anti-entrapment
system with link sheet. Designed for users who move excessively in bed, to prevent limbs
from becoming trapped. The Anti-Entrapment Bumper ts all standard width Woburn beds,
whilst also being suitable for most other manufacturer’s beds with two full length wooden
side rails at each side of the bed. We also offer the Anti-Entrapment Bumper for beds with 3
bar side rails (Ultimate/Safeguard). All the bumpers come with covers that are removable and
machine washable, for better infection control.
Product Code Description
HCSAEBUMP791 Anti-Entrapment Bumper with Net/Mesh Inserts for Woburn &
Community Bed (L: 2000 mm)
HCSAEBUMP140 Anti-entrapment Bumper with Net/Mesh Inserts for Beds with 3
Bar Side Rails (Ultimate/Safeguard) (L: 2000 mm)
HCSAEBUMP791
+ HCSAE-
BUMP791.EX20
Extended Anti-Entrapment Bumper with Net/Mesh Inserts for
Woburn & Community Bed (L: 2200 mm)
HCSAEBUMP140
+ HCSAE-
BUMP140.EX20
Extended Anti-Entrapment Bumper with Net/Mesh Inserts for
Woburn Ultimate Bed (L: 2200 mm)

T+44 (0)1709 377172 F+44 (0)1709 377173
6
GENERAL INFORMATION
INSTRUCTIONS FOR USE
Check the product for damage, and if it is the correct type of product for the bed, before
carrying out the installation.
• If a bumper netting or any other part of the product looks damaged do not t the
bumper.
• Refer to the product code and pictures to make sure you’re using the right instruction for
use.
• Before installing this product read the instruction for use thoroughly and seek advice if
you are unsure how to t the product.
To help prevent injury it is important that patients and equipment are monitored regularly.
The Anti Entrapment bumper may be delivered in a plastic cover for protection; these covers
must be removed and dispose of before the equipment can be used.
Please dispose of the plastic as specied by your local waste disposal service authority.
INTENDED PURPOSE
The 2 bar Anti-Entrapment bumper is designed for users who move excessively in bed, to pre-
vent limbs from becoming trapped.
ANTI-ENTRAPMENT BUMPER INSPECTION RECOMMENDATIONS
The Anti-Entrapment bumper should be checked regularly to ensure it remains ‘t for
purpose’, effective and pose no risk of infection to either the patient or the carer.
Harvest Healthcare Ltd recommend that a thorough inspection of both the exterior (cover)
zips, straps and Hook and Loop is carried out weekly, and each time a new patient is
introduced to this equipment. Visual checks should be carried out daily to identify any
signicant signs of damage or infection risk.
If any signs of contamination are identied, the bumper system should be withdrawn from use
immediately and cleaned.
CLEANING AND CARE
The bumper system has a black mesh and protective Vinyl cover. The cover should be
cleaned regularly in accordance with your organisation’s disinfection protocol. (See page 10)
Facial contact with any covering material such as that used on this
product can cause suffocation and a Risk Assessment should be
carried out prior to the use of this product.

E[email protected] www.harvesthealthcare.co.uk 7
GENERAL INFORMATION
MOVING, HANDLING AND STORAGE
Where possible, the bumper system should be stored at to prevent damage to the product.
It may require more than one person to aid in tting the system.
The bumper system is to be stored between -5 to +40 degrees, in a dry environment.
Do not expose to high humidity or heat.
Do not drag or pull the bumper system by the cover.
SAFE USE
This product is intended as an aid to prevent accidental injury. With a carer present check
the material, zips and fastenings to ensure that these parts of the bumper systems have not
been damaged and do not introduce gaps too or a hazard that could be increased the risk of
entrapment suffocation or injury to the end user or carer.
Before and during use of the bumper system, consider the effectiveness of the system,
including if the side rails has been tted correctly, and the side rails can be raised and lowered
according to the manufacturers instructions. The hazard of entrapment can still occur if the
side rail system has not been tted correctly or the wrong type has been tted.
Seek advice to ensure the correct type is selected before installation as per the manufacturers
instructions.
IMPORTANT NOTICE
The bumper must be able to be removed or lowered in case the user requires urgent medical
attention or CPR.
Do not leave a bumper in place if the side rails can not be removed or lowered as described
in the manufacturers instructions.
Do not sit on the side rails with the bumper on as this will deform the product and could
cause the side rail system to malfunction
WARRANTY
BUMPER SYSTEMS
All Harvest Healthcare bumper systems are covered by warranty for a period of 1 year.
Damage through incorrect use will invalidate this warranty.
GUARANTEE
Harvest Healthcare Ltd guarantees to repair or replace all goods issued to its customers
which are found to be defective whilst still under their applicable warranty period. All
warranties are subject to our standard terms and conditions of sale which can be found on
our website or by request to Harvest Healthcare Ltd.

T+44 (0)1709 377172 F+44 (0)1709 377173
8
1. Lay the bumper system on the mattress platform with the Head end this way up label facing
upwards and at the head end of the bed.
2. Locate the top bumper pad by identifying the pad with the label (on the inside of the bumper pad
saying top rail inside)
3. Present the top pad (with the above label) against the top side rail, the padding from both
pads will hang on the inside of the side rails.
4. Ensure the padding passes over the top of the rail and connect the zip (see picture below)
The long piece of black mesh passes over the top of
the top pad
Padding passes over the top of the side rail and
nishes here
Zip connects along the lower edge of the upper rail
2 BAR BUMPER
INSTALLATION

E[email protected] www.harvesthealthcare.co.uk 9
5. Once the top pad is connected the lower pad should fall in place and can be zipped up, once
again ensure the padding passes over the top of the side rail.
6. Carry out the same procedure for the opposite side.
7. There are 4 zips in the base sheet to allow the mattress guides to pass through.
Open the tips, pass the mattress guides through the base sheet then close both zips around the
mattress guides.
8. Once installed correctly the inside of the bed should look like the below image.
9. Tubing can be passed through the gaps created for the mattress guides.
10. There are zips on each padded section to allow the foam protection to be removed before
washing.
2 BAR BUMPER
INSTALLATION

T+44 (0)1709 377172 F+44 (0)1709 377173
10
1. Lay the system on the bed with the label on the base sheet (saying head end – this way up) at
the head end of the bed facing upwards
2. Lay the padded sections across the top of the base sheet and locate the pad with the label
saying top rail inside
3. Present the pad with the label against the top rail.
3 BAR BUMPER
INSTALLATION
4. Zip the pad around the top rail

E[email protected] www.harvesthealthcare.co.uk 11
5. Bring the rest of the bumper pads from the inside of the bed over the top rail to the outside of
the bed and pass them between the top and middle rails.
6. Zip the pad around the centre rail.
7. Finally zip the pad around the bottom rail.
8. Feed the mattress guides through the base sheet and close the zips.
3 BAR BUMPER
INSTALLATION
9. There are 2 holes in the base sheet to allow tubing to pass between the inside and outside of the
of the platform.

T+44 (0)1709 377172 F+44 (0)1709 377173
12
BUMPER EXTENSION
INSTALLATION
1. Install the full-length bumper as normal on the extended side rails leaving the gap towards the
foot end of the bed.
2. Fit the extension to the side rails with the padded section to the outer edge of the rail.
3. Ensure the 2 Hook and Loop aps are towards the full size bumper.
4. Fold both Hook and Loop aps together with the mesh from the full-length bumper in between
Standard bumper
Hook and Loop
aps
Footboard end
200mm
extension

E[email protected] www.harvesthealthcare.co.uk 13
BUMPER EXTENSION
INSTALLATION
5. The edge of the extension should slightly cover the end on the full-length bumper (there should
be no gap between the 2 parts)
6. View from inside.

T+44 (0)1709 377172 F+44 (0)1709 377173
14
CLEANING & CARE
BUMPER COVER
During general use, the bumper cover can be cleaned by wiping with a mild detergent
solution.
Where necessary the cover can be laundered or wiped clean. Where there is staining or
body uids on the outer cover, wash thoroughly with soap and water, then wipe with a
sodium hypochlorite solution diluted to 1000ppm before laundering. Bumper covers may be
laundered if the foam can be removed.
WARNING
Eye protection, gloves, and protective clothing should be worn when carrying out cleaning
and disinfection procedures.
When disinfecting the system, Harvest Healthcare recommends the following guidelines
which have been developed to comply with recognised infection control procedures.
These procedures are also to be used to prevent cross infection when transferring the
system between patients.
INSTRUCTIONS ON HOW TO LAUNDER THE OUTER COVER
Lay the bumper cover down on a at surface and unzip the pocket to gain access to the
internal foam padding. Remove the foam padding. The bumper can now be laundered.
1 Pre wash cold 10 minutes
2 Main wash 80°C 10 minutes
3 Followed by cold rinses and extraction.
Do not use abrasive cleaners, phenol disinfectants, solvents, or alcohol-based cleansers,
e.g. Dettol, Phenicol, Hibiscrub, Clearsol, Stericol, Hycoline, as these will damage the cover
materials.
Tumble dry at low heat.
Do not iron.
Ensure that the cover is thoroughly dried before inserting the foam and placing the bumper
into storage.
HYPERCARBONATE AND PHENOL-BASED SOLUTIONS SHOULD NOT
BE USED AS THESE WILL DAMAGE THE PRODUCT COVER
DISPOSAL
If contaminated, please dispose of as clinical waste.
If not contaminated dispose of as household waste at your local approved facility.
Note:
• Remove the foam before decontamination.
• Harvest Healthcare recommends using a wash bag to protect the system if
decontaminating in a washing machine.
• Carry out a risk assessment to ensure the bumper is suitable for the users’ requirements.
• In the event of the bumper system becoming damaged discontinue use immediately and
contact Harvest Healthcare for advice.
• If you have any questions, please contact Harvest Healthcare before use.

E[email protected] www.harvesthealthcare.co.uk 15
NOTES

Sheaf House, Bradmarsh Business Park,
Bradmarsh Way, Rotherham S60 1BW
T [phone]
F [phone]
E [e-mail]
www.harvesthealthcare.co.uk
© Copyright Harvest Healthcare - Anti Entrapment Bumper - V1- March 2022
Harvest Healthcare Limited. Company No: 07210261
Our Full Terms & Conditions are available by request or can be found on our Website.
Harvest Healthcare reserves the right to alter or amend this document without notice.
