Prizma PROFI SONIC H User manual

Professional ultrasonic nebuliser 1
Dear customer,
Thank you for purchasing this PRIZMA ultrasonic nebuliser. Please read this instruction manual
carefully before using the unit as it contains important health and safety information. Please
keep your instruction manual at hand all the time.
This unit is medical instrument. Be sure to use unit properly according to instructions given
by medical professionals. Only use medications as prescribed and instructed by your doctor.
We wish you good health and all the best in the future.
With best regards,
PRIZMA, Kragujevac

Instruction manual 2
IMPORTANT INFORMATION – READ THOROUGHLY
History of document revisions ..................................................... 3
Intended use ......................................................................4
Exclusions and limitations of liability .............................................. 5
Safety notes .......................................................................6
PRODUCT DESCRIPTION
Components of the product ......................................................10
Principle of nebulisation .........................................................12
Main features of the product .....................................................12
USE OF NEBULISER
How to prepare before inhalation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
How to inhale ....................................................................16
Finishing the inhalation treatment............................................... 20
PRODUCT CARE & MAINTENANCE
How to take care of the nebuliser unit ............................................ 21
Cleaning and disinfection ........................................................22
SPECIFICATIONS
Troubleshooting .................................................................25
Technical data ....................................................................26
Important information regarding Electro Magnetic Compatibility (EMC) .........27
Correct disposal of this product (Waste electrical & electronic equipment) .......27
Optional parts ................................................................... 28

Professional ultrasonic nebuliser 3
History of document revisions
Version Date Description of changes
1.0 01. 02. 2014. Initial version
1.1 25. 12. 2014. Package contents
1.2 01. 12. 2015. Optional parts

Instruction manual 4
Intended use Device is intended to be used for inhalation of medication for respiratory
disorders.
This device is NOT intended for direct inhalation via mouthpeace or face mask.
The distance between patient and aerosol hose must be at least 10cm.
Intended users • Medical professionals (doctor, nurse, therapist, ...)
• Healthcare personnel or patients trained and guided by qualified medical
professionals.
User must be capable of understanding instruction manual and general
device operation.
Intended patients Conscious, spontaneously breathing patients.
Working environment Device is intended for use in medical facility such as hospital, clinic, doctors
office and in room of general household.
It is assumed that:
• nebuliser is placed on the table or trolley,
• ambient temperature is under 30°C,
• the distance between patient and aerosol hose is at least 10 cm,
• operator is in the vicinity of the nebuliser.
Lifetime
Lifetime of main parts of device if based on 8 hour operation with saline,
at room temperature (23 °C). Lifetime may vary depending on working
environment.
Main unit 5 years
Inhalation hose 1 year
Bacterial filter 50 working hours
Precautions for use User must read warnings and cautions described in this instruction manual.
Intended use
PROFI SONIC H is medical device intended for successfull treatment of asthma, bronchitis,
allergy and other respiratory disorders. Use it only according to recommendations issued
by your doctor or therapist.

Professional ultrasonic nebuliser 5
Please remember that the warranty does not apply:
1. to damage caused by service or maintenance performed by anyone who is not a
representative of PRIZMA or a PRIZMA Authorized Distributor;
2. to damage caused by use with non-PRIZMA products and materials;
3. to damage caused by using unauthorized spare parts;
4. to damage caused by operating the product outside the permitted or intended
uses described by PRIZMA in the Instruction Manual;
5. to damage caused by a poor working environment or failure to follow the
written instructions, including poor or incorrect electricity and inadequate
surroundings;
6. to damage caused by unauthorized modifications of the product and repairs
carried out by unauthorized personnel;
7. to damage caused by Force Majeure, e.g. fire, earthquake, flood or thunder
storm.
Exlusions and limitations of liability
1. Due to our commitment to the ongoing development and improvement of our
products, PRIZMA reserves the right to amend or change the content of this
Instruction Manual without notice.
2. The contents of this manual are believed to be correct at the time of printing.
However, if you should notice any errors or omissions, please contact your local
representative or PRIZMA distributor.
3. In accordance to Copyright Law, any reproduction of this Instruction Manual in
whole or part is strictly prohibited without prior permission in writing by the
Copyright holder.

Instruction manual 6
Safety notes
The warning signs and the sample icons shown here are listed for you to use this
product safely and correctly as well as to prevent the risk of injury.
The icons and meanings are as follows:
Warning sign Contents
Warning
This sign indicates matters in which the possibility of death or severe bodily
injury may arise as a result of incorrect handling.
Caution
It indicates matters in which bodily injury or material damage* may arise as a
result of incorrect handling.
* Material damage refers to a wide range of damage involving your house, household goods, domestic animals and pets.
Examples of signs
The icon indicates caution (including warning
and danger).
Matters involving actual caution are indicated by
text or pictures in or near .
The pictured
icon refers to
‘caution for
flammability’
The pictured
icon refers to
‘caution for
electric shock’
The icon indicates prohibitions (what you
cannot do).
Matters involving specific prohibitions are
indicated by text or pictures in or near .
The pictured
icon refers to
‘prohibition to
disassemble’.
The pictured
icon refers
to ‘general
prohibition’.
The icon indicates something that is
compulsory (must be observed at any time).
Matters involving specific compulsory actions
are indicated by text or pictures in or near .
The pictured
icon refers
to ‘general
compulsion’.
The pictured
icon refers to
‘unplugging the
power plug’.
Warning
Only use medications as prescribed and instructed by your doctor.
• Your physical condition may change for the worse.
When you use the unit for the first time after purchasing or after having not used it
for a long time, be sure to clean and disinfect it.
• Miscellaneous types of bacteria may propagate and you may get infected.
Clean and disinfect the medication cup, medication cup cover and inhalation hose
each time the unit is used.
• Miscellaneous bacteria may propagate and you may get infected. If the unit is
going to be used by more than one person, prepare a disinfected medication cup,
medication cup cover and inhalation hose for each person before using it. This will
prevent cross-infection.
Be sure to immediately dry the cleaned and disinfected parts, and then store them
in a dry place in order to prevent them from getting contaminated in the future.
In case of any problem with your nebuliser please contact your local PRIZMA service
representative (address on/inside package)

Professional ultrasonic nebuliser 7
Warning
Do not use this device in presence of explosive gases or in areas with high risk of
explosion.
Use with nonflammable liquids only.
Do not use this device in combination with ventilation equipment.
Do not use in oxygen rich environment.
• The pressure in the ventilation system may reduce significantly.
When assembling the cleaned, disinfected and dried parts, do not touch the places
where the medication and nebulised medication pass through directly with your
hands to prevent possible infection.
Do not make any contact with the vibrator while the power plug is plugged into the
electric outlet.
• You may suffer electric shock or you may injure yourself.
Do not use this device when ambient temperature is above 30°C.
Do not plug in or pull the power plug from the electric outlet with wet hands.
• You may suffer electric shock or you may injure yourself.
Do not wash the main unit with water or splash water to the power source, do not
use the nebuliser while you are in bath or having a shower, never submerse the
nebuliser in water.
• Short circuit may occur in the unit or you may suffer electric shock.
Caution
Use only aqueous drug solutions to inhale using the nebuliser.
• If you use unsuitable solvents, it may cause failure of components and malfunction
of the unit.
Clean the nebuliser with disinfectant and wash off thoroughly with water.
• If you inhale any of the remaining disinfectant, your physical condition may change
for the worse.
If the nebulisation parts have already become contaminated before using the unit,
clean them first before use.
• If the medication remains in the nebulisation unit, your physical condition may
change for the worse.
Replace the water in the water tank each time you use the unit.
• A dirty vibrator may cause lower nebulisation rate.
Disposal of the product should be carried out in accordance with the national
regulations for the disposal of electronic products.
Safety notes

Instruction manual 8
Caution
This equipment must only be connected to a supply mains with protective earth.
• You may suffer electric shock.
If you are not going to use the unit for a long time, be sure to unplug the power
plug from the electric outlet.
Be sure to turn off the power and unplug the power plug from the electric outlet
when you install or remove the device or take care of the components.
• You may suffer electric shock or you may injure yourself.
Do not look into the nebulisation section during nebulisation.
• A large amount of medication may get into your eyes and cause injury.
Do not operate the unit when the medication cup is empty.
• The unit may be overheated or damaged.
Do not fill the water tank with the liquid other than water.
• The vibrator will deteriorate and may get damaged.
When components are sterilised in an autoclave, make sure they do not directly
contact the heater.
• As the temperature of the heater is very high, these components may melt or
become deformed.
Do not use the power cord or the power plug if it is damaged, or do not plug the
power cord into a loose electric outlet.
• You may suffer electric shock or the unit may ignite due to short circuit.
Do not scratch, tear, modify, forcibly band, pull, twist, or bundle the power cord.
Do not place a heavy material on the power cord. Keep power cord away from
heated or hot surfaces.
• You may suffer electric shock or the unit may ignite due to short circuit caused by
the deteriorated insulation.
Do not disassemble, repair, or modify the unit in any way.
• The unit may malfunction or cause injury.
Contact your nearest PRIZMA service representative.
Do not use the power cord other than the supplied one.
• The unit may ignite or you may suffer electric shock.
Be sure to use the power source as specified on the device.
• The unit may ignite or you may suffer electric shock.
Do not share the electric outlet with other electric appliances.
• The unit may ignite or you may suffer electric shock.
To unplug the power plug from the electric outlet, do not pull the power cord;
instead hold the power plug with your hand.
• The power cord may be broken or shortcircuited. It may cause fire or you may
suffer electric shock.
Safety notes

Professional ultrasonic nebuliser 9
Safety notes
General Advice
Do not use the unit for any purpose other than for inhalation.
Do not use any parts other than the accessories or the optional components listed in this Instruction
Manual.
Do not fill the medication cup with more than 150ml medication or less than 5ml.
Do not move the unit while medication still remains in it.
Do not block the air ventilation holes at the bottom side of the nebuliser.
Place the nebuliser on a plain and stable surface during operation.
Do not apply strong shocks to or drop the main unit.
Do not bend the inhalation hose.
• The medication may be pooled in the hose and the nebulisation rate may be lowered.
Do not inhale from the inhalation hose if the main unit is higher than your head.
• The medication may spill onto your face or clothes.
Be careful not to damage the vibrator when cleaning the water tank of the main unit.
Do not disinfect the unit by boiling in a microwave oven.
After cleaning and disinfecting the components, assemble them after they are completely dried.
Do not wipe the main unit with volatile chemicals, such as benzene or thinners.
Although the nebuliser fulfils the provisions of the EMC (Electromagnetic Compatibility) directive, the use
of it should be avoided in direct vicinity of other electric devices.
Do not allow unsupervised children or infirm persons to use the unit.
Maintenance
Before using the unit, be sure to confirm that the main unit operates normally and safely.
How to handle failures or accidents
If an equipment error occurs, immediately take the following measures:
1) Poweroff the unit and unplug the power plug from the electric outlet.
2) Write ‘FaultyDo not use’ on the main unit so that it will not be used.
3) Contact the store where you purchased the unit or the nearest PRIZMA dealer.

Instruction manual 10
1
4
5
8
9
2
10
3
6
7
Components of the product

Professional ultrasonic nebuliser 11
- Main unit
- LCD touch screen display
 Handle
- Cover fixing lever
- Bacterial filter
- Filter cover
- Medication cup holder
- Medication cup
- Medication cup cover
- Water tank
- Power button
- Fuses
- Electric power socket
- Drain hose
- Inhalation hose holder
 Heater plug
Components of the product
15
12
13 16
11
14

Instruction manual 12
Principle of nebulisation and main features
Principle of nebulisation
1. PROFI SONIC H transmits the energy of ultrasonic
vibrations from the vibrator located at the bottom of
the water tank into water.
2. The ultrasonic vibrations are transmitted to the me-
dication cup through the water in the water tank.
3. The ultrasonic vibrations emit medication from the
medication cup (like a fountain) and it is dispersed as
aerosol.
4. Air from the fan carries this nebulised medication out
of the medication cup.
Main features of the product
1. Easy to use large LCD displays air volume, nebulisation rate, remaining time, and error
location. The back-light illumination featured in the unit enables checking of the
display in the dark.
2. LCD screen is touch sensitive which enables interactive operation. The unit has a
notification buzzer which produces a short sound each time a user touches a co-
mmand on the screen.
3. The buzzer produces characteristic sounds when the time set by the timer is comple
ted or when an error occurs.
4. With the use of a touch screen display, the air volume, nebulisation rate, heating level
and time can be set easily and quickly. The unit can handle various inhalation therapies
with the use of various optional parts.

Professional ultrasonic nebuliser 13
How to prepare before inhalation
1. Disassembling the nebulisation unit
Rotate the medication cup cover fixing lever
clockwise. Take the medication cup holder (plastic
ring) located below the cup cover and lift it up. In this
way, the nebulisation section is removed.
Note: Medication cup holder is a three-legged part
which keeps it steady on the table.
2. Filling the cooling water
Fill the cooling water in the water tank . The proper
amount is approximately 300ml. Pour some water
until the sensor level float in the water tank rises to its
upper position. Recommended water temperature is
approximately 25°C. To prevent scale buildup in the
water tank, use distilled or demineralised water instead
of tap water.
3. Attaching the nebulisation unit
Attach the nebulisation unit to the water tank . Be
sure that the air duct on the rear side of the nebulisation
unit is adjusted properly to the air filter cover .
Sensor level float in upper position
Vibrator
Water level

Instruction manual 14
How to prepare before inhalation
4. Removing the medication cup cover
Hold the medication cup holder with one hand while
the other is removing the medication cup cover .
5. Placing the medication cup
Place the medication cup in the medication cup
holder (opaque plastic ring) .
Note: The medication cup is made of thin plastics.
Take care not to rumple or pierce the cup.
6. Filling medication into the medication cup
Fill medication into the medication cup . Be sure the
medication volume is between 5 ml and 150 ml. Use
only medications prescribed by your doctor.
7. Closing the medication cup
Put the medication cup cover back . Be sure to put
the cover properly onto the medication cup holder. Fix
the medication cup cover by rotating the cover fixing
lever .
Maximum
medicine level

Professional ultrasonic nebuliser 15
11:25
10:00
How to prepare before inhalation
8. Attaching the inhalation hose
Attach the inhalation hose to the medication cup cover
. Approximately 10mm of the hose length should be
fitted over the adapter on the medication cup cover.
Conect cable running from heating tube to socket on
the rear side of unit.
9. Plugging the nebuliser into the electrical outlet
Make sure that the power button is in the OFF/0
position. If the power cord is not attached, insert it
fully in the socket of the nebuliser and plug it into
an electrical outlet.
Note: Mains socket outlet used for connection of the
control unit to the mains shall be easily reachable to
the operator.
10. Turning the nebuliser on
Turn on the power button . The main page will appear
on the screen in a few seconds after introduction.
The initial length of inhalation time is 10 minutes as set
by the manufacturer as well as the minimal values of
the air-flow volume and the nebulisation rate.
11. View of the LCD display
Setting the duration of
inhalation (in minutes)
Setting the air-flow
volume
Setting the nebulisation
rate
Setting the heating
level
Setting the inhalation
start time
Opening the setting
menu
Set buttons
Inhalation START/STOP
button
Current time or starting inhalation time

Instruction manual 16
How to inhale
You operate the nebuliser by pressing the icons on the touch screen. A short beep sound is
produced with each command enabling the user to have greater control over the device.
Note: Use your fingertips only to tap the LCD touch screen in order to prevent damages
and to provide durability to the device. Be careful not to scratch the screen with your
nails or something hard (a pencil, etc.). The time interval between two consecutive taps
must be longer than 200ms, otherwise the device will not register the taps.
Icons on LCD display
Icon for setting the inhalation time. The timer is on the right side from the icon.
Icon for setting the air-flow volume. The air-flow volume is presented in the bar
graph on the right side from the icon.
Icon for setting the nebulisation rate. The nebulisation rate is presented in the bar
graph on the right side from the icon.
Icon for setting the level of aerosol heating. The heating level is presented in the bar
graph on the right side from the icon.
If heating tube is not connected to the nebuliser, this picture will appear on display
as heater button.
Icon for setting the start of inhalation. Current daily time or start of inhalation is
presented on the right side from the icon.
Setting menu icon
START inhalation icon
PAUSE inhalation icon

Professional ultrasonic nebuliser 17
How to inhale
STOP inhalation icon
Press the “+” button to increase a parameter value.
Press the “−“ button to decrease a parameter value.
Bar graph depicting set values of the air-flow volume and the nebulisation rate as
been set.
1. Setting the time
The nebuliser has a battery clock which measures time even if the nebuliser is turned off.
You can set the time by pressing the button . A new page will display. Press the
button and it will change its colour into . Adjust the time by pressing the “+“ and “−“
buttons. If you press and hold the “+” or “−“ button, time will change. Once the current
time has been set, press the button. The main page will show and the time as set
will appear at the bottom of the display.
2. Setting the inhalation time
Press the button. It will change its colour into . Set the inhalation time by pressing
the “+” and “−“ buttons. The longest possible inhalation time is 99 minutes. Once the
inhalation time has been set, it will appear on the right side from the setting button.
3. Setting the nebulisation rate
Press the button. It will change its colour into . Set the nebulisation rate by pressing
the “+” and “−“ buttons. The quantity of aerosol will appear in the eightlevel bar graph
on the right side from the setting button.
If the bar graph depicts the lowest aerosol quantity , and you press the “−“ button
again, the image will appear instead of . It means that the nebuliser has been set
to a low medication dose (less than 5ml). The inhalation time will disappear from the
display, since low doses of medication are nebulised until the whole quantity has been
spent. Even then the nebulisation rate may be set within eight levels.
You may leave the low dosing regime by pressing the “+” button for the highest dose
of aerosol depicted in the bar graph, and then press the “+” button again.

Instruction manual 18
How to inhale
4. Setting the air-flow volume
Press the button and it will change its colour into . Adjust the air-flow volume
by pressing the “+” and “−“ buttons. The air volume can be seen in the eight-level bar
graph adjacent to the setting button.
5. Setting the heating level
If heating tube is connected to nebuliser, button will appear on the screen. Press
button and it will change its colour into . Adjust heating level by pressing the “+” and
“−“ buttons. The heating level can be seen in the eight-level bar graph adjacent to the
setting button. If heater is not connected to nebuliser, adjustment will not be possible.
6. Beginning the inhalation
Inhalation begins by pressing the button. It will start if the water tank is filled with
cooling water, the medication cup cover is placed and the nebuliser is not overheated.
When the inhalation starts, the button will change into , and the button will turn
into . If the nebuliser has been set to a high medication dose, the countdown time
is displayed. When the set time is over, nebulisation will automatically stop along with
the beeping sound.
During the nebulisation you may additionally adjust the quantity of aerosol and airflow
volume, but you may not vary the time of inhalation or the medication dose (low or high).
If the water level in the water tank is low, or if the medication cup cover has not been
properly placed, or if the nebuliser is overheated, the ERROR display will appear:
If the water level is low or if the medication cup cover has not been placed, fix the
problem and press the button. Then start the inhalation again.
If the nebuliser is overheated, wait for it to cool down, then press the button and
start the inhalation again.
7. Temporary interruption of the inhalation session
You may temporarily pause the inhalation session by pressing the button which then
change into . Converting of medication into aerosol will stop as well as the time count-
down (high dose of medication only).
The inhalation session may be continued by pressing the same button again. The count-
down timer will be activated again and continue to the end of session.
No or badly fitted medication cup cover Low water level Overheated nebuliser
min
max

Professional ultrasonic nebuliser 19
How to inhale
8. Interruption of the inhalation before the end of session
The inhalation session may be stopped at any time by pressing the button . The main
page will appear. The air-flow volume and nebulisation rate will remain on the display
as set before, and the inhalation time will return to the initially set value.
9. Programming inhalation
You may set the nebuliser to start inhalation automatically at particular time, instead
by manually pressing the button .
The unit should be prepared for inhalation (fill the cooling water in the water tank, place
the medication cup, fill medication into the medication cup, assemble the medication
cup cover, attach the inhalation hose). Then press the button which will turn into .
Set the inhalation time by pressing the “+” and “−“ buttons. While setting, the desired
inhalation time will display instead of the current time. After setting the inhalation time
press the button. The current time will reappear by the button and the inhalation
time as set before will appear below. The button will disappear and the button
will turn into . The inhalation session will then start automatically when desired
inhalation starting time is reached. From that moment on, the unit is to be handled as
with manually started inhalation.
When completed or interrupted (inhalation) the inhalation time will disappear, e.g.
inhalation time may be set for a single inhalation session only.
Note: If you need to immediately start an inhalation session, press the button to erase
the time previously set, and then press the button. Inhalation will start immediately
and the time previously set will be deleted.
Note: When you turn off the unit, all the values set previously will be overridden (timer
settings, nebulisation rate, airflow volume) and when you turn it on the next time all
the values will reset to default as set by the manufacturer.
min
10 cm
Note:
The distance between
patient and aerosol hose
must be at least 10cm.

Instruction manual 20
Finishing the inhalation treatment
When the treatment is finished you
should:
1. Turn off the power button (position 0).
2. Remove the inhalation hose from the medication cup
cover.
3. Remove the medication cup cover .
4. Discard the remaining medication .
5. Discard the cooling water in the water tank . Remove
the drain hose from its holder. Put the drain hose
in horizontal position (as in the picture) and allow the
water to drain out into a suitable container. Wait until
all the water has been drained out of the water tank
and then put the drain hose back into its holder.
Notes:
- Be sure not to bend the drain hose in directions different to the one in the picture as
it may become damaged.
 The volume of a suitable container should be greater than 300ml.
6. Clean and disinfect the nebuliser.
Warning
When assembling the cleaned, disinfected, and dried parts, do not touch the
places where the medication and nebulised medication pass through directly
with your hands to prevent possible infection.
Do not make any contact to the vibrator while the power plug is plugged into the
electric outlet.
• You may suffer electric shock or injure yourself.
