Pro-Elec PEL00305 User manual

16” Metal Pedestal Fan
Model: PEL00305

IMPORTANT SAFETY INFORMATION
Please read these instructions carefully before use and retain for future
reference.
• When using electrical appliances basic safety precautions should always be
followed.
• Check that the voltage indicated on the rating plate corresponds with that of the
local network before connecting the appliance to the mains power supply.
• This appliance is intended for domestic use only. It should not be used for
commercial purposes.
• This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning the use of
the appliance in a safe way and understands the hazards involved.
• Children shall not play with this appliance.
• Cleaning and maintenance shall not be made by children without supervision.
• There are no user-serviceable parts in this product. Refer servicing to qualied
personnel.
• Do not operate this fan with a damaged plug or cord, after a malfunction or after
being dropped or damaged in any way.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualied persons in order to avoid a hazard.
• Ensure that the fan is switched off before removing the guard.
• Do not insert anything through the grille when the fan is in use.
• Make sure that the fan is on a stable surface when operating.
PRODUCT OVERVIEW
1. Front guard 10. Knob
2. Fan blade 11. Inner tube
3. Fan blade screw 12. Height
adjustment screw
4. Cover xing
screws
13. Outer tube
5. Rear guard 14. Base
6. Motor shaft 15. Weight
7. Speed control 16. Fastener
8. Fan motor 17. Locking screw
9. Mains lead
1 2
34
5
67
8
9
10
11
12
13
14
15
16
17

ASSEMBLY
CLEANING & STORAGE
• Before cleaning, turn the fan off and unplug from the power supply.
• Use a soft cloth to wipe off any dust. If the fan is very dirty, use a damp cloth and
wipe dry.
• Do not use any chemicals, abrasives or solvents that could damage the fan.
• Store the fan in its original packaging in a dry ventilated area.
• The motor bearings are permanently sealed and do not require additional
lubrication.
TECHNICAL SPECIFICATION
Power consumption 50W
Main voltage 220-240V~ 50Hz
Dimensions 400 x 400 x 1250mm
Weight 6.3kg
• Assemble the stand by inserting the outer tube into the base, t the weight and
secure in place using the locking screw. Place the assembly upright.
• Secure the fan motor to the upper tube using the screws provided.
• Remove the guard xing screws from the motor and attach the rear guard to the
fan motor, securing it in place with the screws.
• Slide the fan blade onto the shaft and x into place with the locking screw on the
centre boss.
• Remove the bolt and nut from the bottom of the front guard and rotate all clips to
an open position.
• Attach the front fan guard, lining up the top notch with the rear guard and ensuring
the bolt hole is aligned for the two halves.
• Close the clips and replace the nut and bolt locking the two halves together.
OPERATION
• Connect the power plug to a suitable outlet.
• Select the desired speed using the speed control:
0 = Off
1 = Low speed
2 = Medium speed
3 = High speed
• The incline of the ventilator head can be adjusted by tilting it forwards or
backwards. The ventilator head can then be locked into position, which is indicated
by an audible click.
• To adjust the height, slacken the height adjustment screw, slide the upper section
to the required height and re-tighten the adjustment screw.

INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF ELECTRICAL &
ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical
& Electronic Equipment (WEEE). Any WEEE marked products must not be mixed with
general household waste, but kept separate for the treatment, recovery and recycling of the
materials used. Contact your local authority for details of recycling schemes in your area.
Made in China. PR2 9PP
Man Rev 1.2
