USER’S MANUAL
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
Model No. PFEVEX71316.0
Serial No.
Write the serial number in the space
above for reference.
Serial
Number
Decal
CUSTOMER SERVICE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: [email protected]
Write:
ICON Health & Fitness, Ltd.
Unit 1D, The Gateway
Fryers Way, Silkwood Park
OSSETT
WF5 9TJ
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: [email protected]
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
www.iconeurope.com

2
This drawing shows the location(s) of the warning
decal(s). If a decal is missing or illegible, see
the front cover of this manual and request a
free replacement decal. Apply the decal in the
location shown. Note: The decal(s) may not be
shown at actual size.
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT PRECAUTIONS..................................................................3
BEFORE YOU BEGIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
PART IDENTIFICATION CHART. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
HOW TO USE THE EXERCISE BIKE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
MAINTENANCE AND TROUBLESHOOTING.....................................................25
EXERCISE GUIDELINES ....................................................................27
PART LIST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
EXPLODED DRAWING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
ORDERING REPLACEMENT PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
RECYCLING INFORMATION ......................................................... Back Cover
WARNING DECAL PLACEMENT
TABLE OF CONTENTS
PROFORM is a registered trademark of ICON Health & Fitness, Inc. IFIT is a registered trademark of ICON
Health & Fitness, Inc. LE TOUR DE FRANCE is a registered trademark of Société du Tour de France. App Store
is a trademark of Apple Inc., registered in the U.S. and other countries. Android and Google Play are trademarks
of Google Inc. The BLUETOOTH®word mark and logos are registered trademarks of Bluetooth SIG, Inc. and are
used under license. IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is
used under license.

3
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all
important precautions and instructions in this manual and all warnings on your exercise bike before
using your exercise bike. ICON assumes no responsibility for personal injury or property damage
sustained by or through the use of this product.
1. It is the responsibility of the owner to ensure
that all users of the exercise bike are ade-
quately informed of all precautions.
2. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or per-
sons with pre-existing health problems.
3. The exercise bike is not intended for use by
persons with reduced physical, sensory, or
mental capabilities or lack of experience and
knowledge, unless they are given supervi-
sion or instruction about use of the exercise
bike by someone responsible for their safety.
4. Use the exercise bike only as described in
this manual.
5. The exercise bike is intended for home use
only. Do not use the exercise bike in a com-
mercial, rental, or institutional setting.
6. Keep the exercise bike indoors, away from
moisture and dust. Do not put the exercise
bike in a garage or covered patio, or near
water.
7. Place the exercise bike on a level surface
with at least 2 ft. (0.6 m) of clearance around
the exercise bike. To protect the floor or
carpet from damage, place a mat under the
exercise bike.
8. Inspect and properly tighten all parts each
time the exercise bike is used. Replace any
worn parts immediately.
9. Keep children under age 13 and pets away
from the exercise bike at all times.
10. When connecting the power cord, plug the
power cord into a grounded circuit.
11. Do not modify the power cord or use an
adapter to connect the power cord to an
improper receptacle. Keep the power cord
away from heated surfaces. Do not use an
extension cord.
12. Do not operate the exercise bike if the power
cord or plug is damaged, or if the exercise
bike is not working properly.
13. DANGER: Always unplug the power
cord and press the power switch to the off
position when the exercise bike is not in
use and before cleaning the exercise bike.
Servicing other than the procedures in this
manual should be performed by an autho-
rized service representative only.
14. Wear appropriate clothes while exercising;
do not wear loose clothes that could become
caught on the exercise bike. Always wear
athletic shoes for foot protection.

4
15. The exercise bike should not be used
by persons weighing more than 330 lbs.
(150 kg).
16. Be careful when mounting and dismounting
the exercise bike.
17. Always keep your back straight while using
the exercise bike; do not arch your back.
18. Over exercising may result in serious injury
or death. If you feel faint, if you become short
of breath, or if you experience pain while
exercising, stop immediately and cool down.
SAVE THESE INSTRUCTIONS

5
Congratulations for selecting the revolutionary
PROFORM®LE TOUR DE FRANCE®exercise bike.
The LE TOUR DE FRANCE exercise bike is unlike any
other exercise bike. With an incline system that allows
you to simulate actual terrain and an array of other
features, the LE TOUR DE FRANCE exercise bike is
designed to let you enjoy the outdoor cycling experi-
ence indoors.
For your benefit, read this manual carefully before
you use the exercise bike. If you have questions after
reading this manual, please see the front cover of this
manual. To help us assist you, note the product model
number and serial number before contacting us. The
model number and the location of the serial number
decal are shown on the front cover of this manual.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Seat
Handlebar Knob
Seat Knob
Post Knobs
Seat Carriage
Handlebar
Water Bottle Holder*
*Water bottle is not included
Gear
Control
Wheel
Pedal/Strap
Console
Incline Control
Leveling Foot
Power Switch
Length: 4 ft. 11 in. (150 cm)
Width: 2 ft. 1 in. (64 cm)
Weight: 128 lbs. (58 kg)
BEFORE YOU BEGIN
Handlebar Carriage
Armrest
Tablet Holder
Power Cord

6
#8 x 6mm
Screw (92)–1
#8 x 10mm
Screw (110)–2
M10 x 58mm Screw (74)–4
M4 x 12mm
Screw (94)–4
M6 x 16mm
Screw (103)–4
PART IDENTIFICATION CHART
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following
the key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see
whether it has been preassembled. Extra parts may be included.

7
ASSEMBLY
• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you complete all assembly steps.
• Left parts are marked “L” or “Left” and right parts
are marked “R” or “Right.”
• To identify small parts, see page 6.
• In addition to the included tool(s), assembly
requires the following tools:
one Phillips screwdriver
Assembly may be easier if you have your own set
of wrenches. To avoid damaging parts, do not use
power tools.
1
2
23
1
A
74
2. Remove and discard the indicated shipping
insert (A). If there are shipping screws in
the Rear Stabilizer (23), remove and discard
them.
Attach the Rear Stabilizer (23) to the Base (1)
with two M10 x 58mm Screws (74).
1. Go to www.iconsupport.eu on your computer
and register your product.
• activates your warranty
• saves you time if you ever need to contact
Customer Service
• allows us to notify you of upgrades and offers
Note: If you do not have internet access, call
Customer Service (see the front cover of this
manual) and register your product.

8
2
8
110
3
3. If there are shipping screws in the Front
Stabilizer (22), remove and discard them.
Attach the Front Stabilizer (22) to the Base (1)
with two M10 x 58mm Screws (74).
74 22
1
4. Attach the Water Bottle Holder (8) to the Frame
(2) with two #8 x 10mm Screws (110); start all
the Screws, and then tighten them.
4
5
3
2
47
5. Locate the Post Knob (47) near the rear of the
Frame (2). Loosen the Post Knob, and then pull
it outward.
Next, insert the Seat Post (3) into the Frame (2),
and release the Post Knob (47) into one of the
adjustment holes in the Seat Post. Make sure
that the Post Knob is in an adjustment hole.
Then, tighten the Post Knob.
74

9
6. Loosen the Seat Knob (29), and then pull it
downward.
Next, insert the Seat Carriage (4) into the Seat
Post (3), and release the Seat Knob (29) into
one of the adjustment holes in the Seat Carriage.
Make sure that the Seat Knob is in an adjust-
ment hole. Then, tighten the Seat Knob.
See the inset drawing. Tighten a #8 x 6mm
Screw (92) into the underside of the Seat
Carriage (4).
6
29
3
4
92
4
7
7. Have a second person hold the Handlebar Post
(6) near the Frame (2).
Locate the long wire tie (B) in the Handlebar
Post (6). Tie the lower end of the long wire tie to
the Main Wire (68).
Next, locate the middle of the long wire tie (B) in
the access hole (C) in the Handlebar Carriage
(105). In the indicated location (D), pull the long
wire tie upward until the end of the Main Wire
(68) is in the access hole.
See the inset drawing. Next, pull the free end
of the long wire tie until the Main Wire (68) is
routed through the Handlebar Carriage (105) as
shown. Then, untie and discard the long wire tie;
do not remove the short wire tie.
105
68
Avoid
pinching
the Main
Wire (68)
B
B
C
D
6
105
2
68
B

10
8
47
68
6
2
8. Tip: Avoid pinching the Main Wire (68) during
this step.
Locate the Post Knob (47) near the front of the
Frame (2). Loosen the Post Knob, and then pull
it outward.
Next, insert the Handlebar Post (6) into the
Frame (2), and release the Post Knob (47) into
one of the adjustment holes in the Handlebar
Post. Make sure that the Post Knob is in an
adjustment hole. Then, tighten the Post Knob.
Avoid pinching the
Main Wire (68)
9
105
7
9. Have a second person hold the Handlebar (7)
near the Handlebar Carriage (105).
Locate the remaining wire tie (E) in the
Handlebar Carriage (105). Tie the indicated
end of the wire tie to the two wires (F) on the
Handlebar (7).
Next, pull the other end of the wire tie (E)
until the two wires (F) are routed through the
Handlebar Carriage (105). Then, untie and
discard the wire tie.
E
F
