Pro-Ject Audio Systems Power Box DS2 Sources User manual

INSTRUCTIONS FOR USE
Pro-Ject Power Box DS2 Sources

© Pro-Ject Audio Systems · Pro-Ject Power Box DS2 Sources · Revision 2018.12.13
2
Dear music lover,
Thank you for purchasing a Pro-Ject Audio Systems Power Box DS2 Sources.
In order to achieve maximum performance and reliability you should study these instructions for use carefully.
Warning of a hazard for the user, the unit or possible misuse
Important notice
Safety instructions
AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the
voltage in your area meets the voltage requirements printed on the device.
Never handle the device while your hands are wet or damp. Avoid letting liquids enter the device. Never
place any item containing liquid, such as a flower vase on or near the device. Never spill any liquid on
the device. Never place any naked flame sources, such as lighted candles on or near the device. The product
shall not be used in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar
conditions.
Using the product
Power Box DS2 Sources is designed to power a wide range of DC-powered Pro-Ject products except of power
amplifiers, integrated amplifiers & receivers.
Make all connections whilst the Power Box DS2 Sources is switched off or disconnected from the
mains.
Interconnection cables are included in the packaging. Original power supplies are no longer
required.
In case of any doubts, consult user manuals of all connected products or ask your dealer.
9V output : CD Box DC, CD Box DS2 T, CD Box S, CD Box S2, Dock Box S Digital, MaiA CD, Media Box S,
Remote Box S, Stream Box DS, Stream Box DS net, Bluetooth Box E, Bluetooth Box S, DAC Box S FL, DAC Box S
USB, Switch Box S, Tuner Box S, USB Box S+.
18V output : A/D Phono Box S, AD Box S2 Phono, DAC Box DS, DAC Box E, Dock Box S Fi, Head Box DS, Head
Box S, Head Box S USB, Optical Box E Phono, Phono Box, Phono Box DS, Phono Box DS+, Phono Box DS2,
Phono Box DS2 USB, Phono Box E, Phono Box E BT, Phono Box MM, Phono Box S, Phono Box S2, Phono Box S2
Ultra, Phono Box ultra 500, Phono Box USB, Phono Box USB V, Pre Box S, Pre Box DS, Pre Box DS2 Analogue,
Record Box E, Record Box USB, Speed Box S, Speed Box S2, CD Box DS, DAC Box DS2 Ultra, Head Box DS2 B,
MaiA pre, Pre Box DS2 Digital, Speed Box DS, Stream Box DS+, Tube Box DS, Tube Box Ds2, Tube Box S, Tube
Box S2.
15V turntable output : All of the Pro-Ject DC-powered turntables.
!
!
!

© Pro-Ject Audio Systems · Pro-Ject Power Box DS2 Sources · Revision 2018.12.13
3
Trigger connection
Power Box DS2 Sources is equipped with 12V trigger-out socket (jack 2.5mm) to turn on/off a Pro-Ject product
with trigger input socket.
Do not use the trigger output for any other connections for which it is not designed.
Main power switch
The toggle switch on the front panel turns the unit on or off. The blue LED above the switch shows that the unit
is switched on.
Technical specifications Pro-Ject Power Box DS2 Sources
Output voltage / current (socket diameter): 2x 9V/2A (1,3mm), 3x 18V/1A(2,5mm), 1x 15V(2,1mm)
Trigger output: 2,5mm jack
Dimensions W x H x D with sockets: Aluminium 206 x 71 x 209mm
Wood 240 x 72 x 209mm
Weight: Aluminium 3000g, Wood 3400g
Service
Should you encounter a problem which you are not able to alleviate or identify despite the above information,
please contact your dealer for further advice. Only when the problem cannot be resolved there should the unit
be sent to the responsible distributor in your country.
Warranty
The manufacturer accepts no responsibility for damage caused by not adhering to these instructions
for use. Modification or change to any part of the product by unauthorized persons, release the
manufacturer from any liability over and above the lawful rights of the customer.
Copyright, trademarks
Pro-Ject Audio Systems is a Registered Trademark of
H. Lichtenegger.
This guide was produced by: Pro-Ject Audio Systems
Copyright ©2017. All rights reserved.
The information was correct at the time of going to
press. The manufacturer reserves the right to make
changes to the technical specification without prior
notice as deemed necessary to uphold the ongoing
process of technical development.
!
