Pro-Ject Speed Box SE

© Pro-Ject Audio
2
Dear music lover,
thank you for purchasing a PRO-JECT AUDIO Speed Box SE. * The unit permits electronic speed change of
your Pro-Ject record player between 33 and 45 r.p.m. and also permits the replay of shellac records by
allowing ** 78 r.p.m. with an appropriate pulley and cartridge.
The replay speed can be increased and decreased in twenty steps of 0,1 r.p.m.
* The Pro-Ject Debut/Phono SB, Pro-Ject 1.2 Comfort and Pro-Ject RPM 6 SB may not be used with
the Speed Box.
These models are equipped with an electronic speed change as a standard.
Using the Speed Box with the Pro-Ject Perspective is not recommended.
In order to achieve maximum performance and reliability you should study these instructions for use carefully.
Warning of a hazard for the user, the unit or possible misuse.
Important notice.
Connecting the record player
Output
16V
3W
Output
120V (230V)
3W
Input
16V
1A
Connect the power cable supplied to the Output ~16V socket on the Speed Box SE and to the power
socket on your turntable. The original power supply is then no longer required.
Turntables without an external power supply should be connected to the Output ~120V (~230V) socket on
the Speed Box SE. Check the label before connecting to ensure compliance with the mains rating in your
house.
The Speed Box SE is not designed to run with capacitive loads.
~120V (~230V) and ~16V power output cannot be used simultaneously.
Make all connections whilst the Speed Box is disconnected from the power supply.
Mains power connection
The Speed Box is supplied with a power supply suitable for your country's mains supply. Check the label
before connecting to ensure compliance with the mains rating in your house. Connect the low voltage plug
from the power supply to the socket Input ~16V before connecting the power supply to the mains.
Speed selection 33/45 r.p.m.
Press the speed change button 33/45 to switch between 33 and 45 r.p.m.. The selected speed will be
displayed digitally.
To play at 45 or 78 r.p.m. please always start the turntable at 33 r.p.m. and then switch to the higher speed
when it has attained full speed.

© Pro-Ject Audio
3
Pitch control
Repeatedly pressing the +or -buttons (Adjust) increases or decreases the replay speed in twenty steps of
0,1 r.p.m. respectively. The adjusted speed is displayed digitally.
Speed Box SE
33/45 +
-
Adjust
45.0
Replay at 78 r.p.m.
In order to replay shellac records at 78 r.p.m. your turntable must be equipped with the 78 r.p.m. pulley
which is available as an optional accessory for most models.
After fitting the 78 r.p.m. pulley please proceed as follows: Remove the platter (5) and using the tool (3a)
from the accessory kit fit the belt (3) around the larger diameter step of the pulley (2). Replace the Platter,
start the turntable at 33 r.p.m. and switch the speed to 45 r.p.m., the platter will then revolve at 78 r.p.m..
Fitting the 78 r.p.m. pulley
Before beginning work fit the cartridge’s needle protection cover.
Remove the platter and drive belt. Please remember that sweat or sticky fingers will impair the function of the
belt. Use a piece of kitchen paper or a cloth to remove the belt.
Measure the height of the pulley above the plinth in order to ease correct refitting.
Using a small screwdriver loosen the grub screw in the neck of the pulley just enough to remove the pulley
vertically without using force. Refit the pulley in the opposite order. Tighten the grub screw carefully making
sure you do not overtighten it.
Fit the drive belt around the subplatter and the pulley. Again, use a piece of paper or cloth to avoid soiling
the belt. Replace the platter.
** 78 r.p.m. is not available with the Pro-Ject 1.2 Comfort and the Pro-Ject RPM 9.
The Pro-Ject Debut/Phono SB and the Pro-Ject RPM 6 SB are equipped with an mechanic speed
change for 78 r.p.m..
Switching on and off
Pressing the power switch of Your Pro-Ject Turntable alternately starts or stops the motor.
Technical specifications PRO-JECT SPEED BOX
Speed change 33,33/45,11 r.p.m. or 78 r.p.m. (with optional 78 r.p.m. pulley only)
Pitch control ± 20 steps/0,1 r.p.m.
Power output 16V/190mA AC max. (power consumption 3W max.)
120V model only 120V/25mA AC max. (power consumption 3W max.)
230V model only 230V/13mA AC max. (power consumption 3W max.)
Outboard power supply 16V/1.000mA AC, suitable for your country's mains supply
Dimensions (H x W x D) 80 x 160 x 130mm
Weight without power supply 1.250g
