Pro-Ject Audio Systems RPM 9.2 User manual

INSTRUCTIONS FOR USE
Pro-Ject RPM 9.2 Evolution

© Audio Trade GmbH · Pro-Ject RPM 9.2 Evolution · Revision 2012.7.1
2
16
21
9
7
6a
15
6
18
8
9a
17
14
14
14

© Audio Trade GmbH · Pro-Ject RPM 9.2 Evolution · Revision 2012.7.1
3
Pro-Ject RPM 9.2 Evolution
Controls, features and connections
1 Separate motor unit (motor and motor base) *
2 Stepped drive pulley
3 Drive belt * 3a Hook
4 Operation indicator
5 Platter *
6 Tonearm counterweight * 6a Downforce scale
7 Tonearm lift lever
8/18 Tonearm rest and removable transport lock
9 Tonearm tube 9a Tonearm base
13 Power supply socket
14 Phono output sockets and earth connection
15 Anti-skating weight adjustment scale
16 Anti-skating weight *
17 Anti-skating weight wire support
20 Power switch
21 Headshell with finger lift
22 Height-adjustable, magnet supported feet *
Record weight (not shown) *
Connection cable (not shown) *
Power supply (not shown) *
Optional lid (not shown)
Single adapter (not shown) *
Spirit level (not shown) *
Template (not shown) *
Dear music lover,
thank you for purchasing a PRO-JECT AUDIO record player.
In order to achieve maximum performance and reliability with this record player you should study these instructions
for use carefully.
!
Warning of a hazard for the user, the unit or possible misuse.
Important notice.
During assembly and adjustment of the deck small parts could be lost if not carefully placed in a suitable
receptacle.
Before starting assembly make yourself acquainted with the parts listed above and correspondingly numbered
in the technical drawings above. Separately packed items are marked with an asterisk *.

© Audio Trade GmbH · Pro-Ject RPM 9.2 Evolution · Revision 2012.7.1
4
Set-up
The deck is supplied partially disassembled and carefully packaged for safe transport. Carefully remove all
parts from the transport packaging.
Screw the magnetic field feet (22) onto the threaded bolts located on the underside of the plinth. Make sure
the surface you wish to use the turntable on is level (use the supplied spirit level) before placing the turntable
on it.
Carefully place the platter bearing housing over the bearing axle. Put the record weight on the platter and
level the plinth using the supplied spirit level and the adjustable feet (22).
Assemble motor and motor base. Place the motor unit to the left of the turntable. Position the motor unit with
the aid of the supplied template. Fit the drive belt (3) around the platter (5) and the smaller diameter part of
the motor pulley (2).
Avoid getting sweat or grease on the belt as these will deteriorate the performance and reduce the belt's
lifespan. Use absorbent kitchen paper to remove any oil or grease from the outer edge of the hub and the belt.
Remove the transport lock (18) from the tonearm. Store it in the original packaging so they are available for
any future transportation.
We recommend to use the record player without a mat on the platter.
Fitting and connecting the cartridge
All cartridges with half inch mounting holes can be fitted. Leaving the needle's protection cover on, fit the
cartridge to the headshell using the screws supplied with the cartridge by passing one screw through each
slot in the headshell (21). Do not tighten the nuts yet.
Connect the tonearm wires to the cartridge pins as follows:
white left channel positive (L+)
red right channel pos. (R+)
green right channel return (R -)
blue left channel return (L -)
The full sound quality of the record player can only be achieved if the cartridge is correctly adjusted. Particular
tools like the PRO-JECT alignment tool are required to accomplish this job properly. If you are not well acquainted
with the adjustment of cartridges you are advised to call upon the willing help of your PRO-JECT dealer to
accomplish this task for you.
Please note: adjusting a cartridge and tonearm calls for the greatest care in order to avoid damaging
the cartridge or tonearm bearings. Leave this work to your dealer if you are in any way unsure of the
necessary steps and precautions to be taken.
Cartridge downforce adjustment
The counterweights (6) supplied are suitable for cartridges weighing between 5 - 7,5g (counterweight no. 28),
7 - 10g (counterweight no. 46), 9 - 11g (counterweight no. 43) or 10 - 14g (counterweight no. 29).
Adjust the downforce prior to installing the anti-skating weight.
Pushing carefully, turn the counterweight (6) onto the rear end of the tonearm tube (9), so that the downforce
scale (6a) shows towards the front of the player. Lower the armlift and position the cartridge in the space
between arm rest and platter. Carefully rotate the counterweight (6) until the armtube balances out. The arm
should return to the balanced position if it is moved up or down. This adjustment must be done carefully. Do
not forget to remove the cartridge protection cap if fitted.
Once the arm is correctly balanced return it to the rest. Hold the counterweight (6) without moving it, and gently
revolve the downforce scale ring (6a) until the zero is in line with the anti-skating stub (15). Check whether the
arm still balances out.
Rotate the counterweight counter clockwise (seen from the front) to adjust the downforce according to the
cartridge manufacturer's recommendations. One mark on the scale represents 1 mN (= 0,1g / 0,1 Pond) of
downforce.

© Audio Trade GmbH · Pro-Ject RPM 9.2 Evolution · Revision 2012.7.1
5
Adjusting the vertical tracking angle (vta)
Put a record and the record weight on the platter. When the needle is lowered into the record groove and the
tonearm is not resting on the lift arm, the tube of the tonearm should be parallel to the surface of the record.
If it is not loosen both hexagon screws in the tonearm base just enough to allow vertical movement of the
arm pillar without force and slide the arm up or down until it is parallel.
Carefully retighten the hexagon screws without applying excessive force (which would deform the arm pillar) –
finger tight is quite sufficient.
Adjusting the azimuth
The cartridge needle must be vertical in the record groove in order to trace the
groove wall modulations correctly.
A small screw at the bearing end of the arm allows incorrect azimuth to be
corrected if your needle is not mounted exactly perpendicular to the cartridge
body (which is often the case).
Slacken off the screw just enough to be able to revolve the arm tube without
applying force. Note! Do not remove the screw completely!
Screw
With the aid of a good magnifying glass adjust the needle until it is vertical in the groove (i.e. perpendicular
to the record's surface). Ideally this should correspond to the top surface of the cartridge body being parallel
to the record surface, but in practice this is often not the case.
When you are satisfied that the needle is vertical retighten the screw carefully.
Under no circumstances should the arm tube be adjusted with the needle still in the record groove!
Irreparable damage may be caused to the cantilever suspension! The arm must be lifted to make
each adjustment and lowered afterwards to check it.
Anti-skating force adjustment
The anti-skating force must be adjusted corresponding to the downforce as follows:
Downforce Groove in the stub (15)
10 - 14mN 1st from bearing rings
15 - 19mN 2nd " " "
20mN and bigger 3rd " " "
Hang the loop of the thread of the anti-skating weight in the groove of the anti-skating stub (15) corresponding
to the downforce applied to your cartridge and hang the thread in the groove of the wire support (17).
Connection to the amplifier
The record player has gold plated female RCA phono sockets (14) so you can substitute the interconnect cables
supplied with higher quality cables such as the Pro-Ject Connect it interconnect cables for connection to the
amplifier if you wish.
Use the Phono input (sometimes labelled gram, disc or RIAA) on your amplifier. Make sure that the phono
input offers correct matching and amplification for the type of cartridge used. Line inputs (such as CD, Tuner,
Tape or Video) are not suitable.
Take care to connect the left and right channels correctly. The right channel is usually marked red, the left
channel black or white. Check the manual supplied with your amplifier for relevant information. An earthing
wire may be connected to the screw terminal between the sockets if you encounter hum problems when using
the record player.
If your amplifier does not have an input suitable for phono cartridges you will require a separate phono
amplifier stage for MM or MC cartridges which is then connected between the record player and a free line
level input of the amplifier.
For detailed product information regarding Pro-Ject Audio interconnect cables and phono amplifiers please
refer to the Pro-Ject web site www.project-audio.com.

© Audio Trade GmbH · Pro-Ject RPM 9.2 Evolution · Revision 2012.7.1
6
Mains power connection
The turntable is supplied with a power supply suitable for your country's mains supply. Check the label before
connecting to ensure compliance with the mains rating in your house.
Connect the low voltage plug from the power supply to the record player's motor unit (13) before connecting
the power supply to the mains.
Switching on and off
Pressing the power switch (20) alternately starts or stops the motor.
Changing replay speed
Using the accessory tool provided (3a), hook the belt (3) over the larger diameter part of the motor pulley (2).
To revert to 33 r.p.m. repeat the proceedings using the smaller step on the pulley.
When the Pro-Ject Speed Box is used speed change between 33 and 45 r.p.m. is electronic. There is
no need to move the belt manually.
For detailed product information please refer to the Pro-Ject web site www.project-audio.com.
Fitting the optional lid
Fit the lid carefully on to the record player from above.
Maintenance and cleaning
Your record player requires little or no regular maintenance. Remove dust with a slightly moistened antistatic
cloth. Never use a dry cloth because this will create static electricity which attract more dust! Antistatic
cleaning fluids are available at specialist stores but must be applied sparingly to avoid damage to rubber
parts. It is recommended to fit the needle cover before cleaning or maintenance is carried out to avoid damage.
If the player is not used over a long period of time the drive belt can be removed to prevent unequal stretching.
!
Always disconnect the record player from the mains power supply as a precaution before maintenance!
Useful tips
The lid (optional) is not only a dust cover but also a resonant structure likely to be excited by, and to pass into
the plinth, the acoustic energy emanating from your loudspeakers during replay. It is therefore recommended
that the lid be removed for optimum sound quality.
The record player should be positioned on a low-resonance surface such as wood or multiple layer ply board
to avoid structural vibrations disturbing replay.
Technical specifications PRO-JECT RPM 9.2 Evolution / Pro-Ject 9cc Evolution
Nominal speeds 33/45 r.p.m.
Speed variance ±0,5 %
Wow and flutter ±0,06 %
Signal to noise 73dB
Effective tonearm mass 8g
Effective tonearm length 9 " (230mm)
Overhang 18mm
Power consumption 2W
Outboard power supply 16V/500mA AC, suitable for your country's mains supply
Dimensions (W x H x D) 440 x 180 x 325mm
Weight 12,5kg

© Audio Trade GmbH · Pro-Ject RPM 9.2 Evolution · Revision 2012.7.1
7
Potential incorrect use and fault conditions
Pro-Ject turntables are manufactured to the highest standards and undergo strict quality controls before
leaving the factory. Faults that may possibly occur are not necessarily due to material or production faults but
can sometimes be caused by incorrect use or unfortunate circumstances. Therefore the following list of common
fault symptoms is included.
The platter doesn't turn although the unit is switched on:
The unit is not connected to the mains power supply.
No mains at the socket.
Drive belt is not fitted or has slipped off.
No signal through one or other channel or both channels:
No signal contact from the cartridge to the internal tonearm wiring or from that to the arm lead or
from that to the phono box or between that and the amplifier. This could be due to a faulty plug,
broken wire or solder joint or simply loose plug/socket connection.
Phono input not selected at amplifier.
Amplifier not switched on.
Amplifier or speakers defective or muted.
No connection to the loudspeakers.
Strong hum on phono input:
No earth connection from cartridge or arm or arm cable to amplifier, or earth loop.
Distorted or inconsistent sound from one or both channels:
Record player is connected to wrong input of amplifier, or MM/MC switch incorrectly set.
Needle or cantilever damaged.
Wrong r.p.m., drive belt overstretched or dirty, platter bearing without oil, dirty or damaged.
Service
Should you encounter a problem which you are not able to alleviate or identify despite the above information,
please contact your dealer for further advice. Only when the problem cannot be resolved there should the
unit be sent to the responsible distributor in your country.
Guarantee repairs will only be effected if the unit is returned correctly packaged. For this reason we recommend
keeping the original packaging.
Never return a record player without making sure that is it safely disassembled and correctly packaged in the
original packaging according to the diagrams on the last page of this user guide. Please remove these parts
and pack them separately: counterweight (6), anti-skating weight (16) platter (5) and belt (3). Fit the
cartridge protection cap. Insert the transport lock for the tonearm (18) prior to carefully packaging the record
player.
Warranty
The manufacturer accepts no responsibility for damage caused by not adhering to these instructions
for use and/or by transportation without the original packaging. Modification or change to any part
of the product by unauthorized persons release the manufacturer from any liability over and above
the lawful rights of the customer.
PRO-JECT is a Registered Trademark of H. Lichtenegger.
This guide was produced by: Audio Trade GmbH
Copyright ©2009. All rights reserved.
The information was correct at the time of going to
press. The manufacturer reserves the right to make
changes to the technical specification without prior
notice as deemed necessary to uphold the ongoing
process of technical development.

© Audio Trade GmbH · Pro-Ject RPM 9.2 Evolution · Revision 2012.7.1
8
Accessories
Power supply
Record weight
Motor
Motor base
Tonearm counterweight
Platter
Tonearm
transport lock
Please
remove feet
bevore repacking
!
