PRO SIGNAL PSG3028 User manual

PSG3028
HDMI OVER CAT 1:4 SPLITTER + RXS

WHAT’s IN THE BOX
OVERVIEW
IMPORTANT SAFETY INFORMATION
INSTALLATION
SPECIFICATIONS
• This device can extend and connect one HD source to four HD displays or projectors
using four CAT5/6/7 cables simultaneously. Cat6/7 recommended for greater stability.
• The extending distance is up to 60m.
• Supports 3D.
• Main unit plus 4 CAT to HDMI receivers.
• 5V DC Power Supply x 5 (1 x 3A for main splitter unit plus 4 x 1A for receivers).
• User’s Manual.
Please read these instructions carefully before use and retain for future reference.
• Check that the voltage indicated on the PSU rating plate corresponds with that of the
local network before connecting to the mains power supply.
• Please make sure all devices you wish to connect have been powered off.
• Connect the source device to the converter using appropriate HDMI cable up to 15m.
• Connect up to four CAT5/6/7 outputs to the input of the receiver(s) up to 60m long and
connect the HDMI output to the displays up to 20m long.
• An HDMI to DVi cable can also be used for DVi displays.
• Connect the DC side of the 5V power supplies to the switcher (3A) and the receivers
(1A) then connect the AC side of the power supplies into the mains supply.
• The power LED lights when the power is applied.
• The device reads the output display EDID information and adjusts output accordingly
for each monitor attached.
• The green LED ashes during the read process then goes solid when complete.
Operating environment 0-40o/ Storage -10 to 55o, Humidity up to 90%
Power supply 220-240V~50Hz
Power requirement 5V DC 1A(RX) 3A(TX)
Power consumption (max) 3W
HDMI Input 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Audio formats output LPCM7.1/DTS/Dolby-AC3/DSD
Audio formats input DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
Input video signal 0.5~1.5Volts p-p
Output DDC signal 5 Volts p-p (TT1L)
Max baud rate 6.75Gbps
Max bandwidth 225MHz
Dimensions 205 x 74 x 22mm
Weight (not inc PSU) 750g
INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF ELECTRICAL &
ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical & Electronic
Equipment (WEEE). Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used. Contact your local
authority for details of recycling schemes in your area.
Made in China. PR2 9PP
Man Rev 1.0
