PRO SIGNAL PSG3029 User manual

PSG3029
HDMI TO AV (PHONO) CONVERTER

WHAT’s IN THE BOX
OVERVIEW
IMPORTANT SAFETY INFORMATION
INSTALLATION
SPECIFICATIONS
• This device can convert an HDMI digital HD signal into a composite video (CVBS)
signal plus the L/R stereo audio signal. It allows digital devices to output to an
ordinary TV or monitor which only receives analogue and other CVBS signals. (The
composite video standard resolution is 480I & 576I and NTSC and PAL formats).
• Main unit.
• USB power lead.
• User’s Manual.
Please read these instructions carefully before use and retain for future reference.
• Please make sure all devices you wish to connect have been powered off.
• Connect the source device to the converter using appropriate HDMI cable of up to
10m length (26AWG).
• Connect the output CVBS video and both left and right audio to the receiving display.
• Select either NTSC or PAL using the switch on the input side.
• Connect the USB DC 5V power cable to the converter and to a device with a suitably
equipped USB power socket.
• The power LED lights when the power is applied.
Operating environment 0-40oHumidity <85% / Storage -20 to 60oHumidity <95%
Power supply 220-240V~50Hz
Power requirement 5V DC 600mA
Power consumption (max) 3W
HDMI Input 1080p/1080i/720p/576p/576i/480p
CVBS output resolution 480i/576i
CVBS signal output 0.5~1.0Volts p-p 75ohm
Analogue audio output 0.5~2Volts p-p 47kohm
Dimensions 70 x 60.5 x 20.5mm
Weight (not inc PSU) 113 g
INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF ELECTRICAL &
ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical & Electronic
Equipment (WEEE). Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used. Contact your local
authority for details of recycling schemes in your area.
Made in China. PR2 9PP
Man Rev 1.0
