PRO SIGNAL PSG3373 User manual

3D Ultra HD 4Kx2K@60Hz HDMI Audio Extractor)
HD VIDEO CONVERTER
User Manual
3D Ultra HD 4Kx2K@60Hz HDMI Audio Extractor
(SPDIF+Coaxial+3.5mm Stereo)
Bring High-Definition to your life!

3D Ultra HD 4Kx2K@60Hz HDMI Audio Extractor)
Thank you for purchasing our product. To ensure safety and many years'
trouble-free operation of the product, please read the manual carefully
before using this product.
1.0 INTRODUCTION
The converter allows the HD Source connected to single HD Display and adds
extra one 3.5 Stereo and SPDIF/Coaxial audio out port.
It offers solutions for noise, space and security concerns, data center control,
information distribution, conference room presentation, school and corporate
training environments.
2.0 FEATURES
1.Plug and play, Installs in minutes;
2.Support the HDCP2.2 protocol, Support for HDMI2.0;
3.Support HDR 18Gbps YUV4:4:4;
4.One HDMI input converted to one HDMI+ Audio
(SPDIF+3.5(Stereo)+Coaxial) output;
5.Input/Output Resolution: up to 4Kx2K(60Hz);
6.HDMI to achieve the synchronization of audio signal separation;
7.Support select 2.0CH/5.1CH/by pass audio mode options;
3.0 PACKAGE CONTENTS
Before attempting to use this unit. please check the packing and make sure the
following items are contained in the shipping carton:
1.Main unit----------------------------------1Pcs
2.User's Manual---------------------------1Pcs
3.5V DC Power Supply------------------1Pcs
4.0 SPECIFICATIONS:
HDMI resolution-------------------------480i/p,576i/p,720p,1080i/p,4Kx2K@60Hz
Support video color format-------------------------------24bit/36bit/48bit deep color
Audio output------------------------------------------------SPDIF+Coaxial+3.5 Stereo)
Max bandwidth-----------------------------------------------------------------------600MHz
Max baud rate-------------------------------------------------------------------------18Gbps
Input/Output TMDS signal---------------------------------------0.5~1.5Volts p-p(TTL)
Input/Output DDC signal------------------------------------------------5Volts p-p (TTL)
Input cable distance--------------------------------------------------------≤10m 28AWG
Output cable distance ------------------------≤10m 28AWG HDMI standard cable
Max working current------------------------------------------------------------------500mA
Power adapter ----------------Input: AC(50/60HZ) 100V-240V; Output: DC5V/1A
Operating Temperature range-------------------------------------------- (-15 to +55℃)
Operating Humidity range----------------------5 to 90%RH (No no Condensation)
Dimension (L x W x H)---------------------------------------------73X60.5X22.5 (mm)
Weight---------------------------------------------------------------------------------------90g

3D Ultra HD 4Kx2K@60Hz HDMI Audio Extractor)
5.0 PANEL DESCRIPTIONS
Please study the panel drawings below and become familiar with the signal
input(S),output(S)and power requirements.
Pass ---------HDMI pass mode.The audio and video from the HDMI output
2CH----------------2 channel stereo mode.The HDMI/SPDIF/Coaxial/3.5mm
audio output stereo audio
5.1CH--------5.1channel mode.The HDMI/SPDIF output 5.1channel audio
DC/5V---------------------------------------------------------------5V Power Interface
PWR---------------------------------------------------------------------Power indicator
RCA --------------------------------------------------------------------------RCA Switch
HDMI -------------------------------------------------------------------------HDMI input
SPDIF----------------------------------------------------------------------SPDIFOutput
Coaxial-------------------------------------------------------------------Coaxial Output
Stereo ------------------------------------Analog Sound Track 3.5 stereo Output
6.0 Operating and Connecting:
Before installation, please make sure all devices you wish to connect have
been turned off.
1.To use one HDMI cable to connect the HD Source with the input HDMI port.
2.To connect the converter HDMI output port with the HD Display.
3.To use one audio cable to connect the converter 3.5 stereo port with the
audio equipment.
4.To use the optical cable to connect the SPDIF/COAXIAL port with the audio
equipment.
5.To connect the converter with 5V DC power adaptor.
6.Power on all connected devices, choose the input of the display device to its
HDMI channel.
7.0 INSTALLATION AND PRECAUTIONS

3D Ultra HD 4Kx2K@60Hz HDMI Audio Extractor)
To avoid electric shock , product damage and to protect your safety , please
notice the following:
1. Please slowly plug or unplug signal cables and do not often plug , unplug ,
or shake them.
2. The equipment should not be placed under the sun , rain and damp or
unventilated environment.
3. Liquid items should not be placed on the equipment.
4. Do not install the equipment near heat sources such as fire , power , or
other amplifiers that produce heat.
5. Do not insert the metal or other objects to the equipment in addition to
connecting cables to ports.
6. Do not demolish the equipment by yourself ; it should be maintained by
professional maintenance staff.
