Proactive PROTEKT STS COMPACT 500 User manual

M o d e l : 3 4 5 0 0 - C O M
PROTEKT® STS
COMPACT 500
SIT-TO-STAND P A TIEN T LIFT
Ensure the product has been assembled according to the instructions in this
manual. All operators should read and understand the instructions for safe and
proper operation of the patient lift.

This page was intentionally left blank.

1
Thank you for choosing Proactive!
To better serve you, please record
the following information for future use:
Supplier Name: ___________________________________________
Supplier Telephone: ________________________________________
Product Serial Number: _____________________________________
Date of Purchase: _________________________________________
INSPECT YOUR MERCHANDISE
Upon receipt of your patient lift, verify that all merchandise is complete and free
from any shipping damage. Refuse delivery if the packaging appears to be
badly damaged. If the merchandise is received damaged or is missing
components, contact the shipping company immediately and file a claim.
For further assistance, contact your local dealer or Proactive Medical Products
at the following:
Proactive Medical Products
270 Washington Street
Mount Vernon, NY 10553
Tel: [phone]
www.proactivemedical.com

2
Product Description
Intended Use
The Protekt® STS Compact 500 34500-COM allows the patient
to be lifted and transferred safely with minimal physical effort
provided by the operator. The 34500-COM uses an electric
actuator to lift patients weighing up to 500lbs from a sitting to a
standing position from either a bed or a chair for transferring.
The lift has a standing platform to be used while transferring
patient from one surface to another, also included is a
cushioned knee pad for additional comfort and support while
patient is being transferred. The 34500-COM has a compact
base for maneuvering easily while still providing a wide lifting
range. The 34500-COM is compatible with the stand assist
sling and sani-sling with the option to add the knee and
buttocks support straps.
The 34500-COM is intended for patients who are lacking leg
strength in their lower extremities but are still able to bear
weight. The 34500-COM is intended to assist with standing
from a seated position while using the commode, changing
clothes and/or to relieve pressure. The 34500-COM is intended
to have one caregiver operate the lift to perform the transfer.
Transfers are intended to be performed on a flat, dry surface
and lifts are not to be used in high humidity environments for
extended periods of time.
i
i

3
DEFINITIONS & SYMBOLS
In this manual the user refers to the patient or resident and may be used
interchangeably at different times. Caregiver refers to the operator or person
who is assisting with the transfer.
Warning! Failure to heed this warning may
result in damage to the product or serious
injury to the operator and/or user.
Do Not Bleach. No bleach product may be
used. The garment is not colorfast or
structurally able to withstand any bleach.
Important instructions follow. Read and
understand the instructions in the manual
before using the product.
Do Not Dryclean. Garment may not be
commercially drycleaned.
Type BF applied part. Refer to the part of
the medical device which come into
physical contact with the patient in order
for the device to carry out its intended use.
Do Not Iron. Item may not be smoothed
or finished with an iron.
Class II symbol. To identify equipment is
designed that a connection to electrical
earth (ground) is not required.
Tumble Dry, Normal, Low Heat. A machine
dryer may be regularly used at a maximum
of Low Heat setting.
Note! Important information concerning
the product and/or its correct and proper
usage follows.
Do Not Dry. A machine dryer may not be
used.
Advise the operator to consult the
accompanying documents before use.
Machine Wash, Hot. Initial water
temperature should not exceed 82°C or
180°F.
Right side up Do Not Wash
Fragile, handle with care. Keep dry
Carton storage temperature limit of -25°C
to 70°C. Carton storage humidity limit of 0% to 90%.
European Conformity mark, the product
conforms to European Medical Directive
93/42/EEC and meets applicable health,
safety and environmental requirements.
Handle with care
Symbols used in this manual and on the product and their meanings:

Safety Instructions
A Protekt® STS Compact 500 will provide years of service if it is
properly maintained as any electric and/or mechanical equipment
requires. Please pay careful attention to the following important
information regarding the care, maintenance, and operation of the
patient lift. Carefully read these instructions before assembling
the lift, or attempting to lift a user with the device.
• Before attempting to lift any patient, please practice operating the lift
and explain the lift procedures to the patient.
• Please provide special assistance under the caretakers’ discretion.
(i.e. patients who are comatose, spastic, agitated, or otherwise
severely handicapped).
• The patient lift should be used solely for transferring a user/patient
from one utility (beds, chairs, toilets, etc.) to another. The patient lift
should not be used for transporting or moving any patient from one
location to another location.
• During lifting or lowering, whenever possible, always keep the base
of the lift in the widest position.
• The base of the lift should be closed before moving the lift.
• Do not roll casters over any object while the user/patient is in the
sling.
• Do not lock casters during lifting.
• While being lifted in a sling, always keep the user/patient centered
over the base and facing the caregiver operating the lifter.
• Never leave the user/patient unattended during lifting.
4

5
WARNING!
• NO modification of this equipment is allowed. It is unsafe to modify the equipment
from its original state. This product is deemed safe to use with
only the original parts as delivered. Unauthorized use of any modified
equipment may result in serious injury or death.
•DO NOT replace any components of the lift without consulting with
Proactive Medical Products, and follow proper instruction from Proactive when
replacing any components.
• DO NOT service any parts of the lift while in use with a patient.
•It is NOT safe to load the equipment more than the indicated maximum safe
working load.
• IF any accessories with lower load capacity than the equipment itself is used,
DO NOT load the equipment more than the lowest maximum safe
working load.
• REMOVE the battery pack if the lift will not be used for some time, to prevent
battery leakage. PERIODICALLY check the battery pack and the charger.
•This equipment DOES NOT consist of any materials or ingredients to
which patients are exposed, that may cause bodily harm or injury.
•Prolonged exposure or physical contact with any part of the equipment WILL NOT
cause skin irritation, allergic reaction, etc.
•Using accessories, detachable parts, or materials not described in the instruction
manual MAY RESULT IN SERIOUS INJURIES.
•Keep the equipment away from children and pets when in use. IT MAY
CAUSE SERIOUS INJURY OR DEATH.
•Keep the equipment away from any pests or pest infested area. Diseases
transferred from pests to the equipment MAY CAUSE SERIOUS ILLNESS
to patients upon contact.
•If the lift is exposed to the sun for long periods of time, be CAUTIOUS as the
surface of the lift may be hot.
•There are no risk if the lift is exposed to reasonably foreseeable
environmental conditions.
• CAUTION! The controller contains parts and assemblies that could be susceptible
to damage by electrostatic discharge (ESD). To reduce
the likelihood of this, one should be grounded prior to using the controller.
• DO NOT use the lift on a inclined surface that is greater than 5°.
•CAUTION! The black plastic bolt caps can fall off the bolt and is a choking hazard. If
the cap will not stay on the bolt, replace it immediately.

6
FEATURES & OVERVIEW
i
6
1
8
7
2
3
10
9
13
12
11
5
4
UNLESS OTHERWISE SPECIFIED:
SHEET: SCALE:
PART NUMBER:
DESCRIPTION:
DATE: DRAWN BY:
MATERIAL:
FINISH:
2920 PACIFIC DRIVE
NORCROSS, GA 30071
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
BESTCARE LLC. ANY REPRODUCTION IN PART
OR AS A WHOLE WITHOUT THE WRITTEN
PERMISSION OF BESTCARE LLC IS PROHIBITED.
8/24/2017
1 of 1
16mm Wrench
ALL DIMENSIONS IN MM
1-6
6-30
30-120
120-400
0.1
0.2
0.3
0.5
Easy Tools
Class II Equipment
• Prior to assembly, unpack and inspect all parts from the shipping carton.
Contact your dealer immediately if any parts are damaged or missing.
• Easy tools are provided to assist with initial set up. To ensure maximum
safety, product should not be put into use until all connections are tightened
using standard tools.
Screwdriver
42.3 lb 10.1 lb 10.0 lb
(19.3 kg) (4.6 kg) (4.5 kg)
14.3 lb
(6.5 kg)
8.4 lb 11.0 lb 0.6
(3.8 kg) (5.0 kg) (0.3 kg)
11.6 lb 0.7 lb
(5.3 kg) (0.3 kg)
7 Rear Caster
11
Emergency Lowering122
Actuator
Charger
Mast
13 Emergency Stop Bu�on
1**Base
3 8 Front Caster
Leg Opening Lever
6 Footplate
5 Knee Pad
4
Hand Control
9 Control Unit
10
Boom
** Heaviest detachable part
1.1 lb
(0.5 kg)

7
C
B
A
600
E
D
F 700 H
I
G
M
N
L
K
J
mm (in)
1500.5 (59.1)
559.7 (22.0)
940.7 (37.0)
19.8 (0.8)
386.8 (15.2)
816.1 (32.1)
749.8 (29.5)
547 (21.5)
291.9 (11.5)
646.3 (25.4)
200.8 (7.9)
201.2 (7.9)
123.4 (4.9)
33.4 (1.3)
A
B
C
D
E
F
G
H
I
J
L
M
N
K

8
J A
G
H
C
F
I
E
B
D
Additional Dimensions & Specifications
Safe Working Load
500 lb
A
Base Ext. Width - Closed
24.9"
B
Mast Height
40"
C
Base Length
33.5"
D
Front Caster Height
4.7"
E
Knee Pad Depth Range
4"
F
Knee Pad Height Range
21”, 20” or 19”
G
Base Opened Turning
Diameter
45”
H
Base Closed Turning
Diameter
41.9”
I
Footplate Length
14.4”
J
Footplate Width
13.9”
Standard Features
1 4-Points Boom
2 4" Rear Caster with Brake
3 3" Dual Front Caster
4 Power Control Unit
5 Single Piece Molded Kneepad
6 Depth Adjustable Kneepad
Position
Optional Features
1 Charging Cradle
2 Second Battery Pack
SPECIFICATIONS & OPTIONS
Specications of Control Unit
Input Voltage 220-240VAC 50Hz / 110-120VAC 60Hz
Output Voltage 24 VDC
Battery Pack 24 VDC 5AH
Lift Control Handset and Panel
Protection Class IP54 (Protection against dust and splash of water)
Sound Level Under Full Load 16db
Sound Level Under No Load 11db
Cycles Per Charge 25 full cycles under full load
Overload Warning by LCD
Battery Status by LCD
Duty Cycle 10% Duty cycle (Max 2 minute ON,18 minute OFF)
*Proactive is committed to continuous improvements of our products therefore the
specication, dimensions, and features listed above are for guidance only and are
subject to change without prior notice.

Installation
Step 1: Base and Mast
Step 2: Boom
1
3
2
9

12
10
Step 4: Actuator
It is critical to have the motor part of the actuator to face the same direction as
the big arrow as follows.
2
1
Step 3: Footplate

Step 5: Knee Pad
1 2
3 4
11

Step 6: Power Control Unit
4
3
2
5
M5 SCREWS
M4 SCREWS
UNLESS OTHERWISE SPECIFIED:
SHEET: SCALE:
PART NUMBER:
DESCRIPTION:
DATE: DRAWN BY:
MATERIAL:
FINISH:
2920 PACIFIC DRIVE
NORCROSS, GA 30071
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
BESTCARE LLC. ANY REPRODUCTION IN PART
OR AS A WHOLE WITHOUT THE WRITTEN
PERMISSION OF BESTCARE LLC IS PROHIBITED.
9/27/2017
1 of 1
M4x0.7x10mm Machine Screw
ALL DIMENSIONS IN MM
1-6
6-30
30-120
120-400
0.1
0.2
0.3
0.5
1
13 12

Operating Instructions
i
Double check all assemblies for tightness and read operating
instructions carefully prior to use.
For optimum performance,the lift should be transported and stored
in following condition range:
• -25°C to +5°C (-13°F to 41°F), and
• +5°C to +35°C (41°F to 95°F) at a non-condensing relative humidity 0% to 90%
• +35°C to +70°C at a water vapor pressure up to 5 kPa
For optimum performance,the lift should be operated in following condition
range:
• at a temperature range of +5°C to +40°C (+41°F to +104°F)
• at a non-condensing relative humidity range of 15 % to 90 %, but not requiring a
water vapor partial pressure greater than 5 kPa
• 70 kPa to 106 kPa atmospheric pressure
The lift will not have any potential electromagnetic or other interference with
other devices.
PREPARATION BEFORE LIFTING
• Twist the RED EMERGENCY STOP BUTTON clockwise.
• Verify the Lifting and Lowering Functions by pressing either the UP or DOWN
button on the hand control once.
• Position the base of the lift around or under the object.
• Widen the base and disengage the caster brakes.
Do not attempt to transfer a patient without prior approval of the person’s nurse.
Also, do not transfer without having studied the instructions and performed
several practices in operating the product. Together (with the patients doctor,
nurse, or medical attendant) select a sling that is both practical and comfortable.
The sling selected should be one that serves the needs of the patient, while
providing the patient with optimal safety. Never interfere with the lift, unless
instructed by the attendant. Have a doctor, nurse, or medical attendant
(experienced in the use of the Protekt® STS Compact 500) present during the
first few times the lift is used to transfer a new user.
i
13

14
Actuator
Battery Pack
Release Handle
Emergency Stop Button
Up / Down Button
LCD Display Panel
Battery Pack
Charger
Clear Contact Plastic
Cover
DC In
Not Used
Hand Control
Charging Cradle
(Optional)
Additional Battery Pack
(Optional)
Power Control Unit Overview
WARNING!
• Contains a long charger cord that may cause strangulation if used improperly!
• Keep long charger cord out of walkway where it poses a
tripping hazard!
• Have the charger port on the controller facing away from the wall for easy
disconnection!
• When removing the battery, need to secure the battery with both hands as it
can cause injury if dropped!
1. Connect Actuator as shown above.
2. Connect Hand Control as shown above.
3. The battery should be charged daily to prolong the battery life.
4. Must remove the clear battery contacts plastic cover before use.
Remove the battery in order to remove the plastic cover.

15
DC Charger
(included)
LED Indicator
* Amber = charging
* Green = charging completed
Charger Plug-in
LED Indicator
* Green = power connected
* Blank = power disconnected
Charging Cradle
(Optional)
LCD Display Panel Signs - Charging
During charging, the LCD Display Panel will show one of the four signs below.
• The DC Charger must be connected.
• The emergency stop button must be released.
• The battery will not be charged if the emergency button is pressed in.
Pressed inRelease
Charging: DC Charger or Charging Cradle
LCD Display Panel Signs
When the emergency stop button is released, the LCD Display Panel will show one of the four signs
below.
• The sign will display for 5 seconds.
• Then the lift will go into standby mode and the sign disappears.
• The lift is ready for use.

16
LED Indicator
* Green = In Use
* Blank = Standby
Lifting
Lowering
Operating Lift: Using Hand Control
Operating Lift: Using LCD Display Panel

17
Warning! - Overloaded
During lifting if the lift is overloaded, the LCD
Display Panel will show the sign on the left and
lifting will be deactivated immediately.
• The buzzer will beep 3 times.
• Lowering the lift by pressing the DOWN
button is still allowed.
• The emergency stop button must be pressed in
and then release the button before further
lifting.
Warning! - Charge Battery Immediately
If the battery is critically low, the LCD Display
Panel will show the sign on the left either when
the emergency stop button is released or when a
button on the LCD Display Panel is pressed.
• Lift operation is deactivated.
• Battery needs to be charged immediately
before further use.
Warning! - Battery Low and Charging is Needed
If the battery needs to be charged, the LCD
Display Panel will show a blinking low battery sign
shown on the left either when the emergency stop
button is released or when a button on the LCD
Display Panel is pressed.
• Lift is still functioning.
• Buzzer will beep every 2 seconds.
• Battery needs to be charged immediately after
use.

Available slings compatible with Patient Lift
18
If the patient is pregnant or has skin conditions,
consult with a doctor before use.
ALWAYS check the slings weight capacity is suitable
for the patient.
All slings are type BF applied parts.
30129 Sit to Stand Solid Patient Stand-Assist Sling - Medium
30130 Sit to Stand Solid Patient Stand-Assist Sling - Large
30131 Sit to Stand Solid Patient Stand-Assist Sling - X Large
30139 Sit to Stand Solid Patient Stand-Assist Sling - XX Large
30661 Deluxe Sit-to-Stand Sling, Padded, Small
30662 Deluxe Sit-to-Stand Sling, Padded, Medium
30663 Deluxe Sit-to-Stand Sling, Padded, Large
30664 Deluxe Sit-to-Stand Sling, Padded, X-Large
30134 Sit to Stand Transfer Patient Sling - Large
30136 Sit to Stand Transfer Patient Sling - X Large
30669SA Sit to Stand Buttocks Support Strap, Standard
30669B Sit to Stand Buttocks Support Strap, Bariatric
31230 Sit to Stand Knee Strap Brace
30331 Toileting/Sani-Sling, Padded, Small
30332 Toileting/Sani-Sling, Padded, Medium
30333 Toileting/Sani-Sling, Padded, Large
30334 Toileting/Sani-Sling, Padded, X Large
Sit-to Stand Sling
Padded Sit To Stand Sling
Transfer Sling
Buttocks Support Strap
Toileting/Sani-Sling
Knee Strap Brace
