2014/10 B.0 1900-009-001 REV B www.stryker.com
CUB®
Pediatric Crib
REF FL19F/H (190)
Operations Manual
Detachable
Quick Reference Guide
see back of manual

Warning/Caution, consult accompanying documentation
Safe Working Load Symbol
Type BF device
Battery-powered device with internal electrical source.
IPX4 Protection from liquid splash
Direct Current
In accordance with European Directive 2002/96/EC on Waste Electrical and Electronic Equipment, this
symbol indicates that the product must not be disposed of as unsorted municipal waste, but should be
collected separately. Refer to your local distributor for return and/or collection systems available in your
country.
REF Model
Manufacturer
Symbols

www.stryker.com 1900-009-001 REV B 1-3
English
Table of Contents
Symbols............................................................................... 1-1
Warning / Caution / Note Definition ...........................................................1-5
Introduction ............................................................................1-6
Intended Use ........................................................................1-6
Brief Product Description and Intended Use Statement .........................................1-6
Specifications ....................................................................... 1-7
Environmental Conditions...............................................................1-8
Product Illustration ....................................................................1-9
Contact Information ...................................................................1-10
Summary of safety precautions..............................................................1-1 1
Setup.................................................................................1-13
Rail Verification (OPTIONAL) ............................................................1-13
Access Door Verification (OPTIONAL) .....................................................1-13
Scale Verification (optional) .............................................................1-13
Base Control Verification ...............................................................1-14
Litter Movement Verification.............................................................1-14
Other Equipment:.....................................................................1-14
Operation..............................................................................1-15
Base Controls .......................................................................1-15
Applying or Releasing the Brakes .........................................................1-16
Operating the Directional Fifth Wheel (Optional) ..............................................1-16
Raising or Lowering the Litter (Optional) - FL19H Only .........................................1-17
Trendelenburg / Reverse Trendelenburg (Optional) - FL19H Only..................................1-17
Operating the Fowler / Foot Sections ......................................................1-18
Manual Fowler Positioning ..............................................................1-18
Pneumatic Fowler Positioning............................................................1-18
Foot Section Positioning................................................................1-18
Operating the Siderails.................................................................1-19
Operating Access Doors (Optional) .......................................................1-19
Operating the Scale (Optional).......................................................... 1-20
Battery Replacement ................................................................. 1-22
Accessories ........................................................................... 1-23
Standard Accessory Bracket Usage ...................................................... 1-23
Premium Accessory Bracket Usage (Optional) .............................................. 1-23
Oxygen Bottle Clamp Usage (Optional).................................................... 1-24
Operating the IV Caddy (Optional) ....................................................... 1-24
Operating The Two-Stage Fixed IV Pole (Optional) ........................................... 1-25
Operating the Three-Stage IV Pole (Optional)............................................... 1-26
Chart Holder / Monitor Holder Usage (Optional) ............................................. 1-27
Retracting Protective Top Installation (FA64074-BIL) .......................................... 1-28
Retracting Protective Top Operations (FA64074-BIL) .......................................... 1-29
Retracting Protective Top Cleaning....................................................... 1-29

1-4 1900-009-001 REV B www.stryker.com
English
Protective Top with Supports Installation (FA64183-BIL)........................................ 1-30
Protective Top With Supports Operations (FA64183-BIL) ....................................... 1-31
Protective Top with Supports Cleaning .................................................... 1-31
Cleaning.............................................................................. 1-32
Recommended Cleaning Method ........................................................ 1-32
Recommended Disinfectants ........................................................... 1-32
RINSE OFF CORROSIVE CLEANERS..................................................... 1-32
Special Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-33
REMOVAL OF IODINE STAINS .......................................................... 1-33
Preventive Maintenance .................................................................. 1-34
Checklist .......................................................................... 1-34
Recycling passport ...................................................................... 1-35
Limited Warranty .................................................................... 1-36
Warranty exclusion and damage limitations................................................. 1-36
To obtain parts and service ............................................................ 1-36
Return Authorization.................................................................. 1-36
Damaged Merchandise ............................................................... 1-36
International Warranty Clause........................................................... 1-36
CUB Crib Quick Reference Guide ........................................................... 1-39
Base Controls ...................................................................... 1-41
Applying the Brakes.................................................................. 1-41
Raising / Lowering Litter (Optional) - FL19H Only ............................................ 1-41
Trendelenburg / Reverse Trendelenburg (Optional)
- FL19H Only ....................................................................... 1-41
Table of Contents
Accessories (Continued)

www.stryker.com 1900-009-001 REV B 1-5
Return To Table of Contents
English
Warning / Caution / Note Definition
The words Warning, Caution and Note carry special meanings and should be carefully reviewed.
WARNING
Alerts the reader about a situation, which if not avoided, could result in death or serious injury. It may also describe
potential serious adverse reactions and safety hazards.
CAUTION
Alerts the reader of a potentially hazardous situation, which if not avoided, may result in minor or moderate injury to the
user or patient or damage to the equipment or other property. This includes special care necessary for the safe and
effective use of the device and the care necessary to avoid damage to a device that may occur as a result of use or
misuse.
Note
This provides special information to make maintenance easier or important instructions clearer.

1-6 1900-009-001 REV B www.stryker.com
Return To Table of Contents
English
Introduction
INTENDED USE
This manual is designed to assist you with the operation of the Stryker Model FL19 CUB®Pediatric Stretcher. It is
extremely important for the patient’s safety to read and understand all the information in this manual before operating
the stretcher. The manual must be available at all times to hospital staff for reference.
This Operations Manual is an integral part of the stretcher and should be included if the unit is sold or transferred.
BRIEF PRODUCT DESCRIPTION AND INTENDED USE STATEMENT
INTENDED MEDICAL INDICATIONS: The Stryker Cub Pediatric Crib is a pediatric hospital bed/stretcher intended for
medical purposes that consists of a bed or crib designed for the use of a pediatric patient, with fixed end rails and
movable and latchable siderails. The contour of the bed surface may be adjustable.
INTENDED PATIENT POPULATION: The safe working load indicates the sum of the patient, the mattress, and
accessory weight. The safe working load for Cub is 100lb (45 kg). This crib is not intended for use for any patient
measuring greater than 35 inches.
INTENDED PART OF THE BODY: The Stryker Cub Pediatric Crib is intended to support a patient while meeting safe
working loads. The patient can come in contact with the crib, but should never be placed on the frame without a sleep
surface. Cub is intended to be used with a 4 in. sleep surface, a thicker sleep surface or overlay that offers therapeutic
value. The crib should be used with extra caution. Patient supervision is suggested.
INTENDED USER PROFILE: The Stryker Cub Pediatric Crib is for patient use in acute Care settings, including
emergency departments, critical care, step down, progressive care, med/surg, sub-acute care, post anesthesia care
unit (PACU) or other locations in a professional healthcare facility as prescribed by a healthcare professional. Cub is
not intended to be used in a home healthcare environment. The typical operator for Cub would be trained healthcare
professionals.
INTENDED CONDITION OF USE AND EXPECTED LIFE: The Stryker Cub Pediatric Crib is designed for a 10 year
expected service life under normal use, conditions, and with appropriate periodic maintenance as described in the
maintenance manual for each device. Stryker warrants to the original purchaser that the welds will be free from
structural defects for the expected 10 year life of the product as long as the original purchaser owns the product.

www.stryker.com 1900-009-001 REV B 1-7
Return To Table of Contents
English
SPECIFICATIONS
Model FL19H
190 Hydraulic Base
Model FL19F
190 Fixed Height Base
Safe Working Load 100 lb (45 kg) 100 lb (45 kg)
Overall Length & Width
• No Accessory Supports
• With Accessory Supports
65.5 in. x 37 in. (166 x 94 cm)
72.25 in. x 37.5 in. (184 x 95 cm)
65.5 in. x 37 in. (166 x 94 cm)
72.25 in. x 37.5 in. (184 x 95 cm)
Weight Capacity 400 lb (181 kg) 400 lb (181 kg)
Overall Weight (without options) 375 lb (170 kg) 310 lb (140,6 kg)
Height Range (to litter top)
• High
• Low
40 in. (102 cm)
33 in. (84 cm)
33 in. (84 cm)
33 in. (84 cm)
Litter Positioning
• Manual Activated
• Pneumatic Assist
• Trend./Reverse Trend.
• Foot Section Angle
0° / 25° / 40° / 55°
0° - 50°
+/- 9.5°
0° / 6° / 12°
0° / 25° / 40° / 55°
0° - 50°
0° / 6° / 12° with manual foot prop
0° / 6° / 12°
Patient Surface 29.5 in. x 57 in. (75 x 145 cm) 29.5 in. x 57 in. (75 x 145 cm)
Caster Diameter 6 in. (15 cm) 5 in. (13 cm)
Brake System Four Wheel Ring Brake System Four Locking Casters
Scale (Optional)
Capacity Patients weighing 4 lb (1.8 kg) to 100 lb (54.4 kg)
Accuracy
Perform scale measurement when unit is flat:
± 0.5 lb (0.2 kg) at 50 lb (22 kg) or less
± 1.0 lb (0.4 kg) at ≥ 50 lb (22 kg)
Power
System Battery operated - 4 x “C” Type, Alkaline, 1.5VDC
Electrical
Rating 6 VDC, 0.15 A
Stryker provides special attention to product improvement and reserves the right to change specifications without
notice.
Compliant with the following standards: CSA C22.2, No. 60601.1; UL2601-1; IEC/EN 60601-1.
Note: The Cub®is CE Mark only without the scale option.
Introduction

1-8 1900-009-001 REV B www.stryker.com
Return To Table of Contents
English
ENVIRONMENTAL CONDITIONS
* Operating environment recommended to ensure scale precision.
Environmental Conditions Operation * Storage and Transportation
Ambient Temperature
Relative Humidity
(Non-Condensing)
Atmospheric Pressure
Introduction
60 0F
85 0F
(15.5 0C)
(29.1 0C)
-22 0F
122 0F
(-30 0C)
(50 0C)
0%
95%
0%
95%
700 hPa
1060 hPa
500 hPa
1060 hPa
