Proactive Protekt Take-A-Long 33400P User manual

Ensure the product has been assembled according to the instructions in this
manual. All operators should read and understand the instructions for safe
and proper operation of the patient lift.
Folding Position #1 - Flat
Folding Position #2 - Standing
PROTEKT® TAKE-A-LONG
FOLDING ELECTRIC PATIENT LIFT
Model: 33400P

1
Thank you for choosing !
To better serve you, please record
the following information for future use:
Supplier Name: ___________________________________________
Supplier Telephone: ________________________________________
Product Serial Number: _____________________________________
Date of Purchase: _________________________________________

2
i
i
Product Description
Intended Use
The allows the patient to be
lifted and transferred safely with minimal physical effort
provided by the operator. This is due to it being a full electric
lift . With the
The uses a two point spreader bar. As
an added feature this lift is able to be folded and stored
away for people with limited space in the home or in the trunk
of your car for individuals who like to travel. With the addition
of the optional battery pack you will never have to be worried
about your lift not being charged and ready for use.
The is intended to be used with patients who are
completely immobile or totally dependent on the patient lift for
transfers. The is intended for patients with limited
space in the home or for customers who like to travel as it folds
to be used for transfers of the patient in and out of bed, their
wheelchair, to and from the commode, or any other type of
surface. The is intended to be operated by one
caregiver who will perform the lift and transfer. Transfers
should
used in high humidity environments for extended
amounts of time.

3
DEFINITIONS & SYMBOLS
In this manual the user refers to the patient or resident and may be used
interchangeably at different times. Caregiver refers to the operator or person who is
assisting with the transfer.
Symbols used in this manual and on the product and their meanings:
Warning! Failure to heed this warning may
result in damage to the product or serious
injury to the operator and/or user.
Do Not Bleach. No bleach product may be
used. The garment is not colorfast or
structurally able to withstand any bleach.
Important instruc ons follow. Read and
understand the instruc ons in the manual
before using the product.
Do Not Dryclean. Garment may not be
commercially drycleaned.
Type BF applied part. Refer to the part of
the medical device which come into
physical contact with the pa nt in order
for the device to carry out its intended
Do Not Iron. Item may not be smoot ed
or ed with an iron.
Class II symbol. To iden y equipment is
designed that a connec on to electrical
earth (ground) is not required.
Tumble Dry, Normal, Low Heat. A machine
dryer may be regularly used at a maximum
of Low Heat se ng.
Note! Important informa on concerning
the product and/or its correct and proper
usage follows.
Do Not Dry. A machine dryer may not be
used.
Advise the operator to consult the
accompanying documents before use.
Machine Wash, Hot. Ini al water
temperature should not exceed 82°C or
180°F.
Right side up Do Not Wash
Fragile, handle with care Keep dry
Carton storage temperature limit of -25°C
to 70°C Carton storage humidity limit of 0% to 90%
European Conformity mark, he product
conforms to European Medical Direc ve
93/42/EEC and meets applicable health,
safety and environmental requirements.
Handle with care

4
iSafety Instructions
A will provide years of service if it is properly
maintained as any electric and/or mechanical equipment requires.
Please pay careful attention to the following important information
regarding the care, maintenance, and operation of the patient lift.
Carefully read these instructions before assembling the lift, or
attempting to lift a user with the device.
• Before attempting to lift any patient, please practice operating the lift
and explain the lift procedures to the patient
• Please provide special assistance under the caretakers’ discretion.
(i.e. patients who are comatose, spastic, agitated, or otherwise
severely handicapped)
• The patient lift should be used solely for transferring a user/patient
from one utility (beds, chairs, toilets, etc.) to another. The patient lift
should not be used for transporting or moving any patient from one
location to another location.
• During lifting or lowering, whenever possible, always keep the base
of the lift in the widest position.
• The base of the lift should be closed before moving the lift.
• Do not roll casters over any object while the user/patient is in the
sling.
• Do not lock casters during lifting.
• While being lifted in a sling, always keep the user/patient centered
over the base and facing the caregiver operating the lifter.
• Never leave the user/patient unattended during lifting.

5
WARNING!
• NO
equipment from its original state. This product is deemed safe to use with
equipment may result in serious injury or death.
• DO NOT replace any components of the lift without consulting with
, and follow proper instruction from when
replacing any components.
• DO NOT service any parts of the lift while in use with a patient.
•It is NOT safe to load the equipment more than the indicated maximum safe
working load.
• IF any accessories with lower load capacity than the equipment itself is used,
DO NOT load the equipment more than the lowest maximum safe
working load.
• REMOVE the battery pack if the lift will not be used for some time, to prevent
battery leakage. PERIODICALLY check the battery pack and the charger
•This equipment DOES NOT consist of any materials or ingredients to which
patients are exposed, that may cause bodily harm or injury.
•Prolonged exposure or physical contact with any part of the equipment WILL
NOT cause skin irritation, allergic reaction, etc.
•Using accessories, detachable parts, or materials not described in the
instruction manual MAY RESULT IN SERIOUS INJURIES.
•Keep the equipment away from children and pets when in use. IT MAY
CAUSE SERIOUS INJURY OR DEATH.
•Keep the equipment away from any pests or pest infested area. Diseases
transferred from pests to the equipment MAY CAUSE SERIOUS ILLNESS to
patients upon contact.
•If the lift is exposed to the sun for long periods of time, be CAUTIOUS as the
surface of the lift may be hot.
•There are no risk if the lift is exposed to reasonably foreseeable
environmental conditions
• CAUTION! The controller contains parts and assemblies that could be
susceptible to damage by electrostatic discharge (ESD). To reduce
the likelihood of this, one should be grounded prior to using the controller.
• DO NOT use the lift on a inclined surface that is greater than 5°.
• CAUTION! The black plastic bolt caps can fall off the bolt and is a choking
hazard. If the cap will not stay on the bolt, replace it immediately.

6
FEATURES & OVERVIEW
i• Prior to assembly, unpack and inspect all parts from the shipping carton.
Contact your dealer immediately if any parts are damaged or missing.
• Easy tools are provided to assist with initial set up. To ensure maximum
safety, product should not be put into use until all connections are tightened
using standard tools.
1 Spreader Bar 6 Front Caster 11 Actuator
7.6 lb
(3.5 kg)
2 Boom 7 Rear Caster 12 Hand Control
0.7 lb
(0.3 kg)
3 Mast 8 Standing Bracket 13 Emergency Lowering
4 Leg Opening Pedal 9 Emergency Stop Bu on Charger
0.6 lb
(0.3 kg)
5 **Base 10 Control Unit
11 lb
(5 kg)
Combined
Weight (1-5)
67.2lb
(30.5 kg)
UNLESS OTHERWISE SPECIFIED:
SHEET: SCALE:
PART NUMBER:
DESCRIPTION:
DATE: DRAWN BY:
MATERIAL:
FINISH:
2920 PACIFIC DRIVE
NORCROSS, GA 30071
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
BESTCARE LLC. ANY REPRODUCTION IN PART
OR AS A WHOLE WITHOUT THE WRITTEN
PERMISSION OF BESTCARE LLC IS PROHIBITED.
9/8/2017
1 of 1
DaTong Wrench
ALL DIMENSIONS IN MM
1-6
6-30
30-120
120-400
0.1
0.2
0.3
0.5
Easy Tools Screw Driver
** Heaviest detachable part
Class II Equipment
7
1
2
9
10
3
4
7
8
5
6
11
12
13

SPECIFICATIONS & OPTIONS
dimensions, and features listed above are for guidance only and are subject to change without prior
notice.
REV.
DESCRIPTION DATE
APPROVED
UNLESS OTHERWISE SPECIFIED:
SHEET:
SCALE:
PART NUMBER:
DESCRIPTION:
DATE: DRAWN BY:
MATERIAL:
FINISH:
2920 PACIFIC DRIVE
NORCROSS, GA 30071
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
BESTCARE LLC. ANY REPRODUCTION IN PART
OR AS A WHOLE WITHOUT THE WRITTEN
PERMISSION OF BESTCARE LLC IS PROHIBITED.
5/1/2018
1 of 1
LOUIS CHOW
B
F
E
G
H
PL400EF-New Base - Final Assembly FOLD
ALL DIMENSIONS IN MM
1-6
6-30
30-120
120-400
0.1
0.2
0.3
0.5
Dimensions & Speci ca ons
A Safe Working Load
400 lb
182 kg
B Base Length
41.0”
1041mm
C Base External Width – Closed
25.6”
650mm
D Base Internal Width – Opened
32.0”
813mm
E Mast Height
48.3”
1227mm
F Front Caster Height
4.7”
119mm
G Li ing Height – Lowest
18.5”
465mm
H Li ing Height – Highest
67.2”
1707mm
I Base Opened Turning Diameter
55”
1384.9mm
H Base Closed Turning Diameter
51”
1306.5mm
Unloaded Li Weight
87.3 lb
39.7 kg
Standard Features
2-Point Spreader Bar
4” Rear Caster with Brake
3” Front Caster
Power Control Unit
Op onal Features
Charging Cradle
Digital Scale
Add onal Ba ery Pack
Input Voltage 220-240VAC 50Hz / 110-120VAC 60Hz
Output Voltage 24 VDC
Battery Pack 24 VDC 5AH
Lift Control Handset and Panel
Protection Class IP54 (Protection against dust and splash of water)
Sound Level Under Full Load 16db
Sound Level Under No Load 11db
Lift Cycles Per Charge 25 full cycles under full load
Overload Warning by LCD
Battery Status by LCD
Duty Cycle 10% Duty cycle (Max 2 minute ON,18 minute OFF)
1
2
9
10
3
4
7
8
5
6
11
12
13

Step 1: Remove folded lift from box
Step 3: Remove the quick release pin that is securing the mast
Step 4
by grabbing onto the handle bars
Step 2: Secure the stand to the mast. Make sure the tab on the standing bracket
sit in the top hole on the mast, and insert the screw to the lower hole as follows.
Use the EZ-Tools to tighten the screws.

Step 5: Insert the pin to secure the mast
Step 6: Remove the pin that is securing the boom
Step 7: Remove lower actuator pin

Step 8: Move the boom out of the way, and install the lower end of the
actuator as follows. It is critical to have the motor part of the actuator to face
the same direction as the big arrow as follows.
Step 9: Install the upper end of actuator and reinsert the quick release pin to
secure it.
1
11

M5 SCREWS
M4 SCREWS
UNLESS OTHERWISE SPECIFIED:
SHEET:
SCALE:
PART NUMBER:
DESCRIPTION:
DATE: DRAWN BY:
MATERIAL:
FINISH:
2920 PACIFIC DRIVE
NORCROSS, GA 30071
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
BESTCARE LLC. ANY REPRODUCTION IN PART
OR AS A WHOLE WITHOUT THE WRITTEN
PERMISSION OF BESTCARE LLC IS PROHIBITED.
9/27/2017
1 of 1
M4x0.7x10mm Machine Screw
ALL DIMENSIONS IN MM
1-6
6-30
30-120
120-400
0.1
0.2
0.3
0.5
M4
M5
1 2
3 4
Step 10: Installing the Control box on the Lift

Step 1: Spreader bar at lowest position Step 2: Folding the boom
Step 3: Folding the mast Step 4: Standing position
1
1
2
2
3
3

Operating Instructions
PREPARATION BEFORE LIFTING
• Twist the RED EMERGENCY STOP BUTTON clockwise.
• Verify the Lifting and Lowering Functions by pressing either the UP or DOWN
button on the hand control once.
• Position the base of the lift around or under the object.
• Widen the base and disengage the caster brakes.
Do not attempt to transfer a patient without prior approval of the person’s nurse.
Also, do not transfer without having studied the instructions and performed
several practices in operating the product. Together (with the patients doctor,
nurse, or medical attendant) select a sling that is both practical and comfortable.
The sling selected should be one that serves the needs of the patient, while
providing the patient with optimal safety. Never interfere with the lift, unless
instructed by the attendant. Have a doctor, nurse, or medical attendant
lift is used to transfer a new user.
i
i
• -25°C to +5°C (-13°F to 41°F), and
• +5°C to +35°C (41°F to 95°F) at a non-condensing relative humidity 0% to 90%
• +35°C to +70°C at a water vapor pressure up to 5 kPa
range:
• at a temperature range of +5°C to +40°C (+41°F to +104°F)
• at a non-condensing relative humidity range of 15 % to 90 %, but not requiring a
water vapor partial pressure greater than 5 kPa
• 70 kPa to 106 kPa atmospheric pressure

Actuator
Battery Pack
Release Handle
Emergency Stop Button
Up / Down Button
LCD Display Panel
Battery Pack
Charger
DC In
Not Used
Hand Control
Charging Cradle
(Optional)
Additional Battery Pack
(Optional)
Power Control Unit Overview
1
WARNING!
• Contains a long charger cord that may cause strangulation if used improperly!
• Keep long charger cord out of walkway where it poses a
tripping hazard!
• Have the charger port on the controller facing away from the wall for easy
disconnection!
• When removing the battery, need to secure the battery with both hands as it
can cause injury if dropped!
1. Connect Actuator as shown above.
2. Connect Hand Control as shown above.
3. The battery should be charged daily to prolong the battery life.

DC Charger
(included)
LED Indicator
* Amber = charging
* Green = charging completed
Charger Plug-in
LED Indicator
Charging Cradle (Optional)
LCD Display Panel Signs - Charging
LCD Display Panel Signs
Release Pressed In
Charging: DC Charger or Charging Cradle
During charging, the LCD Display Panel will show one of the four signs below.
• The DC Charger must be connected.
• The emergency stop button must be released.
• The battery will not be charged if the emergency button is pressed in.
When the emergency stop button is released, the LCD Display Panel will show one of the four signs
below.
• The sign will display for 5 seconds.
• Then the lift will go into standby mode and the sign disappears.
• The lift is ready for use.

1
LED Indicator
* Green = In Use
* Blank = Standby
Lifting
Lowering
Operating Lift: Using Hand Control
Operating Lift: Using LCD Display Panel

During lifting if the lift is overloaded, the LCD
Display Panel will show the sign on the left and
lifting will be deactivated immediately.
• The buzzer will beep 3 times.
• Lowering the lift by pressing the DOWN
button is still allowed.
• The emergency stop button must be pressed
in and then release the button before further
lifting.
Warning! - Charge Battery Immediately
If the battery is critically low, the LCD Display
Panel will show the sign on the left either when
the emergency stop button is released or when a
button on the LCD Display Panel is pressed.
• Lift operation is deactivated.
• Battery needs to be charged immediately
before further use.
Warning! - Battery Low and Charging is Needed
If the battery needs to be charged, the LCD
Display Panel will show a blinking low battery sign
shown on the left either when the emergency stop
button is released or when a button on the LCD
Display Panel is pressed.
• Lift is still functioning.
• Buzzer will beep every 2 seconds.
• Battery needs to be charged immediately after
use.

REPLACEMENT PARTS
LP-TBC2-CRDL Ba ry Charger Cradle ONLY (no plug) f/ Protekt Li /Stand
LP-TBC2-CRDL-PK Ba ry Charger Cradle Pack (includes plug) f/ Protekt Li /Stand
LP-TC12-BPAK Replacement Ba ry Pack f/ Protekt Li /Stand
LP-TC12-CBOX Replacement Control Box f/ Protekt Li /Stand
LP-TH10-PEN Replacement Hand Pendant f/ Protekt Li /Stand
LP-TP7C-ADP Replacement Plug f/ Protekt Li /Stand
Warning!
Use ONLY Proactive Medical slings/products with this
Full Body Mesh Slings
Full Body Mesh Slings w/Commode
ITEM # DESCRIPTION
30110 Medium Mesh full body: medium 600 lb. weight capacity
30111 Large Mesh full body: large 600lb. weight capacity
30124 X-Large Mesh full body: X-large 600lb. weight capacity
30118 XX-Large Mesh full body: XX-large 600lb. weight capac y
ITEM # DESCRIPTION
30114 Medium
Mesh full body: medium w/ commode opening
600 lb. weight capacity
30115 Large
Mesh full body: large w/ commode opening
600lb. weight capacity
30116 X-Large
Mesh full body: X-large w/ commode opening
600lb. weight capacity
30119 XX-Large
Mesh full body: XX-large w/ commode opening
600lb. weight capac y
Full Body Solid Slings
DESCRIPTION
30112 Medium
Solid fabric full body: medium
600 lb. weight capacity
30113 Large
Solid fabric full body: large 600lb.
weight capacity
30117 X-Large
Solid fabric full body: X-large
600lb. weight capacity
30123 XX-Large
Solid fabric full body: XX-large
600lb. weight capac y
ITEM #

Divided Leg Slings
Divided leg design is best suited for high level spinal cord injuries or patients
use of bathroom facilities.
DESCRIPTION
30100P Small
Solid divided leg: small 450 lb. weight capacity
30100 Medium
Solid divided leg: medium 450 lb. weight capacity
30101 Large
Solid divided leg: large 450 lb. weight capacity
30102 X-Large Solid divided leg: X-large 450 lb. weight capacity
30103 XX-Large
Solid divided leg: XX-large 600 lb. weight capacity
ITEM #
Padded Divided Leg Slings w/o Head Support
DESCRIPTION
30100P-NHS Small
Solid padded divided leg w/o head support: small
600 lb. weight capacity
30100-NHS Medium
Solid padded divided leg w/o head support: medium
600 lb. weight capacity
30101-NHS Large
Solid padded divided leg w/o head support: large 600
lb. weight capacity
30102-NHS X-Large
Solid padded divided leg w/o head support: X-large
600 lb. weight capacity
ITEM #
Padded Divided Leg Slings w/Head Support
DESCRIPTION
30100P-HS Small
Solid padded divided leg w/ head support: small 600
lb. weight capacity
30100-HS Medium
Solid padded divided leg w/ head support: medium
600 lb. weight capacity
30101-HS Large
Solid padded divided leg w/ head support: large 600
lb. weight capacity
30102-HS X-Large
Solid padded divided leg w/ head support: X-large
600 lb. weight capacity
ITEM #
