Problem Solvers ChainSpy User manual

6400 West 105th Street / Bloomington, MN 55438 / www.problemsolversbike.com
Figure 1
Figure 3
Figure 2
Figure 4
Figure 5
1900 01/13
WARNING: Cycling can be dangerous. Bicycle products
should be installed and serviced by a professional mechanic.
Never modify your bicycle or accessories. Read and follow
all product instructions and warnings including information
on the manufacturer’s website. Inspect your bicycle before
every ride. Always wear a helmet and use lights at night.
Failure to heed any of these warnings may result in serious
injury or death.
STUFF YOU NEED:
• AframewithaØ28.6/31.8mmseattube
• Adrivetrainwitha7–11-speedchain
TOOlS:
• 4mmhexwrench
• 2.5mmhexwrench
• Torquewrench
INSTAllATION:
1. Open up the clamp and place the ChainSpy on the
seattube(for28.6mmtubes,usetheincludedshims).
Looselysnugtheclampboltwitha4mmhexwrench
(g1).
2. Loosen the slider bolt and position the chain cradle over
thechain.Whenit’sinplace,looselysecuretheslider
bolt(g2).
3. You will probably have to adjust the clamp up and down
aswellastheside-to-sidepositiontogettheChainSpy
in just the right place. Be sure to run through all of your
rear gears to ensure the chain doesn’t rub on the sides
(g3).AdjusttheChainSpyheightbymovingtheclamp
up and down. You can also make adjustments by rotating
thesliderforeandaft(g4).
4. WhentheChainSpyisinplace,torquetheclampand
sliderbolts3–5Nm.
chAINSpY INSTAllATION INSTRUcTIONS

6400 West 105th Street / Bloomington, MN 55438 / www.problemsolversbike.com
1900 01/13
WARRANTY pOlIcY
One thing we want to make clear: Problem Solvers products
let you alter your bike for purposes never conceived by the
manufacturer.Therefore,theuseofourproductsmayvoidthe
warranty provided by other manufacturers. If you’re interested
inkeepingyourwarrantysecure,checkwiththembefore
installation of any Problem Solvers product.
lImITED 2-YEAR WARRANTY
PROBLEM SOLVERS™ warrants this new PROBLEM SOLVERS
product against defects svin materials and workmanship for two
(2)yearsfromtheoriginaldateofretailpurchasebytheconsumer.
Thislimitedwarrantyisexpresslylimitedtotherepairor
replacementoftheoriginalproduct,attheoptionofPROBLEM
SOLVERS,andisthesoleremedyofthewarranty.Thislimited
warranty applies only to the original purchaser of the PROBLEM
SOLVERS product and is not transferable.
InnoeventshallPROBLEMSOLVERSbeliableforanyloss,
inconvenienceordamage,whetherdirect,incidentalor
consequentialorotherwiseresultingfrombreachofanyexpress
orimpliedwarrantyorconditionofmerchantability,tnessfor
aparticularpurpose,orotherwisewithrespecttothisproduct
exceptassetforthherein.Thiswarrantygivestheconsumer
speciclegalrights,andthoserightsandotherrightsmayvary
from state to state.
Thiswarrantydoesnotcoverthefollowing:
• Damageduetoimproperassemblyorfollow-upmaintenance
orlackofskill,competenceorexperienceoftheenduser
• Productsthathavebeenmodied,neglected,usedin
competitionorforcommercialpurposes,misusedorabused,
involved in accidents or anything other than normal use
• Damageordeteriorationtothesurfacenish,aesthetics
or appearance of the product
• Normalwearandtear
• Laborrequiredtoremoveand/orretandre-adjusttheproduct
within the bicycle assembly
Totheextentnotprohibitedbylaw,thesewarrantiesareexclusive
andtherearenootherexpressorimpliedwarrantiesorconditions
including warranties or conditions of merchant ability and fitness for
a particular purpose.
Fortechnicalandsafetyinformation,visit:
www.problemsolversbike.com/safety
chAINSpY INSTAllATION INSTRUcTIONS
