probst HVZ-UNI-II-EK User manual

51400040-001
V2
GB
Operating Instructions
Translation of original operating instructions
Hydraulic Installation Clamp HVZ
HVZ-UNI-II-EK

Bitte beachten Sie, dass das Produkt ohne vorliegende Betriebsanleitung in Landessprache nicht
eingesetzt / in Betrieb gesetzt werden darf. Sollten Sie mit der Lieferung des Produkts keine
Betriebsanleitung in Ihrer Landessprache erhalten haben, kontaktieren Sie uns bitte. In Länder der
EU / EFTA senden wir Ihnen diese kostenlos nach. Für Länder außerhalb der EU / EFTA erstellen wir
Ihnen gerne ein Angebot für eine Betriebsanleitung in Landessprache, falls die Übersetzung nicht
durch den Händler/Importeur organisiert werden kann.
Please note that the product may not be used / put into operation without these operating
instructions in the national language. If you did not receive operating instructions in your national
language with the delivery of the product, please contact us. In countries of the EU / EFTA we will
send them to you free of charge. For countries outside the EU / EFTA, we will be pleased to provide
you with an offer for an operating manual in the national language if the translation cannot be
organised by the dealer/importer.

Contents
2 / 42
V2
GB
1 Contents
1Contents ................................................................................................................................................................. 2
2EC-Declaration of Conformity ............................................................................................................................... 4
3Safety...................................................................................................................................................................... 5
3.1 Definition skilled worker / specialist .............................................................................................................. 5
3.2 Explanation of basic concepts ....................................................................................................................... 5
3.3 Safety symbols................................................................................................................................................ 5
3.4 Safety Marking................................................................................................................................................6
3.5 Personal safety requirements ........................................................................................................................ 7
3.6 Protective equipment..................................................................................................................................... 7
3.7 Accident prevention ....................................................................................................................................... 7
3.8 Function Control............................................................................................................................................. 7
3.8.1 General ......................................................................................................................................................... 7
3.8.2 Hydraulic.......................................................................................................................................................8
3.9 Safety procedures ..........................................................................................................................................8
3.9.1 Hydraulic excavator and other carrier ........................................................................................................8
3.9.2 Safety at installation work...........................................................................................................................8
3.9.3 Check on the gripping quality of certain layers of paving stones .............................................................9
4General...................................................................................................................................................................10
4.1 Authorized use.............................................................................................................................................. 10
4.2 Stone formations........................................................................................................................................... 11
4.3 Survey and construction ...............................................................................................................................13
4.1 Technical data ................................................................................................................................................13
5Installation.............................................................................................................................................................14
5.1 Mechanical connection .................................................................................................................................14
5.2 Hydraulical connection..................................................................................................................................15
5.2.1 Adjustment of the hydraulic control......................................................................................................... 16
5.3 Setting 170 bar and 200 bar.......................................................................................................................... 16
5.4 Adjustment „Bypass valve“ (valve block at HVZ) ........................................................................................17
5.5 Adjustment additional „Bypass-Valve“ (hydraulic rotator/rotating head)................................................ 18
6Adjustments ..........................................................................................................................................................19
6.1 General .......................................................................................................................................................... 19
6.2 Adjustments of the feather-steel-lamellas ................................................................................................. 19
6.3 Adjusting the gripping depth .......................................................................................................................20
6.3.1 Facing bedding sand (planum).................................................................................................................. 20
6.3.2 Machine Side.............................................................................................................................................. 22
6.4 Height adjustment of the rollers.................................................................................................................. 23
6.5 Adjustment of the main clamping ............................................................................................................... 24
6.5.1 Machine Side.............................................................................................................................................. 24
6.5.2 Facing bedding sand (Planum).................................................................................................................. 25
6.5.3 Pushing-off bar........................................................................................................................................... 27
6.5.4 Extension of the gripper width ................................................................................................................. 27

Contents
3 / 42
V2
GB
6.5.5 Adjustment –gripping depth (side clamping)..........................................................................................28
6.5.6 Adjustment of the gripper width .............................................................................................................. 29
6.5.7 Gripper depth side clamping direction .....................................................................................................30
6.6 Adjustment weight balance .........................................................................................................................30
7Operation ............................................................................................................................................................. 32
7.1 General .......................................................................................................................................................... 32
7.1.1 Programms.................................................................................................................................................... 32
7.2 Indications for concrete paver installation, complying with the standards .............................................. 33
7.3 Operating procedure of laying cycle ...........................................................................................................34
7.4 General hints for laying according to standards ......................................................................................... 37
7.5 General laying-hints: .....................................................................................................................................38
8Maintenance and care ......................................................................................................................................... 39
8.1 Maintenance .................................................................................................................................................39
8.2 MECHNICAL ..................................................................................................................................................39
8.3 HYDRAULIC...................................................................................................................................................39
8.4 Trouble shooting ..........................................................................................................................................40
8.5 Repairs ...........................................................................................................................................................41
8.6 Safety procedures .........................................................................................................................................41
8.1 Hints to the type plate.................................................................................................................................. 42
8.2 Hints to the renting/leasing of PROBST devices ......................................................................................... 42

EC-Declaration of Conformity
4 / 42
V2
GB
2 EC-Declaration of Conformity
Description:
Type:
Order-Nr.:
Hydraulic Installation Clamp HVZ
HVZ-UNI-II-EK
51400040-001
Manufacturer:
Probst GmbH
Gottlieb-Daimler-Straße 6
71729 Erdmannhausen, Germany
[email protected] www.probst-handling.de
The machine described above complies with the relevant requirements of the following EU directives:
EC-machinery directive 2006/42/EC
The following standards and technical specifications were used:
DIN EN ISO 12100
Safety of machinery - General principles for design - Risk assessment and risk reduction (ISO 12100:2010)
DIN EN ISO 13857
Safety of machinery ― Safety distances to prevent hazard zones being reached by upper and lower limbs (ISO
13857:2008)
Authorized person for EC-documentation:
Name: J. Holderied
Address: Probst GmbH; Gottlieb-Daimler-Str. 6; 71729 Erdmannhausen, Germany
Signature, informations to the subscriber:
Erdmannhausen, 04.10.2018..........................................................................
(M. Probst, Managing director)

EC-Declaration of Conformity / UKCA-Declaration of Conformity
Manufacturer:
Probst GmbH
Gottlieb-Daimler-Straße 6
71729 Erdmannhausen, Germany
[email protected]
www.probst-handling.com
Importer:
Probst Ltd
Unit 2 Fletcher House
Stafford Park 17
Telford Shropshire TF3 3DG, United Kingdom
www.probst-handling.co.uk
[e-mail]
The machine described above complies with the relevant requirements of the following EU directives:
The object of the declaration described above is in conformity with the relevant UK-Regulations and UK-Guidelines:
EC-machinery directive 2006/42/EC (Reference: OJ L 157, 09.06.2006)
UK-Regulation: Supply of Machinery (Safety) Regulations 2008 (SI 2008 No. 1597)
The following standards and technical specifications were used:
DIN EN ISO 12100
Safety of machinery - General principles for design - Risk assessment and risk reduction
UK-Regulation: BS EN ISO 12100-1:2003+A1:2009
DIN EN ISO 13857
Safety of machinery - safety distances to prevent hazard zones being reached by upper and lower limbs.
UK-Regulation: BS EN ISO 13857:2019
Authorized person for EC-documentation:
Name: Jean Holderied
Address: Probst GmbH; Gottlieb-Daimler-Straße 6; 71729 Erdmannhausen, Germany
Authorized person for UK-documentation:
Name: Nigel Hughes
Address: Probst Ltd ; Unit 2 Fletcher House; Stafford Park 17; Telford Shropshire TF3 3DG, United Kingdom
Signature, information to the subscriber:
Erdmannhausen, 02.08.2021..........................................................................
(Eric Wilhelm, Managing director)

Safety
5 / 42
V2
GB
3 Safety
3.1 Definition skilled worker / specialist
Only skilled workers or specialists is it allowed to carry out the installation,- maintenance, - and repair work on these
device!
Skilled workers or specialists must have for the following points (if it applies for
these device), the necessary professional knowledge.
● for mechanic
● for hydraulics
● for pneumatics
● for electrics
3.2 Explanation of basic concepts
Gripping range:
● specify the minimum and maximum product measurements of the gripping good,
which can be gripped with this device.
Gripping good (s):
● is the product, which will be gripped or transported.
Opening width:
● consists of the gripping range and the measure to drive over the gripping good.
gripping range + measure to drive over the gripping good = opening width
Immersion depth:
● is the maximum gripping height of gripping goods, conditional of the height of the
gripping arms of the device.
Device:
● is the description for the gripping device.
Product dimensions:
● Are the dimensions of the gripping good (e.g. length, breadth, height
of the product).
Dead weight:
● is the own weight (without gripping good) of the device.
Carrying capacity/working
load limit (WLL*):
● specify the maximum possible load capacity of the device (for lifting of gripping
goods).
*= WLL →(english:) Working Load Limit
3.3 Safety symbols
Danger to life!
Identifies imminent hazard. If you do not avoid the hazard, death or severe injury will result.
Hazardous situation!
Identifies a potentially hazardous situation. If you do not avoid the situation, injury or damage to property can
result.
Prohibition!
Identifies imminent a prohibition. If you do not avoid the prohibition, death and severe injury, or damage to
property will result.

Safety
6 / 42
V2
GB
3.4 Safety Marking
PROHIBITION SIGN
Symbole
Meaning
Order-No
Size:
It is not allowed to be under hanging loads. Danger to life!
2904.0210
2904.0209
2904.0204
30 mm
50 mm
80 mm
Caution! Danger of squeezing! Touch only at handles.
2904.0367
205x30 mm
WARNING SIGN
Symbole
Meaning
Order-No
Size:
Danger of squeezing the hands.
2904.0221
2904.0220
2904.0107
30 mm
50 mm
80 mm
REGULATORY SIGN
Symbole
Meaning
Order-No
Size:
Each operator must have read and understood the operating
instructions (and all safety instructions).
2904.0665
2904.0666
30 mm
50 mm
OPERATING SIGNS
Symbole
Meaning
Order-No
Size:
Setting 170 bar for articulated shovels/roll mops
Setting 200 bar for wheel loaders
29040775
29x33 mm
Setting the side clamping/ main clamping
Approx. 2 turns to the left to "+" = side clamping and main
clamping, open simultaneously.
Approx. 2 turns to the right to "-" = first the side clamping, opens
and only then does the main clamping open.
29040774
30x45 mm
Lever for activating/deactivating side clamping
2904.0773
46x87 mm

Safety
7 / 42
V2
GB
3.5 Personal safety requirements
● Each operator must have read and understood the operating instructions.
● Only qualified, authorized personal is allowed to operate the device and all devices which are connected
(lifting equipment).
● The manual guiding is only allowed for devices with handles.
3.6 Protective equipment
<
The protective equipment must consist, according to the safety regulations of
the following parts:
● Protective clothing
● Safety gloves
● Safety shoes
3.7 Accident prevention
● The workplace has to be covered for unauthorized persons, especially children.
● Take care in case of thunderstorm!
● The workplace has to be sufficiently illuminated.
● Take care with handling wet, dirty and not solidified components.
● The working with the device in case of atmospheric editions under 3° C (37,5° F) is forbidden!
Because the goods could be fall down caused by dampness or freezing.
3.8 Function Control
3.8.1 General
● Before using the device check the functions and the working condition.
● Maintenance and lubrication are only permitted when device is shut down!
● Do not use the device, until all faults which can cause safety hazards are removed.
● If there are any cracks, splits or damaged parts on any parts of the device, immediately stop using it.
● The operating instructions must be available at the workplace every time.
● Do not remove the type plate of the machine.
● Unrecognisable information signs (such as regulatory or prohibition signs) must be replaced.

Safety
8 / 42
V2
GB
3.8.2 Hydraulic
● Check all hydraulic hoses and connection for tightness. Only experts are allowed to replace faulty parts
(depressurized)
● Ensure a clean working environment before opening the hydraulic connection.
● The hydraulic hoses must be free of breaks and abrasion. Take care that there are no outstanding edges,
where the hoses could hook in.
The operator of the device is responsible for a constant line pressure, which is necessary for the working with
this device.
Only under these conditions is a safety gripping, lifting and transporting of the gripping goods with this
device ensured.
3.9 Safety procedures
3.9.1 Hydraulic excavator and other carrier
● Hydraulic excavator and other carrier have to be in good, safe working condition.
● Only authorized and qualified personnel is allowed to operate the excavator and other carrier.
● The operator staff must have all the necessary qualifications.
● Never exceed the maximum capacity of the hydraulic excavator and other carrier.
3.9.2 Safety at installation work
● The manual guiding of is only allowed for devices with handles!
● The load must always be in the range of vision of the operator, during the transporting and laying
operation.
● Do not lift any components off-centre, because that could fall down.
● Set the stone layer carefully down.
● Safety before rapidity.
● While using the device be sure that there are no persons in the working area. Life danger!!
● The use of the device is only permitted in proximity to the ground. Do not swing it over people heads!
● While using the device the stay of persons in the working area is forbidden. Except it is indispensable,
caused of the way of using the device, e.g. if the device must be leaded by hand.
● The operator is not allowed to leave the control unit as long as the device loaded with load.
● The device should not be opened if the opening path of the gripping arm is blocked by a resistance (e.g.
other concrete blocks or the like)!
● Do not pull out stuck or tightened loads with the device.
● Do not replace the seal of the pressure relief valve to increase pressure without talking to the
manufacturer!
● Never pull or drag loads sideways. Otherwise parts of the device could be damage
● Never exceed the capacity and the nominal width the device.

Safety
9 / 42
V2
GB
3.9.3 Check on the gripping quality of certain layers of paving stones
For the secure function of the automatic cuber/the device the gripping quality of certain layers of paving stones has to be
checked as follows:
Take the number of blocks you want to grip, the blocks in
main gripper direction have to face the ground.
If the tower is falling, the
blocks can fall out of the
cube moving grab STAZ.
If the tower is standing, the
gripping quality is OK.
Blocks have "feet" (for instance by torn paver moulds)
Blocks have "bellies" (for instance by wet mixture)
The sand in the gabs of the lowest layer enforces "bridges"
(just with multi layer production)
Spacers do not reach the top ("blind Spacers")
Conclusion: Layer of blocks falls down and tears apart

General
10 / 42
V2
GB
4 General
4.1 Authorized use
● This Hydraulic Installation Clamp HVZ-UNI-II-EK was developed to meet the need of builders for a device to
mechanically install a wide range of pavers which are delivered to the site in ready-to-install formation. The HVZ-UNI-II-
EK may be used in connection with any carrier (mini-excavator, hydraulic excavator, wheel loader, forklift truck ….)
with a minimum dead weight of 1,500 kg (3,300 lbs).
● To operate the hydraulic installation clamp 2 separate hydraulic circuits are required on the carrier (excavator).
● With the device (HVZ-UNI-II-EK) it is possible to handle one layer of pavers. Do not exceed the and the maximum width
of the device HVZ-UNI-II-EK .
● Only pavers in good quality are allowed for laying. Pavers with „feet, bellies and blind spacers” are not allowed“,
because the complete bricklayer could fall out of the device.
The device is equipped with:
● Adjustable main tension, movable on low-maintenance steel-
polyamid sliders.
● Adjustable side gripping direction for accurate positioning of the
laying formation.
● Three operating handles for optimal guiding of the clamp.
● Height adjustable support for a variable gripping depth.
● Oil pressure gauge.
● With pressure control valve to avoid overload.
● With spring-mounted steel-lamellas for gripping.
● universal excavator suspension (UBA) with hydraulic rotating
motor (360°).
Requirements for hydraulic operation (Operating hydraulics of the carrier)
HVZ-UNI-II-EK:
–Volumetric flow (l/min), usable min. 25, optimal 35 –40, max. 80
–Working pressure (bar), usable min. 180, optimal 200, max. 320
–Backflow pressure: max. 20 bar
Minimum excavator operating weight:
–HVZ-UNI-II-EK from approx. 2 t
(Operating weight may vary depending on excavator type and form. No binding specifications: must be co-
ordinated in the individual case.)
ACCESSORIES SET:
A
Tubular box spanner for adjusting the side clamping
(7063.0001)
B
Allen key No. 08 to shift the position adapter rail (7063.0001)
C
Feather steel lamellas to extend the gripper length at the
main clamping (34010100)
D
Feather steel lamellas to reduce the gripper length at the
main clamping (34010016)

General
11 / 42
V2
GB
4.2 Stone formations
1.) The stone formations 1 –20 shown
below are suitable among others for
mechanical installation. Other stone
formations can also be laid by machines as
long as the stones are packed in the
correct formation ready for the machine to
lay them.
2.) The stone formations 16 –20 are
suitable for mechanical installation by the
shifting adapter PA (4140.0003).
3.) The stone formations 21 –25 are
suitable for mechanical installation by
special adapter.
Special adapters SA for installation units 21–24 or similar are available on request (indicate stone formation).
● The device is only designed for the use specified in this documentation.
● Every other use is not authorized and is forbidden!
● All relevant safety regulations, corresponding legal regulations, especially regulations of the declaration of
conformity, and additional local health and safety regulations have to be observed.
Prior to every operation the user must ensure that:
● the equipment is suited to the intended operation, the functioning and the working condition of the
equipment is examined, and the loads are suitable to be handled.
Any doubts about instructions should be raised with the manufacturer prior to use.

General
12 / 42
V2
GB
ATTENTION: The use of this device is only permitted in proximity to the ground.
Only stone elements with parallel and plane surface are allowed to be picked-up and handled.
Because the gripping good could fall down.
NOT ALLOWED AKTIVITIES:
Unauthorized alterations of the device and the use of any self-made additional equipment
could cause danger and are therefore forbidden!!
Never exceed the carrying capacity/working load limit (WLL) and the nominal width/gripping range of the
device.
All unauthorized transportations with the device are not allowed:
● Transportation of people and animals.
● Transportation of other loads and materials than described in this
manual.
● Never suspend any goods with ropes, chains or similar at the device.
● Transportation of non rectangular and round gripping goods, because
they could fall down. (see figure to the right). ➔
● Gripping of gripping goods with packaging foil, because they could fall
down.
● Transportation of material with “feet”, “bellies” and “blind spacers”.

General
13 / 42
V2
GB
4.3 Survey and construction
1
Operating handle
6
Halfen rail
2
Rotating head (360°)
7
Adjustment of gripping depth
3
Height adjustment of the rollers
8
Main clamping (facing bedding sand/planum)
4
Main clamping (machine side)
9
Steel lamellas
5
Side clamping
4.1 Technical data
Type
Main gripping
width
Gripping
depth
Side gripping width
Gripper
length L
Carrying capacity/working
load limit (WLL)
Dead
weight
HVZ-UNI-II-EK
580 –1,260 mm *
(22¾ –49¾”) *
600 –1,200 **
(23½“--55“)**
50-140 mm
(2 –5 1/2“)
960 - 1,440 mm *
(37¾ –56¾”) *
900 - 1,400 **
(35½“-55“) **
1,200 mm
(47”)
400 kg
(880 lbs)
ca. 258kg
(approx.
567 lbs)
*= Opening width of the Installation Clamp ** =Gripping range (for stone layer dimensions)

Installation
14 / 42
V2
GB
5 Installation
5.1 Mechanical connection
The mechanical connection of the HVZ at the carrier (excavator) takes place with the universal-excavator-suspension
(UBA or Lehnhofadapter).
Excavator-suspension - Lehnhofadapter
Make a secure connection (bolt with locking ring) between
the rotating head and the excavator-suspension.
Excavator-suspension - UBA
Make a secure connection (locking bolt with nut and a
addition lock nut) between the rotating head and the
excavator-suspension.
the adjustment of the nut with locknut takes effect of the speed movement of the grab swing brake.
Rotating head
Safety bolt with locking
ring
Excavator-suspension
(Lehnhofadapter)
Excavator-suspension
(UBA)
Rotating head
Safety bolt with locking ring
(+ locknut) 
Grab swing brake
Grab swing brake

Installation
15 / 42
V2
GB
5.2 Hydraulical connection
Two separate hydraulic circuit are required to connect the HVZ to the carrier
The connection of the hydraulic hoses takes place on the hydraulic rotator.
The opening width between the bolt sockets can be adjusted () by loosening of the locking screws. Remove both
bolt sockets and rotate them at 180° (see arrows). Insert the two bolt sockets again and secure them with locking
screws.
Connection RED for
clamp movement
„close “
Connection for
rotating head
movement
to the right
Connection for
rotating head
movement
to the left
Connection YELLO for
clamp movement „
open “
Locking screws
Locking screws

Installation
16 / 42
V2
GB
5.2.1 Adjustment of the hydraulic control
● The hydraulic control is adjusted for an operating pressure
(operating pressure of the carrier –e.g. excavator) of
about 200 bar.
● Should the HVZ are mounted to a carrier with a higher
operating pressure (e.g. 200 bar or higher) must first be
checked, if the complete sequence (close and reopen)
works without problems.
● If the case occurs, that the main clamping (HSP) is already
opened, when the side clamping (SSP) is opening, the
bypass valve (1) needs to be open slightly.
5.3 Setting 170 bar and 200 bar
The bypass valve (see ) integrated in the control unit allows the hydraulic control to be adapted to carrier
machines (crane) with various oil flow rates. For loaders with large oil capacities, the bypass valve is opened even
wider (200 bar). On carrier machines with small oil capacities, the bypass valve is closed (170 bar).
Setting the side clamping / main clamping
Approx. 2 turns to the left to "+" = side clamping
and main clamping open simultaneously.
Approx. 2 turns to the right to "-" = first the side
clamping opens and only then does the main
clamping open.
→Lever for
activating/deactivating side
clamping
1

Installation
17 / 42
V2
GB
Setting 170 bar for articulated
shovels/roll mops
Setting 200 bar for wheel
loaders
5.4 Adjustment „Bypass valve“ (valve block at HVZ)
The integrated bypass valve in the control block (see ) allows an adjustment of the hydraulic control to the
carriers (excavators) with different oil flow volumes.
Carriers with large oil flows, the bypass valve is further turned up (rotation anti-clockwise).
Carriers with small amounts of oil flow, the bypass valve is further turned off (clockwise rotation).
Thereafter, secure the bypass valve again with the knurled nut.

Installation
18 / 42
V2
GB
5.5 Adjustment additional „Bypass-Valve“ (hydraulic rotator/rotating head)
If the bypass function (of the above-described bypass valve) is not sufficient, for carriers with a larger oil flow volumes
(about 60 to 80 l / min) , to ensure a trouble-free sequence of the HVZ, there is the possibility to assemble an additional
bypass valve (see ) at the hydraulic rotating head.
The bypass valve in the control block (see ) allows an adjustment of the hydraulic control to the carriers (excavators)
with different oil flow volumes.
Carriers with large oil flows, the bypass valve is further turned up (rotation anti-clockwise).
Carriers with small amounts of oil flow, the bypass valve is further turned off (clockwise rotation).
WARNING:
If the shifting force of the side grippers is too low, the bypass valve most likely is opened too far! In this case the bypass
valve has to be tighten up slightly (so the volume flow rate of the oil to the installation clamp is reduced).
For support devices with volume flow rate ≤ 40 l/min the bypass valve remain completely closed!
To support appliances with hydraulic oil flow ≤ 40 l/min, the bypass valve is completely closed!
