Procom FIB100 User manual

   ITEM#0293810
BLOWER ACCESSORY
Questions, problems, missing parts?Beforereturningtoyourretailer,callour
customerservicedepartmentat1-877-886-5989,8:00a.m-4:30p.m.,EST,
Monday-Fridayore-mail[email protected].
PC-FANFIB-1104
MODEL#FIB100
Españolp.17

2
PACKAGE CONTENTS
PART DESCRIPTION Quantity
A PowerCord 1
B Blower 1
C TemperatureSensor 1
D ConnectWire 1
E RockerSwitch 1
A
C
B
D
E

3
HARDWARE CONTENTS
AA
6
6
CableTie
M4.2X8Screw
WARNINGS AND CAUTIONS
WARNING
• Readallinstructionsandwarningscarefullybeforestartinginstallation.Failuretofollowthese
instructionsmayresultinapossibleelectricshock,rehazardandwillvoidthewarranty.
• Readallinstructionsbeforeusingthisappliance.
• Ifpossiblealwaysunplugthisappliancewhennotinuse.
• Donotoperateanyheaterwithadamagedcordorplugoraftertheappliancemalfunctions,
hasbeendroppedordamagedinanymanner.
• Anyrepairstothisapplianceshouldbecarriedoutbyaqualiedserviceperson.
• Undernocircumstancesshouldthisappliancebemodied.Partshavingtoberemovedfor
servicingmustbereplacedpriortooperatingthisapplianceagain.
• Donotuseoutdoors.
• Neverlocatethisappliancewhereitmayfallintoabathtuborotherwatercontainer.
• Donotruncordundercarpeting.Donotcovercordwiththrowrugs,runnersorthelike.
Arrangecordawayfromtrafcareasandwhereitwillnotbetrippedover.
• Todisconnectthisappliance,turncontrolstotheoffposition,thenremoveplugfromoutlet.
• Connecttoproperlygroundedoutletsonly.
• Thisappliance,wheninstalledmustbeelectricallygroundedinaccordancewithlocalcodes,
withthecurrentCSAC22.1CanadianElectricalcodesorforUSAinstallations,followlocal
codesandtheNationalElectricCode,ANSI/NFPANo.70.
• Donotinsertorallowforeignobjectstoenteranyventilationorexhaustopeningasthismay
causeanelectricshock,reordamagetheappliance.
• Topreventpossiblere,donotblockairintakesorexhaustinanymanner.
• Usethisapplianceonlyasdescribedinthismanual.Anyotherusenotrecommendedbythe
manufacturermaycausere,electricshockorinjurytopersons.
• Avoidtheuseofanextensioncordbecauseoftheriskofoverheatingthecordandtherisk
ofre.Extensioncordsarefortemporaryuseonly.Ifanextensioncordmustbeused,it
mustbeUL/CSAcertied,ratedat10A(1250W),125Vmaximumwith16AWGminimumand
constructedoftwocurrentcarryingconductorswithground.Aheavydutyextensioncordwith
theshortestlengthpossiblefortheconnectionisrecommendedandmustnotbelongerthan
50ft.(15.2m).Donotcoilorcovertheextensioncord.
BB
CC 1M4.0X8Screw
Picture
Part  Description  Quantity  (Showntosize)
Notshowntosize

4
Fig.1
ASSEMBLY INSTRUCTIONS
PREPARATION
Beforebeginningassemblyofproduct,makesureallpartsarepresent.Comparepartswith
packagecontentslist.Ifanypartismissingordamaged,donotattempttoassemblethe
product.Contactcustomerserviceforreplacementparts.
EstimatedAssemblyTime:30minutes
ToolsRequiredforAssembly:PhilipsScrewdriverandWireCutter
1.Removeupperreboxbyunscrewing
left/rightscrewsontherebox.SeeFig.1.
Beforeinstallingtheblower,becertain
toturnofftheunit,andallowtimefor
unittocooldown.
This blower contains assembly instructions for the following models and item numbers.
For the CRHFD28TCM-6-AU (Item # 0309527), CRHFD32RT-M-MO, FBD28 and FBD32 series,
PC32VFC and PC36VFC

5
Fig.2
2.Unscrewtwoscrewsonheatinsulation
boardcoveranddrawitout.SeeFig.2.
Fig.3
3.Afxtemperaturesensortoheatinsulation
boardcoverwithM4.2X8screws(AA).
SeeFig.3.
Hardware Used
M4.2X8screw x2
AA
c
AA
Fig.4
4.Insertwiresintothespacebetweenwire
protectingboardandshell;Fixthewiresto
thetopcoverwithwirexture.SeeFig.4.
Protecting
Board
Wire
Fixture
Protecting
Board
Wire
Fixture

6
5.Connecttemperaturesensor(C)with
connectwire(D.Installthecover
accordingtoFigure2,thenxtheupper
reboxaccordingtoFig.1.SeeFig.5.
Fig.5
6.Unscrewandremovepanelontheleft
side.SeeFig.6.(ForModel#CRHFD32RT-M-
MO(Item#0293807),FBD32seriesonly)
Fig.6
Fig.7
D
C
7.Removebloweraccesspanel.SeeFig.7.
(ForPC32VFCandPC36VFCseriesonly)

7
Fig.8
8.Insertblower(B)intothebottomspaceof
burnerpan.Payattentionnottotouch
wiresinside.SeeFig.8.
B
Fig.9
9.Setblower(B)planeandxitontotwo
bracketsofshellboard.Makesureblower
(B)isinstalledintotheslots.SeeFig.9.
Install
Blower
Into slots B
Install
Blower
Intoslots
Fig.10
10.Afxblower(B)withM4.0X8screws(CC),
after,manuallyinstallitintoslots.SeeFig.10.
Hardware Used
M4.0X8screw
CC
cc
x1

8
Fig.12
Fig.11
12.Attachthepowercord(A)tothereplace
withM4.2X8screws(AA)onthetop
cover.SeeFig.12.
Hardware Used
M4.2X8screws x3
AA
AA
A
Fig.13
13.AfxthegroundingterminalwithM4.2X8
screw(AA).SeeFig.13.
Hardware Used
M4.2X8screw x1
AA
AA
11.Mountblowerontobloweraccesspanel.
SeeFig.11.(ForPC32VFCandPC36VFC
seriesonly).

9
Fig.14
14.Insertthemaleportofblower(B)andin
tothecorrespondingfemaleport.
SeeFig.14.
B
Male Port
Female Port
FemalePort MalePort
Fig.15
15.Connecttheportandshellboardwith
linker(maleport)intothethreewires
withprotectingjacket(pleasereferto
linker(femaleport)(red,yellowand
black)withgroundinglabel);Put
protectingjacketintorockerswitch(E)
corresponding.SeeFig.15.
E
AUTO
OFF
MAN
Fig.16
16.Pushtherockerswitchintotheholeon
thepanel.SeeFig.16.
E

10
Fig.17
17.Pushtherockerswitchintotheholeon
thepanel.SeeFig.17.(ForPC32VFCand
PC36VFCseriesonly).
Fig.18
18.Insertthemaleport,whichisontheblack
powersupplywire(markedwithP2),intothe
correspondingfemaleport(markedwithP2).
SeeFig.18.
Fig.19
19.Insertthefemaleport,whichisonthewhite
powersupplywire(markedwithP1),intothe
correspondingmaleport.(markedwithP1).
SeeFig.19.
P2
P1

11
Installation blower assembly position
Installation blower assembly position For PC32VFC and PC36VFC series only.
Install temperature sensor
Install wire
and grounding
Install rocker
switch
Install blower
Installwire
andgrounding
Installwire
andgrounding
Installrocker
switch
Installrocker
switch
Installblower
Installblower
Installtemperaturesensor
Installtemperaturesensor

12
ELECTRICAL CONNECTION
A15amp,120Volt,60Hzcircuitwithaproperlygroundedoutletisrequired.Preferably,the
replacewillbeonadedicatedcircuitasotherappliancesonthesamecircuitmaycausethecircuit
breakertotriporthefusetoblowwhentheheaterisinoperation.Plantheinstallationtoavoidthe
useofanextensioncord.Extensioncordsarefortemporaryuseonly.Ifanextensioncordmustbe
used,itmustbeUL/CSAcertied,ratedat10A(1250W),125Vmaximumwith16AWGminimum
andconstructedoftwocurrentcarryingconductorswithground.Aheavydutyextensioncordwith
theshortestlengthpossiblefortheconnectionisrecommendedandmustnotbelongerthan50ft.
(15.2m).Donotcoilorcovertheextensioncord.
Electricaloutletwiringmustcomplywithlocalbuildingcodesandotherapplicableregulationsto
reducetheriskofre,electricalshockandinjurytopersons.
Donotusethisreplaceifanypartofithasbeenunderwater.Immediatelycallaqualied
servicetechniciantoinspectthereplaceandreplaceanypartoftheelectricalsystemwhich
hasbeenunderwater.
GROUNDING INSTRUCTIONS
Thisheaterisforuseon120volts.ThecordhasaplugasshownatAinFig.20.Anadapteras
shownatCisavailableforconnectingthree-bladegrounding-typeplugstotwo-slotreceptacles.
Thegreengroundinglugextendingfromtheadaptermustbeconnectedtoapermanentground
suchasaproperlygroundedoutletbox.Theadaptershouldnotbeusedifathree-slotgrounded
receptacleisavailable.
Fig.20
OPERATING INSTRUCTIONS
Usingrockerswitch,turnbloweronandcheckforoperation.Turnonrockerswitchtothedesired
position.IntheMANpositionitwillremainconstantlyon.AUTOpositionwillbecontrolledbythe
temperaturesensor.TostoptheoperationturnrockerswitchtotheOposition.
GroundingPin
Adapter
GroundingMeans
MetalScrew
Coverof
Grounded
OutletBox

13
CARE AND MAINTENANCE
Always disconnect the appliance from the main power supply and allow it to cool before
any servicing operation.
Themotorsusedonthefanheaterandameblowerarepre-lubricatedforextendedbearinglife
andrequirenofurtherlubrication.However,periodiccleaning/vacuumingoftheappliancearound
theairintakeandexhaust,aswellasthefanheaterisrecommended.Forheavyorcontinuous
use,periodiccleaningmustbedonemorefrequently.Iftheheaterblowsalternatingcoldand
warmair,checkthefanforfreemovementandfordebrisrestrictingairow.Ifthefandoesnot
movefreely,theunitmustbeturnedoffandthefanreplacedimmediatelyinordertoprevent
furtherdamagetotheunit.
ELECTRICAL WIRING DIAGRAM
Anyelectricalre-wiringofthisappliancemustbedonebyaqualiedelectrician.Thiswiringmust
bedoneinaccordancewithlocalcodesand/orinCanadawiththecurrentCSAC22.1Canadian
ElectricalCode,andforUSinstallations,theNationalElectricalCodeANSI/NFPANO70.
Ifrepairingorreplacinganyelectricalcomponentorwiring,theoriginalwirerouting,color
codingandsecuringlocationsmustbefollowed.
1.PowerCord
2.BushingStrainRelief
3.Fan
4.TemperatureLimiter
5.RockerSwitch
WHITE
GREEN BLACK
RED
FAN
BLACK

14
REPLACEMENT PARTS
NOTE:Useonlyoriginalreplacementparts.Thiswillprotectyourwarrantycoverageforparts
replacedunderwarranty.
PARTS UNDER WARRANTY
CallCustomerServicetollfreeat( 1-877-886-5989 )forreferralinformation.
WhencallingCustomerService,haveready:
• Yourname
• Youraddress
• Modelandserialnumberofyourheater
• Howheaterwasmalfunctioning
• Typeofgasused(Propane/LPorNaturalgas/NG)
• Purchasedate
• Usually,wewillaskyoutoreturnthedefectiveparttothefactory
PARTS NOT UNDER WARRANTY
CallCustomerServicetollfreeat( 1-877-886-5989 )forreferralinformation.
WhencallingCustomerServicehaveready:
• Modelnumberofyourheater
• Thereplacementpartnumber

15
REPLACEMENT PARTS LIST
Forreplacementparts,callourcustomerservicedepartmentat 1-877-886-5989,
8:00a.m-4:30p.m.,EST,Monday-Fridayore-mail[email protected].
PART PART NUMBER DESCRIPTION Quantity
A XB001-01 PowerCord 1
B XB002-01F Blower 1
C XB003-01 TemperatureSensor 1
D XB004-01F ConnectWire 1
E PF06-0400-A RockerSwitch 1
A
C
B
D
E

16
WARRANTYINFORMATION
KeepThisWarranty
IMPORTANT:WeurgeyoutollyourwarrantyregistrationcardwithinTEN(10)daysofdate
ofinstallation,completewiththeentireserialnumberwhichcanbefoundontheratingplate.
Retainthisportionofthecardforyourrecord.
Alwaysspecifymodelandserialnumberswhencommunicatingwithcustomerservice.
Wereservetherighttoamendthesespecicationsatanytimewithoutnotice.Theonly
warrantyapplicableisourstandardwrittenwarranty.Wemakenootherwarranty,expressed
orimplied.
LIMITED WARRANTY:
PRO-COMwarrantsthisproducttobefreefromdefectsinmaterialsandcomponentsforTWO
(2)yearsfromthedateofrstpurchase,providedthattheproducthasbeenproperlyinstalled,
operatedandmaintainedinaccordancewithallapplicableinstructions,tomakeaclaimunder
thiswarranty,theBillofSaleorcancelledcheckmustbepresented.
RESPONSIBILITY OF OWNER
Thiswarrantyisextendedonlytotheoriginalretailpurchaser.Thiswarrantycoversthecost
ofpart(s)requiredtorestorethisheatertoproperoperatingconditionandanallowancefor
laborwhenprovidedbyaPRO-COMAuthorizedServiceCenter.Warrantypart(s)MUSTbe
obtainedthroughauthorizeddealersofthisproductand/orPRO-COMwhowillprovideoriginal
factoryreplacementparts.Failuretouseoriginalfactoryreplacementpartsvoidsthiswarranty.
TheheaterMUSTbeinstalledbyaqualiedinstallerinaccordancewithalllocalcodesand
instructionsfurnishedwiththeunit.
WHAT IS NOT COVERED
Thiswarrantydoesnotapplytopartsthatarenotinoriginalconditionbecauseofnormal
wearandtearorpartsthatfailorbecomedamagedasaresultofmisuse,accidents,lackof
propermaintenanceordefectscausedbyimproperinstallation.Travel,diagnosticcost,labor,
transportationandanyandallsuchothercostsrelatedtorepairingadefectiveheaterwillbe
theresponsibilityoftheowner.
TOTHEFULLEXTENTALLOWEDBYTHELAWOFTHEJURISDICTIONTHATGOVERNS
THESALEOFTHEPRODUCT,THISEXPRESSWARRANTYEXCLUDESANYAND
ALLOTHEREXPRESSEDWARRANTIESANDLIMITSTHEDURATIONOFANYAND
ALLIMPLIEDWARRANTIES.INCLUDINGWARRANTIESOFMERCHANTABILITYAND
FITNESSFORAPARTICULARPURPOSETOTWO(2)YEARSONALLCOMPONENTS
FROMTHEDATEOFFIRSTPURCHASE.PRO-COM'SLIABILITYISHEREBYLIMITED
TOTHEPURCHASEPRICEOFTHEPRODUCTANDPRO-COMSHALLNOTBELIABLE
FORANYOTHERDAMAGESWHATSOEVERINCLUDINGINDIRECT.INCIDENTALOR
CONSEQUENTIALDAMAGES.
Somestatesdonotallowalimitationonhowlonganimpliedwarrantylastsoranexclusionor
limitationofaccidentalorconsequentialdamages,theabovelimitationonimpliedwarranties,
orexclusionorlimitationondamagesmaynotapplytoyou.
Thiswarrantygivesyouspeciclegalright,andyoumayalsohaveotherrightsthatvaryfrom
statetostate.
PrintedinChina
