Procomp K3099B User manual

PRO COMP SUSPENSION
This document contains very important information that includes warranty information and instructions for
resolving problems you may encounter. Please keep it in the vehicle as a permanent record.
K3101B/K3101BMX
55728B/55728BMX
2007-2015 Jeep Wrangler JK 4WD 2 Door Stage One 2 1/2” Lift Kit
K3099B/K3099BMX
55728B/55728BMX
2007-2015 Jeep Wrangler JK 4WD 4 Door Stage One 2 1/2” Lift Kit

55728/K3099B/
K3101B
Created
7.25.15
2
90-4002 FRONT BUMPSTOP SPACER 2 1 5
90-6662 HARDWARE PACK:
Front Bump Stop Spacer 1 - -
70-0372001800 3/8” X 2” HEX BOLT GR. 8 2 1 5
72-0371100816 3/8” NYLOCK NUT 2 1 5
73-03700034 3/8” HARDENED FLAT WASHER 4 1 5
91-5841 REAR TRACK BAR BRACKET 1 2 7
90-2650 REAR TRACK BAR SPACER 1 2 7
13-90496 U-BOLT:
Rear Track Bar Relocation Bracket 1 2 7
72-050100816 1/2” STOVER NUT GR. C 2 2 7
73-05000830 1/2" SAE FLAT WASHER 2 2 7
90-6722 HARDWARE PACK:
Rear Track Bar Bracket 1 - -
70-0563251800 9/16” X 3 1/4” GR. 8 HEX BOLT 1 2 7
72-056100816 9/16” STOVER NUT 1 2 7
73-05600830 9/16” SAE FLAT WASHER 2 2 7
70-0371001800 3/8” X 1” GR. 8 HEX BOLT 2 2 7
72-037100816 3/8” STOVER NUT 2 2 7
73-03700830 3/8” SAE FLAT WASHER 4 2 7
90-6529 HARDWARE PACK:
Jeep Cam Kit 1- -
73-01410940 14mm FLAT WASHER 1 2 7
72-01415008812 14mm– 1.5 NUT 1 2 7
90-3245 NOTCHED CAM 1 2 7
90-3718 CAM BOLT 1 2 7
91-5289 REAR BUMP STOP 2 - -
90-6299 HARDWARE PACK: Rear Bump Stop 2 - -
70-0311001800 5/16” X 1" HEX BOLT GR. 8 2 - -
72-0531100816 5/16” NYLOCK NUT 2 - -
73-03100034 5/16” HARDENED FLAT WASHER 4 - -
91-5182 FRONT SWAY BAR DROP BRACKET 2 - -
90-6340 HARDWARE PACK:
Front Sway Bar Drop 1 - -
70-0431251800 7/16” X 1 1/4” HEX BOLT GR. 8 4 - -
72-043100816 7/16” STOVER NUT GR. C 4 - -
73-0400830 7/16” SAE FLATWASHER 8 - -
Part # Description Qty Illus. Page
PN 55728B

55728/K3099B/
K3101B
Created
7.25.15
3
TRACK BAR: JTB 402
JK LIGHT BAR: 23700
FRONT ARM CAMS: 20-65227
REAR ARM CAMS: 20-65228
Also, check out our outstanding selection of Pro Comp tires to
compliment your new installation!
Optional EquipmentAvailable from your Pro Comp Distributor!
55728B JEEP JK 4WD 2/12” LIFT KIT 1 - -
55210 FRONT COIL SPRINGS 1 - -
55211 REAR COIL SPRINGS 1 - -
MX6024 MX SERIES FRONT SHOCK 2 - -
MX6155 MX SERIES REAR SHOCK 2 - -
PN K3101BMX
55728B JEEP JK 4WD 2/12” LIFT KIT 1 - -
55399 FRONT COIL SPRINGS 1 - -
55207 REAR COIL SPRINGS 1 - -
MX6024 MX SERIES FRONT SHOCK 2 - -
MX6155 MX SERIES REAR SHOCK 2 - -
PN K3099BMX
55728B JEEP JK 4WD 2/12” LIFT KIT 1 - -
55399 FRONT COIL SPRINGS 1 - -
55207 REAR COIL SPRINGS 1 - -
924510 ES9000 SERIES FRONT SHOCK 2 - -
924507 ES9000 SERIES REAR SHOCK 2 - -
PN K3099B
55728B JEEP JK 4WD 2/12” LIFT KIT 1 - -
55210 FRONT COIL SPRINGS 1 - -
55211 REAR COIL SPRINGS 1 - -
924510 ES9000 SERIES FRONT SHOCK 2 - -
924507 ES9000 SERIES REAR SHOCK 2 - -
PN K3101B
Part # Description Qty Illus. Page

55728/K3099B/
K3101B
Created
7.25.15
4
 This installation requires a professional mechanic!
 We recommend that you have access to a factory service manual for your vehicle to assist in the
disassembly and reassembly of your vehicle. It contains a wealth of detailed information.
 Prior to installation, carefully inspect the vehicle’s steering and driveline systems paying close at-
tention to the tie rod ends, ball joints, wheel bearing preload, pitman and idler arm. Additionally,
check steering-to-frame and suspension-to-frame attaching points for stress cracks. The overall
vehicle must be in excellent working condition. Repair or replace all worn or damaged parts!
 Read the instructions carefully and study the illustrations before attempting installation! You may
save yourself a lot of extra work.
 Check the parts and hardware against the parts list to assure that your kit is complete. Separating
parts according to the areas where they will be used and placing the hardware with the brackets
before you begin will save installation time.
 Check the special equipment list and ensure the availability of these tools.
 Secure and properly block vehicle prior to beginning installation.
 ALWAYS wear safety glasses when using power tools or working under the vehicle!
 Use caution when cutting is required under the vehicle. The factory undercoating is flammable.
Take appropriate precautions. Have a fire extinguisher close at hand.
 Foot pound torque readings are listed on the Torque Specifications chart at the end of the instruc-
tions. These are to be used unless specifically directed otherwise. Apply thread lockretaining
compound where specified.
 Please note that while every effort is made to ensure that the installation of your
Pro Comp lift kit is a positive experience, variations in construction and assembly
in the vehicle manufacturing process will virtually ensure that some parts may
seem difficult to install. Additionally, the current trend in manufacturing of vehicles
results in a frame that is highly flexible and may shift slightly on disassembly prior
to installation. The use of pry bars and tapered punches for alignment is considered
normal and usually does not indicate a faulty product. However, if you are uncertain
about some aspect of the installation process, please feel free to call our tech sup-
port department at the number listed on the cover page. We do not recommend that
you modify the Pro Comp parts in any way as this will void any warranty expressed
or implied by the Pro Comp Suspension company.
Introduction:
PLEASE NOTE:
Due to differences in manufacturing, dimensions and inflated measurements, tire
and wheel combinations should be test fit prior to installation. Tire and wheel
choice is crucial in assuring proper fit, performance, and the safety of your Pro
Comp equipped vehicle. For this application, we recommend a 17” wheel not to ex-
ceed 9” in width with a maximum backspacing of 5” must be used.Additionally,
quality tire of radial design, not exceeding 35” tall X 12.5” wide is also recom-
mended. Please note that the use of a 35” X 12.5” tire may require fender modifica-
tion. Violation of these recommendations will not be endorsed as acceptable by Pro
Comp Suspension and will void any and all warranties either written or implied.

55728/K3099B/
K3101B
Created
7.25.15
5
1. Position your vehicle on a smooth, flat, hard
surface (i.e. concrete or asphalt). Block the
rear tires and set the emergency brake.
2. Measure and record the distance from the
center of each wheel to the top of its fender
opening. Record below.
3. Place the vehicle in neutral. Place your floor
jack under the front axle and raise the vehicle.
Place jack stands under the frame rails and
lower the frame onto the stands. Remove the
jack and place the vehicle back in gear, set
the emergency brake, and place blocks both
in front and behind the rear wheels.
4. Unbolt and remove the transmission skid
plate from the vehicle.
5. Unbolt the front sway bar frame mounts
from the vehicle. Save the hardware for re-
use.
6. Remove the shocks on both sides of the vehi-
cle. It may be necessary that you slightly
raise the axle to unload the shocks for re-
moval.
7. Unbolt the front track bar from the front axle
mount and secure up and out of the work
area. Save the hardware for reinstallation.
8. Unbolt the all the ABS mounting clips from
the vehicle.
9. Unbolt the front brake line brackets from the
frame.
10. Lower the front axle enough to remove the
coil springs from the front spring pockets.
Save the factory isolators for re-use.
NOTE: Be sure to support the axle while
the springs and shocks are removed.
11. Drill out the center of the front axle pad to
3/8”. See ILLUSTRATION 1.
12. Install the aluminum bump stop (90-4002)
into the previously drilled 3/8” hole using the
supplied 3/8” X 2” bolt and hardware. See
ILLUSTRATION 1.
13. Carefully lower the front axle to ease in the
new front coil spring installation. Using the
factory isolators install the Pro Comp coil
springs (55399) into the spring buckets and
raise the front axle into place. Make sure the
front coil spring seats properly on the lower
spring perch.
14. Install the sway bar drop brackets (91-5182)
using the previously removed OE hardware.
15. Reattach the sway bar frame mounts to the
sway bar drop brackets (91-5182) using the
supplied 7/16”” X 1 1/4” hardware.
16. Torque the sway bar hardware to 35 ft./lbs.
17. Reinstall the transmission skid plate using the
previously removed OE hardware.
18. Install your new Pro Comp front shocks
(MX6024 w/body end up or 924510 w/shaft
end up) using the OE hardware. Torque the
upper mounting hardware to 17 ft./lbs. and
FRONT INSTALLATION:
LR: RR:
RF:LF:
Drill 3/8”
3/8” X 2”
Bolt
Aluminum
Bump Stop
90-4002
3/8” Flat Washer
Coil
Spring
Spring
Plate
Illustration 1
Aluminum Bump Stop
Install

55728/K3099B/
K3101B
Created
7.25.15
6
the lower to 35 ft./lbs.
19. Reinstall the ABS and brake line brackets to
the vehicle using the previously removed OE
hardware.
20. On both sides of the vehicle, check the
routing of the brake lines and the ABS wire
harnesses. There must be no pinching,
rubbing, or stretching of either component.
Use zip ties to secure these items to the
steering components. At full droop, cycle the
steering from lock to lock while observing the
reaction of these components. Reposition
them if needed.
21. Reinstall the front wheels and lower the vehi-
cle to the ground. Torque the lug nuts ac-
cording to the wheel manufacturers recom-
mendations.
22. Reinstall the OE front track bar to the axle
mount using the previously removed OE
hardware. Torque the track bar mounting
bolt according to manufacturers specifica-
tions.
NOTES:
 On completion of the installation, have
the suspension and headlights re-
aligned.
 After 100 miles recheck for proper
torque on all newly installed hardware.
 Recheck all hardware for tightness af-
ter off road use.
REAR INSTALLATION:
1. Block the front tires and raise the rear of the
vehicle. Support the frame with jack stands
forward of the rear springs.
2. Remove the rear wheels.
3. Unbolt the rear track bar from the rear axle
mount and secure up and out of the work
area. Save the hardware for reinstallation.
4. Remove the shocks on both sides of the vehi-
cle. It may be necessary that you slightly
raise the axle to unload the shocks for re-
moval.
5. Unbolt and remove the rear sway bar end
links from the vehicle. Save the hardware for
reuse.
6. Unbolt the rear brake line brackets from the
vehicle.
7. Lower the rear axle enough to remove the
coil springs from the rear spring pockets.
Save the factory isolators for re-use.
NOTE: Be sure to support the axle while
the springs and shocks are removed.
8. Install the driver side rear track bar relocation
bracket (91-5841) into the original track bar
mounting pocket using the supplied 9/16” X 3
1/4” bolt and supplied spacer (90-2650). See
ILLUSTRATION 2.
9. Insert the (2) 3/8” X 1” bolt into the track bar
bracket and secure it to the driver side rear axle
shock mount. See ILLUSTRATION 2.

55728/K3099B/
K3101B
Created
7.25.15
7
10. Tighten the previously installed 9/16” and 3/8”
hardware.
11. Install the U-bolt around the rear end axle tube
and secure to the rear track bar relocation
bracket (91-5841) using the supplied 1/2”
washer and nut. See ILLUSTRATION 2.
12. Torque the 3/8”, 1/2” U-bolt and 9/16” track
bar hardware according to the torque chart on
page 9.
13. Install the rear bump stop (91-5289) onto the
axle pad. Secure through the existing holes in
the axle pad using the (2) supplied 5/16” X
1” bolts and hardware. Torque bolts accord-
ing to the torque chart on page 9.
14. Carefully lower the rear axle to ease in the
new rear coil spring installation. Using the
factory isolators install the Pro Comp rear
coil springs (55207) into the spring buckets
and raise the rear axle into place. Make sure
the coil spring seats properly on the lower
spring perch.
NOTE: Be sure to reinstall the factory
isolators before raising the springs into place.
15. Install your new Pro Comp rear shocks
(MX6155 w/body end up or 924507 w/shaft
end up) using the OE hardware. Torque the
upper mounting hardware to 20 ft./lbs. and
the lower to 35 ft./lbs.
16. Reinstall the sway bar end links using the
previously removed OE hardware.
17. Reinstall the rear brake line brackets to the
vehicle using the previously removed OE
hardware.
18. On both sides of the vehicle, check the routing
of the brake lines and the ABS wire harnesses.
There must be no pinching, rubbing, or
stretching of either component. Ensure lines
are also clear of any moving parts. Reposition
lines if needed.
19. Reinstall the rear wheels and lower the vehi-
cle to the ground. Torque the lug nuts ac-
cording to the wheel manufacturers recom-
mendations.
Rear Axle
Rear
Track
Bar
91-5841 Rear Track
Bar Relocation Bracket
13-90496
U-Bolt
9/16” X 3
1/4” Bolt
90-3718
Cam Bolt
1/2” U-Bolt Hardware
OE Track
Bar Mount
Pocket
Rear Track
Bar Spacer
90-2650
Cam
Hardware
3/8” X
1” Bolts
Illustration 2
Rear Track Bar
Relocation Bracket

55728/K3099B/
K3101B
Created
7.25.15
8
20. Install the rear track bar to the relocation
bracket (91-5841) using the supplied adjust-
able cam bolt (90-3718) and hardware from
hardware pack (90-6529). Do not torque the
cam bolt at this time. See ILLUSTRATION 2.
21. Position your vehicle on a smooth, flat, hard
surface (i.e. concrete or asphalt).
22. Rotate the track bar cam bolt until the wheels
are centered under the vehicle.
23. Torque track bar cam bolt to 103 ft./lbs.
24. Drive the vehicle forward and backward a
few feet to be sure that the axle is adjusted
properly and the vehicle is tracking in a
straight line.
IMPORTANT!: If the steering wheel is
not centered properly it will trigger the anti-lock
brake and traction control warning lights.
NOTES:
 On completion of the installation, have
the suspension and headlights re-
aligned.
 After 100 miles recheck for proper
torque on all newly installed hardware.
 Recheck all hardware for tightness af-
ter off road use.

55728/K3099B/
K3101B
Created
7.25.15
9
8.30.12: Moved (90-3718) cam bolt into hardware pack (90-6529).
10.1.12: Changed kit fitment to include 2013.
4.10.14: Updated rear install step 18.
7.25.15: Added K3101B, K3101BMX, K3099B, K3099BMX to the BOM.
Modifications Page:
