progressive automations FLT-03-2-1 User manual

FLT-03-2-1
User Manual
Page 2
Page 4
Page 5
Caution/Liability
Technical Specifications
Parts
Operational Procedure
Dimensions
Contents
Page 3
Page 6

Caution
Liability
2

Technical Specifications
3
Duty Cycle 10% Max. 2 mins on, 18 mins off
Height Range 23.5” - 49” (without table top)
Minimum Table Top Size 43"x 24”
Weight Capacity 440lbs
Input Voltage 120 VAC, 60 Hz
Output Voltage 24 VDC
Stroke 22"-38"
Speed 0.5"/sec
Material Steel
Certification UL

Parts
4
FLT-03-2-1 LIFTING COLUMN
Wired Remote
1 Lifting Column Control Box and Remote
Control Box
Setup

5
Operational Procedure
Once the table lift is installed, use the wired remote for full up and down motion control. The momentary
buttons require the user to press and hold the button for both up and down control. Once the button is
released, the FLT-03-2-1 will stop moving.

Dimensions
6
3.9"
Ø0.2"
Ø0.8"
2.8"
1.6"
0.2" 2.3"
0.3"
1.0"
1.5" 1.6"
2.4"
4.5"
Ø0.3"
0.5"
0.8"
4.1"
3.6"
1.4"
0.4"
0.7"
0.4"
1.0"
2.8" 2.4"
3.2"
4.5"
2.1"
3.6"
0.6"
3.8"
3.3"
4.4"
6.7"
Ø0.5"
2.5"
2.5"
22.0"
0.5"
0.5"
7.9"
4.4"
1.9"
7.9"
4.4"
0.8"
3.9"
0.3"
Ø0.2"
1.4"
3.2"
1.6"
1.6"
0.3"
Leg
Control Box
Remote
