progressive automations flt-05 User manual

Page 1 of 7
FLT-05
The FLT-05 is a three-column table lift set with a 25.5” stroke size and 330 lbs of
force. This model comes with a power supply and an interactive remote with four
programmable preset functions. It comes with everything needed for installation.
Table top is not included.
TABLE LIFT SET – 3 LEGS – 3 STEP – STROKE SIZE 25.5”
HOW TO ORDER 1.800.676.6123 | [e-mail] | www.progressiveautomations.com

Page 2 of 7
CAUTION/INFORMATION
HOW TO ORDER 1.800.676.6123 | [e-mail] | www.progressiveautomations.com
USE/LIABILITY

PARTS
HOW TO ORDER 1.800.676.6123 | [e-mail] | www.progressiveautomations.com
Page 3 of 5
Remote
Remote
Handset
Control Box
Power Cord Cable (1.3m) x2
Machine Screw
M6x14 x24
Machine Screw
M6x10 x8
Center Rail x2
Crossbar end-CB Side Bracket x3
Crossbar end x2 Foot x3
Cable Clip x15
Leg x3
Wood Screw
ST5x15 x2
Wood Screw
ST5x20 x24
3
3
3
2
3
1
1
1
2
18
32
2
12
16
Machine Screw
M6x35 x6

Page 4 of 7
STEP 1
Before starting lay out all the components and hardware to
ensure you have everything listed on the Parts page.
Separate the Crossbar Ends (P3) so you can remove the
Crossbar Center Rails (P4) inside.
STEP 2
Position one of the Crossbar Ends (P3) on its side.
Place one of the three Legs (P1) into the Crossbar End (P3)
making sure that the bar is on top in relation to the Leg (P1).
Then line up the holes on each Leg (P1) with the holes on
each Crossbar End (P3).
STEP 3
Insert four M6x14 Machine Screws (P10) through the
holes on each Crossbar End (P3) going into the Leg (P1).
Rotate each screw with the supplied Allen Wrench just a
few turns, we don’t want to tighten them just yet.
ASSEMBLY INSTRUCTIONS
HOW TO ORDER 1.800.676.6123 | [e-mail] |
www.progressiveautomations.com
Caution: DO NOT tighten the screws just yet
STEP 4
Take the Side Bracket (P5) and insert four M6x14
Machine Screws (P10) through the four holes going into
the assembled Crossbar End/Leg. Like the previous step
use the Allen Wrench to rotate the screws just a few
turns.
Repeat Steps 1-4 for the other two Legs (P1) and
Crossbar Ends (P3). Once you are finished you can now
tighten the screws from the Steps 3 and 4 until they are
fully secure.
STEP 5
Slide the two Crossbar Center Rails (P4)into two of the
assembled Crossbar Ends (P3). Make sure that the slots
face inward and that the slot is closer to the top edge of the
Crossbar Center Rail (P4) while the assembly is upside
down.
If you drop a screw inside the Crossbar End (P3),
just tilt it until the screw falls out
If you are having difficulty inserting any of
the screws from Steps 3 or 4 it is most
likely because the screws are too tight at
this point

Page 5 of 7
ASSEMBLY INSTRUCTIONS
HOW TO ORDER 1.800.676.6123 | [e-mail] |
www.progressiveautomations.com
STEP 6
Attach a Foot (P2) to the bottom of each Leg (P1) using
four M6x14 Machine Screws and tighten them until fully
secure.
STEP 8
Grab your table top and check if it’s pre-drilled or not before
you start to place your assembled table lift bases upside-
down on the underside of your table top.
Carefully place the upside down 2-Leg table lift base
assembly on the underside of your table top. Adjust the
width of the table lift base to fit your table top by sliding the
two halves outward if necessary. We recommend leaving at
least a half inch overhang of the table top width over the
table lift base on each side.
Place the 1-Leg table lift base assembly in an
appropriate position on the underside of your table top.
Choose whatever position you feel will provide the most
support.
STEP 9
If your table top is pre-drilled go ahead to Step 10 and
come back to this after.
If it’s not pre-drilled, secure the position of the Crossbar
Center Rails (P4) using eight M6x10 Machine Screws
(P11). Keep in mind the maximum width is 74”.
Caution: Ensure that the M6x10 Machine
Screws (P11) touch the Center Rails (P4)
by sliding the Center Rails (P4) as needed

Page 6 of 7
ASSEMBLY INSTRUCTIONS
HOW TO ORDER 1.800.676.6123 | [e-mail] |
www.progressiveautomations.com
STEP 10
Double-check that the assembled table lift bases are properly
positioned on the underside of your table top.
Attach the 2-Leg table lift base assembly to the underside of
your table top using eight M5x20 ST Screws (P12). Use three
for each Side Bracket (P3) and one for each Crossbar End
(P4).
Attach the 1-Leg table lift base assembly to the underside of
your table top using four M5x20 ST Screws (P12). Use three
for the Side Bracket (P3) and one for the Crossbar End (P4).
Attach the Control Box (P6) to the underside of the table top
using two M5x16 Screws (P13). Make sure you have enough
space near the wire ports for cable connections.
Place the Remote (P7) so the front of it lines up with the front
edge of your table top. We recommend placing it toward an
end of your table top so it doesn’t get in the way while you’re
seated. Use two M5x16 Screws (P13) to attach the Remote to
the table top.
STEP 11
Connect the Cables (P9), Remote (P7) and the Power Cord
(P8) to the Control Box (P6). Use the adhesive backed
Cable Clips (P14) to secure the Cables and Remote cable
so they aren’t loose.
STEP 12
For this step we recommend using two people. Grab the
table lift by the BASE (not the table top) and turn the fully
assembled table lift right-side up. Adjust the pre-installed
Levelling Studs if need be.
STEP 13
Plug the Power Cord (P8) into a 110V outlet.
IMPORTANT
You MUST reset the table lift prior to use.
To reset you must push and hold the DOWN button on the
remote (P7) until the table lift reaches its lowest point,
slightly rises and then stops completely. Release the
DOWN button and your table lift is ready for action.
To program up to four presets with the remote just use the
Up/Down buttons to find your desired position, then press
the “M” button followed by a number 1-4.
Caution: Double check that the wood
screws are not too long for your table top
and won’t puncture the surface once
screwed all the way in
We recommend that you pre-drill any
holes needed for fasteners to connect
the Control Box (P6) or Remote
(P7) to the table top. NEVER use
countersunk screws
Caution: Do not overtighten screws.
Overtightening could cause damage
to components
Caution: Make sure no obstacles are
in the table lifts path and the top is
not touching any walls. Make sure all
the cords are the correct length to
accommodate the change in height
Caution: Once a preset button is
pushed, the table lift will move to
the programmed height
(see caution box above)
Caution: Ensure the cables are not
obstructing the path of either of the
Legs (P1) before proceeding

DIMENSIONAL DRAWING
HOW TO ORDER 1.800.676.6123 | [e-mail] | www.progressiveautomations.com
70.9"
40.1"
49"
23.5"
22.6"
2"
27.5"
1.2"

Page 7 of 7
Height Range 23.5’ - 49” (without desktop)
Base Width 40.1” min. - 70.9” max.
Travel Speed 1.5” per second (no load)
Weight Capacity 330 lbs (110 lbs per leg)
Duty Cycle 10% Max. 2 mins on, 18 mins off
Features Soft start/stop
Adjustable leveling studs
4 Memory presets (some models)
TROUBLESHOOTING
TECHNICAL SPECIFICATIONS
HOW TO ORDER 1.800.676.6123 | [e-mail] | www.progressiveautomations.com

SETTING UPPER & LOWER LIMITS
Upper Limit
To set the upper limit, use the UP/DOWN buttons to move the table lift to your desired
max height position. Once it is at the desired position, press and hold the "M" until the
LED display flashes "S-" once, then release the button. Press and release the button two
more times in quick succession. The LED display should then show "999" on the third
press and then automatically return to the desired height. The upper limit is now set.
Lower Limit
To set the upper limit, use the UP/DOWN buttons to move the table lift to your desired
minimum height position. Once it is at the desired position, press and hold the "M" until
the LED display flashes "S-" once, then release the button. Press and release the button
two more times in quick succession. The LED display should then show "000" on the third
press and then automatically return to the desired height. The lower limit is now set.
Removing Limits
To remove the upper and lower limits, use the UP/DOWN buttons to move the desk to
any desired position. Press and hold the "M" button until the LED display flashes "S-"
once, then release the button. Press and release the button in succession until the display
changes to "555"(ignore any other readings). After a few seconds, the display will
automatically change back to the numbered height position. Upper and lower limits should
now be removed.
*After the upper and lower limits are set, the previous memory positions (1,2,3,4) may be
outside the new range of movement. If this happens, simply reset the memory positions.
*A Reset procedure requires the desk base to fully retract beyond any lower limit. Please
ensure you have proper clearance below the desk base.
*If you attempt to revise a previously set upper or lower limit and it is outside of the
existing range, you will need to remove the original upper/lower limits first.
HOW TO ORDER 1.800.676.6123 | [e-mail] | www.progressiveautomations.com

HOW TO ORDER 1.800.676.6123 | [e-mail] | www.progressiveautomations.com
MODIFIYING LED DISPLAY
Press the DOWN button on the Hand Remote until the base reaches its lowest position.
Measure the height of the base from the floor and if the number on the LED display does
not match your measurements, follow the steps below:
Press and hold the DOWN button again until the LED display reads "RST".
Press and hold the "M" button for about 5 seconds until the LED displays the flashing
starting height.
To change the value of the starting height:
Increase by 0.1s, press the UP button
Decrease by 0.1s, press the DOWN button
Increase by 1s, press the "1" button
Decrease by 1s, press the "2" button
Increase by 10s, press the "3" button
Decrease by 10s, press the "4" button
Once the new value is displayed, wait about 5 seconds and the display will return to
"RST". Finish the reset process by pressing and holding the DOWN button again until
the desk lowers a little bit more, slightly rises and stops. Release the DOWN button and
the new starting height value is saved.
