progressive automations FLT-09 User manual

Contents
Caution
Specifications
Dimensional Drawing
Components
Assembly
Operation
Reset Procedure
Troubleshooting
Model: FLT-09 User Guide
1
2
3
4
5-6
7
7
8

Ensure no obstacles are in the desk's path. Ensure the
tabletop is not touching any walls. Ensure all cords are
appropriate length to accommodate the change in height.
Warning
Pinch Point
Keep hands and
fingers clear.
Keep children away from electric height-adjustable desks, control units, and handsets. There is a
risk of injury and electric shock.
During the Reset Procedure, the desk will retract 7mm below the lowest normal operating
height, ensure no obstacles impede this motion of travel.
Keep all electrical components away from liquids.
Do not sit or stand on the desk frame. Do not crawl or lie under the desk frame.
Do not place any objects taller than 20" underneath the desk.
01 Caution

02 Specifications
Feature Description
Soft Start and Stop The tablelift will accelerate to maximum speed and
deccelerate to a stop to ensure smooth travel.
Memory Presets The Smart Remote has the ability to save preset height locations for convenience. Set the numbered buttons on the Smart Remote
for quick and seamless adjustment.
Anti-Collision The Anti-Collision feature will help protect the tablelift against obstacles which impede the motion of travel. There are 3 force settings which can
be detected during travel, 22lbs, 33lbs, and 44lbs.
Input Voltage 120VAC, 60 Hz
Output Voltage 24VDC
Stroke (movement) 25.5"
Height Range (without tabletop) 23.5” - 49”
Weight Capacity (load) 330 lbs (110 lbs per leg)
No Load Speed 1.57"/s
Full Load Speed 1.18"/s
Duty Cycle 10% (2 minutes on, 18 minutes off)
Operating Noise < 50 dB
Frame Material SPCC/ SPHC Steel
Finish Powder Coat - Grey(RAL7045)
Leveling Adjustable Leveling Feet
Low Power Mode Standby < 0.1W
Certification UL and BIFMA United Certificate

*Feet and column style may vary slightly
03Dimensional Drawing
Maximum Width - 75.3"
Minimum Width - 43.4"
Extended - 49"
22.6"
2"
27.5"
1.2"
Retracted - 23.5"

Parts
Parts Diagram
Tools
4mm Allen Wrench (included) Phillips Head Screwdriver
and/or Power Drill
Tape Measure
04Components
Description
Feet
Leg
Side Bracket
Frame 1
Frame 2
Center Rail
120° Frame 1
120° Frame 2
M6x14 Machine Screw
M6x10 Machine Screw
M6x35 Machine Screw
M6x20 Wood Screw
M6x16 Wood Screw
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
1 2
x5 x2 3 4 5
x3 x3 x2
6 7 8 9 10
x4 x1 x4
11 12 13
x16 x28
x20 x2 x1
1
9
2
9
3
10
10
8
4
6
7
Qty
3
3
3
1
1
4
1
1
16
24
4
2
14

05Assembly
STEP 3
Slide the Side Brackets (3) into both Frames (4,5).
Attach the brackets using two M6x35 Machine Screws
(11).
STEP 1
Attach the 120° Frames (7,8) to one of the Legs (3) as shown
in the picture below. Line up the holes on the Leg with the
holes on the Frames.
Use the supplied Allen Wrench to insert four M6x10
Machine Screws (10) through the holes on the Frame
(7,8) going into the Leg (1). Rotate each screw just a few
turns until all four are inserted, then tighten them.
STEP 2
Place one of the Legs (3) into one of the Frames (5)
and line up the holes.
Use the supplied Allen Wrench to insert four M6x10
Machine Screws (10) through the holes on the Frame
(5) going into the Leg (3). Rotate each screw just a
few turns until all four are inserted, then tighten them.
Repeat the process for the other Leg and Frame.
STEP 4
Slide the Center Rails (6) into the 120° Frames (7,8) and
attach them into position using sixteen of the M6x10
Machine Screws (10).
STEP 5
Attach each Foot (1) to each Leg (2) with four M6x14
Machine Screws (9) and tighten them.

06Assembly
STEP 6
Place the assembled three-leg frame onto the
underside of your tabletop. Adjust the width of the frame
to fit your tabletop by sliding the two halves apart.
We recommend leaving at least 1.25" of the tabletop
extending beyond the assembled frame. Make sure
to center the Side Brackets (3).
STEP 7
If your tabletop has pre-drilled holes, skip ahead to Step
8. If not, lock the position of the Center Rails using eight
of the M6x10 Machine Screws (10). Make sure the
screws make contact with the Center Rails (6) by sliding
them as needed.
STEP 8
Ensure that the wood screws are not too long for
your tabletop.
If possible, pre-drill pilot holes to ease the installation
process. Attach the frame to the tabletop using four of
the M6x16 Wood Screws (12).
Attach the hand remote so the front of the remote is
lined up with the tabletop edge. Place the remote
anywhere along the edge so that you'll have easy
access to it. Use two of the M6x20 Wood Screws (13) to
attach and secure the remote to the tabletop. Do not
over-tighten the screws as this could cause damage to
the components.
STEP 9
Connect the cable from each Leg (1) directly into the
control box. Use cable extenders when necessary.
Then connect the hand remote cable to the control box.
Use the adhesive-backed cable clips to secure the
cables so they are not loose and in the way.
STEP 10
We recommend having two people for this step. Flip
the fully assembled desk by the legs (not by the
tabletop).
IMPORTANT
Prior to normal operation, please complete a Reset
Procedure outlined in the next section.

WARNING: During the Reset Procedure, the table lift will retract 7mm below the lowest normal operating height,
please ensure that no obstacles impede this motion of travel.
1. Move the table lift to the lowest position. (If there is an 'RSt' displayed on the remote, continue
to step 3.)
2. To initiate the Reset Procedure, press and hold the down button on the remote until "ASr" is
displayed. Release the down button.
3. Press and hold the down button on the remote, the table lift will begin to retract 7mm lower
than the lowest normal operating height. To stop motion at any time, let go of the down button.
4. Once the table lift has completed the Reset Procedure, height will be displayed on the remote.
Normal Operation
Using the wired remote, press and hold the 'Up' button to raise the table lift. To lower the table lift, press and hold
the 'Down' button. The 'Up' and 'Down' buttons are momentary controlled, when they are released, the table lift will
stop immediately.
To set a preset location, move the table lift to the desired height. Press the 'M' button followed by a numbered
button. The LED display will flash an 'S', followed by an 'S - Number'. This will indicate that the preset has been saved.
To use a preset, press any of the numbered buttons and the table lift will begin to move to the preset position. It is
important to ensure that no obstacles impede the motion of travel. To stop the table lift, press any button.
If the table lift does not function as intended or the LED display flashes "RSt", please follow the Reset Procedure
outlined in the next section.
07Operation
Using the wired smart remote, retract the table lift to the lowest position. Press and
hold the 'Down' button again until the LED display flashes "RST".
Press and hold the 'M' button until the LED display flashes the starting height (if
the display returns to "RSt" before the next step, repeat this step).
To change the value of the starting height, use the 'Up', 'Down' to increase and
decrease by 0.1. Use the '1', '2' to increase and decrease by 1s. Use the '3', and '4'
buttons to increase or decrease by 10s.
Once the correct value is displayed, wait 5 seconds until the LED display flashes
"RSt". Follow the Reset Procedure outlined in the next section to save the new
starting height.
Note: the LED display has a tolerance of ±0.1.
Setting the LED Display
Reset Procedure

08Troubleshooting
Problem Possible Cause Corrective Action
Low power mode
activated Press any button on the remote and LED will activate.
Connection issue Disconnect and reconnect the RJ-45 remote connector. Ensure connection is
secure and cable is not damaged.
Limit switch reached Follow "Setting Limit Switches" instructions to remove the programmed limit. If maximum or minimum height limit has been reached, please move the system
in the opposite direction.
Connection issue Disconnect and reconnect the Lifting Columns, Control Box, AC Power, and
Remote.
Table lift travels at a
significantly slower
speed than rated
specification.
Weight issue Ensure weight capacity has not exceeded the maximum load rating.
Unusual noise during
travel. Weight issue Ensure weight capacity has not exceeded the maximum load rating.
Table lift stops abruptly
during travel. Obstacle Ensure there are no obstacles in the path of the table lift. If the movement continues to fail, initiate the Reset Procedure.
Table lift is not level. Out of sync Disconnect and reconnect all cables (Lifting Column, Control Box, AC Power,
and Remote), then initiate the Reset Procedure.
Troubleshooting Guide
Remote LED is off.
Table lift does not
move when motion
control buttons are
pressed.
Error Code Error Summary Description
E01 M1 overcurrent protection
E02 M2 overcurrent protection
E03 M3 overcurrent protection
E04 M4 overcurrent protection
E07 M1 hall error
E08 M2 hall error
E09 M3 hall error
E10 M4 hall error
H01 Over heat /duty cycle
protection
All columns stop moving, remote displays H01 (if LED screen available). Allow
the system to rest for 16 minutes, use normally. Follow the Duty Cycle rating to
ensure no issues arise from overheating.
Error Codes (remotes with LED display)
All columns stop moving and remote displays E01-E04. Ensure that the total
weight capacity of the table lift has not been exceeded and that no obstacles
obstruct the movement. Press any key and remote will display
RST, initiate the Reset Procedure. If the issue persists, disconnect and
reconnect all of the lifting columns, including the main power. Repeat the Reset
Procedure.
All columns stop moving and remote displays E07-E10. Ensure that all columns
are still properly connected to the control box. Check to see if any cables have
been damaged. Press any key and remote will display RST, initiate the Reset
Procedure. If the issue persists, disconnect and reconnect all of the lifting
columns, including the main power. Repeat the Reset Procedure.
