progressive automations FLT-03-2-2 User manual

FLT-03-2-2
User Manual
Page 2
Page 4
Page 5
Page 6
Caution/Liability
Technical Specifications
Parts
Operational/Reset Procedure,
Troubleshooting
Dimensions
Contents
Page 3

Caution
Liability
2

Technical Specifications
3
Duty Cycle 10% Max. 2 mins on, 18 mins off
Height Range 22” - 38”
Weight Capacity 880 lbs (440lbs Per Columns)
Features Soft start/stop, adjustable leveling studs & 4 memory presets
Input Voltage 120 VAC, 60 Hz
Output Voltage 24 VDC
Stroke 16"
Speed 0.5"/sec
Material Steel
Certification UL

Parts
4
Lifting Columns x 2 Control Box and Remote
AC Power Cord
FLT-03-2-2
CONTROL BOX
F
HS
M2AC
M1
110/240VAC
WIRED REMOTE
FLT-03-2-2
LIFTING COLUMN [M1]
FLT-03-2-2
LIFTING COLUMN [M2]
Setup

5
Reset Procedure
Operational Procedure
Once the table lift is installed, use the wired remote for full up and down motion control. The
momentary buttons require the user to press and hold the button for both up and down control. Once
the button is released, the FLT-03-2-2 will stop moving.
You can program up to 4 locations using the memory setup: Use the up/down buttons on the remote
to find your desired height(s), then press “M” followed by a number 1-4. The column height positions
are now saved. To move to the set position, hold the number button.
IMPORTANT
You must reset the columns prior to use:
To reset, press and hold the DOWN button on the Hand Remote (7) until the columns reach their
lowest point. Release the DOWN button. Press and hold the DOWN button again until the LED display
shows "RST". If you are not using an LED hand remote hold it for about 10 seconds. Release the
DOWN button. Finally, press and hold the DOWN button once more until the columns lower, slightly
rises then stops. This signals the end of the reset procedure. Release the DOWN button and your
lifting columns are now ready to use.
Troubleshooting
If your columns are not functioning, they may need to be reset. Follow the RESET procedure.
If your hand remote has an LED display and it displays "RST" (reset), perform the reset procedure.
If the LED displays shows an error message ("Er1" - "Er13"), confirm that all wired connections are
secure. Then perform the reset procedure.
If the LED remote displays "HOT", let the unit cool down for 20 minutes.
If the error message persists after the reset procedure, contact us at 1-800-676-6123 or
[email protected].

Dimensions
6
3.8"
3.3"
4.4"
6.7"
Ø0.5"
Ø0.2"
2.5"
2.5"
23.0"
0.5"
0.5"
7.9"
4.4"
1.4"
3.2"
1.6"
7.9"
4.4"
1.9"
0.8"
3.9"
1.6"
0.3"
0.3"
Legs
Remote
M
34
2
1
˄˅
5.7"
3.3"
2.0"
3.4"
2.2"
1.4" 0.2"
Control Box
AC
F HS M2
10.1"
0.1"
0.3"
3.5"
1.6"
3.5"
0.7"
AC
M2
F
HS
M1
M1
