Purkeys BOSS-01 User manual

BOSS-01
DIAGNOSTIC GUIDE
300-25 Doc 1.00

1
P: 479.419.4800 | F: 479.419.4801 | www.purkeys.net
CONTENTS
General Information ..........................................................................................2
System Diagram..................................................................................................3
Battery Not Being Charged ...............................................................................4
Battery Indicator In Operation.........................................................................7
Indicator LED Logic...........................................................................................8
Limited Commercial Warranty Policy.............................................................9

2
GENERAL INFORMATION
e BOSS™ Dump Trailer Charging System utilizes a DC/DC converter to
boost the voltage and optimally charge the dump trailer battery.
e BOSS has an easy to interpret LED indicator that clearly shows the
battery status.
e Boss:
• Can be used with Flooded and AGM batteries
• Can be used with two batteries
We recommend using a battery with a higher RC capacity and lower CCA.

3
P: 479.419.4800 | F: 479.419.4801 | www.purkeys.net
BOSS-01 DIAGNOSTIC GUIDE
SYSTEM DIAGRAM
Boss-01 Consists of:
• MOD00082 (Boss Dump Trailer Battery Indicator)
• H-00363 (Boss Dump Trailer DC/DC Converter with Harness)
• 11010C11 (DC/DC 10AMP Trail Charger)
• H-00379 (Boss Dump Trail Charger Harness
• INST072 (Boss Installation Guide)
• L-086 (Boss w/Serial #Cut Out Decal)
From 7-way
Truck Plug
