Projectiondesign F82 series User manual

Black------
Grey------
White------
Silver-------
Black------
Grey------
White------
Silver-------
Black------
Grey------
White------
Silver-------
Black------
Grey------
White------
Silver-------
www.projectiondesign.com
professional projector series
F82 series
WUXGA,1080p or SXGA+ resolution
3-chip DLP® technology
up to 10 000 ANSI lumens
Advanced Color Optical Processing

Black------
Grey------
White------
Silver-------
Black------
Grey------
White------
Silver-------
Black------
Grey------
White------
Silver-------
Black------
Grey------
White------
Silver-------
F82 series
The projectiondesign F82 series of three-chip DLP® projectors is
our top professional model, and is made for large screen imaging
and the ultimate image quality for demanding users.
Markets and applications
With its brightness and numerous configuration, performance and warranty options, the F82 series is made
for users with extra high requirements and expectations. It fills large screens in auditoriums, on stages or other
applications that require high brightness and the ultimate in image quality and reliability.
www.projectiondesign.com
Key features
• RealColor™ colour management provides completely unique colour management accuracy
• Full 24/7 warranty covers nearly any operating environment and installation requirement
• DynamicBlack™ gives totally unique dynamic range for a three-chip projector
• ACOP optical colour processing enables user selectable color management without loss of bit depth
• 3-chip DLP® technology provides outstanding colours and dynamics
• Comprehensive lens range designed for high resolution
• Choice of WUXGA,1080p or SXGA+ resolution options
The projectiondesign professional series of projectors
include high resolution, high performance products
designed and made specifically for graphically
challenging appllications such as scientific
visualisation, training and simulation, media and
entertainment in public displays, and other similar
applications.
Our utmost concern is customer satisfaction through
image quality and operational reliability. All professional
series projectors come with a 24/7 operation warranty,
and a wide range of configuration options to ensure the
best possible application fit.
series
professional
projector

www.projectiondesign.com
DLP technology
– chosen for reliability
The DLP technology from Texas Instruments® is
chosen for its unmatched reliability, and its unique
coupling with long lasting image quality. With a
widely recognised and proven reliability record and
high brightness and contrast, all whilst displaying
utterly natural colours, it is the obvious choice for
heavy duty applications that run continuously, or are
mission critical. Independent testing has proven DLP
technology to be the most reliable of all microdisplays;
not degrading when subjected to UV light, inherent in
all projectors. Unlike competing technologies, showing
severe image quality degradation after only a few
thousand hours, DLP technology remains constant
over hundreds of thousands of hours.
overview
3-chip DLP®
3-chip DLP technology is renowned for producing
formidable on-screen images, as it uses three DMD®
(Digital Micromirrod Device) imagers for strongly saturated
and accurate colours. With lots of brightness from
the 3-chip engine’s high efciency, and many options
for adjusting colour and brightness performance, the
F82 series can be tailored to suit a a vast number of
applications, focusing on large screen video centric
displays and events.
WUXGA, 1080p or SXGA+
resolution
The projectiondesign F82 can be configured with either
WUXGA, 1080p or SXGA+ resolution for computer or
video centric applications. In large auditoriums and with
large screens, where computer imaging with maximum
level of detail is a primary requirement, 1920x1200 pixels
(WUXGA) is the obvious choice and fully compatible with
the legacy 1600x1200 format. Furthermore, for video
centric applications, the 1920x1080 (Full HD 1080p)
pixel resolution perfectly ts high dention video and
data. For editing and video centric applications where
a menu line, or additional information is needed on
screen simultaneously with the unaltered 1080p video
image, WUXGA resolution gives just that. FInally, SXGA+
resolution at 1400 x 1050 pixels is perfect for multi tiled
projection applications in domes or with curved screens,
with minimum amount of overlap and wasted pixels.

California Academy of Sciences, California, USA.
The California Academy of Sciences in San Fransisco, USA, uses more than 30 projectiondesign projectors in various configurations
Precision projection lenses
The F82 series features a wide range of custom designed, precision
projection lenses for the best image quality, and the most reliable setups.
Key features include innitely adjustable IRIS and aperture settings,
and motorized zoom, focus and lens shift with profile memories for
use in multiple settings and installations with programmed calibration
and screen congurations. Most importantly, every single lens uses
Low Dispersion (LD) glass and aspherical lens elements for high quality
focusing and sharpness, as well as high optical interfield contrast,
resulting in very high image quality. Unlike many competing projector
ranges, the lenses are designed and made with high resolution in mind,
not taking standard, off the shelf lenses for use in higher performance
applications. The range of lenses span from an an ultra wide angle
0.74 : 1, to a long tele zoom at 6.24 : 1, and comprises ve options.
Advanced Color Optical Processing
The F82 series projectors feature new and revolutionary projectiondesign
A wide range of lenses, from ultra wide 0.74 : 1 to 6.24 : 1 gives unique flexibility in
installations and placement of product
optics and applications

RealColor™ colour calibration
Each F82 projector is uniquely characterised and calibrated during manufacture. Unique optical performance values are
recorded and matched to the electronic image processing to secure perfect on-site calibration. With RealColor, it is possible
to match any number of projectors, and ensure they all project the same primaries and grey scale, without going through a
very complicated process. Using our ProNet 2.0 software automates this process.
What RealColor gives
RealColor provides a unique and quick way to calibrate and set up perfect images for any number of projectors. RealColor
can alter imagery by changing simple characteristics such as the colour temperature of the image – perfectly along the
black body curve, or very complex details such as each colour’s relative saturation and x,y coordiantes. RealColor works by
mathematically calculating each colour independently, in fact, it is perfect to within 0.002 along all axes of measurement.
optical color processing technology. By combining xed and motorised optical
filters for each colour channel, red, green, and blue, the projector can be
optically calibrated with near innite accuracy. It also means that by the ick of
a switch, you can change the projected colour gamut from standard computer
graphics optimised, to comply with for instance REC709 (High Denition
programming) All this without any loss of bit depth, as the compensation is
purely optical, and not electronic. Unlike competing projectors, where colour
calibration is based upon a simple yellow notch filter to change the green point
of the picture, or simply by changing electronic values, ACOP gives vastly
superior performance on all important levels.
0.9
0.8
0.5
0.3
0.2
0.1
0.6
0.7
0.90.80.50.40.30.20.1 0.6 0.7
0.4
colour management and performance
24
7
24
ACOP
2560
1600
Colour matching
Like all other projectiondesign professional projectors, the F82 series features numerous possibilities and alternatives for matching of several projectors, so that they all appear
and perform similarly. Actual colour matching is realised through several process steps, including that of hand selecting units that are optically similar. Additionally, colour matching
is realised using extensive features of the RealColor colour management suite, so that every single projector performs absolutely similarly. ProNet 2.0 calibration software suite
automates this process.
www.projectiondesign.com
DynamicBlack™ for outstanding dynamics
The F82 series features unmatched imaging dynamics amongst large venue
projectors. The unique DynamicBlack functionality automatically adapts to
the input histogram of the image, and adjusts so that image output contrast
is maximised at any one point in time. This creates much more dynamic
imaging, and a more involving experience. If DynamicBlack functionality
is not desired, the user can manually adjust IRIS and settings to match
a constant, desired output level, with constrast up to 15 000 : 1, and
brightness levels to match that of the desired screen size requirement.
DynamicBlack automatically adjusts output to the input signal, and maximises available contrast in the image.
The result is unmatched dynamic performance
24
7
24
ACOP
2560
1600
revolutionary
colour
performance

Original lamp with projectiondesign optimised fixture mechanics
Low Total Cost of Ownership
Thanks to its complex and robust build and
construction, the F82 series requires very little
maintenance and in-life maintenance. There are no
user serviceable parts, and it does not have any
filters or other parts that need periodical replacement.
That means it does not require a costly and high
frequency maintenance contract. At the same time,
and compared to similarly performing xenon high
power lamps, lamp replacement cost is low*, and
typical lamp life is long. In total, a very cost effective
projector over time, resulting in low and predictable,
cost of ownership.
* When replacing lamps, it is advised to use only original
parts and accessories, as non original aftermarket lamps
may reduce performance, damage the projector, and void
warranties.
Low Frequency Maintenace programme
Our Low Frequency Maintenance programme can be set to automatically notify of required services and maintenace.
When run continuously, moving parts such as fans and colour wheels require periodic replacement in order to secure
and enable heavy duty and uninterrupted operation. With the F82, the shortest duty cycle of any one component – run in
full power mode, is as long as 8000 hours, meaning a full year’s operation in 24/7 without maintenance. Add to that hot
swappable lamps, and you have a projector that simply does not need to be turned off, running either in automatic lamp
relay mode, or even with two lamps at any power setting around the clock.
Designed for full 24/7 operation
All projectiondesign professional projectors feature full
24/7 operation warranties. That means they are designed
to operate continuously. There is no fine print. Designing
for 24/7 operation requires a lot of attention to detail.
Some technologies are better than others when it comes
to withstand the abuse of time. We use only components
that have predictable behaviours, for instance fans,
colour wheel motors, and electronic components that
are designed by their respective manufacturers to do
the same - withstand time. There are no off-the-shelf
components. That is why we also closely monitor
the creation of every detail, apply dedicated thermal
management, and use specific materials in all parts of the
process.
applications and features
Black------
Grey------
White------
Silver-------
Black------
Grey------
White------
Silver-------
Black------
Grey------
White------
Silver-------
Black------
Grey------
White------
Silver-------
Changing lamps is easily done from the side of the projector
24
7
24
ACOP
2560
1600

www.projectiondesign.com
projectiondesign in-house EMC lab
In-house acoustics lab
Every single F82 projector is rigorously tested, and
characterised in-house. We keep test records and
performance statistics for every single unit. Also, as we put
our pride into making great projectors, they are not passed
down an automated production line, but enjoy the careful
management of people at all stages of their manufacture.
That also means we are personally responsible for all of
them. In addition, every single projector is made to specic
order. The configuration ordered is the configuration built,
and only existing in that particular installation.
immaculate
process
management
In house development and
process management
Every single part of the F82 series projectors is
developed, rigorously tested, and veried in-house
at projectiondesign. With more than 800 models and
variations of projectors in regular manufacture, test,
research and verication facilities include everything from
acoustical analysis labs, to a full featured FCC certied
EMC lab, environmental labs for lifetime and operational
testing, such as temperature variations and testing of
vibration resistance, as well as our own optics lab and
various test and demo facilities.
www.projectiondesign.com
RoHS compliant PCB assembly line
F82 series undergoing vibration testing
projectiondesign warehouse is completely automatic

Extensive input compatibility
Two discrete digital inputs, HDMI and DVI-D enables simple and source switching setups in smaller installations. Both inputs feature HDCP - High bandwidth Digital Content
Protection. The F82 also features legacy formats such as RGBHV over VGA, and a 5-BNC input, in addtion to standard video formats. Importantly, the F82 features a
projectiondesign unique interface, XPort™, for connection to third party modules, as well as standard modules provided by projectiondesign. An HD-SDI module is available from
projectiondesign.
ProNet 2.0 asset management and calibration
Adding to the serviceability and in-life monitoring features, projectiondesign ProNet 2.0 asset management suite can be set up to monitor and report on an unlimted number of
projectors in a dedicated or corporate network, in a single site, or in multiple sites. ProNet 2.0 monitors every single aspect of the projector, from individual lamp and fan status, to
operating hours, use statistics, and any other related information. ProNet 2.0 offers ProNet.calibrator which extends features to simplify and automate colour matching and projector
calibration.
ProNet.enterprise
ProNet.site 1
ProNet.site n
ProNet.site 2
ftp
service
www.projectiondesign.com
fundamentals

www.projectiondesign.com
fundamentals

Black------
Grey------
White------
Silver-------
Black------
Grey------
White------
Silver-------
Black------
Grey------
White------
Silver-------
Black------
Grey------
White------
Silver-------
techncal specifications
Technical specifications
projector DLP® digital projector
display technology 3-chip DMD™ (Digital Micromirror Device™) connectivity computer 1x HDMI (1.3)
concept sealed, all-glass optical design with lens shift 1x DVI-D
available resolutions 1920 x 1200 1920 x 1080 1400 x 1050 1x 15-pin DSUB
brightness centre lumens 10000 10000 10000 1x BNC x5
REC709 7000 7000 7000 video 1x HDMI (v1.3) (HDCP)
1x DVI-D (HDCP)
contrast ratio up to 15 000 : 1 (on/off) (automatically adaptive) 1x RCA x3 YUV
colours 30-bit 1x 4-pin mini DIN Y/C
colour management accuracy ± 0.002 on x, y, z axes 1x RCA composite video
image processing latency ~ 22 ms on graphics port control and communication 1x RJ45 TCP/IP network port
input signal compatibility computer up to 1920 x 1200 pixels 2x RS232 9-pin DSUB (in / out)
RGBHV, RGBS, RGsB 1x USB – mouse control & firmware upgrade
horizontal scan frequency 15 - 150 kHz 2x 12V (60mA) triggers (screen drop / aspect)
vertical scan frequency 48 - 190 Hz 1x RC repeater, 3.5mm mini jack
video HDTV (1080i, 720p, 576i/p, 480i/p) other 2x configurable XPort™ (front- / back end)
NTSC 3.56/4.43, PAL BGHI, M, N, SECAM supplied accessories cables 4m power cord (country dependant)
bandwidth 205 MHz analog RGB other backlit IR remote control
165 MHz digital RGB (DVI or HDMI) product documentation
optics available lenses fixed focal ultra wide angle EN22 (503-0172-00) general dimensions (dwh) 505 x 604 x 250 mm (ex. lens)
fixed focal wide angle EN23 (503-0173-00) weight about 24 kg (net, ex. lens)
standard zoom EN21 (503-0136-00) about 38 kg (shipping)
short tele zoom EN24 (503-0174-00) environmental RoHS, WEEE
short tele zoom EN26 (503-0176-00) security 4-digit PIN code, Kensington lock
focusing distance 0.7 - 20m power requirements 12.5A or 6.5A, 100-120V or 200-240V, 50-60Hz
optical lens shift vertical and horizontal <1050W power consumption
EN22 on axis only BTU/hr <2900
lens iris control F/2.1 – 6.5 for all lenses, continuously adjustable conformances CE, CSA cUL, FCC Class A, CCC
DynamicBlack™user adjustable operating temperature 10 – 40ºC / 32 – 104ºF, 0 – 1500 m
shutter mechanical 0 – 35ºC / 32 – 95ºF, 1500 – 3000 m
ACOP colour filters standard RGB operating and storage 20 – 90% RH
motorised REC 709 available colours soft touch rubber black matte
warranties standard 2 years, full 24/7 operation
lamp 2 x 330W UHP™ 500 hours or 90 days on lamp
lamp life 2000 hrs (max typical) (5000 hrs in eco relay mode) up to 5 years total extended warranty available.
replacement lamp part no. 400-0700-00 conditions apply.

technical specifications
Black------
Grey------
White------
Silver-------
Black------
Grey------
White------
Silver-------
Black------
Grey------
White------
Silver-------
Black------
Grey------
White------
Silver-------
www.projectiondesign.com
Model Part Number
F82 1080 101-1610-08
F82 wuxga 101-1611-08
F82 sx+ 101-1623-08
Available versions
The F82 can be rotated 360 degrees around the side to side axis, and for instance project
straight down or up, as well as +25/-15 degrees side to side.
Rotation
360°
+15°
-25°
Standard bolt-on ceiling mount interface
0.4
158.2
167
164
83.5
4
LENS RELEASE
PUSH AND HOLD
Flexible vertical and horisontal lens shift
355 249
135
115
250
Multiple lens options and very wide lens shift adjustment ranges allow
for flexibility in installations.
Wide range of projection lenses
WUXGA: 118 %
1080: 131 %
SXGA+: 110%
WUXGA: 84 %
1080: 85 %
SXGA+: 89%
WUXGA: 84 %
1080: 85 %
SXGA+: 89%
EN 22 Ultra wide angle 0.74 : 1 xed focal (on axis only)
0.5 – 2.5 m
EN 23 Wide angle zoom 1.2 - 1.7 : 1
1.0 – 15 m
EN 21 Standard zoom 1.70 – 2.55 : 1
1.0 – 15 m
EN 24 Short tele zoom 2.50 – 4.00 : 1
2.0 – 15 m
EN 26 Tele zoom 3.90 – 6.24 : 1
2.0 – 30 m
