Proluxe Apex x1 User manual

Operations Manual

Apex X1 - Air-driven Automatic Dough Press

Model #: DP1300



WWW.PROLUXE.COM

Version: 52619

Congratulations on your selection of

the Apex X1 Automatic Dough

Press. Proluxe is a leading

manufacturer of food preparation

and cooking equipment designed for

the most demanding commercial

kitchens. Proluxe equipment is a

result of the highest quality

engineering and time-tested design.



This manual includes installation,

operation, and maintenance

procedures for your new Apex X1

Dough Press. Please read this

manual carefully and keep it with

your machine for proper operation

and lasting service.



I N S T A L L A T I O N



Domestic

Use a separate 15 amp AC circuit. Only

industrial extension cords with proper wire

size should be used; size 16/3 wire for

distance up to 25 feet, and size 14/3 for

distance up to 50 feet.



International

Use a designated 16 amp AC circuit. Only

industrial extension cords with proper wire

size (2.5 sq. mm) shall be used. Make sure

there is a proper electrical wall outlet located

within reach of the cord and plug attached to

the press.



Then place the press in an area which allows

for “swing clearance” of the lower platen plus

vertical and horizontal clearance of the press

itself.



Limited Machine Warranty

Proluxe warrants this dough press machine,

when operated under normal conditions, to

be free from manufacturing defects in

material and workmanship for a period of

one year on parts and labor from the invoice

date.



This warranty will be effective only when

Proluxe authorizes the original purchaser to

return the product to the factory in Perris,

California freight prepaid and only when the

product, upon examination, has proven to be

defective. This warranty does not apply to

any machine that has been subjected to

misuse, negligence or accident. Proluxe shall

not be liable for the injury, loss or damage,

direct or consequential, arising out of the use

or the inability to use the product. No claim

of any kind shall be greater in amount than

the sale price of the product or part to which

claim is made.



This is the sole warranty given by the

company, it is in lieu of any other warranties,

expressed or implied, in law or in fact,

including the warranties of merchantability

and fitness for a particular use, and is

accepted such by the purchaser in taking

delivery of this product.



S P E C I F I C A T I O N S



Electrical:

120V/50-60Hz/1450W/12.5Amps/AC



Also available; specify when ordering:

1

●Voltage: 120/208/240

●Amps: 12.5/11.05/5.94

●Watts: 1500/2300/1500

Includes: 72” cord and NEMA approved plug.



Air Compressor Requirements:

U.S. 5 SCFM (Standard Cubic FT/MIN) EUR.

8.5 SCMH (Standard Cubic Meters/HR)



Shipping Weight:

200lbs. (91kg.) – DP1300

280 lbs. (127 kgs.) – DP1300C



I N T E R N A T I O N A L S Y M B O L S



Power Off



Power On



Hot Surface



Risk of Electrical Shock



Protective Earth Terminal



Caution - Warning



S A F E T Y S U M M A R Y



Warning

To reduce the risk of electrical shock, do not

remove or open cover. No user-serviceable

parts inside. Refer servicing to qualified

personnel.



Avertissement

Pour réduire le risque de choc électrique, ne pas

retirer ou couvercle ouvert Aucune pièce

réparable par l’utillsateur, reportez-vous à du

personnel qualifié.



Warning

In case of power cord damage, do not

attempt to repair or replace the power cord.

Please contact the manufacturer or the local

distributor.



Warning

For continued protection against fire and

electric shock, replace with the same type

and rating fuse. Listed Supplemental Fuse

rated max 3A, 120Vac.



Avertissement

Pour une protection continue contre l’incendie

et de choc électrique, remplacer avec le même

type et calibre du fusible. Mis fusible

supplémentaire nominale max 3A, 120 Vac.



2



Caution Hot

Avoid touching hot surfaces while operating

the machine.



Caution

When servicing or cleaning the machine,

make sure that the power cord is removed

from the wall socket.



During normal operation, the base of the

machine must be installed or placed above

the wall socket.



O P E R A T I O N T E M P E R A T U R E

& T I M E R C O N T R O L



FIG. A



Solid State Controller

This controller has three (3) control features:

1. Temperature – May be set from

100°-425°F (38°-163°C)



2. Time – Time may be set from 1 second to

10 minutes.



3. Counter – Cycle counter counts the

number of applications from 1 to 9999 (see

additional Notes – Counter).



4. “2 Lower” (Fig. A) Refers to models using

upper and lower heated surfaces.



Controller Operation

1. Viewing the Modes of Operation:

To view the set points of temperature, timer

and counter, press MODE button to view the

desired mode of operation.



2. Changing Temperature:

Press MODE button until temperature is

displayed.



Press and hold SET button while pressing the

UP (↑) and DOWN (↓) arrow buttons to

desired temperature setting.



3. Changing Time:

Press MODE button until time is displayed.

Press and hold SET button while pressing the

UP (↑) and DOWN (↓) arrow buttons to

desired timer setting.



4. Resetting the Counter:

Press MODE button until the

counter is displayed.



To reset the counter (# of cycles),

simultaneously push UP (↑) or DOWN (↓)

arrow buttons (approx. 5 seconds).



Pressing Dough:

For best results, your dough should be

proofed before pressing, but it will also press

directly out of your refrigerator. Flour is not

3

required to press a crust and should not be

dusted on any part of the machine.



2. Press the On/Off button.



Note:



Initial temperature setting of 150°F has

been shown to be acceptable for most dough

formulations; however, you may have to

determine the best temperature for your own

dough by trial and error testing of your product

at different temperature settings.



3. Set the timer in accordance with the

following information:



2-4 seconds –For warm dough with

moderate yeast content.



2-6 seconds – For room temperature dough

with moderate yeast content.



6-8 seconds – For cold dough right out of the

refrigerator with low yeast content.



*Remember that the timer does not actuate

until the upper platen mates with the lower

platen and resistance is felt.



4. Set the thickness control lever to “thick” or

“thin” or anywhere in between these settings

as your product requires.



Note:



Diameter and thickness is determined

through experimenting with your own dough

and is a product of dough weight, temperature,

pressing time, and thickness setting.



5. Swing open the lower platen and

apply a quick spray of a good

water based food release on the lower

platen. Proluxe offers its own food release

spray NATURALLY CLEAR Model No.

DPPC1. (See our catalog and price list for

information.) This spray will not affect

the taste of your crust in any way.



6. Place your pre-portioned ball of dough in

the approximate center of the lower platen.

Add another dash of spray to the top of the

dough ball.



7. Close the platen and, with both hands,

press the two green buttons on each side of

the machine simultaneously.



8. Hold the buttons until resistance is felt

then release at once. The timer will actuate

and, when the time cycle is completed, the

upper platen will rise automatically (timer is

preset at the factory for six seconds, but this

is easily changed by following the upcoming

instructions.)



9. Remove the crust, place on a pan or peel,

add toppings and bake.



Warning: Incoming air to machine shall not

exceed 90psi as this will damage internal

parts and void the machine warranty.



R E C O M M E N D E D S E A S O N I N G

& C L E A N I N G P R O C E D U R E S



Before use you must properly season

your platens to prevent your dough from

sticking.



Tools Required:

●Food release

●Soapy water solution

4

●Washcloth

●Paper towels



DO NOT use steel wool or harsh abrasives, it

will you will cause costly damage.



1. Before cleaning make sure the

unit is turned off.



2. Spray lower platen with approved

food release/oil spray.



3. Wipe oil across lower platen with

paper towel.



4. Wipe oil across upper platen.



5. Mix a warm dish soap and water

solution.



6. Soak washcloth and wring to

remove excess water.



7. Wipe lower and upper platen with

damp cloth.



P R E V E N T A T I V E 

M A I N T E N A N C E 



Proluxe machines are relatively maintenance

free. For a long lifespan, the following

preventative maintenance should be

followed:



Daily Care:

1. Platens: Turn your machine off and allow

to cool down before attempting to clean.

These platens should only be cleaned with

mild soap and warm water then wiped off

with a clean, soft cloth or soft sponge.



2. Exterior surfaces: Wipe daily with mild

soap and warm water will do the job quite

nicely.



Service Problems:

Contact our factory at (800) 624-6717 (U.S.

only) or approved service agency. When

contacting the factory for information, parts

or service instructions, please provide the

serial number of the machine be provided.

This number can be found on the serial plate

located on the rear of the machine.



Apex X1 Troubleshoot Guide - Model #: DP1300



Problem

Cause

Action

Ref #

5

Power Button on

Digital Controller

face is depressed but

doesn’t turn on.

1. Power cord is not plugged in.



2. Circuit breaker is tripped off in the

site's breaker box.



3. Transformer has taken an

electrical surge and is damaged.



4. Check voltage on the secondary

side of the Transformer. If you read

12VDC then you are receiving

voltage to the controller.



5. Possible blown fuse.



1. Plug the power cord into wall

receptacle and power button.



2. Reset circuit breaker that the

grill is plugged into. Depress

Power Button to turn on.



3. Replace Transformer after you

check secondary side of

transformer. If working properly,

you should receive 12vdc.



4. Replace controller. Controller

should be on once the power

button is depressed.



5. Replace fuse.



68



-----



91



85



105

Digital Controller's

LED's are scrambled

or randomly erratic.

If when turning on,

the display will first

go to segment check

1. Possibly a component on the

Digital controller is damaged.



2. Control needs to reset.

Replace digital controller.



While unit is on unplug unit, wait

for 1 min. Then plug machine on

again and depress power button.



-----



85

Digital Controller on

startup goes through

LED segment check

(8888) then to

version # and then

loops back to to the

above reboot.

The relay driver on the digital control

may be blown.

Replace digital controller.

85

Digital display shows

PROB. No heat on

Upper Platen.



Sensor lost it's continuity as shown

on a muti-meter.

Disconnect prob that is open (no

continuity as shown on a multi-

meter. Must replace sensor

(RTD). Do not cut and splice new

sensor. Install new 2000 ohm

RTD sensor to under side of heat

platen and reconnect to the

controller.



41

When depressing the

tactile button

on digital controller,

nothing happens.



The tactile buttons under the overlay

may be not close enough to activate.

Same goes if the buttons are already

pressed by overlay without

depressing button.



Carefully (no too much at one

time

to avoid fracturing the traces on

the controller) tighten the nuts on

the back of the controller until

button activate. Same goes in

reverse if buttons are held down



6

by the overlay.



Digital display shows

relay and particular

zone is overheating.



1. The relay on the switched side is

not opening to regulate temperature.



1. Replace the relay.

92

Beeper not

functioning or

intermittent beeper

sound.

1. Beeper on digital control board

failed.

1. Replace digital controller

board

76

If setpoint is reached

but slightly off in

temperature.

Offset may need to be calibrated and

adjusted.

Call (800) 624-6717 ext. 129 for

instructions.



Heater platen

overheating

If the relay (depending on the year of

the model) on the coil side are

receiving 12vdc indicates the

Controller is functioning properly.

On

the switching side of the relay, is

there 120 vac going to the heater in

question. If there is no voltage on

the to the switching side of the relay

to the heaters, the relay is not

working properly.



Replace relay If the controller's

heat-on LED is not lit indicating

the controller is working

properly.



92

Thickness crank on

top of press

turns endless



Set screws on crank may be loose.

Make sure the shaft is on thin

setting by turning counter

clockwise then tightening the

stacked allen screws (2 set

screws on top of each other) with

allen wrench.



A5

Dough not having

same thickness

across the press

dough.



Adjust upper platen for level press

Underneath the housing there is

4 stacked hex bolts sitting over

the upper platen attached to the

arm. The top bolts are called

locking bolts. The 4 larger hex

bolts below are adjustment bolts.

Break free the 4 locking bolts.

With an open end wrench adjust

the bolts (1/8 turn at a time).

After testing, tighten the locking

bolts making sure not to move

the larger adjustment bolts

11



And



12

Power is on but hear

a leaking of air

The O'rings are warn allowing the air

to pass through the cylinder

The cylinder needs orings, gasket

and new cylinder grease. Request

-----

7

under the lower

platen / Swing Arm

while Press is idle.



instruction sheet and need to

order

P/N 110033 for the kit.



Press does not close

when pressing

the two, green, start

buttons

1. Did not simultaneously press the

start buttons exactly at the same

time.



2. The Lower Platen switch mounted

on the base is not in contact to

complete circuit.



1. Try pressing both buttons

exactly at the same time. This is a

anti-tie-down safety feature.



2. Make sure the roller plunger

comes into contact (clicking

noise). This is also a safety feature

that both platens are aligned

before



2

After activation

lower platen and

when the cycle is

complete, the lower

Platen either is very

slow coming down or

doesn’t come down

at all.



The mMufflers on the solenoid valve

are dirty and now allowing air from

passing though.

Replace both solenoid valve

mufflers.



Upon activation, the

lower platen is slow

to come up and

down.

Filter encased in a black housing in

the back of the machine is

dirty.

Replace filter.



8



9



10

Apex X1 Part List - Model #: DP1300



ITEM

#

DESCRIPTION

DP1300A

120 ~ AC

DP1300B 240 ~

AC

DP1300TA 120

~ AC

DP1300TB 240

~ AC

DP1300TE 208

~ AC

DP1300TGB

240 ~ AC

QT

Y.

1

HOUSING, INSTRUMENT

1101025220

1

11010252201

1

2

BUTTON BLACK MUSHROOM

SCREW ON GE

P9ARB3N

1

3

GREEN MUSHROOM BUTTON

SCREW ON

P9ARB3V

2

4

ARM

DP1822101

1

5

BOLT, HEX 5/16-18X2 1/2 G5

BH51618212

G5

BH51618212G

5

BH51618212G

5

BH51618212G

5

BH51618212G

5

BH51618212G

5

4

6

BOLT, LEVEL

11067

4

7

BOLT, HEX 1/4-20X5/8

BH142058

4

8

CABLE, POWER DISTRIBUTION

1101025068

1

9

TERMINAL BLOCK 6 STAGE

6016

2

10

NUT, HEX 1/4-20

NH1420

1

11

SCREW SET 1/4"-20 X 1 3/4

SST1420134

1

12

BUMPER

110503450

1

13

STUD, LOWER PLATEN

110249065

1

14

BUSHING, LOWER PLATEN

110249049

1

15

BEARINGS, SEALED

62042NSL

2

16

NUT, JAM MACHINED

110102570

1

17

SCREW, SOCKET HEAD

3/8-16X1

SSH38161

1

18

WASHER, LOCK INTERNAL 1/4"

WLIT14

1

19

ANTI-ROTATION BLOCK

110148

1

20

PIVOT ARM

1103001

1

21

SKREW, SET 3/8-16x1/2 CONE

POINT

SST381612C

P

SST381612CP

2

22

BASE ASSEMBLY

DP1821101

1

23

COVER PLATE, BASE

11054

1

24

SCREW, PHILLIPS PAN HEAD

8-32 X 1/4

SP83214

2

25

SPACER, CRANK

1101097028

1

26

SCREW, SET 1/4-20X1/4

SST142014

1

27

SCREW, SET 1/4-20 X 3/8 CONE

POINT

SST142038C

P

SST142038CP

1

28

HEYCO STRAIN RELIEF #LFT

1/2"

3231

1

29

STOP CONTROL

11061

1

30

JAM NUT UPPER

11070

1

11

31

WASHER, THRUST

11059

1

32

SCREW, ADJUSTMENT POST

11042

1

33

THRUST PLATE

11058

1

34

SCREW, SET 8-32 X 1"

SST8321

1

35

SCREW, SOCKET FLAT HEAD

1/4-20 X 3/4

SF142034

1

36

WASHER, STEEL

311150019

4

37

WASHER, #8 INTERNAL

TOOTH LOCK

WLIT8

2

38

CLAMP, CABLE 1/2

CC12

2

39

SCREW, SOCKET HEAD CAP,

DOMESTIC FASTER 1/4-20 X 1

SSH14201D

16

40

AIR, TUBE, POLY AIR 3/8 O.D. X

7

T38

1

FT.

41

ORING, #2-265 N-70 7.734 ID x

.139 THICK

MPSR138

2

42

O'RING, PISTON ROD

62308

1

43

FITTING, AIR 1/4" PIPE X 3/8

TUBE ELBOW 90 DEG

110559025

2

44

PISTON ASSEMBLY

11039

1

45

GASKET

MPSG140

1

46

PISTON COVER

11013

1

47

FITTING, AIR 1/8 PIPE X 1/4

TUBE 90 DEG

AQ69P4X2

1

ITEM

#

DESCRIPTION

DP1300A

120 ~ AC

DP1300B 240 ~

AC

DP1300TA 120

~ AC

DP1300TB 240

~ AC

DP1300TE 208

~ AC

DP1300TGB

240 ~ AC

QT

Y.

48

AIR TUBE

TPE4014

2

FT.

49

POWER CORD

110969174

110969175

110969174

110969175

1101009176

DP149203

1

50

GUIDE POST

11072

1

51

BUSHING, GUIDE POST

MPSB070

1

52

STUD, THREADED

11048

1

53

NUT, HEX 3/8-16

NH3816

1

54

NUT, COUPLING 3/8-16X1-3/4

NC3816134

1

55

SCREW, SOCKET HEAD

3/8-16X4

SSH38164

1

56

BEARING SPACER

11046

1

57

TERMINAL, #6 RING 18-22 GA

2202

3

58

NUT, HEX 3/4-16

NH3416

1

59

HOUSING, SWITCH

PROXIMITY SENSOR

110103

1

60

WASHER, SAE #8

WSAE8

10

61

NUT, HEX 8-32

NH832

2

62

WIRE HARNESS

11017069250

1

63

CONTROL PANEL OVERLAY

ODP1300

1

12

64

MARKER STRIP #6

MS6016

2

65

CONTROL FACIA

11086027

1

66

DIGITAL CONTROL

11010250521

3

110102505213

1

67

SPACER, NYLON

110969111

4

68

NUT, HEX 6-32

NH632

8

69

WASHER, INTERNAL TOOTH

LOCK #6

WLIT6

8

70

SCREW, SET 10-32X3/16

SST1032316

1

71

TRANSFORMER

11096975

MPPT700R

1

72

RELAY

MPR90217

1

73

SCREW, PAN HEAD PHILLIPS

8-32X3/8

SP83238

6

74

SCREW, PAN HEAD PHILLIPS

8-32X 1/2

SP83212

4

75

FUSE HOLDER 1 AMP

MPPF708

1

76

SCREW, PAN HEAD PHILLIPS

2-56X1/4

SP25614

1

77

FUSE BUSS 1 AMP

MPPF701R

1

78

FEET, RUBBER

RF209

4

79

SWITCH, MOM P/S OP

SCREW ON GE

P9XPLOSO

3

80

CONTACT N/O SCREW TYPE,

GE #P9B10VN

110101751

3

81

SCREW, SET 3/8-16X1/2" CUP

SST381612

2

82

SWTICH, PROXIMITY

SENSOR

11017452377

1

83

OPERATION MANUAL

MDP1300

1

84

BOLT, HEX HEAD 8-32 X 1/4

BH83214

12

86

ELBOW, 90 DEG NPT X 1/4

BRASS FEMAL

3020404

1

87

ELBOW, 90 DEG STREET 1/4"

3040404

1

88

FILTER W/ METAL BOWL

AUTO DRAIN 1/4"

11017452302

1

90

NIPPLE BRASS 1/4 X 2

N142

1

91

ADAPTOR, UNION 1/4 X 2

MALE BRASS STRAIGHT

1720404

1

92

WIRE, TGGT, 14 GA

110069

4.2

5

FT.

93

TFE, SHRINK TUBING 7 AWG

110131

.33

FT.

94

TERMINAL, RING #6 14-16 GA

(HI-TEMP)

1601HT

1

95

TERMINAL, RING #8 14-16 GA

(BLUE)

1604

2

96

TERMINAL, QD 3/16 X 18-22

GA (PINK)

2280

2

13

97

WASHER, SAE #6

WSAE6

1

98

SCREW, PAN HEAD PHILLIPS

6-32X1/4

SP63214

1

99

WIRE, TFE 14 GA. GREEN

WTFE14G

2

FT.

100

RTD SENSOR ASSEMBLY

110949110

1

101

SCREW, SET 3/8-16X1/2" CUP

SST381612

1

102

SLEEVING, PVC WIRE

OPVC1050

.16

FT.

103

WASHER, SAE 5/16"

WSAE516

4

104

TERMINAL, FORK #10 10-12

GA

TF101012

1

105

UPPER HEAT SHROUD

1109336

1

ITEM

#

DESCRIPTION

DP1300A

120 ~ AC

DP1300B 240 ~

AC

DP1300TA 120

~ AC

DP1300TB 240

~ AC

DP1300TE 208

~ AC

DP1300TGB

240 ~ AC

QT

Y.

106

SCREW, FLAT HEAD SOCKET

1/2-20X2

SF12202

1

107

SCREW, SET CONE POINT

1/4-20 X 5/8

SST142058C

P

SST142058CP

1

108

BOLT, HEX 5/16-18 X 1.0

STAINLESS STEEL

BH516181S

3

109

HANDLE, BRACKET

11045336301

1

110

SCREW, BOLT HEX HEAD

1/4-20 1.0 STAINLESS STEEL

BH14201S

2

111

PRESSURE APPLYING KNOB

MPSK215

1

112

SPLIT LOCK WASHER 3/8

STAINLESS STEEL

WL38S

1

113

SCREW, BUTTON HEAD 3/8-16

X 1.0

SB38161

1

114

GUIDE. LOWER PLATEN

11044

1

115

WASHER, LOCK INTERNAL

TOOTH 1/4

WLIT14

2

116

WASHER, LOCK INTERNAL

TOOTH 5/16

WLIT516

3

117

NUT, HEX 1/4-20

NH1420

1

118

BOLT, HEX 1/4-20 X 1 1/2

BH1420112

1

119

SOLENOID VALVE 4-W 1/4",

12V DC WITH LEADS

11017511604

1

120

NUT, HEX JAM 1-14

NHJ114

1

121

FITTING, AIR 1/4" PIPE X 1/4"

TUBE 90°

AQ69P4X4

3

122

SCREW, PAN HEAD PHILLIPS

8-32X1 1/2 STAINLESS STEEL

SP832112S

2

123

TERMINAL, #6 RING 18-22 GA

2202

2

124

BOLT, HEX 5/16-18 X 1.0

STAINLESS STEEL

110559029

2

125

CRANK, ADJUSTMENT

1106001

1

14

126

SCREW, SET KNURLED CUP

POINT 5/16-18 X 3/8

SST5161838

KN

SST5161838K

N

SST5161838K

N

SST5161838K

N

SST5161838K

N

SST5161838KN

2

ITEM

#

DESCRIPTION

DP1300A

120 ~ AC

DP1300B 240 ~

AC

DP1300TA 120

~ AC

DP1300TB 240

~ AC

DP1300TE 208

~ AC

DP1300TGB

240 ~ AC

QT

Y.

A1

UPPER PLATEN WITH WIRING

ONLY

11010253120

0

110102531201

110079120K

110079240K

110079208K

110079240K

1

A2

UPPER PLATEN COMPLETE

ASSEMBLY

11010253110

110102531101

110079120AK

110079240AK

110079208AK

110079240AK

1

A3

KITTED, LOWER PLATEN

ASSEMBLY

11032A

11032TA

1

A4

KITTED, SOLENOID VALVE

ASSY

11017452330

K

11017452330K

1

A5

CRANK, ASSEMBLY

11061A

1

A6

SWITCH, PROXIMITY SENSOR,

KIT

110103K

1

A7

START SWITCH ASSY

MUSHROOM

11051845

2

A8

STOP SWITCH ASSY

MUSHROOM

11051850

1

A9

KITTED, PISTON ASSEMBLY

11039K

1



15



16



Warranty & Return Policy



Proluxe warrants all products manufactured

by it against defects in workmanship or

materials from the date of purchase for a

period of 1 year on parts and labor. This

warranty applies to only equipment

purchased and used in the United States.



Warranty period shall begin when equipment

ships. Warranty travel will only be covered

for 60 miles.



ALL WARRANTY SERVICE CALLS MUST BE

APPROVED BY PROLUXE. IF THIS

PROCEDURE IS NOT FOLLOWED,

WARRANTY SERVICE WILL NOT BE

COVERED. WARRANTY SERVICE WILL BE

PAID ON STRAIGHT TIME, OVERTIME

WILL NOT BE COVERED.



E X C L U S I O N S



Wood & Gas Fired Ovens

Warranty applies to the main body of the

oven being steel / refractory and insulation

shall be free from defects in materials and

workmanship for a period of four years from

the date of purchase. The gas equipment

shall be free from defects in materials and

workmanship for a period of one (1) year

from the date of purchase. Lifetime warranty

against cracks on the oven floor.



Air Compressors

Are excluded from this warranty, but Proluxe

may act as a warranty expeditor in certain

instances regarding these compressors. The

air compressor manufacturer provides a

limited warranty and a copy of this warranty

is furnished with all compressors sold by

Proluxe. For prompt handling of compressor

warranty claims the instructions of the

compressor manufacturer must be adhered

to.



Special Order Equipment and

Accessories

Cannot be canceled and are not returnable

unless defective within the terms of this

warranty.



In no event shall Proluxe be liable for

consequential damages arising out of the

failure of any of its products if operated

improperly or caused by normal wear or

damaged by operator abuse.



Limited Lifetime Warranty on

Heating Elements

If replacement is needed, Proluxe will send

the new part at no charge but labor will not

be covered unless the unit is still under the 1

year manufacturer warranty.



R E T U R N E D M E R C H A N D I S E

P O L I C Y



Should it become necessary to return any of

the company’s products, the following

instructions must be adhered to: First,

contact our customer service department for

approval and a return authorization number.

Please have the serial number of your item

available at that time. All merchandise must

be shipped freight prepaid by customer or

17

service agency. Subject to the inspection of

the product by the company, a restocking

charge of 20% of the Net purchased price

paid to Proluxe will be assessed.

Merchandise may not be returned for credit

without prior written approval of Proluxe.



Collect shipments will not be accepted. No

returns after 60 days of original shipment

date on machines. Purchased parts may not

be returned after 30 days. If upon inspection

by Proluxe or its authorized agent it is

determined the equipment has not been used

in an appropriate manner, has been modified,

or has not been properly maintained, or has

been subject to misuse, misapplication,

neglect, abuse, accident, unauthorized

modification, damage during transit, delivery,

fire, flood, act or war, riot or act of God, then

this warranty shall be deemed null and void.



T E R M S & C O N D I T I O N S



1. Price List prices are suggested retail prices

and are shown in U.S. Dollars.



2. Terms of Payment: 1% 10 days, NET 30

days.



3. New Accounts: Satisfactory credit

information must be provided before open

account status can be extended.



Unless agreed otherwise, all shipments will

be made C.O.D., Cash in advance.



4. Pricing: Prices, specifications, model

numbers, capacities and accessories are

subject to change without notice.



5. Freight/Routing: Method of shipment will

be determined by Proluxe unless otherwise

advised by purchaser.



6. Damaged Claims: All merchandise shipped

at purchaser’s risk. Inspection must be made

by purchaser at time goods are received. If

goods are damaged, the PURCHASER shall

request that the agent of the transportation

company make a written notation on the

proper shipping documents immediately and

then file a claim for damages.



Note



: Goods damaged in shipping are

non-returnable.



7. Returns: Machines may not be returned

after 60 days. Purchased parts may not be

returned after 30 days. A restocking fee of

20% will be assessed on non-warranty

returns.



8. Taxes: Prices indicated herein DO NOT

include State, Federal, Local or foreign taxes

or duties, nor do they include fees, permits,

insurance or other levies, all of which are the

responsibility of the purchaser.



9. All orders are subject to acceptance by

Proluxe.



10. Possession of this price list shall not be

considered an offer to sell.



18

Proluxe Apex X1 User manual

Popular Commercial Food Equipment manuals by other brands
