Proluxe Apex Pro X1 User manual
Operations Manual
Apex Pro X1 Hydraulic Automatic Dough Press
Model #: DP1350
WWW.PROLUXE.COM
Version: 122820
Proluxe is a leading manufacturer of
food preparation and cooking
equipment designed for the most
demanding commercial kitchens.
Proluxe equipment is a result of the
highest quality engineering and
time-tested design.
This manual includes installation,
operation, and maintenance
procedures for your new hydraulic
dough press. Please read this
manual carefully and keep it with
your machine for proper operation
and lasting service.
I N S T A L L A T I O N
Domestic
Use a separate 15 amp AC circuit. Only
industrial extension cords with proper wire
size should be used; size 16/3 wire for
distance up to 25 feet, and size 14/3 for
distance up to 50 feet.
International
Use a designated 16 amp AC circuit. Only
industrial extension cords with proper wire
size (2.5 sq. mm) shall be used. Make sure
there is a proper electrical wall outlet located
within reach of the cord and plug attached to
the press.
Place the press in an area that allows for
“swing clearance” of the lower platen plus
vertical and horizontal clearance of the press
itself.
Limited Machine Warranty
Proluxe warrants this dough press machine,
when operated under normal conditions, to
be free from manufacturing defects in
material and workmanship for a period of
one year on parts and labor from the invoice
date.
This warranty will be effective only when
Proluxe authorizes the original purchaser to
return the product to the factory in Perris,
California freight prepaid and only when the
product, upon examination, has proven to be
defective. This warranty does not apply to
any machine that has been subjected to
misuse, negligence or accident. Proluxe shall
not be liable for the injury, loss or damage,
direct or consequential, arising out of the use
or the inability to use the product. No claim
of any kind shall be greater in amount than
the sale price of the product or part to which
claim is made.
This warranty given by the company, it is in
lieu of any other warranties, expressed or
implied, in law or in fact, including the
warranties of merchantability and fitness for
a particular use, and is accepted such by the
purchaser in taking delivery of this product.
S P E C I F I C A T I O N S
Electrical:
120V/50-60Hz/1450W/12.5Amps/AC
Also available; specify when ordering:
Other options available:
●Voltage: 120/208/240
●Amps: 12.5/11.1/16.5
●Watts: 1500/2300/1500
Includes: 72” cord and NEMA approved plug.
Shipping Weight:
200lbs. (91kg.) – DP1350
Poids d'expédition:
200lbs. (91kg.) – DP1350
I N T E R N A T I O N A L S Y M B O L S
Symboles internationaux
Power Off
éteindre
Power On
allumer
Hot Surface
surface chaude
Risk of Electrical Shock
Risque de choc électrique
Protective Earth Terminal
Borne de terre de protection
Caution - Warning
chaud - avertissement
S A F E T Y S U M M A R Y
Warning
To reduce the risk of electrical shock, do not
remove or open cover. No user-serviceable
parts inside. Refer servicing to qualified
personnel.
Avertissement
Pour réduire le risque de choc électrique, ne pas
retirer ou couvercle ouvert Aucune pièce
réparable par l’utillsateur, reportez-vous à du
personnel qualifié.
Warning
In case of power cord damage, do not
attempt to repair or replace the power cord.
Please contact the manufacturer or the local
distributor.
Avertissement
Pour une protection continue contre l’incendie
et de choc électrique, remplacer avec le même
type et calibre du fusible. Mis fusible
supplémentaire nominale max 3A, 120 Vac.
Warning
For continued protection against fire and
electric shock, replace with the same type
and rating fuse. Listed Supplemental Fuse
rated max 3A, 120Vac.
Avertissement
Pour une protection continue contre l’incendie
et de choc électrique, remplacer avec le même
type et calibre du fusible. Mis fusible
supplémentaire nominale max 3A, 120 Vac.
Caution Hot
Avoid touching hot surfaces while operating
the machine.
Attention à chaud
Évitez de toucher les surfaces chaudes lorsque
vous utilisez la machine.
Caution
When servicing or cleaning the machine,
make sure that the power cord is removed
from the wall socket.
During normal operation, the base of the
machine must be installed or placed above
the wall socket.
Avertissement
Lors de l'entretien ou du nettoyage de la
machine, assurez-vous que le cordon
d'alimentation est débranché de la prise murale.
O P E R A T I O N T E M P E R A T U R E
& T I M E R C O N T R O L
FIG. A
Solid State Controller
This controller has three (3) control features:
1. Temperature – May be set from
100°-425°F (38°-163°C)
2. Time – Time may be set from 1 second to
10 minutes.
3. Counter – Cycle counter counts the
number of applications from 1 to 9999 (see
additional Notes – Counter).
4. “2 Lower” (Fig. A) Refers to models using
upper and lower heated surfaces.
Controller Operation
1. Viewing the Modes of Operation :
To view the set points of temperature, timer,
and counter, press MODE button to view the
desired mode of operation.
2. Changing Temperature:
Press MODE button until the temperature is
displayed.
Press and hold SET button while pressing the
UP (↑) and DOWN (↓) arrow buttons to the
desired temperature setting.
3. Changing Time:
Press MODE button until the time is
displayed.
Press and hold SET button while pressing the
UP (↑) and DOWN (↓) arrow buttons to
desired timer setting.
4. Resetting the Counter:
Press MODE button until the counter is
displayed.
To reset the counter (# of cycles),
simultaneously push UP (↑) or DOWN (↓)
arrow buttons (approx. 5 seconds).
Pressing Dough:
1. For best results, your dough should be
proofed before pressing, but it will also press
directly out of your refrigerator. Flour is not
required to press a crust and should not be
dusted on any part of the machine.
2. Press the On/Off button.
Note: Initial temperature setting of 150°F has
been shown to be acceptable for most dough
formulations; however, you may have to
determine the best temperature for your own
dough by trial and error testing of your product
at different temperature settings.
3. Set the timer in accordance with company
settings.
*Remember that the timer does not actuate
until the upper platen mates with the lower
platen and resistance is felt.
4. Swing open the lower platen and
apply a quick spray food release on the lower
platen.
5. Place your dough in the center of the lower
platen.
6. Close the platen and, with both hands,
press the two green buttons on each side of
the machine simultaneously.
7. Hold the buttons until resistance is felt
then release at once. The timer will actuate
and, when the time cycle is completed, the
upper platen will rise automatically (timer is
preset at the factory for six seconds, but this
is easily changed by following the upcoming
instructions.)
8. Remove the crust, place on a pan or peel,
add toppings and bake.
R E C O M M E N D E D S E A S O N I N G
& C L E A N I N G P R O C E D U R E S
Before use, you must properly season
your platens to prevent your dough from
sticking.
Tools Required:
●Food release
●Soapy water solution
●Washcloth
●Paper towels
DO NOT use steel wool or harsh abrasives, it
will you will cause costly damage.
1. Before cleaning make sure the
unit is turned off.
2. Spray lower platen with approved
food release/oil spray.
3. Wipe excess oil across upper and
lower platens.
4. Mix a warm dish soap and water
solution.
5. Wipe lower and upper platen
clean with a damp cloth.
P R E V E N T A T I V E
M A I N T E N A N C E
For a long lifespan, the following
preventative maintenance should be
followed:
Daily Care:
1. Platens: Turn your machine off and allow it
to cool down before attempting to clean.
These platens should only be cleaned with
mild soap and warm water then wiped off
with a clean, soft cloth or soft sponge.
2. Exterior surfaces: Wipe daily with mild
soap and warm water will do the job quite
nicely.
Service Problems:
Contact our factory at (800) 624-6717 (U.S.
only) or an approved service agency. When
contacting the factory for information, parts
or service instructions, please provide the
serial number of the machine be provided.
This number can be found on the serial plate
located on the rear of the machine.
Refilling hydraulic oil:
Recommended ISO/AW46 Hydraulic oil
Capacity of Reservoir is 650 ml
Remove threaded breather, fill 200 ml at a
time and add as desired. Replace threaded
breather.
Troubleshoot Guide - Model #: DP1350
Problem
Cause
Action
Ref #
Power button on
digital controller face
is depressed but
doesn’t turn on.
1. Power cord is not plugged in.
2. Circuit breaker is tripped off in the
site's breaker box.
3. Transformer has taken an
electrical surge and is damaged.
4. Check voltage on the secondary
side of the transformer. If you read
12VDC then you are receiving
voltage to the controller.
5. Possible blown fuse.
1. Plug the power cord into wall
receptacle and power button.
2. Reset circuit breaker that the
grill is plugged into. Depress
power button to turn on.
3. Replace Transformer after you
check secondary side of
transformer. If working properly,
you should receive 12vdc.
4. Replace controller. Controller
should be on once the power
button is depressed.
5. Replace fuse.
60
-----
66
76
39
Digital controller's
LED's are scrambled
or randomly erratic.
If when turning on,
the display will first
go to segment check
1. Possibly a component on the
Digital controller is damaged.
2. Control needs to reset.
Replace digital controller.
While unit is on unplug unit, wait
for 1 min. Then plug machine on
again and depress power button.
-----
76
Digital controller on
startup goes through
The relay driver on the digital control
may be blown.
Replace digital controller.
76
LED segment check
(8888) then to
version # and then
loops back to to the
above reboot.
Digital display shows
PROB. No heat on
upper platen.
Sensor lost it's continuity as shown
on a muti-meter.
Disconnect prob that is open (no
continuity as shown on a multi-
meter. Must replace sensor
(RTD). Do not cut and splice new
sensor. Install new 2000 ohm
RTD sensor to under side of heat
platen and reconnect to the
controller.
A1.10
When depressing the
tactile button
on digital controller,
nothing happens.
The tactile buttons under the overlay
may be not close enough to activate.
Same goes if the buttons are already
pressed by overlay without
depressing button.
Carefully tighten the nuts on the
back of the controller until button
activate. Same goes in reverse if
buttons are held down by the
overlay.
----
Press does not close
when pressing the
two, green, start
buttons
1. Did not simultaneously press the
start buttons exactly at the same
time.
2. The lower platen switch mounted
on the base is not in contact to
complete circuit.
Try pressing both buttons exactly
at the same time. This is a safety
feature.
2. Make sure the roller plunger
comes into contact (clicking
noise). This is also a safety feature
that both platens are aligned.
82
Digital display shows
relay and particular
zone is overheating.
1. The relay on the switched side is
not opening to regulate temperature.
1. Replace the relay.
92
Beeper not
functioning
1. Beeper on digital control board
failed.
1. Replace digital controller
board.
76
If setpoint is reached
but slightly off in
temperature.
Offset may need to be calibrated and
adjusted.
Call (800) 624-6717 ext. 129 for
instructions.
Heater platen
overheating
If the relay (depending on the year of
the model) on the coil side are
receiving 12vdc indicates the
controller is functioning properly. On
the switching side of the relay, is
there 120 vac going to the heater in
question. If there is no voltage on
the to the switching side of the relay
to the heaters, the relay is not
Replace relay If the controller's
heat-on LED is not lit indicating
the controller is working
properly.
55
working properly.
Both upper and
lower platen not
aligned when
activating. You may
experience a shifting
of the platens when
coming into contact,
or striking noise.
Upper and lower platen are
misaligned.
On the left side of the post collar
(#35) are back-to-back set
screws. Remove the first locking
set screw. Adjust stopping set
screw to align platen
*IMPORTANT* must reduce
air pressure to a minimum as not
to damaging closing platens. After
alignment is complete, re-install
locking set screw as not to move
the alignment set screw.
17
Dough is not a
consistent thickness.
Adjust upper platen for level press
Underneath the housing there is
4 stacked hex bolts sitting over
the upper platen attached to the
arm. The top bolts are called
locking bolts. The 4 larger hex
bolts below are adjustment bolts.
Break free the 4 locking bolts.
With an open end wrench adjust
the bolts (1/8 turn at a time).
After testing, tighten the locking
bolts making sure not to move the
larger adjustment bolts.
11
And
12
EXPLOSION VIEW
DP1350
EXPDP1350 RH 051820
CUSTOMER MANUAL
05/18/20
1
2
7
8
9
10
10
11
12
13
14
127
20
17
22
23
25
25
29
28
30
31
31
32
33 3X
34
3X
35
36
126 39
40
2X
41
42
50
44
45
59
47
48
49
50
51
52
3X
53
4X
54
4X
55
4X
56
57
57
58
58
58
46
60
61 2X
62
63
4X
63
4X
64
4X
64
4X
65
66 2X
67
68
69
70
72
73
76
4X
77 4X
78
81
86
83
85 86
86
88
89
3X
90
90 90
91
92
95
96
97
98
87
98 99
100 101
102 103
104
105
24
26
95
79 80
84 16
43
123
37
71
4X
26
127
131
112
113
A1
A2
A3
A4
A6
A6
A5
A7
111
110
19
130
129 22 2X 107
107
3
109
82
125
93
4X
6
16
4X
17
4X
4
18
106
4X
125
125
21
38
117
16
79
80 84
16
84
108
74
115 4X
5
119
116
120
121
122
124
114
114
119
118
118
128
4X
132
EXPDP1350 RH 051820
CUSTOMER MANUAL
PROLUXE PARTS LIST FOR
DP1350
DP1350A DP1350TA DP1350B DP1350E DP1350TE DP1350CEB DP1350CEC DP1350TCEC DP1350GCEC DP1350TGCEC
120 ~ AC 120 ~ AC 240 ~ AC 208 ~ AC 208 ~ AC 240 ~ AC 220 ~ AC 220 ~ AC 220 ~ AC 220 ~ AC
1 BASE AND POST WELDING ASSEMBLY WITHOUT KEYWAY, DP1350/DP2350 DP1315501 DP1315501 DP1315501 DP1315501 DP1315501 DP1315501 DP1315501 DP1315501 DP1315501 DP1315501 1
2 PISTON GUIDE WELDING ASSEMBLY WITHOUT KEYWAY, DP1350 DP13157 DP13157 DP13157 DP13157 DP13157 DP13157 DP13157 DP13157 DP13157 DP13157 1
3 CYLINDER, HYDRAULIC - 40 MM BORE x 1.687 STROKE DP13140 DP13140 DP13140 DP13140 DP13140 DP13140 DP13140 DP13140 DP13140 DP13140 1
4 MOUNTING PLATE DP13105 DP13105 DP13105 DP13105 DP13105 DP13105 DP13105 DP13105 DP13105 DP13105 1
5 POWER SUPPLY, 24VDC / 85-265VAC DP13110 DP13110 DP13110 DP13110 DP13110 DP13110 DP13110 DP13110 DP13110 DP13110 1
6 ELECTRICAL BOX MOUNTING BRACKET DP13107 DP13107 DP13107 DP13107 DP13107 DP13107 DP13107 DP13107 DP13107 DP13107 2
7 PIVOT ARM MACHINED, DP1350 DP1315201 DP1315201 DP1315201 DP1315201 DP1315201 DP1315201 DP1315201 DP1315201 DP1315201 DP1315201 1
8 SCREW, SOCKET HEAD, 5/16"-24 THREAD SIZE, 1" LONG, ZINC PLATED SSH516241P SSH516241P SSH516241P SSH516241P SSH516241P SSH516241P SSH516241P SSH516241P SSH516241P SSH516241P 1
9 SWING ARM/LOWER PLATEN BUMPER 110503450 110503450 110503450 110503450 110503450 110503450 110503450 110503450 110503450 110503450 1
10 BEARING, DP1300 62042NSL 62042NSL 62042NSL 62042NSL 62042NSL 62042NSL 62042NSL 62042NSL 62042NSL 62042NSL 2
11 SWING AWAY WASHER 110249049 110249049 110249049 110249049 110249049 110249049 110249049 110249049 110249049 110249049 1
12 STUD, LOWER PLATEN, DP1300 110249065 110249065 110249065 110249065 110249065 110249065 110249065 110249065 110249065 110249065 1
13 BEARING SLEEVE SPACER 11046 11046 11046 11046 11046 11046 11046 11046 11046 11046 1
14 NUT, JAM (PIVOT ARM) MACHINED 110102570 110102570 110102570 110102570 110102570 110102570 110102570 110102570 110102570 110102570 1
15 BOLT, HEX 3/8-16 X 1-1/2" BH3816112 BH3816112 BH3816112 BH3816112 BH3816112 BH3816112 BH3816112 BH3816112 BH3816112 BH3816112 2
16 WASHER, SAE #8 WSAE8 WSAE8 WSAE8 WSAE8 WSAE8 WSAE8 WSAE8 WSAE8 WSAE8 WSAE8 10
17 SCREW, PHILLIPS PAN HEAD 8-32 X 1/4 SP83214 SP83214 SP83214 SP83214 SP83214 SP83214 SP83214 SP83214 SP83214 SP83214 6
18 PUMP MOUNTING BRACKET DP13108 DP13108 DP13108 DP13108 DP13108 DP13108 DP13108 DP13108 DP13108 DP13108 1
19 CONTACTOR, 12V GE DP13117 DP13117 DP13117 DP13117 DP13117 DP13117 DP13117 DP13117 DP13117 DP13117 2
20 TERMINAL BLOCK STAGE #7 6017 6017 6017 6017 6017 6017 6017 6017 6017 6017 1
21 WASHER, SAE 5/16 WSAE516 WSAE516 WSAE516 WSAE516 WSAE516 WSAE516 WSAE516 WSAE516 WSAE516 WSAE516 2
22 SCREW, PHILLIPS PAN HEAD 8-32 X 3/8 SP83238 SP83238 SP83238 SP83238 SP83238 SP83238 SP83238 SP83238 SP83238 SP83238 8
23 SCREW, SOCKET HEAD 3/8-16 X 1 SSH38161 SSH38161 SSH38161 SSH38161 SSH38161 SSH38161 SSH38161 SSH38161 SSH38161 SSH38161 1
24 WASHER, SAE 3/8" WSAE38 WSAE38 WSAE38 WSAE38 WSAE38 WSAE38 WSAE38 WSAE38 WSAE38 WSAE38 1
25 WASHER, LOCK 3/8 WL38 WL38 WL38 WL38 WL38 WL38 WL38 WL38 WL38 WL38 2
26 NUT, HEX 3/8-16 NH3816 NH3816 NH3816 NH3816 NH3816 NH3816 NH3816 NH3816 NH3816 NH3816 2
28 SCREW, FLAT HEAD SOCKET 1/2-20 X 2 SF12202 SF12202 SF12202 SF12202 SF12202 SF12202 SF12202 SF12202 SF12202 SF12202 1
29 SCREW, SET 1/4-20X3/8" CONE POINT SST142038CP SST142038CP SST142038CP SST142038CP SST142038CP SST142038CP SST142038CP SST142038CP SST142038CP SST142038CP 1
30 BOLT, HEX 1/4-20 X 1-1/2, GRD.5 TAP BH1420112G5T BH1420112G5T BH1420112G5T BH1420112G5T BH1420112G5T BH1420112G5T BH1420112G5T BH1420112G5T BH1420112G5T BH1420112G5T 1
31 NUT, HEX 1/4-20 NH1420 NH1420 NH1420 NH1420 NH1420 NH1420 NH1420 NH1420 NH1420 NH1420 2
32 GUIDE, LOWER PLATEN 11044 11044 11044 11044 11044 11044 11044 11044 11044 11044 1
33 WASHER, LOCK INTERNAL TOOTH 5/16" WLIT516 WLIT516 WLIT516 WLIT516 WLIT516 WLIT516 WLIT516 WLIT516 WLIT516 WLIT516 3
34 5/16 - 18 x 1 SS., BOLT HEX HEAD BH516181S BH516181S BH516181S BH516181S BH516181S BH516181S BH516181S BH516181S BH516181S BH516181S 3
35 HANDLE BRACKET 11045336301 11045336301 11045336301 11045336301 11045336301 11045336301 11045336301 11045336301 11045336301 11045336301 1
36 KNOB, PRESSURE ALUMINUM MPSK215 MPSK215 MPSK215 MPSK215 MPSK215 MPSK215 MPSK215 MPSK215 MPSK215 MPSK215 1
37 WASHER, LOCK INTRNL TOOTH 3/4" WLIT34 WLIT34 WLIT34 WLIT34 WLIT34 WLIT34 WLIT34 WLIT34 WLIT34 WLIT34 1
38 NUT, HEX SELF LOCKING 7/16-20 NHSL71620 NHSL71620 NHSL71620 NHSL71620 NHSL71620 NHSL71620 NHSL71620 NHSL71620 NHSL71620 NHSL71620 2
39 WASHER, SPLIT LOCK 1/4" WLIT14 WLIT14 WLIT14 WLIT14 WLIT14 WLIT14 WLIT14 WLIT14 WLIT14 WLIT14 2
40 HEX BOLT CAP 1/4-20 X 7/8" LONG S.S. BH142078S BH142078S BH142078S BH142078S BH142078S BH142078S BH142078S BH142078S BH142078S BH142078S 2
41 SCREW SET 1/4"-20 X 1 3/4" SST1420134 SST1420134 SST1420134 SST1420134 SST1420134 SST1420134 SST1420134 SST1420134 SST1420134 SST1420134 1
42 ANTI ROTATION BAR ARM-PIZZA MACHINE 110148 110148 110148 110148 110148 110148 110148 110148 110148 110148 1
43 GUIDE POST HOLE PLUG, (1.093", KOS LT 3/4) DP13143 DP13143 DP13143 DP13143 DP13143 DP13143 DP13143 DP13143 DP13143 DP13143 1
44 ARM MACHINED DP1822101 DP1822101 DP1822101 DP1822101 DP1822101 DP1822101 DP1822101 DP1822101 DP1822101 DP1822101 1
45 THRUST PLATE 110230058 110230058 110230058 110230058 110230058 110230058 110230058 110230058 110230058 110230058 1
46 THRUST WASHER 11059 11059 11059 11059 11059 11059 11059 11059 11059 11059 1
47 SCREW, ADJUSTMENT POST, DP1300 11042 11042 11042 11042 11042 11042 11042 11042 11042 11042 1
48 BOLT, STRIPPER 3/8" X 1/2" BS3812 BS3812 BS3812 BS3812 BS3812 BS3812 BS3812 BS3812 BS3812 BS3812 1
49 BRACKET, ADJUSTMENT STOP 11065 11065 11065 11065 11065 11065 11065 11065 11065 11065 1
50 LOCKING JAM NUT 11070 11070 11070 11070 11070 11070 11070 11070 11070 11070 2
51 SCREW, SET 1/4-20 X 3/8 CONE POINT SST142038CP SST142038CP SST142038CP SST142038CP SST142038CP SST142038CP SST142038CP SST142038CP SST142038CP SST142038CP 1
52 SCREW, SOCKET HEAD 1/4-20 X 3/4" SSH142034 SSH142034 SSH142034 SSH142034 SSH142034 SSH142034 SSH142034 SSH142034 SSH142034 SSH142034 3
ITEM
NO.
DESCRIPTION
QTY.
DP1350 RH 051820 CUSTOMER MANUAL
PROLUXE PARTS LIST FOR
DP1350
DP1350A DP1350TA DP1350B DP1350E DP1350TE DP1350CEB DP1350CEC DP1350TCEC DP1350GCEC DP1350TGCEC
120 ~ AC 120 ~ AC 240 ~ AC 208 ~ AC 208 ~ AC 240 ~ AC 220 ~ AC 220 ~ AC 220 ~ AC 220 ~ AC
ITEM
NO.
DESCRIPTION
QTY.
53 BOLT, U.P. ADJUSTMENT 11067 11067 11067 11067 11067 11067 11067 11067 11067 11067 4
54 5/16-18 X 2-1/2" HEX BOLT GR5, DP1300 BH51618212G5 BH51618212G5 BH51618212G5 BH51618212G5 BH51618212G5 BH51618212G5 BH51618212G5 BH51618212G5 BH51618212G5 BH51618212G5 4
55 BOLT, HEX 1/4-20 X 5/8" ZINC PLATED BH142058 BH142058 BH142058 BH142058 BH142058 BH142058 BH142058 BH142058 BH142058 BH142058 4
56 HOUSING, MACHINING 11010252201 11010252201 11010252201 11010252201 11010252201 11010252201 11010252201 11010252201 11010252201 11010252201 1
57 GREEN MUSHROOM BUTTON SCREW ON P9ARB3V P9ARB3V P9ARB3V P9ARB3V P9ARB3V P9ARB3V P9ARB3V P9ARB3V P9ARB3V P9ARB3V 2
58 SWITCH, MOM P/S OP SCREW ON GE P9XPLOSO P9XPLOSO P9XPLOSO P9XPLOSO P9XPLOSO P9XPLOSO P9XPLOSO P9XPLOSO P9XPLOSO P9XPLOSO 3
59 CRANK SPACER 11064 11064 11064 11064 11064 11064 11064 11064 11064 11064 1
60 CRANK HANDLE, ADJUSTMENT 1106001 1106001 1106001 1106001 1106001 1106001 1106001 1106001 1106001 1106001 1
61 SCREW, SET 5/16-18 X 3/8 SET SCREW KNURLED CUP POINT SST5161838KN SST5161838KN SST5161838KN SST5161838KN SST5161838KN SST5161838KN SST5161838KN SST5161838KN SST5161838KN SST5161838KN 2
62 ASSEMBLY, CONTROL FACIA 11086027 11086027 11086027 11086027 11086027 11086027 11086027 11086027 11086027 11086027 1
63 WASHER, INTERNAL TOOTH LOCK #6 WLIT6 WLIT6 WLIT6 WLIT6 WLIT6 WLIT6 WLIT6 WLIT6 WLIT6 WLIT6 8
64 NUT, HEX 6-32 NH632 NH632 NH632 NH632 NH632 NH632 NH632 NH632 NH632 NH632 8
65 MARKER STRIP #7 MS6017 MS6017 MS6017 MS6017 MS6017 MS6017 MS6017 MS6017 MS6017 MS6017 1
66 SCREW, PAN HD 8-32 X 5/8" SP83258 SP83258 SP83258 SP83258 SP83258 SP83258 SP83258 SP83258 SP83258 SP83258 2
67 FUSE HOLDER 1 AMP MPPF708 MPPF708 MPPF708 MPPF708 MPPF708 MPPF708 MPPF708 MPPF708 MPPF708 MPPF708 1
68 FUSE BUSS 1 AMP MPPF701R MPPF701R MPPF701R MPPF701R MPPF701R MPPF701R MPPF701R MPPF701R MPPF701R MPPF701R 1
69 SCREW, PHILLIPS PAN 2-56x1/4 SP25614 SP25614 SP25614 SP25614 SP25614 SP25614 SP25614 SP25614 SP25614 SP25614 1
70 TRANSFORMER 11096975 11096975 11096975 11096975 11096975 MPPT700R MPPT700R MPPT700R MPPT700R MPPT700R 1
71 WASHER, SAE 1/4 WSAE14 WSAE14 WSAE14 WSAE14 WSAE14 WSAE14 WSAE14 WSAE14 WSAE14 WSAE14 4
72 OVERLAY-BLUE, DP1300/DP1350, DP2350/DP2300 ODP2350B ODP2350B ODP2350B ODP2350B ODP2350B ODP2350B ODP2350B ODP2350B ODP2350B ODP2350B 1
73 DIGITAL CONTROL REV. 5.06 DP131052 DP131052 DP131052 DP131052 DP131052 DP131052 DP131052 DP131052 DP131052 DP131052 1
74 BOTTOM COVER DP13154 DP13154 DP13154 DP13154 DP13154 DP13154 DP13154 DP13154 DP13154 DP13154 1
75 OPERATION MANUAL MDP1350 MDP1350 MDP1350 MDP1350 MDP1350 MDP1350 MDP1350 MDP1350 MDP1350 MDP1350 1
76 NYLON SPACER, 1/4 X .141 X 9/32 LONG 110969111 110969111 110969111 110969111 110969111 110969111 110969111 110969111 110969111 110969111 4
77 WASHER, STEEL 311150019 311150019 311150019 311150019 311150019 311150019 311150019 311150019 311150019 311150019 4
78 SWITCH, PROXIMITY SENSOR 11017452377 11017452377 11017452377 11017452377 11017452377 11017452377 11017452377 11017452377 11017452377 11017452377 1
79 SCREW, SET 8-32X1 SST8321 SST8321 SST8321 SST8321 SST8321 SST8321 SST8321 SST8321 SST8321 SST8321 2
80 WASHER, INTERNAL TOOTH LOCK #8 WLIT8 WLIT8 WLIT8 WLIT8 WLIT8 WLIT8 WLIT8 WLIT8 WLIT8 WLIT8 4
81 HOUSING, SWITCH PROXIMITY SENSOR 110103 110103 110103 110103 110103 110103 110103 110103 110103 110103 1
82 BOLT, HEX 7/16-20 X 1-1/2", GRADE 8 BH71620112 BH71620112 BH71620112 BH71620112 BH71620112 BH71620112 BH71620112 BH71620112 BH71620112 BH71620112 2
83 RELAY, SOLID STATE MPR90217 MPR90217 MPR90217 MPR90217 MPR90217 MPR90217 MPR90217 MPR90217 MPR90217 MPR90217 1
84 NUT, HEX 8-32 NH832 NH832 NH832 NH832 NH832 NH832 NH832 NH832 NH832 NH832 4
85 SCREW, SOCKET FLAT HEAD 1/4-20 X 3/4 SF142034 SF142034 SF142034 SF142034 SF142034 SF142034 SF142034 SF142034 SF142034 SF142034 1
86 SCREW, SET 3/8-16 X 1/2 SST381612 SST381612 SST381612 SST381612 SST381612 SST381612 SST381612 SST381612 SST381612 SST381612 2
87 TERMINAL, FORK #10 10-12 GA TF101012 TF101012 TF101012 TF101012 TF101012 TF101012 TF101012 TF101012 TF101012 TF101012 1
88 NUT, HEX 3/4-16 MACHINED DP13162 DP13162 DP13162 DP13162 DP13162 DP13162 DP13162 DP13162 DP13162 DP13162 1
89 TERMINAL, #6 RING 18‐22 GA 2202 2202 2202 2202 2202 2202 2202 2202 2202 2202 3
90 CONTACT N/O SCREW TYPE, GE #P9B10VN 110101751 110101751 110101751 110101751 110101751 110101751 110101751 110101751 110101751 110101751 3
91 BUTTON BLACK MUSHROOM SCREW ON GE P9ARB3N P9ARB3N P9ARB3N P9ARB3N P9ARB3N P9ARB3N P9ARB3N P9ARB3N P9ARB3N P9ARB3N 1
92 UPPER HEAT SHROUD 1109336 1109336 1109336 1109336 1109336 1109336 1109336 1109336 1109336 1109336 1
93 8-32 X 1/4" PHIL. HD 100 DEG., SCREW STAINLESS STEEL SF83214S SF83214S SF83214S SF83214S SF83214S SF83214S SF83214S SF83214S SF83214S SF83214S 4
95 WIRE, TGGT, 14 GA. (HEATER) 110069 110069 110069 110069 110069 110069 110069 110069 110069 110069 4.25 FT.
96 TFE, SHRINK TUBING 7AWG 110131 110131 110131 110131 110131 110131 110131 110131 110131 110131 .33 FT.
97 TERMINAL, RING #6 14-16 GA HIGH TEMP 1601HT 1601HT 1601HT 1601HT 1601HT 1601HT 1601HT 1601HT 1601HT 1601HT 1
98 TERMINAL, RING #8 14-16 GA 1604 1604 1604 1604 1604 1604 1604 1604 1604 1604 2
99 TERMINAL, QD 3/16 X 18-22 GA 2280 2280 2280 2280 2280 2280 2280 2280 2280 2280 2
100 WASHER, SAE #6 WSAE6 WSAE6 WSAE6 WSAE6 WSAE6 WSAE6 WSAE6 WSAE6 WSAE6 WSAE6 1
101 SCREW, PAN HEAD 6-32 X 1/4 SP63214 SP63214 SP63214 SP63214 SP63214 SP63214 SP63214 SP63214 SP63214 SP63214 1
102 WIRE, TFE 14GA. GREEN WTFE14G WTFE14G WTFE14G WTFE14G WTFE14G WTFE14G WTFE14G WTFE14G WTFE14G WTFE14G 1.5 FT.
103 RTD, SENSOR ASSEMBLY 110949110 110949110 110949110 110949110 110949110 110949110 110949110 110949110 110949110 110949110 1
104 SLEEVING, PVC WIRE OPVC1050 OPVC1050 OPVC1050 OPVC1050 OPVC1050 OPVC1050 OPVC1050 OPVC1050 OPVC1050 OPVC1050 .16 FT.
DP1350 RH 051820 CUSTOMER MANUAL
PROLUXE PARTS LIST FOR
DP1350
DP1350A DP1350TA DP1350B DP1350E DP1350TE DP1350CEB DP1350CEC DP1350TCEC DP1350GCEC DP1350TGCEC
120 ~ AC 120 ~ AC 240 ~ AC 208 ~ AC 208 ~ AC 240 ~ AC 220 ~ AC 220 ~ AC 220 ~ AC 220 ~ AC
ITEM
NO.
DESCRIPTION
QTY.
105 SCREW, SET 1/4-20 X 1/2" SST142012 SST142012 SST142012 SST142012 SST142012 SST142012 SST142012 SST142012 SST142012 SST142012 1
106 SCREW BUTTON HEAD 3/8-16 X 1/2 SB381612 SB381612 SB381612 SB381612 SB381612 SB381612 SB381612 SB381612 SB381612 SB381612 4
107 HYDRAULIC MOTOR HOSES DP13141 DP13141 DP13141 DP13141 DP13141 DP13141 DP13141 DP13141 DP13141 DP13141 2
108 HYDRAULIC PUMP/MOTOR WITH OIL CANISTER (DP1350,DP2350) DP13149 DP13149 DP13149 DP13149 DP13149 DP13149 DP13149 DP13149 DP13149 DP13149 1
109 90 DEGREE ELBOW X-LONG FORGE DP13158 DP13158 DP13158 DP13158 DP13158 DP13158 DP13158 DP13158 DP13158 DP13158 2
110 POWER CORD 110969174 110969174 110969175 110969175 110969175 MPPW202 MPPW202 MPPW202 DP149203 DP149203 1
111 STRAIN RELIEF 3231 3231 3231 3231 3231 3231 3231 3231 3231 3231 1
112 WIRE HARNESS DP13150 DP13150 DP13150 DP13150 DP13150 DP13150 DP13150 DP13150 DP13150 DP13150 1
113 CABLE, POWER DISTRIBUTION DP13168 DP13168 DP13168 DP13168 DP13168 DP13168 DP13168 DP13168 DP13168 DP13168 1
114 PORT FITTING DP13121 DP13121 DP13121 DP13121 DP13121 DP13121 DP13121 DP13121 DP13121 DP13121 2
115 PAN HEAD SLOTTED 8-32 X 3/8" PLATED SPS83238 SPS83238 SPS83238 SPS83238 SPS83238 SPS83238 SPS83238 SPS83238 SPS83238 SPS83238 4
116 TUBING, BLACK AIR LINE 1/4" TPE4014 TPE4014 TPE4014 TPE4014 TPE4014 TPE4014 TPE4014 TPE4014 TPE4014 TPE4014 1 FT.
117 BOLT, HEX 5/16-18 X 1 BH516181 BH516181 BH516181 BH516181 BH516181 BH516181 BH516181 BH516181 BH516181 BH516181 2
118 WASHER, LOCK 7/16 WL716 WL716 WL716 WL716 WL716 WL716 WL716 WL716 WL716 WL716 2
119 RAIL LOCK DP13122 DP13122 DP13122 DP13122 DP13122 DP13122 DP13122 DP13122 DP13122 DP13122 2
120 FITTING, AIR 1/4" FEM.PIPE X, 1/4 TUBE 90 DEGREE AQ70P4X4 AQ70P4X4 AQ70P4X4 AQ70P4X4 AQ70P4X4 AQ70P4X4 AQ70P4X4 AQ70P4X4 AQ70P4X4 AQ70P4X4 1
121 MUFFLER SILENCER QUIET FLOW 1/4" NPT SQF-2 110559029 110559029 110559029 110559029 110559029 110559029 110559029 110559029 110559029 110559029 1
122 NUT, CONDUIT 1/2" NC12 NC12 NC12 NC12 NC12 NC12 NC12 NC12 NC12 NC12 1
123 SCREW, SET 1/4-20 X 1/4 SST142014 SST142014 SST142014 SST142014 SST142014 SST142014 SST142014 SST142014 SST142014 SST142014 1
124 BRIDGE, PLUG IN, 2, RED, CROSS CONNECTIONS 110116920 110116920 110116920 110116920 110116920 110116920 110116920 110116920 110116920 110116920 2
125 WASHER, SAE 7/16 WSAE716 WSAE716 WSAE716 WSAE716 WSAE716 WSAE716 WSAE716 WSAE716 WSAE716 WSAE716 4
126 BOLT HEX 3/8-16X1 STAINLESS STEEL BH38161S BH38161S BH38161S BH38161S BH38161S BH38161S BH38161S BH38161S BH38161S BH38161S 1
127 SCREW, SET 10‐32 X 3/16" SST1032316 SST1032316 SST1032316 SST1032316 SST1032316 SST1032316 SST1032316 SST1032316 SST1032316 SST1032316 2
128 TERMINAL RING 12-10 GA #6 1402 1402 1402 1402 1402 1402 1402 1402 1402 1402 4
129 TERMINAL BLOCK #11 60111 60111 60111 60111 60111 60111 60111 60111 60111 60111 1
130 MARKER STRIP #11 MS60111 MS60111 MS60111 MS60111 MS60111 MS60111 MS60111 MS60111 MS60111 MS60111 1
131 PIVOT ARM CLOSURE PLUG DP13161 DP13161 DP13161 DP13161 DP13161 DP13161 DP13161 DP13161 DP13161 DP13161 1
132 FITTING, AIR 1/4" PIPE X 1/4" TUBE, 90 DEGREE AQ69P4X4 AQ69P4X4 AQ69P4X4 AQ69P4X4 AQ69P4X4 AQ69P4X4 AQ69P4X4 AQ69P4X4 AQ69P4X4 AQ69P4X4 1
A1 KITTED, UPPER PLATEN COMPLETE ASSEMBLY 11010253110 110079120AK 110102531101 110079208PAK 110079208AK 110102531101 110079220PAK 110079220AK 110079220PAK 110079220AK 1
A2 KITTED, UPPER PLATEN WITH WIRING ONLY 110102531200 110079120K 110102531201 110079208PK 110079208K 110102531201 110079220PK 110079220K 110079220PK 110079220K 1
A3 KITTED, LOWER PLATEN ASSEMBLY 11032A 11032TA 11032A 11032A 11032TA 11032A 11032A 11032TA 11032A 11032TA 1
A4 SWITCH, PROXIMITY SENSOR, KIT 110103K 110103K 110103K 110103K 110103K 110103K 110103K 110103K 110103K 110103K 1
A5 CRANK, ASSEMBLY 11061A 11061A 11061A 11061A 11061A 11061A 11061A 11061A 11061A 11061A 1
A6 START SWITCH ASSY MUSHROOM 11051845 11051845 11051845 11051845 11051845 11051845 11051845 11051845 11051845 11051845 2
A7 STOP SWITCH ASSY MUSHROOM 11051850 11051850 11051850 11051850 11051850 11051850 11051850 11051850 11051850 11051850 1
DP1350 RH 051820 CUSTOMER MANUAL
Warranty & Return Policy
Proluxe warrants all products manufactured
by it against defects in workmanship or
materials from the date of purchase for a
period of 1 year on parts and labor. This
warranty applies to only equipment
purchased and used in the United States.
Warranty period shall begin when equipment
ships. Warranty travel will only be covered
for 60 miles.
ALL WARRANTY SERVICE CALLS MUST BE
APPROVED BY PROLUXE. IF THIS
PROCEDURE IS NOT FOLLOWED,
WARRANTY SERVICE WILL NOT BE
COVERED. WARRANTY SERVICE WILL BE
PAID ON STRAIGHT TIME, OVERTIME
WILL NOT BE COVERED.
E X C L U S I O N S
Special Order Equipment and
Accessories
Cannot be canceled and are not returnable
unless defective within the terms of this
warranty.
In no event shall Proluxe be liable for
consequential damages arising out of the
failure of any of its products if operated
improperly or caused by normal wear or
damaged by operator abuse.
Limited Lifetime Warranty on
Heating Elements
If a replacement is needed, Proluxe will send
the new part at no charge but labor will not
be covered unless the unit is still under the 1
year manufacturer warranty.
R E T U R N E D M E R C H A N D I S E
P O L I C Y
Should it become necessary to return any of
the company’s products, the following
instructions must be adhered to: First,
contact our customer service department for
approval and a return authorization number.
Please have the serial number of your item
available at that time. All merchandise must
be shipped freight prepaid by customer or
service agency. Subject to the inspection of
the product by the company, a restocking
charge of 20% of the Net purchased price
paid to Proluxe will be assessed.
Merchandise may not be returned for credit
without prior written approval of Proluxe.
Collect shipments will not be accepted. No
returns after 60 days of original shipment
date on machines. Purchased parts may not
be returned after 30 days. If upon inspection
by Proluxe or its authorized agent it is
determined the equipment has not been
used in an appropriate manner, has been
modified, or has not been properly
maintained, or has been subject to misuse,
misapplication, neglect, abuse, accident,
unauthorized modification, damage during
transit, delivery, fire, flood, act or war, riot or
act of God, then this warranty shall be
deemed null and void.
T E R M S & C O N D I T I O N S
1. Price List prices are suggested retail prices
and are shown in U.S. Dollars.
2. Terms of Payment: 1% 10 days, NET 30
days.
3. New Accounts : Satisfactory credit
information must be provided before open
account status can be extended.
Unless agreed otherwise, all shipments will
be made C.O.D., Cash in advance.
4. Pricing : Prices, specifications, model
numbers, capacities and accessories are
subject to change without notice.
5. Freight/Routing : Method of shipment will
be determined by Proluxe unless otherwise
advised by purchaser.
6. Damaged Claims : All merchandise shipped
at purchaser’s risk. Inspection must be made
by purchaser at time goods are received. If
goods are damaged, the PURCHASER shall
request that the agent of the transportation
company make a written notation on the
proper shipping documents immediately and
then file a claim for damages.
Note : Goods damaged in shipping are
non-returnable.
7. Returns : Machines may not be returned
after 60 days. Purchased parts may not be
returned after 30 days. A restocking fee of
20% will be assessed on non-warranty
returns.
8. Taxes : Prices indicated herein DO NOT
include State, Federal, Local or foreign taxes
or duties, nor do they include fees, permits,
insurance or other levies, all of which are the
responsibility of the purchaser.
9. All orders are subject to acceptance by
Proluxe.
10. Possession of this price list shall not be
considered an offer to sell.
Other manuals for Apex Pro X1
1
This manual suits for next models
1
Table of contents
Other Proluxe Commercial Food Equipment manuals
Proluxe
Proluxe Impact X1 User manual
Proluxe
Proluxe DP1350 User manual
Proluxe
Proluxe CS157 User manual
Proluxe
Proluxe DP2010SE User manual
Proluxe
Proluxe DOUGHPRO DP1300BP Series User manual
Proluxe
Proluxe TORTILLAPRO DP2000PB User manual
Proluxe
Proluxe DP2000FPE User manual
Proluxe
Proluxe DP2010ZPE User manual
Proluxe
Proluxe DPR2000 User manual
Proluxe
Proluxe Endurance Pro X2M User manual
Proluxe
Proluxe Apex Pro X2M User manual
Proluxe
Proluxe Endurance X1M User manual
Proluxe
Proluxe DP2000CKE User manual
Proluxe
Proluxe DP2300PIP User manual
Proluxe
Proluxe Endurance Pro X2 User manual
Proluxe
Proluxe Doughpro Apex Pro X2 User manual
Proluxe
Proluxe Apex X1 User manual
Proluxe
Proluxe DOUGHPRO DP1100BZ Series User manual
Proluxe
Proluxe DP2000UPE User manual
Proluxe
Proluxe PIEOLOGY DOUGHPRO DP2000PIP User manual
Popular Commercial Food Equipment manuals by other brands
Structural Concepts
Structural Concepts Oasis B4732 Installation & operating manual
Stalgast
Stalgast 880177V03 instruction manual
Hendi
Hendi THERMOSYSTEM user manual
Roller Grill
Roller Grill SB 40 M Instructions for installation and use
Bartscher
Bartscher 406.051 instruction manual
Server
Server TWIN FS 81220 Important instructions
