ProMinent gamma G/4b User manual

Operating Instructions
Metering Pump
ProMinent®gamma G/4b
Part No. 981071 ProMinent Dosiertechnik GmbH •D-69123 Heidelberg •Germany BA G4 015 8/99 GB
Please first read the operating instructions from cover to cover! •Do not throw them away!
The warranty does not cover damages due to faulty operation!
Affix type identification plate here!
®

DeviceOverview/ControlElements
4
STOP
STOP
START
START
P
gamma/4
10
20
30
40
50
60
70
80
90
100
3218765
910111213
G/4b-002-D
1514
16 17 / 17a / 17b
181922 20
21
10
20
30
40
50
60
70
80
90100
STOP
STOP
START
START
P
g
amma/4

➠
Alwaysunfoldthepagefirst!

Page2of 88 pages Version2.0
More detailed information
on pages:
1 Pulse/pilot light (yellow) ................................................................ 51, 75, 81
2 Down key .............................................................................................. 51 ff.
3 Stroke length adjustment knob.................................................................. –
4 LCD display field....................................................................................... 50
5 Program selection key .......................................................................... 51 ff.
6 Up key.................................................................................................. 51 ff.
7 Stop/start key....................................................................................... 51 ff.
8 Display light for empty display and fault annunciation (red).......... 51, 56, 76
9 Connection thread PG-9 for relay output (with blank plug)...................... 51
10 Connection socket metering monitor ..................................... 34, 37, 51, 59
11 Connection socket for float switch (with function plug) .... 34, 37, 51, 54, 59
12 On/off control (with function plug)..................................... 34, 37, 54, 58, 59
13 Mains supply............................................................................................ 34
14 View window.............................................................................................. –
15 Enclosure................................................................................................... –
16 Pressure valve.............................................................................. 25, 29-33
19 Liquid end........................................................................................... 76-80
20 Intermediate disk with leakage bore................................................... 76-80
21 Suction valve ................................................................................ 25, 29-33
22 Short operating instructions....................................................................... –
Only for PP and NP version:
17 Bleed valve ................................................................................................ –
17a Fine bleed valve......................................................................................... –
17b Star handle ................................................................................................ –
18 Bypass tube nozzle ................................................................................... –

Page3of 88pagesVersion2.0
Imprint:
Operating Instructions gamma 4b metering Pump
© ProMinent Dosiertechnik GmbH, 1993
ProMinent Dosiertechnik GmbH
Im Schuhmachergewann 5-11
D-69123 Heidelberg, Germany
P.O. Box 101760
D-69007 Heidelberg, Germany
[email protected]
www.prominent.de
Subject to alterations
Techn. documentation:
Bartha Docuteam
D-64625 Bensheim
Issue 08/99, version 2.0
Printed in Germany

Page4of 88 pages Version2.0
Contents
Page
i General notes for users .......................................................... 7
1 Introduction ............................................................................... 8
2 Functions .................................................................................. 8
2.1 Functional principle .......................................................... 8
2.2 Functions ......................................................................... 9
2.2.1 The mechanics ..................................................... 9
2.2.2 The setting range................................................ 10
2.2.3 Options............................................................... 11
3 Technical data......................................................................... 13
3.1 Technical data G/4b (with 120 strokes/min) ................... 13
3.2 Technical data G/4b (with 180 strokes/min) ................... 14
4 Installation dimensions ............................................................ 16
5 Tests for your safety ................................................................ 17
6 Accessories ............................................................................ 19
6.1 Float switch................................................................... 19
6.2 Control cables ............................................................... 19
6.3 Foot valves ................................................................... 19
6.4 Injection valves ............................................................. 19
6.5 Injection lances ............................................................. 19
6.6 Back-pressure valves .................................................... 19
6.7 Accumulators ................................................................ 19
6.8 Metering monitors ......................................................... 19
6.9 Suction lances .............................................................. 19
6.10 Supply tanks ................................................................. 19
6.11 Manual/electric stirrers .................................................. 19
6.12 Console ........................................................................ 19
6.13 ProMinent "Remote Control".......................................... 19
7 SAFETY INSTRUCTIONS ...................................................... 20
8 Device identification/identity code ............................................ 21
9 Unpacking............................................................................... 22
10 Installation............................................................................... 24
10.1 Installing the pump: mechanical part............................... 24
10.1.1 Pump installation with console or tank ............... 24
10.1.2 Connection of suction/discharge line to the pump .. 24
10.1.3 Installation suction line (general instructions) ..... 26
10.1.4 Installation discharge line (general information) ...... 27
10.1.5 Installation bybass bleed line............................. 27

Page5of 88pagesVersion2.0
Contents
Page
10.1.6 Installation examples......................................... 28
Correct installation:........................................... 29
Incorrect installation: ........................................ 33
10.2 Installation pump: electrical part...................................... 34
10.2.1 Electrical connection (general instructions) ....... 34
10.2.2 Operating modes ............................................. 35
10.2.3. Functions superior to the operating modes ....... 35
10.2.4 Parallel connection........................................... 36
10.2.5 Wiring diagram................................................. 37
11 Commissioning ....................................................................... 38
11.1 General instructions ..................................................... 38
11.2 Operating conditions .................................................... 38
11.3 Suction capacity/bleeding ............................................. 39
11.4 Metering accuracy........................................................ 40
11.5 Determining the capacity by means of nomograms ....... 41
11.5.1 General information......................................... 41
11.5.2 Nomogram 1000/1001 .................................... 43
11.5.3 Nomogram 1601/1602 .................................... 44
11.5.4 Nomogram 1201/1203 .................................... 45
11.5.5 Nomogram 0803/0806 .................................... 46
11.5.6 Nomogram 1002/1003 .................................... 47
11.5.7 Nomogram 0308/0313 .................................... 48
11.5.8 Nomogram 0215/0223 .................................... 49
12 Operation ................................................................................ 50
12.1 Explanation of the operating and display elements ......... 50
12.1.1 Display............................................................. 50
12.1.2 Control panel: keys and display lamps.............. 51
12.1.3 Multiple connector strip. Symbols and connections 51
12.2 Overview operating diagram........................................... 52
12.3 Operating functions basic version................................... 53
12.3.1 Starting the pump............................................. 53
12.3.2 Stopping the metering ...................................... 53
12.3.3 Internal "Manual" operation .............................. 54
12.3.4 External "Contact" operation............................. 55
12.3.5 Connecting a float switch.................................. 56
12.3.6 On/off function "Pause" .................................... 58
12.3.7 Metering monitor "flow"..................................... 58
12.3.8 Error messages -
acknowledging error messages ........................ 59

Page6of 88 pages Version2.0
Contents
Page
12.4 Overview operating scheme (option version) .................. 60
12.5 Operation (option version) .............................................. 62
12.5.1 Analog control.................................................... 62
12.5.2 Pulse control ...................................................... 66
12.5.3 Preselection operation and memory ................... 71
12.5.4 Relay option....................................................... 72
Switching mode no. 1:
"Fault annunciation relay de-energising" ............. 72
Switching mode no. 2:
"Pacing relay energising".................................... 72
Switching mode no. 3:
"Fault annunciation relay energising" .................. 72
Switching mode no. 4:
"Timer relay energising" ..................................... 72
13 Maintenance ........................................................................... 74
14 Trouble shooting/eliminating errors .......................................... 74
14.1 Errors you can eliminate yourself.................................... 74
14.1.1 Pump does not prime in spite of full stroke
movement and bleeding..................................... 75
14.1.2 Float switch does not switch the metering
pump off at minimum chemical level................... 75
14.1.3 Pump does not meter although yellow display
lamp (1) flashes ................................................. 75
14.1.4 Red warning lamp (8)lights up - "Error"
readout on display (4) flashes............................. 76
14.1.5 Fluid is leaking at the intermediate disk............... 77
14.1.6 Exchanging the complete liquid end ................... 80
14.2 Errors which require customer service assistance........... 80
14.2.1 Pump does not move,
yellow display light (1) does not light up,
no readout on the display (4) .............................. 81
14.2.2 Mains connection line (system cable) damaged.. 81
15 Repair ..................................................................................... 82
16 Disposal of old parts ............................................................. 83
Appendix/cross section of pump................................................. 84
Warranty application .................................................................... 85
Safety certificate ........................................................................... 87

Page7of 88pagesVersion2.0
i General notes for users
Theseoperatinginstructionsdescribethetechnicaldataandfunctioning
oftheG/4bmeteringpump,providecomprehensivesafetyinstructions
and are arranged in clear operational steps, as explained in the
following examples.
Equipment descriptions are indicated by normal text:
Analoguesignalssuchascurrentsignals0/4-20mAorvoltagesignals
adjustable from 0 - 60 mV, 0 - 1 V and 0 - 10 V can be used for direct
proportional control of the stroking rate.
Operations/activities to be performed are shown by bullets:
• Pressindowelandscrewinthescrewsofaruntilthescrewheadstill
projects 3.5 to 4 mm.
References are shown by arrows and bold texts:
> Detailed description from page 61
Safety precautions are indented, in bold italics and provided with a
warning symbol:
WARNING:
Themeteringpumpcanstillcontainwaterfromthefactory
test!
Work instructions are indented and set in italics:
PLEASE NOTE:
Youobtain afixed hose connectionif youpull shortlyon the line
connectedtotheliquidendandsubsequentlyretightentheunion
nut hand-tight!
Mains supply
Keywordstoenabletherelevantpartofthetexttobequicklylocatedare
given in italics and arranged to the left of the text.
GeneralNotesforUsers

Page8of 88 pages Version2.0
1 Introduction
ProMinent®gamma/4b are microprocessor-controlled, solenoid-driven
diaphragm metering pumps capable of dialogue for metering fluids.
Sophisticated mechanics, state-of-the art control technology, easy uni-
formoperationwithuserguidanceinplainlanguage,maximumoperational
safetythankstodiagnosisofexternalerrorsourcestoo,almostunlimited
adaption possibilities to process automation systems, self-monitoring of
the metering capacity and high metering safety in the capacity range of
0,2 to 23 l/h at a maximum counter pressure of 16 to 1,5 bar.
2 Functions
2.1 Functional principle
Gamma/4b metering pumps predominantly consist of
a pump drive
with enclosure, stroke solenoid and electronic microprocessor control
and a liquid end
withliquidend,suctionandpressureconnection,pumpdiaphragmand
intermediate disk.
Thefeedingproceduretakesplaceinbatches.Thestrokelengthismax.
1.25 mm.
Foreverypulsewhichcomesfromtheelectronicsamagneticfieldbuilds
upin the fieldcoil anda moveable mountedpressure piece isattracted.
Indoingsothepumpdiaphragmdisplacesthemediumintheliquidend
bymeansofapressurevalve,andthevalveonthesuctionsidecloses.
After the switch-on pulse is terminated the magnetic field de-energises,
the pressure piece from the stroke solenoid is reset by the recuperating
springandthediaphragmreturnstotheinitialposition.Thepressureside
is closed. In this way the medium is sucked into the liquid end (suction
stroke).
Thecapacityperstrokecanbepreselectedviathestrokelengthadjustment
knob (3).
The metering pumps can be retrofitted to suit the customer’s specific
needs (options).
Introduction/Functions

Page9of 88pagesVersion2.0
2.2 Functions
2.2.1 The mechanics
The enclosure Highest protection against chemical attacks, dust and spray water by
meansofglass-fibrereinforcedplastic. Sturdy, impact-proof, lightand
enclosure rating IP 65 according to DIN 40050 and IEC 529.
The solenoid drive Conventional pump drives consist of an electric motor with gears and
many moving parts.
TheProMinentsolenoiddrivehasonlyonemovingpart,thearmature!
This is a low-maintenance short-stroke solenoid with a new type of
noise suppression and a maximum stroke length of 1.25 mm.
The stroke length adjusting mechanism is connected directly to the
solenoid. Thus a most accurate stroke length adjustment is possible
without locking and self- adjustment.
The pump diaphragm A DEVELOPAN®composite pump diaphragm with long service life of
fabric-reinforced high-quality EPDM with a vulcanised steel core and
PTFE Teflon coating on the media-contacted side.
The liquid end Liquid ends for gamma pumps are available in four material versions
- polypropylene (PP)
- acrylic (NP)
- PTFE (TT)
- stainless steel 1.4571 (SS)
AdditionallymaterialversionsPPandNPhaveacombinedbleedvalve
with fine adjustment.
Especially for highly viscous materials, liquid ends from the HV series
are available in
- polypropylene (PP4)
with extended flow cross section and larger, springloaded single ball
valves.
Operating voltages Gamma metering pumps are available for 230 and 115 V mains
voltages. Wide voltage ranges are accepted: from 207 to 254 V in the
upperand from 108to 135V in thelower range:for mains frequencies
from 50 to 60 Hz.
Self-monitoring The electronic control system is continuously self-monitoring. In the
eventofasystemerrorinthemicroprocessor,thepumpisswitchedoff
and an alarm is issued.
Lighting The optional illumination of the LCD display (4) guarantees that the
display can be easily read even in bad light conditions.
Functions

Page10 of 88 pages Version2.0
2.2.2 The setting range
"Pause" control Bymeansoftheuniversalcontrolcablethepumpcanbeswitchedonand
offvoltage-free.Thecontrolfunctionoperatesaccordingtothezerosignal
current:whenthecontactisopenthepumpisidle,brownandblackwires
are not connected with each other. When the contact is closed the pump
operates, brown and black wires are connected with each other.
The pause control is effective in each of the functions described here
below.
> Detailed description from page 58
Internal operation "Manual" Thesettingofthestrokevolumetakesplaceusingthestrokelength(3).
This can be set from 0 - 100% up to a maximum of 1.25 mm. Accurate
metering is achieved from 30% stroke length.
The stroking rate can be set with the keys (2 or 6) from 120 (180)
to 0 strokes/min. The number is displayed on the display (4).
> Detailed description from page 54 onwards.
External operation "Contact" Thestrokecycleofthegammapumpcanalsobecontrolledexternallye.g.
viaawatermetercontact.Theconnectiontakesplacewithacontrolcable
at the connection socket (12). Each incoming pulse corresponds to one
meteringstroke.Amax.of120(180)strokes/minarepossible-thereisno
danger of overdriving.
Please note:
Thestrokingratesetintheinternaloperation"Manual"isvalidfor
the external operation "Contact" as max. stroking rate.
> Detailed description from page 55
Metering monitoring "flow" Gammameteringpumpschecktheirownperformance.Aftertheassembly
of an optional metering monitor on the liquid end (19) and activation,
every complete metering stroke is recorded and passed on to the pump
electronics. If the correct metering amount is not present eight times the
pump stops.
> Detailed description from page 58
Float switch Byattachingthetwo-stagefloatswitchtothesocket(11)thesupplyoffluid
mediaismonitored.Whenaminimumheightisreachedanearlywarning
is issued, the pump however continues to operate.
Thepumpswitchesoffonlyoncethelevelhasdroppedanother30mm.
A fault annunciation relay can be switched as an option.
> Detailed description from page 58
Functions

Page11 of 88 pagesVersion2.0
2.2.3 Options
TheversionslistedbelowcanbeobtainedfromProMinentindividually
or as a freely combinable package.
Analog Control Analogue signals can be used for proportional control of the stroking
rate. The stroking rate is varied between 0 and 100% according to the
0/4 - 20 mA signal.
For example, in the event of a cable rupture (input signal < 4 mA) an
alarm message is issued and the pump switches off. Other input
signals (0-1 V, 0-10 V, 0-60 mV) can be entered on ordering with the
identity code.
> Detailed description from page 62
Pulse Control Pulse Control is used for adapting the gamma metering pump to all
types of pacers and for saving additional control devices.
The following functions listed below can be set using the keyboard:
Pulse set-down
and step-up By entering a factor in the range from 0.01 to 9999 the step-down or
step-up ratio can be set.
Example:
Step-down withfactor 0.01 :100 pulses= 1 metering stroke
Step-down withfactor 0.25 : 4 pulses= 1 metering stroke
Step-down with factor 1: 1 pulse = 1 metering stroke
Step-up with factor 4 : 1 pulse = 4 meteringstrokes
Step-up with factor 9999 : 1 pulse = 9999 meteringstrokes
> Detailed description from page 67
Display "f" Displays the stroking rate in 0 to 120 (180) strokes/min.
> Detailed description from page 69
Predetermining counter "N ÷ " The predetermined number of strokes can be called up by means of a
voltage-free contact or the P key (5). The strokes still to be executed
are shown on the display (4) subtracting.
> Detailed description from page 69
Stroke counter "N" Thestrokecounterinalloperatingmodescountsthestrokesexecuted
and shows these on the display (4). A maximum of 9999 strokes can
be counted, after this the display starts at 1 again.
> Detailed description from page 69
Memory "Mem" A memory with a storage capacity of 65,535 (216-1) pulses or strokes
canbeadditionallyswitchedon.Thusincomingpulsescanberegistered
and worked off.
> Detailed description from page 71
Functions

Page12 of 88 pages Version2.0
Relay output (9) This is used for remote transfer of alarm messages or as a pacer for
remotecontrole.g.ofasecondProMinent®meteringpumpinsynchronous
pacing operation.
The relay output can be used for:
Collective fault indication Forthelevelearlywarningandfinalswitchoff,meteringmonitor,system
errorannunciation,fuseandmainsfailureannunciation.Function:relay
de-energises in the event of an alarm.
Alarm relay For the level early warning and final switch off, metering monitor and
systemerrormessage.Function:relayenergisesintheeventofanalarm.
Pacing relay With contact pacing parallel to the discharge stroke of the metering
solenoid. Contact duration 150 ms.
Timer relay Switchesparallelto31differentmeteringtimes(from1minutetoupto24
hours), repeating daily or weekly.
> Detailed description from page 72
Functions

Page13 of 88 pagesVersion2.0
3 Technical Data
3.1 Technical Data G/4b (with 120 strokes/min)
Gamma /4b, Typ 1000 1601 1201 0803 1002 1002 0308 0215
HV
Capacity (l/h) 0.2 1,0 1.7 3.4 2.3 1.7 8.4 14.8
Capacity (ml/stroke) 0.027 0.14 0.24 0.48 0.32 0.24 1.17 2.05
at max. counter pressure (bar) 10 16 12 8 10 10 3 1.5
Capacity (l/h) 0.27 1.2 1.9 3.8 2.6 2.5 9.1 15.8
Capacity (ml/stroke) 0.038 0.17 0.27 0.53 0.36 0.34 1.27 2.20
at med. counter pressure (bar) 5864551.51
Suction lift (m WS) 1.5 6 6 3 6 6 6 1.5
Priming lift
at 100% stroke length (m) ** 0.5 1.8 2.5 2.8 1.0 - 1.8 1.5
Max. pressure suction side(bar) 8.0 8.0 5.5 3.0 3.0 3.0 1.5 0.8
Max. stroking rate (stroke/min) 120 120 120 120 120 120 120 120
Liqid end version *** PP PP PP PP PP PP PP PP
NP NP NP NP NP - NP NP
with suction and TT TT TT TT TT - TT TT
discharge connections *** SS SS SS SS SS - SS SS
Connection size
o.Ø x i.Ø (mm) 6x4 6x4 6x4 6x4 8x5 DN10 8x5 12x9
Shipping weight. PP. NP. TT (kg) 2.7 2.7 2.7 2.7 2.9 2.9 2.9 3.1
Shipping weight. SS (kg) 3.4 3.4 3.4 3.4 4.1 4.1 4.1 4.7
Medium power drain
at max. 120 strokes/min (W) refer to typelabel
Peak power drain
at discharge stroke (A) refer to typelabel
**)Primingliftswithcleandampenedvalvesforwaterandsuction
**) line as specified.
Liquid end version Liquid end Suction/discharge valve seals valve balls
PP1 polypropylene polypropylene EPDM ceramic
PP2 polypropylene polypropylene FPM (Viton®A) ceramic
PP3 polypropylene polypropylene FPM (Viton®B) ceramic
PP41) polypropylene polypropylene EPDM ceramic
NP1 acrylic PVC FPM (Viton®A) ceramic
NP2 acrylic PVC EPDM ceramic
NP3 acrylic PVC FPM (Viton®B) ceramic
TT1 PTFE with carbon PTFE with carbon PTFE ceramic
SS… stainless steel2) stainless steel2) PTFE ceramic
1)PP4 with Hast. C valve springs, 2) material no. 1.4571
DEVELOPAN®= pump diaphragm with PTFE layer.
Viton®(FPM) is a registered trademark of DuPont Dow Elastomers.
TechnicalData

Page14 of 88 pages Version2.0
3.2 Technical Data G/4b (with 180 strokes/min)
Gamma /4b, Typ 1001 1602 1203 0806 1003 1003 0313 0223
HV
Capacity (l/h) 0.3 1.5 2.5 5.3 3.4 3.0 13.0 23.0
Capacity (ml/stroke) 0.027 0.14 0.24 0.48 0.31 0.28 1.20 2.13
at max. counter pressure (bar) 10 16 12 8 10 10 3 1.5
Capacity (l/h) 0.42 1.8 2.9 5.6 3.7 3.7 15.5 25.5
Capacity (ml/stroke) 0.038 0.17 0.27 0.53 0.34 0.34 1.43 2.36
at med. counter pressure (bar) 5864551.51
Suction lift (m WS) 1.56636661.5
Priming lift
atz100% stroke length (m) ** 0.5 1.8 2.5 2.8 1.0 - 1.8 1.5
Max. pressure suction side(bar) 8.0 8.0 5.5 3.0 3.0 3.0 1.5 0.8
Max. stroking rate (stroke/min) 180 180 180 180 180 180 180 180
Liqid end version *** PP PP PP PP PP PP PP PP
NP NP NP NP NP - NP NP
with suction and TT TT TT TT TT - TT TT
discharge connections *** SS SS SS SS SS - SS SS
Connection size
o.Ø x i.Ø (mm) 6x4 6x4 6x4 6x4 8x5 DN10 8x5 12x9
Shipping weight. PP. NP. TT (kg) 2.7 2.7 2.7 2.7 2.9 2.9 2.9 3.1
Shipping weight. SS (kg) 3.4 3.4 3.4 3.4 4.1 4.1 4.1 4.7
Medium power drain
at max. 120 strokes/min (W) refer to typelabel
Peak power drain
at discharge stroke (A) refer to typelabel
**) Priming lifts with clean dampened valves for water and suction
**) line as specified.
Liquid end version Liquid end Suction/discharge valve seals valve balls
PP1 polypropylene polypropylene EPDM ceramic
PP2 polypropylene polypropylene FPM (Viton®A) ceramic
PP3 polypropylene polypropylene FPM (Viton®B) ceramic
PP41) polypropylene polypropylene EPDM ceramic
NP1 acrylic PVC FPM (Viton®A) ceramic
NP2 acrylic PVC EPDM ceramic
NP3 acrylic PVC FPM (Viton®B) ceramic
TT1 PTFE with carbon PTFE with carbon PTFE ceramic
SS… stainless steel2) stainless steel2) PTFE ceramic
1)PP4 with Hast. C valve springs, 2) material no. 1.4571
DEVELOPAN®= pump diaphragm with PTFE layer.
Viton®(FPM) is a registered trademark of DuPont Dow Elastomers.
Metering deviances For all material versions –5% to +15%
TechnicalData

Page15 of 88 pagesVersion2.0
TechnicalData
Reproducibility of the metering When used according to the instructions of the operating instructions
±2%
Permissible ambient temperature -10 °C to +45 °C
Resolution of the stroke setting 1:20
Power supply 230 V ±10%; 115 V ±10%, 50/60 Hz
Voltage range 207 to 254 V: 108 to 135 V
Enclosure rating IP 65
Insulation class F
Control function - Voltage level with
open contact : approx. +5 V
- Impedance : 10 kOhm
- Control : With voltage-free contact or semi-
conductor control with a residual
voltageof<700mV,thecontactload
is approx. 0.5 mA at +5 V.
Contact input - Voltage level with
open contact : approx. +5 V
- Impedance : 10 kOhm
- Control : With voltage-free contact or semi-
conductor control with a residual
voltageof<700mV,thecontactload
is approx. 0.5 mA at +5 V.
- Max. pulse freq. : 40 pulses/sec
- Necessary contact duration : 20 ms
Option Analog - current - Burden : approx. 70 ohm
- max. input current : 50 mA
Relay option
Fault indicating relay
max. load: 250 V – 2 A, floating
Pacing relay – max. load: 42 V – 0,1 A, floating

Page16 of 88 pages Version2.0
4 Installation dimensions
gamma/4b AB CD E FG
1000,1001, 1601,1602, 1201, 1203 PP 232 186 17 70 6x4 81 38
NP 230 179 19 70 6x4 81 38
TT 213 173 25 60 6x4 79 38
SS1 211 164 34 60 6x5 79 38
SK1 211 162 36 60 1/8" 79 38
0803, 0806 PP 232 186 17 70 6x4 81 38
NP 230 179 19 70 6x4 81 38
TT 213 178 20 70 6x4 79 38
SS1 211 169 29 70 6x5 79 38
1002, 1003 PP 225 186 17 70 8x5 76 50
NP 230 179 19 70 8x5 81 50
TT 216 206 -8 80 8x5 79 50
SS1 214 206 -8 80 8x7 77 50
0308, 0313 PP 225 186 17 70 8x5 75 50
NP 223 187 11 85 8x5 75 50
TT 216 206 -8 80 8x5 79 50
SS1 214 206 -8 80 8x7 77 50
0215, 0223 PP 225 197 6 90 12x9 76 66
NP 223 195 3 100 12x9 76 66
TT 216 214 -16 95 12x9 79 66
SS1 214 209 -11 95 12x10 77 66
1002 HV, 1003 HV PP4 214 172 -4 70 DN10 60 50
InstallationDimensions
Version
forPP4 = DN 10

Page17 of 88 pagesVersion2.0
5 Test for your safety
ThegammapumpseriesissuppliedwiththeCEsymbol.Thiscertifiesthat
itcomplieswithrelevantECregulationswhicharespecifiedintheconformity
declaration.
BG Chemie (Employersinsuranceass.) Test accordingtoZH 1/109 (closedrefilling
and metering systems - basic rules for the acceptance) passed in
connection with the appropriate liquid end version.
Tests

Page18 of 88 pages Version2.0
ConformityDeclaration
EC Declaration of Conformity
We, ProMinent Dosiertechnik GmbH
Im Schuhmachergewann 5 - 11
D - 69123 Heidelberg
hereby declare that, on the basis of its functional concept and design and in the version brought into circula-
tion by us, the product specified in the following complies with the relevant, fundamental safety and health
stipulations laid down by EC directives.
Any modification to the product not approved by us will invalidate this declaration.
Product description: Metering pump, Series Gamma/ _b
Product Type: G/4b…, G/5b…
Serial number: See type identification plate overleaf and on device
Relevant EC EC - machine regulation (89/392/EEC)
regulations: subsequently 93/44/EEC
EC - low voltage regulation (73/23/EEC)
EC - EMC - regulation 89/336/EEC
subsequently 92/31/EEC
Harmonised standards used, EN 292-1 , EN 292-2 , EN 809
in particular: EN 60335-1 A6 , EN 60335-2-41
EN 50081-1/2 , EN 50082-1/2 , EN 55014
EN 60555-2 , EN 60555-3
National standards and DIN VDE 0700 T1 , DIN VDE 0700 T41 , DIN VDE 0700 T500
technical specifications CSA Standard C 22.2 No. 0 - M 91 (115 V-Version)
used, in particular: CSA Standard C 22.2 No. 108 - M 89 (115 V-Version)
Date/manufacturer's signature: .......................................................................
The undersigned: Mr. Manfred Hüholt, factury manager
28.03.1996
