Prorack K423 User manual

K423
Fitting Kit
EN Fitting Instructions for Basic Carrier
x 4 x 8 x 12 x 2
x 8 x 8 x 4 x 4
Revision No: 11E 1

Fitting Kit K423
x 2 x 2 x 2 x 2
x 4 x 4 x 4
2

Fitting Kit K423
MAX kgs (lbs)
W/P WHD
Nissan
X-Trail Lowline, 5dr SUV 01-07 ZA 75 kgs (165 lbs) 75 kgs (165 lbs)
X-Trail, 5dr SUV 01-06 EU 75 kgs (165 lbs) 75 kgs (165 lbs)
X-Trail, 5dr SUV 04-04 CN 75 kgs (165 lbs) 75 kgs (165 lbs)
X-Trail, 5dr SUV 07-10 ZA 75 kgs (165 lbs) 75 kgs (165 lbs)
X-Trail, 5dr SUV 07-10 EU 75 kgs (165 lbs) 75 kgs (165 lbs)
X-Trail, 5dr SUV 07-10 CN 75 kgs (165 lbs) 75 kgs (165 lbs)
X-Trail, 5dr SUV 10-14 EU 75 kgs (165 lbs) 75 kgs (165 lbs)
X-Trail, 5dr SUV 10-14 ZA 75 kgs (165 lbs) 75 kgs (165 lbs)
X-Trail, 5dr SUV 10-Mar 14 NZ 75 kgs (165 lbs) 75 kgs (165 lbs)
X-Trail, 5dr SUV 10-Mar 14 AU 75 kgs (165 lbs) 75 kgs (165 lbs)
X-Trail, 5dr SUV Oct 01-Sep 07 NZ 75 kgs (165 lbs) 75 kgs (165 lbs)
X-Trail, 5dr SUV Oct 01-Sep 07 AU 75 kgs (165 lbs) 75 kgs (165 lbs)
X-Trail, 5dr SUV Oct 07-10 NZ 75 kgs (165 lbs) 75 kgs (165 lbs)
X-Trail, 5dr SUV Oct 07-10 AU 75 kgs (165 lbs) 75 kgs (165 lbs)
3

Fitting Kit K423
X
A B C 1 2 3
X-Trail Lowline, 5dr SUV 01-07 (ZA) -140mm 590mm - 875mm 840mm -
-5 -1/2ths" 23 1/4ths" - 34 7/16ths" 33 1/16ths" -
X-Trail, 5dr SUV 01-06 (EU) -140mm 590mm - 875mm 840mm -
-5 -1/2ths" 23 1/4ths" - 34 7/16ths" 33 1/16ths" -
X-Trail, 5dr SUV 04-04 (CN) -140mm 590mm - 875mm 840mm -
-5 -1/2ths" 23 1/4ths" - 34 7/16ths" 33 1/16ths" -
X-Trail, 5dr SUV 07-10 (ZA) -30mm 720mm - 885mm 855mm -
-1 -3/16ths" 28 3/8ths" - 34 13/16ths" 33 11/16ths" -
X-Trail, 5dr SUV 07-10 (EU) -30mm 720mm - 885mm 855mm -
-1 -3/16ths" 28 3/8ths" - 34 13/16ths" 33 11/16ths" -
X-Trail, 5dr SUV 07-10 (CN) -30mm 720mm - 885mm 855mm -
-1 -3/16ths" 28 3/8ths" - 34 13/16ths" 33 11/16ths" -
X-Trail, 5dr SUV 10-14 (EU) -30mm 720mm - 885mm 855mm -
-1 -3/16ths" 28 3/8ths" - 34 13/16ths" 33 11/16ths" -
X-Trail, 5dr SUV 10-14 (ZA) -30mm 720mm - 885mm 855mm -
-1 -3/16ths" 28 3/8ths" - 34 13/16ths" 33 11/16ths" -
X-Trail, 5dr SUV 10-Mar 14 (NZ) -30mm 720mm - 885mm 855mm -
-1 -3/16ths" 28 3/8ths" - 34 13/16ths" 33 11/16ths" -
X-Trail, 5dr SUV 10-Mar 14 (AU) -30mm 720mm - 885mm 855mm -
-1 -3/16ths" 28 3/8ths" - 34 13/16ths" 33 11/16ths" -
X-Trail, 5dr SUV Oct 01-Sep 07 (NZ) -140mm 590mm - 875mm 840mm -
-5 -1/2ths" 23 1/4ths" - 34 7/16ths" 33 1/16ths" -
X-Trail, 5dr SUV Oct 01-Sep 07 (AU) -140mm 590mm - 875mm 840mm -
-5 -1/2ths" 23 1/4ths" - 34 7/16ths" 33 1/16ths" -
X-Trail, 5dr SUV Oct 07-10 (NZ) -30mm 720mm - 885mm 855mm -
-1 -3/16ths" 28 3/8ths" - 34 13/16ths" 33 11/16ths" -
X-Trail, 5dr SUV Oct 07-10 (AU) -30mm 720mm - 885mm 855mm -
-1 -3/16ths" 28 3/8ths" - 34 13/16ths" 33 11/16ths" -
4

Fitting Kit EN
K423
First Time Installation
●Remove parts from inside the package and
check. Contact your dealer if any parts are
missing or damaged.
●This kit fits type A, B, C and D.
●These instructions show type A crossbar
fitted. They also apply to type B, C and D.
●Use keys to remove covers.
5

Fitting Kit EN
K423
●Use hex screwdriver to reverse adjusting
screw 10 turns.
●Press adjusting screw and pull crossbar
legs out. Refer to the crossbar instructions
for crossbar adjustment method.
●Ensure each end of the crossbar is
adjusted equally.
●Clamps onto flush roof rail. Pins locate on
inside of rail.
●Please check the front of this manual for
information relating specifically to your
vehicle.
●Set bars to length (revert to rear of these
instructions).
6

Fitting Kit EN
K423
●Tighten adjusting screw to 3 Nm (2.2 ft lb)
hand tight.
●Remove plastic clamp block by gripping bar
leg with fingers and push firmly with
thumbs until clamp block drops out behind
leg.
●Remove both pins from each leg. Use
tapered end of spanner located inside left
hand cover to assist.
7

Fitting Kit EN
K423
●Detach foot from leg. Store loose parts in a
safe place.
●Repeat for all legs.
●Foot Part Number:
X-Trail 07-10, 10-13
= 11-02-236A left
= 11-02-237A right
X-Trail 01-07
= 11-02-238A left
= 11-02-239A right
●Select four feet assemblies and match the
left and right assemblies to the left and
right roof rack legs.
●Using short capscrew and washer, secure
assembly onto leg (use Hex Screwdriver
supplied with crossbar to assist)
●Do not over tighten.
●Repeat for all legs.
8

Fitting Kit EN
K423
●Use two M5 x 12 mm self tapping screws to
secure the assembly onto the leg.
●Do not over tighten.
●Open or remove fixed-point covers.
●From the kit select the mounting plates and
fit the M6 x 25mm countersunk bolts
through the spacer and tighten.
9

Fitting Kit EN
K423
●Ensure edge of rail aligns with edge of slot.
●Apply protective strip as shown.
Trim if required.
●Use fixed-point cover to check spacer
height as shown.
