Prorack K443 User manual

K443
Fitting Kit
EN Fitting Instructions for Basic Carrier
x 2 x 2 x 4 x 4
Revision No: 7G 1

Fitting Kit K443
MAX kgs (lbs)
W/P WHD
Mazda
323 Familia, 5dr Estate 98-03 EU 40 kgs (88 lbs) 40 kgs (88 lbs)
Familia Import SP2, 5dr Hatch Sep 98-03 NZ 40 kgs (88 lbs) 40 kgs (88 lbs)
2

Fitting Kit K443
X
A B C 1 2 3
323 Familia, 5dr Estate 98-03 (EU) -100mm 530mm - 764mm 726mm -
-3 -15/16ths" 20 7/8ths" - 30 1/16ths" 28 9/16ths" -
Familia Import SP2, 5dr Hatch Sep 98-03 (NZ) -100mm 530mm - 764mm 726mm -
-3 -15/16ths" 20 7/8ths" - 30 1/16ths" 28 9/16ths" -
3

Fitting Kit EN
K443
First Time Installation
●Remove parts from inside the package and
check. Contact your dealer if any parts are
missing or damaged.
●This kit fits type A, B, C and D.
●These instructions show type A crossbar
fitted. They also apply to type B, C and D.
NOTE: Clamp images in these instructions may
not be representative of the clamps in this kit
4

Fitting Kit EN
K443
●Use keys to remove covers.
●Use hex screwdriver to reverse adjusting
screw 10 turns.
●Press adjusting screw and pull crossbar
legs out. Refer to the crossbar instructions
for crossbar adjustment method.
●Ensure each end of the crossbar is
adjusted equally.
5

Fitting Kit EN
K443
●Remove locking screw.
●Apply protective strip as shown.
Trim if required.
●Letters refer to the part numbers stamped
on clamps.
●Clamp Part Number:
A = 597A
B = 598A
6

Fitting Kit EN
K443
●Attach clamp to each leg. NOTE; clamps
may have labels showing their positions on
the vehicle (For example; "Front Right").
●Refit locking screw so that it goes through
the hole in the clamp. Do not begin to
tighten the locking screw.
●Fit rubber pads (supplied with fitting kit) to
foot.
7

Fitting Kit EN
K443
●Make sure the pad fits into the holes
underneath the foot.
Fitment
●Place crossbar on vehicle. Minimum
recommended spacing between the bars is
700mm (27 1/2") (unless otherwise stated).
●Clamps directly to edge of roof under the
doors
●Please check the front of this manual for
information relating specifically to your
vehicle.
●Adjust the legs on the crossbar so that they
are positioned equally from the ends of the
crossbar, and the clamps engage firmly on
the body work of the vehicle.
8

Fitting Kit EN
K443
●Tighten adjusting screw to 5 Nm (3.7 ft lb)
hand tight.
●Tighten locking screw on both legs evenly.
●Check crossbar is securely attached to the
vehicle.
9

Fitting Kit EN
K443
●Use keys to fit and lock covers
CAUTION: Recheck all fasteners immediately after
a load is applied to the crossbars.
Regularly check screws are tight.
10
