protech Prox SG-S152 User manual

Ver. Q1
All Rights Reserved. Copyright 2023
SG-S152 / SG-S162 / SG-S172
SG-S152/SG-S162/SG-S172
SG-S152/
SG-S162/
SG-S172
Quick
Reference
Guide
Specifications
used batteries according to the manufacturer’s instructions.
Danger of explosion may occur if the battery is replaced incorrectly. Replace batteries only with the same or equivalent type recommended by the manufacturer. Dispose the
The waterproof capability of the device may be incapable when the screws are loosened.
The O-ring to seal the device may be damaged during the maintenance process. Qualified engineer is recommended to make the O-ring replacement to keep the waterproof
capability of the device.
Jumper Setting
CAUTION!
Low Pin Count
Selection
1
(default)
80 Port LPC Device
1
1
Clear CMOS Data
Selection
(default)
Normal Clear CMOS
1
USB Power
Selection
1
S5,
USB Power=5V
S5,USB Power=0V
(default)
1
LVDS Voltage Selection
5V
1
(default)
LVDS Backlight Control
Selection
(default)
5V
1
1
COM1 Port
Voltage
Selection
12V
1
1
5V
(default)
NC
1
LVDS Sequence Control
Selection
BKLTCTL
from CPU
(default)
1
26
5
6
51
2
BKLTEN
from CPU
(default)
USB2
USB1
JDP_HDMI1
LAN1LAN2
JSPI
1
2
7
1
JCOMS1
JLED1 JBAT1
JBTN1
1
1
1
1 2 PWR2
JDIO2
JDIO1
JCOM2
JCOM1
JUSB1
JAUDIO1
1 2
1 2
1 6
1 6
1 2
JP_COM1
1
M2_E1
JUSB2
LVDS1
JINV1
M2_M1
SATA1 JHD_PWR1
1
71
1
2
57
58
67
68
74
75
1
1
M.2 Wi-Fi
1
24
1
JP_VDD1
JP1
1
JP7
SO-DIMM1
M.2 SSD
M2 M1
JP_USB1
1
19
10
JLPC1
1
JP_LPC1
M_PCIE1
1
2
16
1
2
29
30
1
(DP & HDMI)
System
CPU Support Intel®Celeron®J6412 processor
Intel®Atom®x6425RE processor (option)
Memory Support 1 x DDR4 3200MHz SO-DIMM socket (up to 32GB) (non-ECC)
Operating System Windows®11 / Windows®10 IoT LTSC 64bit
Ubuntu 20.04 (Kernel 5.4)
Mounting Support VESA 100 / Stand
Power Input DC In 12V/24V
Watchdog 1~255 second Watchdog timer selectable
System Weight SG-S152:13kg / SG-S162: 12.7kg / SG-S172: 14.4kg
Dimensions (WxHxD) SG-S152:420 x 335 x 92.1mm/ SG-S162:450 x 305 x 92.5mm
(w/o Stand) SG-S172: 450 x 381 x 96.1mm
Enclosure Stainless SUS304
IP Rating IP66 / IP69K
I/O Ports
LAN 2 x 1GbE LANs with M12 waterproof connectors
Supports Wake-On-LAN
Power Input 1 x M12 waterproof connector, supporting 12V/24V DC
USB 2 x USB 2.0 M12 waterproof connectors (4 x USB ports)
Serial Ports 2 x COM M12 waterproof connectors, with RS-232/422/485
Storage 1 x 2.5" SATA III SSD
Expansion Bus 1 x full-sized Mini PCIe slot (Mini PCIe and USB signal)
Environment
Operating Temperature 0°C~50°C (32°F~122°F)
(with airflow) -20°C~50°C (-4°F~122°F) (Wide-ranged temp. sku and components)
Storage Temperature -20°C~80°C (-4°F~176°F)
Humidity 20% ~ 90%
Display
LCD SG-S152: 15” TFT LCD (LED) resolution 1024 x 768
SG-S162: 15.6” TFT LCD (LED) resolution 1366 x 768
SG-S172: 17" TFT LCD (LED) resolution 1280 x 1024
Touchscreen Projected capacitive touchscreen (USB interface)
or 5-wire resistive touchscreen (option)
Dimensions (WxHxD) SG-S152:420 x 387.5 x 160mm/SG-S162:450 x 372.5 x 160mm
(with Stand) SG-S172:450 x 433.5 x 160mm
Certifications FCC / CE

Safety Precaution
Front View Rear View
All Rights Reserved. Copyright 2023
Rear I/O View
•
Do not turn the system upside down. This may cuase the hard drive to mal-function.
4. Good Care
•When the outside of the case is stained, remove the stain with a neutral washing agent with a dry cloth.
•Never use strong agents such as benzene and thinner to clean the system.
•If heavy stains are present, moisten a cloth with diluted neutral washing agent or with alcohol and then wipe thoroughly with a dry cloth.
•If dust has been accumulated on the outside, remove it by using a special vacuum cleaner for computers.
CAUTION! Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the manufacturer’s instructions.
WARNING! Some internal parts of the system may have high electrical voltage. And therefore we strongly recommend that qualified engineers
can open and disassemble the system. Please handle LCD and Touchscreen with extra care as they are easily breakable.
3. Handling
Avoid putting heavy objects on top of the system.
•
•
•
•
•
•
•
•
•
•
The following messages are reminders for safety on how to protect your system from damages and extend a long life of the system.
1. Check the Cable Voltage
The range of operating voltage should be DC 12V/24V. Otherwise, the system could be damaged.
2. Environmental Conditions
Place your SG-S152 / SG-S162 / SG-S172 on a sturdy, level surface. Be sure to allow enough space to have easy access around
the system.
Avoid extremely hot or cold place to install the system.
Avoid exposure to sunlight for a long period of time or in an airtight space.
Avoid the system from any heating device or using the system when it’s been left outdoors in a cold winter day.
Bear in mind that the operating ambient temperature is from 0°C ~ 50°C ((32°F~122°F).
Avoid moving the system rapidly from a hot place to a cold place and vice versa because condensation may come from inside
of the system.
Placing the sy in strong vibrations may cause hard disk failure.
Don’t place the system close to any radio-active device in case of signal interference.
SG-S152 Overview
SG-S162 Overview
SG-S172 Overview
Quick Setup
Installing VESA Mount VESA Mount Accessories
Installing Stand Kit Stand Installation Accessories
(Unit: mm)
Top View
Bottom View
Front View Rear View Top View
Bottom View
Rear I/O View
Front View Rear View Rear I/O View Top View
Bottom View
Wall
VESA Mount
VESA Mount Kit x 1
Step 1. Attach Panel PC onto Stand Kit and align the side holes on the rear
of Panel PC with the upper holes of the Stand Kit.
Step 2. Fasten the two handles into the side holes of the Stand Kit
to secure the system and complete.
Stand Kit
Handle
upper hole of
Stand Kit
Stand Kit x 1 + Screw x 4
Handle x 2
Hand Screw Bracket x 2
+ Screw x 4
Hand Screw Bracket
P/N: 20-206-07001527
M4x0.7P screw
P/N: 22-210-40010011
P/N: 20-035-35001000
M4 x 0.7P screw
P/N: 22-240-40020011
66.50
C.L.333
C.L.100 (VESA)
233 37
100 (VESA)
ANT ANT
Antenna
Hole
Antenna
Hole
I/O Ports
COM VENT COMUSB
USBLAN
LAN
DC IN
VENT
USBLANDC IN LAN USB COM COM
VENT
LAN
LAN
DC IN
Power
Switch
w/LED
COM1
COM2
(colay Audio)
(colay DIO)
2 x USB Connectors
(4 x USB 2.0 Ports)
420
335
ANT ANT
Antenna
Hole
Antenna
Hole
I/O Ports
COM
VENT
COMUSB
USBLAN
LAN
DC IN
450
305
381
450
ANT ANT
Antenna
Hole
Antenna
Hole
I/O Ports
COM
VENT
COMUSB
USBLAN
LAN
DC IN
Side View
92.10
42.60 48.50
Side View
92.50
42.60 48.50
Side View
96.10
233 73
46.60
48.50
233
35.50
66.50
C.L.333
C.L.100 (VESA)
100 (VESA)
66.50
C.L.333
C.L.100 (VESA)
100 (VESA)
VENT
USBLANDC IN LAN USB COM COM
VENT
LAN
LAN
DC IN
Power
Switch
w/LED
COM1
COM2
(colay Audio)
(colay DIO)
2 x USB Connectors
(4 x USB 2.0 Ports)
VENT
USBLANDC IN LAN USB COM COM
VENT
LAN
LAN
DC IN
Power
Switch
w/LED
COM1
COM2
(colay Audio)
(colay DIO)
2 x USB Connectors
(4 x USB 2.0 Ports)
