Protector EASY SCREEN User manual

Josh and Jenna show you how
at www.protectoraluminium.com.au
EASY SCREEN SPECIFICATIONS
(PART A) Blades 76x16x1994mm
(PART B) Slat End Rails
20x20x2000mm
(PART C) Slat Top/Bottom Rails
25x25x2000mm
(Rails and Blades can be cut to fi t the size you require)
Fixing Brackets – 25x20 angle x 80mm – packs of 4
Screws – Wafer Head 16mm long – packs of 50
(4 screws required per blade and 8 screws per Top/Bottom Rail)
BLADE CALCULATOR
The calculator shows at a glance the number of blades (PART A)
required to fi t maximum height 2000mm.
S L AT
C
A
B
Max width 2000mm Max width 2000mm
Max height 2000mm
LOUVER
C
A
B
(PART A) Blades 76x16x1994mm
(PART B) Louver End Rails
L & R required 50x25x2000mm
(PART C) Louver Top/Bottom Rails
55x25x2000mm
EASY SCREEN
INSTALLATION GUIDE
2000
1750
1500
1250
1000
750
500
250
Height in mm
20
18
16
14
12
10
8
6
4
2
No. of blades
required:
0
2000
1750
1500
1250
1000
750
500
250
32
30
28
26
24
22
20
18
16
14
12
10
8
6
4
2
No. of blades
required:
S L AT LOUVER

FIX TO WALL
CUT TO SUIT
100-500mm
HOW TO ASSEMBLE YOUR EASY SCREEN
Tools Required: Pencil, String-line, Tape Measure, Spirit Level, Drill, Tek Gun/Drill,
Angle Grinder/Hacksaw
HOW TO INSTALL YOUR EASY SCREEN
If using the Easy Screen Fixing Brackets:
1. Remove the two screws from each side of
the screen as shown.
2. Fit bracket in position so the holes line
up and re-fit the screws. Repeat for the
other brackets as required.
3. Hold the Easy Screen in place and mark
hole position.
4. Position screen and screw in place
through the Fixing Brackets
If using Easy Screen Mounting Brackets:
1. Mark and cut bracket (A) to required
length
2. Fix bracket in position with suitable
fixing screws.
3. Position and fix the Mounting Brackets
(B) to the back of the Screen using
self-drilling screws or rivets.
4. Position and mark the hole to the
wall.
5. Fix the Screen to the wall with suitable
fixing screws.
CUSTOM SERVICE AVAILABLE
If you can dream it, we
can make it! Any size,
any colour. Visit Bunnings
Warehouse Special Orders
for details.
Bracket Positioning
SLAT
LOUVER
LOUVER
SLAT
1. Cut Blades (A) 5mm shorter than total
width of Screen.
2. Cut Side Rails (B) 4mm shorter than
total height of Screen.
3. Cut Top/Bottom Capping (C) to total
width of Screen.
4. Insert Blades into side Rails (B).
Fit top/bottom capping (C).
5. Screw Top/Bottom Capping to side Rails.
Screw side Rails to Blades through
holes provided.
A
A
B
B
C
C
SIDE
FRONT
Awning Bracket Fixing
A
B
