Tempur-Pedic ERGO Twin Long User manual

ERGOTM
+ SLEEPTRACKER®SYSTEM
OWNER’S MANUAL
MANUEL DU PROPRIÉTAIRE
Tempur-Pedic Customer Service U.S. : 1-844-309-3597 | Canada: 1-800-887-4321 | México: 01-722-273-1810
Service à la clientèle Tempur-Pedic É-U. : 1-844-309-3597 | Canada : 1-800-887-4321 | México: 01-722-273-1810
Servicio al Cliente Tempur-Pedic É-U. : 1-844-309-3597 | Canada : 1-800-887-4321 | México: 01-722-273-1810
MANUAL DEL PROPIETARIO

table of contents
Safety Precautions and Usage Statements ......................................................1-4
Parts List ...................................................................................... 5
Base Overview ................................................................................ 6
Quick Reference Guide ..........................................................................7
Installation Guide ............................................................................ 8-9
Remote Control .............................................................................10-11
Remote Control Pairing .........................................................................12
Emergency Battery Backup Box ................................................................13
Connecting Strap ..............................................................................14
Syncing Two Bases.............................................................................15
Headboard Brackets (not included)..............................................................16
Troubleshooting ...............................................................................17
Warranty ...................................................................................18-19

table des matières
Consignes de sécurité et directives d’utilisation ..............................................20-23
Liste des pièces ...............................................................................24
Aperçu de la base ............................................................................ 25
Guide de référence rapide .....................................................................26
Guide d’installation ......................................................................... 27-28
Télécommande ............................................................................29-30
Couplage des télécommandes ..................................................................31
Boîtier des piles de secours .................................................................... 32
Attaches de raccordement.....................................................................33
Synchronisation de deux bases ................................................................34
Guide d’installation des xations de la tête de lit (non incluses) .................................. 35
Dépannage ...................................................................................36
Garantie................................................................................... 37-38

tabla de contenidos
Precauciones de Seguridad. ................................................................39-42
Lista de las Partes.............................................................................43
Diagrama de la Base .........................................................................44
Guía de Conexiones. ..........................................................................45
Guía de Instalación de la base ..............................................................46-47
Control Remoto ...........................................................................48-49
Conguración de Control Remoto ..............................................................50
Caja de Emergencia ...........................................................................51
Correas de Conexión .......................................................................... 52
Sincronización de Dos Bases. .................................................................. 53
Guía de Instalación de Soportes de la Cabecera (opcional /no incluida) ............................54
Solución de Problemas. ....................................................................... 55
Garantía...................................................................................56-57

1
safety precautions and usage statements
Attention: Important Safety Disclaimers
Read all instructions before using your TEMPUR-PEDIC ERGOTM + SLEEPTRACKER®SYSTEM adjustable base.
SAVE THESE INSTRUCTIONS.
To reduce the risk of shock, burns, re or injury:
Always unplug the base from the electrical outlet before servicing any
part of the base. To reduce risk of electric shock, unplug the base before
cleaning. To safely disconnect, ensure the base is in a at position with all
motors off, and unplug from power source.
Keep the power cord away from heated surfaces. Never operate the base
when the air openings are blocked. Keep air openings free of lint, hair and
the like. Do not drop or insert any object into any opening.
Discontinue use of the bed base and contact a qualied service center if: it
has a damaged cord or plug, is not working properly, or has been dropped
into water.
Only use this bed base for its intended use as described in this manual.
Do not use accessories/attachments that are not recommended by the
manufacturer.
Close supervision is required when the bed base is used by or near children,
convalescents or disabled persons.
Outlet Safety:
For optimal safety and operation, plug bed base into a
surge protector (not included).
The bed base should only be plugged directly into a wall outlet or surge
protector (recommended). Improper connection of the equipment can result
in the risk of electrical shock, electrical re or faulty operation of this bed
base. If the plug does not t your outlet, contact a qualied electrician to
install a suitable outlet. Unauthorized modication or failure to use a wall
outlet or surge protector could void the electrical portion of your warranty.
Warranty Warning:
Do not open or tamper with control box, motors, or remote (with the
exception of battery compartments). The warranty will be void if the internal
workings of these components are tampered with. For complete warranty
information refer to the warranty information section on pages 18-19.
In-Home Use and Hospital Disclaimer:
The TEMPUR-PEDIC ERGOTM + SLEEPTRACKER®SYSTEM adjustable bases
are designed solely for in-home use. This base was not designed as a
hospital bed and is not designed to meet hospital standards. Do not use this
base with TENT TYPE oxygen therapy equipment or near explosive gases.
Pets and Small Children:
Immediately dispose of all packing materials as they may pose a smothering
risk to small children and pets. To avoid injury, it is not advised to allow
children and small pets to play on or under the bed. Children should not
operate the bed base without adult supervision.
Safety Features:
Free-release head and foot motors are designed to lower the mattress by
retracting only with gravity, never pulling downwards, which minimizes pinch
points.
The remote control is programmed with a child lock feature. More
information on activation and deactivation of this feature can be found on
page 12.
Model No:
Twin Long: 19003-38.80-4166
Full: 19003-54.74-4166
King: 19003-76.80-4166
CA King: 19003-72.84-4166
Queen: 19003-60.80-4166
CA King Split: 19003-36.84-4166
Power Ratings:
INPUT: AC 100–240V 50/60 HZ 2.0A
OUTPUT: DC 29V 2.0A
WATTS: 58W

2
Product Ratings:
The lift motors are not designed to operate continuously for more than two
[2] minutes in an eighteen [18] minute time period or approximately 10% duty
cycle. Attempting to circumvent or exceed this rating will shorten the life
expectancy of the product and may void the warranty.
The massage motors are not designed to operate continuously for more
that 30 minutes at a time. Please allow the massaging system to rest for 30
minutes after automatic massage shut off before restarting.
Weight Limits:
The recommended weight limits on the TEMPUR-PEDIC ERGOTM +
SLEEPTRACKER®SYSTEM are:
Twin Long / Full / Queen / King / Split CA King / CA King: 700 pounds.
Maximum weight the bed can support per person is 275 pounds with the
weight evenly distributed across the head and foot sections. This product
is not designed to support or lift this amount of weight in the head or foot
sections alone. NOTE: Exceeding the recommended weight restrictions could
damage your TEMPUR-PEDIC ERGOTM + SLEEPTRACKER®SYSTEMand void
your warranty. For best performance, you should enter and exit the TEMPUR-
PEDIC ERGOTM + SLEEPTRACKER® SYSTEM while it is in the at or fully
lowered position.
TEMPUR-PEDIC ERGOTM + SLEEPTRACKER® SYSTEM ts easily inside
bed frames, furniture beds and platform beds that are certied to hold a
minimum of 900 pounds. If using this adjustable base without the legs
and placing directly on a bed frame or platform bed, cross-bed supports
(slats) are strongly recommended to ensure TEMPUR-PEDIC ERGOTM +
SLEEPTRACKER®SYSTEM maintains stability during operation.
Acoustics:
In normal base operation the wheels, which allow the bed to maintain its
distance from the wall, will make contact with the steel platform supports of
the base creating a contact noise. When entering, exiting or shifting weight
on the base, this contact noise may be audible as the wheels make contact.
This is normal.
Fabric Care:
To prolong the life of your fabric, protect from direct sunlight whenever
possible. For spot cleaning, wipe area with a light damp sponge or vacuum
with a soft brush attachment to remove particles. Keep at a minimum of
30cm (12 inches) away from direct heat sources.
For deeper cleaning, blot liquid spills with a clean dry cloth. Wipe with a clean
cloth dampened with warm water. Do not wet excessively. A soft bristle brush
may be used to remove ingrained soil. Avoid scratching by gentle brushing.
Wipe with a clean cloth dampened with warm water to remove residues after
brushing. Dry in shade away from direct heat.
If persistent marks remain visible after cleaning, seek professional advice.
Tempur-Pedic®Sleeptracker®System
For Tempur-Pedic Ergo™
System Components
Sleeptracker Sleep Monitoring System Model STS-40:
- One Sleeptracker Processor Units
- One or two Sleeptracker Sensors*
Sleeptracker Smart Cable Model STC-10
Quick Start Card with QR code
Safety and Warranty Information
safety precautions and usage statements
FCC Compliance:
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference and (2) this device must accept any interference received,
including interference that may cause undesired operation.
To comply with the FCC RF exposure compliance requirements, no
change to the antenna or the device is permitted. Any change to the
antenna or the device could result in the device exceeding the RF
exposure requirements and void user’s authority to operate the device.
Radio Frequency: 2.4 GHz
CAN ICES-3 (B)/NMB-3(B)
Exceeding this weight restriction could damage the bed
and/or cause injury and will void the warranty.

3
*Note: the number of sensor units included depends on the particular
Tempur-Pedic Ergo + Sleeptracker System size purchased.
Specications
Sleeptracker Sleep Monitoring System Model STS-40:
- Input power: 5V DC, 500mA
- Wi-Fi mode: 802.11 b/g/n 2.4G Band
- Wi-Fi frequency range: 2412.0–2462.0 MHz
- Wi-Fi AP broadcast: 2.4GHz
- Wi-Fi AP channel: Variable, 1 through 11.
Channel selection is performed by scanning the area to choose a
non-overlapping channel.
- Wi-Fi output power: 0.25 watts
Sleeptracker Smart Cable Model STC-10: - Input power: 29V DC, 100mA
- Output power: 5V DC, max 500mA
Certications:
- FCC Part 15B, FCC Part 15C
- Industry Canada ICES-003, RSS-210
© 2019 Tempur Sealy International, Inc.
All rights reserved. Tempur-Pedic is a registered trademark of Tempur Sealy
International, Inc. Tempur-Pedic Ergo and Tempur-Pedic Ergo Extend are
trademarks of Tempur Sealy International, Inc.
© 2005–2019 Fullpower Technologies, Inc.
All rights reserved. U.S. and international patents granted and pending.
Sleeptracker is a trademark of Fullpower Technologies, Inc., registered in the
U.S. and other countries.
For assistance visit our web site: www.sleeptracker.com
Services and app availability are subject to change at any time, may not be
available in all areas and may require separate subscriptions.
This product is not a medical device and should not be used to diagnose or
treat any medical condition.
Designed in Santa Cruz, California
Made in China
System Requirements:
• Mobile device running iOS or Android
• Existing Wi-Fi network
Requires Tempur-Pedic®Sleeptracker®app from Fullpower Technologies,
available on the Apple App Store or on Google Play. Requires Wi-Fi
connection to your home network, and Internet access via a router or modem.
Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S.
and other countries. App Store is a service mark of Apple Inc., registered in
the U.S. and other countries. iOS is a trademark or registered trademark of
Cisco in the U.S. and other countries and is used under license.
Google Play, Android and the Google Play logo are trademarks of Google Inc.
100–240 V AC 50/60 Hz
Contains transmitter module FCC ID: H8N-WLL6540, IC: 1353A-WLL6540.
Tempur-Pedic North America, Inc.
1000 Tempur Way
Lexington, KY 40511
Tempur-Pedic Canada
145 Milner Ave.
Scarborough, Ontario M1S 3R1
FCC Certication Statement
This equipment complies with Part 15 of the FCC Rules. Operation of this
safety precautions and usage statements

4
safety precautions and usage statements
equipment is subject to the following two conditions: (1) the equipment may
not cause harmful interference, and (2) the equipment must accept any
interference that might cause undesired operation.
Radio and Television Interference
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
an can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that such interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by taking one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Important: Any changes or modications not expressly approved by Tempur
Sealy International (”Tempur”) could void the electromagnetic compatibility
compliance and negate your authority to operate this equipment.
This equipment was tested for FCC compliance under conditions that
included the use of Tempur peripheral devices and Tempur cables and
connectors between system components. It is important that you use Tempur
cables and connectors between system components to reduce the possibility
of causing interference to radios, television sets, and other electronic devices.
You can obtain proper Tempur cables and connectors through an Tempur-
authorized dealer.
Responsible party (contact for FCC matters only):
Tempur-Pedic North America, Inc.
1000 Tempur Way
Lexington, KY 40511
Sleeptracker Sleep Monitoring System model STS-40 contains FCC ID H8N-
WLL6540.
Industry Canada Statement of Compliance
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device. This device
complies with ICES-003 Class B specications of Industry Canada.
Responsible party (contact for Industry Canada matters only):
1390658 Ontario Inc (Tempur Canada)
145 Milner Ave.
Scarborough, Ontario
M1S 3R1
Sleeptracker Sleep Monitoring System model STS-40 contains IC
1353A-WLL6540.
Exposure to Radio Frequency Energy
This equipment complies with radiation exposure limits set forth in the FCC’s
OET Bulletin 65 and Industry Canada’s RSS-102 standard for an uncontrolled
environment. This equipment should be installed and operated with minimum
distance of 20cm (about 8 inches) between the radiator and your body. This
equipment must not be co-located or operating in conjunction with any other
antenna or transmitter.
Pacemaker Notice
If you use a medical device such as a pacemaker or implantable cardioverter-
debrillator (ICD), please consult your physician before using this product.

5
parts list
All electronics and components that need to be installed
are located in boxes under the base or attached to the
frame.
A) Wireless Remote Control (1) AAA Batteries (3)
B) Mattress Retainer Bar (1)*
C) Legs (6)
D) Power Cord (1)
E) Power Supply (1)
F) Battery Backup Box (1) (9-Volt batteries not included)
G) Connecting Strap ‡*
H) Sync Cord ‡
Miscellaneous Parts (not included):
Surge Protector (1)
9 Volt Batteries (2)
* These items are attached to the base for shipping purposes.
Carefully remove from base and set aside.
‡ Only included in Twin Long, and California King Split bases.
Before discarding the packing materials, ensure all the parts are accounted for.
A
D
G
B
E
C
F
H
IMPORTANT!: For your safety, read the owner’s manual
carefully and completely before operating this product.
Electric shock may occur if electrical components are not
installed or operated according to these guidelines.
A) * C)
D) E) F)
‡* ‡

6
base overview
Foot
Motor
Head Motor
Control Box Sleeptracker®
Smart Cable
USB Ports
Sleeptracker®
Sensor
Sleeptracker®
Sensor USB Ports
Massage Motor
Massage Motor
Battery Backup Box
Underbed Light
Underbed Light
Underbed Light
Sleeptracker®
Processor
USB Extension
Cable

7
Not to scale. For illustration purposes only. Read all instructions before beginning installation.
If installing a split unit, see page 15.
quick reference guide
Power Cord Input
Power Cord
Power Supply
Control Box
connection
ports
to head and
foot motors
(massage and
lift). Installed
under the base.
Battery
Backup Box
USB Charging Ports
USB Charger
Splitter
Underbed Lighting
Sleeptracker®
Sensor
Sleeptracker®
Sensor
Sleeptracker®
Processor
USB
Extension
Cable
Sleeptracker®
Smart Cable

8
Legs are shipped fully assembled. Alternative heights in 3"
increments can be achieved by removing leg segments.
To install the legs, thread the leg into frame, and tighten by
hand. Do not over tighten.
STEP 1
STEP 2
installation guide
Always use two people when setting up the base.
Place the bed base box in a desired location with the
bottom of the box facing up.
Remove the binding straps and packing materials, making
sure not to puncture the box with any sharp objects.
Remove the bed base from the box.
Unfold the bed making sure to keep the
bottom of the bed facing upwards.
STEP 3
STEP 4
STEP 5
STEP 6
Uncoil input power cord (connected
to control box's power port) and
plug into power supply.
If installing a split unit, see page 15.
To install headboard brackets (sold separately), see
instructions on page 16.
Locate the battery backup box
and install (2) 9-Volt batteries (not
included).
(For operating instructions see page
13).
Uncoil the power cord and connect to
the power supply. Place power supply
on the ground and extend from the
base. Ensure that the power supply
and all attached cords are directed
toward the desired
surge protector.
For Tempur-Pedic customer service call: U.S. 1-844-309-3597 | Canada: 1-800-887-4321 | México: 01-722-273-1810

9
STEP 7
STEP 8
STEP 9
Carefully ip the base over on to its legs. Important: Two
people are required to move the bed base. Do not drag
across the oor. Do not rest frame on its side, excessive
pressure may damage the legs.
Plug the power cord into a power source. A surge
protector is recommended.
Ensure batteries are correctly installed in the back of the
remote.
Quickly test functions to verify proper setup before placing
mattress on base. Return the base to a at position before
placing the mattress on top.
Setup is now complete! Test all functions on remote.
To install the mattress retainer bar, insert each end of the
bar into the holes at the foot of the platform.
installation guide
STEP 10
For Tempur-Pedic customer service call: U.S. 1-844-309-3597 | Canada: 1-800-887-4321 | México: 01-722-273-1810
STEP 11
STEP 12
Raise head of the base to maximum articulation.
Remove Sleeptracker®Sensor(s)
from twist ties. Queen, Full and
King/Cal King bases will have 2
sensors each.
STEP 13
STEP 14
Insert Sleeptracker®Sensor(s) into pocket on top of base.
Secure pocket to velcro strip.
Find the QR code included on the Let's Get Started card
and scan using a QR code reader app from your phone for
help installing the Tempur-Pedic®Sleeptracker®app.
Information can also be found at :
https://www.sleeptracker.com/getapp/tempur

10
Remote Control arrives paired to the adjustable base.
Three (3) AAA batteries are required to operate the remote.
remote control
MASSAGE
Head Zone Massage Control
Activates simple steady-state massage and
toggles through 2 intensity levels. Low, high
and off.
Foot Zone Massage Control
Activates simple steady-state massage and
toggles through 2 intensity levels. Low, high
and off.
Massage Wave Mode Control
Turns on and activates programmed
massage mode. Toggles wave modes 1, 2 ,3
and off. Intensity default to low.
There are 3 possible wave massage modes and 2 intensity levels
to choose from. Press the Wave Massage Mode Selector to choose
the desired mode (1,2,or 3), then use the Head Massage and/or the
Foot Massage buttons to cycle through the available intensity levels.
Once the massage mode is chosen, it will run for 30 minutes unless
it is cancelled by pressing the Wave Massage Mode Selector button
repeatedly until massage stops.
If one of the wave massage modes is not needed, pressing Head
and/or Foot Massage buttons will initiate massage for those sections
and cycle through 2 different intensity levels as well as "OFF".

11
remote control
ADJUST
Head Position Adjustments
Use to raise and lower the head section of
your adjustable base.
Foot Position Adjustments
Use to raise and lower the foot section of
your adjustable base.
PRESET
Zero G ‡
Adjusts your legs to relieve pressure off the
lower back.
Flat *
One-Touch Flat lowers head and foot to at
position and turns off massage (if running).
TV in Bed Preset Position ‡
Brings head and foot into position for
viewing TV.
Anti-Snore Preset Position ‡
Raises the head of the bed slightly to help
open airways.
Favorite 1 Preset Position ‡
Reprogrammable Preset Position.
Underbed LED lighting *
Turn on/off underbed LED lighting.
* Not user programmable.
‡ Can be reprogrammed to user desired position.
The ZERO G, TV in Bed, Anti-Snore, and Favorite 1 in
bed presets can be re-programmed to any position
chosen by the user. Simply adjust the bed to the desired
position, then hold any of the 4 buttons down until the
remote backlight ashes twice. The button is now re-
programmed.
To restore the buttons to their original positions, depress
the One-touch Flat and Zero-G buttons simultaneously
for 5 seconds. The remote backlight will ash twice to
indicate the original positions have been restored.
Remote Control arrives paired to the adjustable base.
Three (3) AAA batteries are required to operate the remote.

12
remote control pairing
Remote Pairing
*ALTERNATE REMOTE PAIRING PROCESS
Locate the control box (see parts list on page 6) and
press the button twice. A green LED light will illuminate
on the control box. On the back of the remote, press and
hold the PAIR button. The PAIR button will illuminate
blue and start ashing. When the PAIR button stops
ashing, the green LED light on the control box will go
out. Release the PAIR button. The remote is now paired
to the adjustable base.
Battery
backup box
button
PAIR
Button
Test all remote functions. If the remote buttons do
not impact the adjustable base movements, please
repeat the process again or call Tempur-Pedic customer
service: U.S. 1-844-309-3597 | Canada : 1-800-887-4321
México: 01-722-273-1810
STEP 1
STEP 2
The original remote that comes in the box is already paired to the adjustable base. No further action is required. In the event
that the remote is not paired with the base, follow the steps below.
Locate the battery backup box and
press the button TWICE. A light
on the battery back up box will
illuminate.
Remove the back cover of the
remote, press and hold down the
PAIR button. The PAIR button will
illuminate blue and start ashing.
When the PAIR button stops
ashing, the illuminated light on
the battery backup box will go
out. Release the PAIR button.
The remote is now paired to the
adjustable base.
STEP 3
Child Lock Feature
Press and hold HEAD UP and HEAD DOWN
buttons together for approximately six (6) seconds.
The remote backlight will ash twice. When the
backlight light goes away, the remote is now in
Child Lock. Pressing any buttons while in Child
Lock will yield no movement to your adjustable
base.
Press and hold FOOT UP and FOOT DOWN buttons
together for approximately six (6) seconds. The
remote backlight will ash twice. When the
backlight light goes away, the remote is no longer
in Child Lock. The remote and adjustable base will
work normally.
Activate Child Lock
Deactivate Child Lock

13
emergency battery backup box
Two (2) 9 Volt batteries are required to operate the battery backup box feature and are NOT included.
For emergency use only, in case of a power outage.
In the event that the base is stuck in an articulated
position during a power outage, the battery backup
box will return the base to a at position. Batteries
are not to be used for normal operation of the base.
Install the 9 Volt batteries into the provided battery
backup box.
Do not mix brand name batteries.
Press the button on the battery backup box to
lower the base to at position.
OVERVIEW
STEP 2
STEP 1
For Tempur-Pedic customer service call: U.S. 1-844-309-3597 | Canada: 1-800-887-4321 | México: 01-722-273-1810
Control Box
Battery
Backup Box
Sleeptracker®
Smart Cable

14
Connecting straps are secured to the base frame upon delivery.
If a split setup is being installed, plastic connecting straps are provided (one per
base) to secure the bases together. Use both straps to secure the head and foot
portions together.
With the bases in their desired location, slightly
loosen both legs to allow the strap to t on the leg
bolt, between the leg washer and frame.
Slide side (a) of the connecting strap onto leg bolt.
Swing the strap and connect side (b) to the leg bolt.
Secure the strap by shifting to the left.
Re-tighten legs. Do not over tighten. Use the
remaining strap on other end of the base.
OVERVIEW
STEP 2
STEP 1
connecting strap (optional)
ab
STEP 3

15
syncing two bases
A Sync Cord is included with Twin Long and Split Cal King size bases.
The Sync Cord connects the two control boxes for the synchronization of two bases.
These steps are required in order to operate side-by-side Sleeptracker installations.
Disconnect the battery backup box cable from each Sleeptracker®Smart
Cable (make note where the cable was plugged in).
Remove Sleeptracker® Sensor cable from Sleeptracker®Processor on
Base A and plug into open port on Sleeptracker® Processor on Base B.
Make sure to properly route wires through rubber conduits. Disconnect
the Sleeptracker®Processor on Base A by unplugging it from the USB
Extension Cable.
If bases become mismatched, return both bases to the at position to
re-sync the bases.
Connect the male end of each sync cord to the Sleeptracker®Smart Cable.
Insert it into the same port that you disconnected the battery backup box
from in Step 2.
Plug bases back into the power source.
Check to ensure all cords are securely attached. Both remotes will now
operate both bases simultaneously.
For both bases to operate independentely with their remote controls
instead of simultaneously, please use the Tempur-Pedic®Sleeptracker®app
to setup the bases as 'split'. This is generally preferred when using split
mattresses.
Unplug the base(s) from power source.
Connect each battery backup box male connection to the sync cord
female connection (Refer to illustration at right).
STEP 3
STEP 6
STEP 7
STEP 8
STEP 2
STEP 5
STEP 1
STEP 4
PERFORMANCE NOTES
Battery
Backup
Box 1
Sync Cord
Sleeptracker®
Smart Cable 1
Sleeptracker®
Smart Cable 2
Battery
Backup
Box 2
Control Box 1
Sleeptracker®
Processor (A)
Sleeptracker®
Processor (B)
Sleeptracker®
Sensor cable
Control Box 2
The system is now linked. Pressed buttons on either remote will
control the two bases simultaneously.
Return to page 8 step 4 for additional setup information.
B A
A B

16
headboard bracket installation guide (optional)
Connect your headboard to the attachment plate using the
remaining long screws or hardware that came with your
headboard. The heads of the bolts will face outward. Use
hex key to tighten bolts.
STEP 1
STEP 2
STEP 3
a.) Align the hole in the bracket to the brass sleeve into
which the leg threads. Hold the bracket in place and
screw the leg into the base until it is snug. DO NOT
OVERTIGHTEN.Too much force may cause the leg to
spin freely.
b.) Align the tab with the hole in the frame (located towards
the foot of the base) and use a short bolt and nut to
secure the bracket. Make sure the bolt is tight.
Attach the T-Bracket.
a.) Measure the distance between the mounting holes
on the headboard and install the T-Bracket to
accommodate the headboard.
Headboard Brackets are an optional accessory and are not included.
b.) To install the T-Bracket, slide the T-Bracket through the
end of the headboard bracket. Align the at side of the
T-Bracket plate to the mounting holes on the headboard.
c.) Secure T-Bracket in place by inserting two short screws
through top of bracket. Use hex key to tighten screws.
