PRYME nano 99A User manual

3
4
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. To maintain compliance with FCC RF exposure compliance requirements, please
avoid direct contact to the transmitting antenna during transmitting.
911 Mariner St., Brea, CA 92821
PH: 714.257.0300 FAX: [phone]
TOLL FREE: 800.666.2654
WWW.PRYME.COM
Controls and Connection
PRYME NANO-99A
Audio Accessory Kit with “SMART” PTT Button
for Smartphones and Tablets
The NANO is a revolutionary wired microphone kit with a removable earphone, for use
with Smart Devices running many different Push-to-Talk over Cellular (PoC) apps.
Version 1.00 AUGUST 2018
BATTERY LIFE
The NANO uses one CR2032 coin cell type battery. A single battery can provide up to two full years or more of
operating time. However, operating time can vary depending on the usage cycle and the age and condition
of the battery. At the end of the battery's lifetime, it is necessary to replace the battery with a new one.
NOTE: The NANO has a sleep mode which is used to preserve battery life. This sleep mode will engage When
the power switch is turned to the "ON" position and a long period of time goes by without the Smart PTT
button being pressed. While sleeping, the power consumption of the NANO is greatly reduced. To preserve
battery life even longer, it is recommended that you turn the NANO’s power switch to the off position when
you are not using it.
The battery is internal, but can be replaced using only a jeweler's/eyeglass
screwdriver. To change the battery:
1. Remove the 2 small Phillips head screws on the rear of the NANO using
a jeweler's/eyeglass screwdriver. Separate the two halves of the housing.
2. Locate the remove the 2 small Philips head screws
which secure the PC Board of the NANO inside the housing.
3. Carefully remove the PCB from the housing and flip
it over to reveal the battery holder. Be careful not to
damage the wire leads that connect the PCB to the
microphone element or cabling.
4. Remove the old battery from the battery holder. A ball point pen can be used
to push the battery out of the holder if needed.
5. Insert a new CR2032 3-volt coin cell battery into the battery holder, observing
proper polarity.
The positive side of the battery (marked with a “+” sign) should face away from
the circuit board.
6. Reseat the PCB and reinstall the 2 Phillips screws. Take care not to crimp any
of the wires between the PCB and housing.
7. Reseat the two halves of the housing and reinstall the 2 screws to secure it in place.
NOTE: If you are unable to perform the battery replacement yourself, battery replacement
service is available from PRYME for a flat fee. Contact PRYME Support for further details.
BUILT-IN MICROPHONE
When using the NANO with a listen-only earphonem, this microphone is used for making
PTT Over Cellular (PoC) transmissions and phone calls. For best results, the microphone
should be positioned a maximum of 6-9” away from the user’s mouth. (Note, if an
accessory with a microphone is connected to the NANO, the accessory microphone will
be used instead.)
CLOTHING CLIP
The alligator-type clip secures the
NANO to the lapel of the user’s
clothing during use. The clip can be
rotated to allow the microphone to
be better positioned.
AUDIO ACCESSORY JACK
Allows the connection of an earphone or
an Apple®-compatible wired audio
accessory that contains both an
earphone(s) and a built-in microphone.
(Note that the plug on the audio
accessory must use the CTIA or Apple
iPhone standard. For more compatibility
information see pg 5.) Audio Accessory
not included.
HOOK BUTTON
This button can be pressed to answer or hang up
phone calls. Pressing and holding the button will
either reject an incoming call or launch your smart
device’s voice assistant (if no phone call is incoming).
SMART PTT BUTTON
Pressing and holding this button will
cause your PTT Over Cellular (POC)
app to transmit a message. Release
the button when done speaking.
POWER SWITCH
Used to toggle the Smart PTT
Button function on or off. Turn
this switch off to preserve the
battery life of the NANO if it will
not be used for a long period of
time.
Made in Taiwan
PRYME® is a trademark owned by PRYME Radio Products, Brea CA. All other product or service names are the property of their respective owners.
© 2018 PRYME Radio Products, Brea CA. All Rights Reserved
ACCESSORY CONNECTOR
The 3.5 mm audio connector
on the PICO connects the kit
to the earphone accessory
jack on your smart device.

8
65
7
SUPPORT AND WARRANTY
PRYME Radio Products warrants this product against defects in materials or workmanship for a
period of one year from the date of retail purchase. PRYME will repair or replace a defective unit, at
our option, without charge for parts or labor. The limited warranty is extended only to the original
purchaser and is valid only to consumers in the United States and Canada. It does not cover damage
or failure caused by or attributable to Acts of God, abuse, misuse, improper or abnormal usage,
faulty installation, improper maintenance, lightning, or other incidences of excessive voltage, or any
tampering or repairs by other than a PRYME authorized repair facility.
It does not cover replacement of consumable parts, transportation costs, or damage in transit.
Repair or replacement under the terms of this warranty does not extend the terms of this warranty.
This warranty can only be modified by an officer of PRYME Radio Products, and then only in writing.
Should this product prove defective in workmanship or material, the consumer’s sole remedies shall
be such repair or replacement as provided by the terms of this warranty. Under no circumstances
shall PRYME Radio Products be liable for any loss or damage, direct, consequential, or incidental,
arising out of the use of or inability to use this product. Some states do not allow limitations on how
long an implied warranty lasts or the exclusions or limitations of incidental or consequential
damages, so the above limitations or exclusions may not apply to you. This warranty gives you
specific legal rights. You may also have other rights, which may vary, from state to state.
For support or warranty service on your PRYME product, contact us at 1-800-666-2654 or visit us on
the web at www.PRYME.com.
COPYRIGHT AND TRADEMARK INFO
© 2018 PRYME Radio Products, Brea CA. All rights reserved.
PRYME® is a trademark owned by PRYME Radio Products, Brea CA.
Android is a trademark of Google Inc.
Apple is a trademark of Apple Inc.
AT&T is a trademark of AT&T Intellectual Property and/or AT&T affiliated companies.
ESChat is a registered trademark of San Luis Aviation, Inc.
iOS is a trademark of Cisco Systems and is used by Apple Inc. under license.
Kodiak Networks is a trademark of Kodiak Networks Inc., a wholly owned subsidiary of
Motorola Solutions, Inc.
Verizon Wireless is a trademark of Verizon Trademark Services, LLC.
WAVE and WAVE COMMUNICATOR are trademarks of Twisted Pair Solutions, a wholly owned
subsidiary of Motorola Solutions, Inc.
ZELLO is a trademark of Zello, Inc..
All other product or service names are the property of their respective owners.
65
POC App Setup
The NANO is compatible with most PTT Over Cellular apps and in most cases no setup is needed. Just
connect the NANO kit to your smart device, sign into your POC app, and make sure that Power Switch
on the NANO is set to the ON position!
All of the following apps work with the NANO including Zello, Wave Communicator, KODIAK
Networks app (such as AT&T EPTT and Verizon PTT Plus), ES Chat, ZINC, VOXER and many more.
As long as your POC app supports using the Headset Hook button for Push-to-Talk or Toggle-to-Talk,
the NANO should work!
Using the NANO
When the NANO is connected to your smart device:
• Media audio, phone audio and PTT app audio will be heard through the NANO’s earphone.
• As long as the power switch on the NANO is set to the ON position, you can make a PTT Over Cellular
call by pressing the holding the Smart PTT Button on the NANO.
• You can make or take a phone call by using the controls on the screen of your smart device.
• You can answer an incoming phone call, or hang up a call in progress, by pressing the Headset Hook
button on the NANO.
• If you have a listen-only earphone plugged intio the NANO's accessory jack, when you make a phone
call or PTT Over Cellular (PoC) app call,, the sound of your voice will be picked up by the NANO’s
built-in microphone. You should speak slowly and clearly with the microphone positioned
approximately 6 inches away from your mouth. If you have an accessory that includes both an
earphone and a microphone plugged into the NANO's accessory jack, then the accessory microphone
will be used instead.
• You can press and hold the Headset Hook button on the NANO to launch your smart device’s voice
assistant feature.
To connect an audio accessory, simply plug the audio accessory into the accessory jack on the NANO.
Make sure that the connector on the audio accessory is pushed all the way into the jack and seats firmly.
TROUBLESHOOTING
The earphone and/or microphone on my audio accessory isn’t working with my NANO
First, make sure that the accessory is firmly plugged into the accessory jack of the NANO.
Keep in mind that the accessory must also be wired using the CTIA or Apple iPhone
standard. Some accessories may be wired differently and could therefore be be
incompatible with the NANO even though the have a plug which fits the accessory jack.
Please contact PRYME Tech Support for further assistance.
The Smart PTT Button on my NANO isn’t working.
First, ensure that the power switch on the NANO is set to the ON position. Then, make
sure that you are signed into your POC app, that you have an active cellular data or WiFi
connection, and have selected the contact you wish to speak with in your POC app. If
pressing the Smart PTT button still does not cause the POC app to transmit a message,
then it may be necessary to replace the battery inside your NANO.
The Smart PTT Button on my NANO is out of synch (transmits when released)
In the unlikely event that this occurs, press and release the Headset Hook button on the
NANO. This should restore normal operation.
PRYME makes a variety of listen-only earphones that will work with the NANO:
MODEL NUMBER
EH-1189SC
EH-1399SC Recon™
EH-3099SC Bullet™
EH-GH99SC G-Hook™
SPM-499D Ranger™
SPM-1599 Gladiator™
SPM-899B Highway™
TYPE
Listen-only
Listen-only
Listen-only
Listen-only
Mic+Earphone
Mic+Earphone
Mic+Earphone
STYLE
Ear Bud Earphone
Acoustic Tube Earphone
Bullet Transducer Acoustic Tube Earphone
G-hook Swivel Earphone
Boom Mic Headset with D-ring Earphone
Throat Mic Headset with Acoustic Tube Earphone
Motorcycle Helmet Boom Mic Kit
SPM-800B
CONNECTING AN AUDIO ACCESSORY TO THE NANO
SHOWN WITH APPLE EAR PODS (NOT INCLUDED)
In order to be able to hear audio from the attached handset, the NANO requires an Apple®-compatible
wired audio accessory. This audio accessory may be a listen-only earphone or it may be an audio accessory
that includes both an earphone and a microphone. The plug on the audio accessory must by a 3.5 mm
TRRS type using the CTIA or Apple iPhone wiring standard. This includes several different PRYME audio
accessories (sold separately, see below), Apple earbuds such as part number ME186LL/A, or MD827LL/A, or
another similar audio accessory.
