PS EDGEHALT LSG-1520 Instruction Manual
1
LSG Series
Rev041823
© 2023 PS Industries®Incorporated. All Rights Reserved.
IMPORTANT! This is an abbreviated manual for installation into a typical guardrail/railing systems. In all cases the
installer and end-user should read the entire O&M and Installation Manual for detailed installation requirements
and operation and maintenance guidelines.
I. Product Information
A. Retain this manual for future reference.
B. To download a copy of the full O&M, scan above QR Code, go to website: https://www.pssafetyaccess.com/o-m/
edgehalt-ladder-safety-gate/; or pssafetyaccess.com to request an O&M download.
C. This product should be used by trained employees only and should not be installed in an area accessible to the
general public.
NOTICE This product is a fall protection product. The effectiveness of the product is directly related to the proper
installation and operation of this product. Failure to properly maintain this product will affect performance.
NOTICE Unauthorized modication of or to the Product voids this Limited Warranty. Authorized modications,
received in writing from PS Industries® Incorporated, as long as the modication is accomplished in strict
accordance with PS Industries’ instructions, does not void warranty. If this product is modied or altered without
manufacturer’s permission, manufacturer is no longer responsible for the product design, engineering, or
performance and owner assumes all responsibility. To request product modications contact PS Industries
Incorporated, 1150 S. 48th Street, Grand Forks, ND 58201, phone 877-446-1519, email: 4psinfo@psindustries.
com
II. Safety Precautions
A. Ensure opening is clear of all obstructions through the entire proposed travel of the Ladder Safety Gate during
operation.
B. Comply with all OSHA and ANSI Safety Regulations and/or company safety policies when installing.
IMPORTANT! Due to variances in eld conditions, it is the responsibility of the installer to ensure that the product
is installed to a mounting surface that is capable of supporting all imposed loading from the product. The installer
is responsible for ensuring that the eld congured mounting arrangement is capable of supporting all eld loads
and meets applicable codes and regulations.
CAUTIONCAUTION For products that are approved for use as a means of fall protection, the product only serves as a
means of fall protection when the product is in the closed position.
WARNING Do NOT force components if they do not operate freely.
DANGER Ensure area below installation is blocked off from personnel
during installation.
Quick Start Installation Guide
(Full Installation and O&M Manual online)
PN 515938 A
Models:
LSG-1520
LSG-2030
LSG-3040
LSG-4050
Scan for full O&M
Website
pssafetyaccess.com
Toll Free Phone
877.446.1519
2LSG Series
Rev041823
© 2023 PS Industries®Incorporated. All Rights Reserved.
Standard Square or Round Installation
NOTICE Alternate mounting congurations detailed in
full O&M available online.
STEP 1. Hang Hinge Plate, align top of railing or 42” to
oor.
a. Install Hinge Brackets at 90○to the gate
opening.
Step 1
Illustration I
Step 2
Illustration I
STEP 3. Apply Bumper, install Strike Block.
NOTICE Strike Block to support 200 lbs downward
OSHA loading.
STEP 2. Install Hoop.
CRITICAL End of gate tube must be installed within
”HOOP ADJ. RANGE”.
STEP 4. Install Slam-ProofTM Damper Kit.
1. Loosen nut on the hinge bolt; DON’T fully remove
nut.
2. Push hinge bolt up to expose head of hinge bolt.
3. Slide Damper Stud onto bolt head (not nut) and
align pin of Damper Stud into receiving hole in
hinge bracket.
4. Tighten nut of hinge bolt to snug Damper Stud
onto hinge bracket. Over-tightening will prevent
friction-free hinge movement.
5. Slide Damper onto Damper Stud. Pivot gate to
create alignment.
6. Install the O-ring over Damper Stud to secure
Damper in place.
Step 3
Illustration I
DISTANCE TO
FLOOR: 42”
20ft*lbs
20ft*lbs
10ft*lbs
10ft*lbs
1/
4”
1
1/
4”
2
3
4
5
6
Loosen
Tighten
HOOP ADJ.
RANGE
Step 4
Illustration I
FINISHED GATE
TOP VIEW
Swing Direction
(On to Platform) ✔
✖
Not Enough Strike
Plate Overlap
90○
90○Proper Strike
Plate Overlap
1
2
3
4
5
6
Push
Slide
Slide
Install
