PSB Alpha B1 User manual

Owner's Manual
,.,' .. , ... , .. : .... ,+, .. ,~., ......•. , •..• :,.
/\Manuel d'informations du proprietaire
6ufade propietario
Benutzerhandbuch
81
C1
T1
LFl1
CUR1

Thank you for your purchase. The speakers in ourAlpha series are designed to
deliver high performance in many uses, and we hope they add much enjoyment
to your listening life.
I. SIMPLE STEPS FOR A QUICK START:
A. Be sure power to your amplifier/receiver and other electronics is off before
making connections.
B. Install bumpers, adjustable levelers or spikes in the feet.
C. Position your main speakers, as symmetrically as possible, at a
comfortable listening distance-slightly closer to each other than they are
to you. (For surround speakers, see later instructions.)
D. Using standard 18 gauge (1.0mm dia) lamp wire or better, connect the
Red (positive) terminal on each channel of your amp/receiver to aRed
terminal post on that channel's speaker, and the Black (negative) terminal
to aBlack terminal post on the speaker.
E. Setting the volume low beforehand, turn on your associated equipment,
find acomfortable listening volume-and enjoy your favourite audio and/or
video selections.
F. After you have settled in with your speakers, read through this booklet. Be
sure to read "Protecting Your Investment."
II. MORE ON SPEAKER POSITIONING
A. Main Speakers:
The three factors to adjust according to your own tastes-keeping in mind that
you are the judge and the one(s) to be satisfied-are:
1. The closer you place speakers to the boundary surfaces of your
room, the greater the proportion of bass in their overall sound. This is
due to the enclosing, "focusing" effects of nearby surfaces on longer-
wavelength (lower) frequencies. Positioning the speakers near the
intersection of two surfaces (wall and wall, wall and floor, or wall-and
ceiling) will produce more apparent bass than placement near asingle
surface. The greatest proportion of bass is delivered by placement near
three intersecting surfaces-in aroom corner near the floor or ceiling,
where the convergence of the two walls and the floor/ceiling produces an
amplifying effect that is abit like that of amegaphone. And the least bass
comes from placing aspeaker away from all boundaries. Your own tastes
should decide what proportion of bass response seems right in your room.
2. Distances of speakers from the walls can make great differences in
the number, strength, and particular frequencies of secondary
reflections-changing frequency-balance, sonic spaciousness, and
definition. Most listeners prefer their speakers at least afew inches from
2

all walls, but the choice is yours to determine by listening.
3. Small changes in positioning may make a big difference in sound
quality. Because of the varying relationships of the dimensions of aroom
and their relation both
to where you place the speakers and where you sit,
the wavelengths
of sound and their interaction both with you and with the
room can vary agreat deal. There can
be sharp increases or decreases
in the relative loudness of different frequency bands, greatly amplifying or
almost nullifying whole ranges. Since Alphas are small and easy to
position, it's easy to experiment with small, incremental changes until you
are satisfied.
Ideal speaker placement: 5.1
All distances are equal
/\
IT] GJ
Ideal speaker placement: 7.1
B. Surround Speakers
Begin with the knowledge
of the above factors about main speakers. Then
modify things as needed for your convenience and the surround effect that
works best for you. If you want maximum localization and definition, you
probably will want to aim the speakers toward your seating area, both
horizontally and vertically. If you prefer the surround effect to
be more
diffused rather than pinpointed, aiming the speakers somewhat away from
your ears probably will
be more satisfying. You may want even to place them
to reflect their sound off the sides or rear
of you room rather than have them
radiate toward you. Side-wall positioning, slightly behind you as specified
in
our Quick Start tips, is preferable to most listeners, but rear-wall placement
can work well-especially for bouncing the sound off the side walls.
C. About Wall-Mounting for Surround and Other Uses
The Alpha's rear baffle incorporates akeyhole slot for direct wall-mounting.
There are also
~ x20 brass inserts and screw bosses which can easily
secure speakers to OmniMount, Vogel's VLB
50NLB500 and other brackets.
III. ADDITIONAL DETAILS
ON CONNECTING YOUR SPEAKERS
A.
Important: Always turn off your electronic equipment before connecting
speakers. If you don't, severe damage to equipment and/or your ears
may result.
3

18-gauge or 1.0 mm dia (lamp cord)
16-gauge or 1.3 mm dia (heater cord)
14-gauge or 1.6 mm dia
12-gauge
or 2.0 mm dia
B. Selecting Speaker Wire
We recommend the following gauge of standard two-conductor wire for the
wiring distances specified; if you prefer you can use thicker (lower-gauge)
wire.
Under 25 ft
«7.5m)
25 -50 ft (7.5-15 m)
50 -100 ft (15-30 m)
Over 100 ft (>30 m)
C. Connecting In Phase
Connect speakers identically to your amplifier or receiver on each
channel-Red amp/receiver terminal to Red speaker terminal, Black to
Black. This will ensure that the diaphragms of the speakers on both channels
move forward and backward together ("in-phase"), rather than in opposition
("out-of-phase"). In-phase connection provides maximum clarity and bass,
while out-of-phase connection results
in frequency cancellations and
produces thinner and less distinct
sound-with less bass, vague vocal quality,
and no solid centre image.
To help insure the proper connection, the two
separate conducting wires in astandard two-conductor speaker cable are
coded
in one way or another to be distinguishable from each other. (The
jacket
of one wire may be ribbed or marked with "+" signs, or one wire under
the insulation may be adifferent colour from the other.) Use this wire-coding,
together with the amp/receiver and speaker colour-coding, to be sure you are
connecting the same wire
of agiven pair to alike-coded terminal at both ends
of your connection.
Right
Speaker
:a
1 __ -
Left
Speaker
a
.... ~
Amplifier
Output
Right
a
C'.
Wiring in Phase Between Speakers and Amplifier
D. Be sure all wiring terminals, are tightened firmly secure, but be careful not to
over-tighten and damage the connectors.
E. Bi-wiring and Bi-amping (Alpha T1 only)
The metal jumper strap that connects the two sets of terminals on some of our
speakers is removable. This allows you to connect either separate cables to
4

the separated woofer and tweeter terminals ("bi-wiring") or separate amplifiers
("bi-amping"). With Bi-Amp hookup you must use either identical amplifiers or
amplifiers adjusted to have the same voltage gain. Consult your PSB dealer
for further information. (Illustrations are for one speaker hookup only). With
single cable inputs, the jumper straps must be in place and both sets of
terminals tightened firmly.
SPEAKER
+
SPEAKER
Amp #1
Output
--
Mid/High
+
Woofer
Amp #2 "
Output
- (Labeled)
'---'f-----I + Woofer
-- (Labeled)
r---I+
Mid/High
IJ I~L..-~_~_i~_+--,
u... _output
Bi-Wire Hookup Bi-Amp Hookup
Bi-wire and Bi-amp Wiring between Speakers and Amplifier
IV. PROTECTING YOUR SPEAKERS
A. For full, year-after-year enjoyment from your speakers, you should respect
their limits. They will produce room-filling volume in average-sized
rooms-and handle peak momentary levels at those volumes without audible
strain. But avoid louder-than-life playback of music or movies, especially
in large rooms. Even the most "bulletproof" speakers can be damaged by
excessive volume levels, especially for long periods.
B. When listening to music or movies at very loud volume, you shouldn't
turn up bass or treble all the way or close thereto. This sends
tremendously increased, disproportionate power into the speakers, and may
well damage them. Some loudness compensation ("Loudness") controls,
which boost both bass and treble, can also be troublesome at high volume.
They are intended only for low-volume listening.
C. Finally, you should be aware that when amplifiers and receivers are
pushed to their limits to produce excessive volume levels, they are
driven into "clipping" and can do severe damage-especially to
tweeters. Often, the damage is done by underpowered amplifiers, which may
reach their limits very soon. When such units begin to "clip" the audio
waveform, they may generate high-frequency "spikes" of tremendous power.
More tweeters have probably been destroyed by this phenomenon than any
other. If using your speakers at loud levels, listen carefully for any sign
of harsh, garbled midrange and diminishing intelligibility-and turn the
volume down right away if you detect it.
NEVER TURN UP THE VOLUME ALL THE WAY TO SEE HOW LOUD
YOUR SYSTEM WILL PLAY!
5

D. Recommended Power
We recommend amplifiers and receivers rated from a range of 20-150 watts
with our compact systems, 20-200 watts with our tower models. For playing at
consistently room-filling volume, aminimum
of 50 watts is usually agood
idea. As just indicated
in the paragraph above, be wary of driving low-
powered amplifiers to their limits.
We recommend amaximum
of 80-150 watts for sustained program
material-as, for instance, with organ pedal tones of long duration, or minutes-
long subterranean special effects
in movies.
Be aware amplifiers with equal power rating may not play equally loud. Those
with higher dynamic power ratings, better satisfy the power requirements.
Some have protective circuitry that curtails power available
in demanding
situations.
E. Cabinet Care
Cabinets have varying materials and finishes, including wood veneers, vinyl,
anodized aluminum and high gloss "poly lacquers" and should be treated as
you would furniture with similar finishes. Dust lightly with asoft cloth; avoiding
abrasives. If necessary, wipe carefully with acloth slightly dampened with
glass cleaner to remove heavy soil.
F. Grilles and Ports
Alint brush does agood job of cleaning grilles. Removable grilles can be
taken off and vacuumed if you prefer. If need be, you can use alint brush to
clean ports. Avoid touching speaker diaphragms. Particularly, pushing
in the
domes will permanently damage tweeters.
v. IN CASE OF PROBLEMS
A. Lower power if aspeaker begins to sound distorted, or seems to be missing
certain frequencies, to check first to see whether playing at somewhat lower
volume seems to clear up the problem. As we noted under "Recommended
Power," it can be especially important to turn down the volume right away if
you have pushed alow-powered amplifier or receiver past its comfortable
limits.
B. Isolate the problem to the electronics or the speakers and, if the speakers, to
specific speakers. Interchange the speaker wire connections on your amplifier
or receiver between channels, so that the left speaker is connected to the
right channel, or vice versa. If the problem shifts to the other speaker, the
problem is not
in the speaker but in the electronics.
C. Another component-or, very often, acable or connection problem between
components-may be at fault. If the problem stays in the same speaker,
irrespective
of the channel to which it's connected-and after changing the
connecting
wire-chances are the speaker itself probably needs service.
6

D. See your dealer if you require service. PSB dealers are equipped to handle
almost all problems. If you have moved since your purchase, the nearest
authorized PSB dealer should be able to help you. If the problem
is not
resolved, please contact us, providing the Model name, Serial Number, date
of purchase, dealer name, and afull description ofthe problem.
We appreciate your purchase, and hope this owner's guide helps you enjoy
the exceptional satisfaction that PSB speaker systems have to offer.
We wish
you many years of enjoyable listening!
At the end of its useful life, this product must not be disposed of with regular household
waste but must be returned to a collection point for the recycling of electrical and
electronic equipment. The symbol on the product, user's manual and packaging, point
this out.
The materials can be reused in accordance with their markings. Through re-use,
recycling of raw materials, or other forms of recycling of old products, you are making
an important contribution to the protection of our environment.
Your local administrative office can advise you of the responsible waste disposal
point.
-
Notes on environmental protection
R
7

VI. SPECIFICATIONS
Alpha LR1
Compact Monitor
FREQUENCY RANGE (Anechoic Chamber)
Response
On Axis @00± 3dB 90-21,000Hz
Off Axis @ 30° ± 1.5dB 90-10,000Hz
LF cutoff - 10dB 85Hz
Alpha CLR1
CenterlMonitor
90-21,000Hz
90-10,000Hz
78Hz
Alpha B1
Compact Monitor
65-21,000Hz
65-10,000Hz
55Hz
SENSITIVITY (1W (2.83V) @ 1m, IEC-filtered Pink Noise, C-weighted)
Anechoic Chamber 85dB 86dB 89dB
Typical Listening Room 87dB 88dB 91dB
IMPEDANCE
Nominal 60hms 8 Ohms 60hms
Minimum 4 Ohms 6 Ohms
4 Ohms
INPUT POWER (RMS, Clipping < 10% Time)
Recommended 15-80 Watts
15-80 Watts 10-90 Watts
Program 60 Watts 60 Watts 60 Watts
ACOUSTIC DESIGN
Tweeter (Nominal)
%" (19mm) %" (19mm) %" (19mm)
Aluminum Dome Aluminum Dome Aluminum Dome
with Ferrofluid with Ferrofluid
with Ferrofluid
Woofer (Nominal)
3 'j," (90mm)
2x 3 'I,"~ (90mm)
5'I." (130mm)
Injection Molded Metalized Injection Molded Metalized Injection Molded Metalized
Polypropylene cone with
Polypropylene cone with Polypropylene cone with
Rubber surround Rubber surround Rubber surround
Crossover
3,000Hz, B3 3,000Hz, B3 3,000Hz, B3
Internal Volume 0.07 cu ft (2.0 liters) 0.10 cu ft (2.8 liters)
0.29 cu ft (8.0 liters)
Design Type Acoustic Suspension Acoustic Suspension
Bass Reflex
Sealed Sealed
1 ';2" (40mm) Rear Port
SIZE (W xHx D)
45/8" x 7 1/8" x6 3/8" 101/8" x4 5/8" x6 3/8" 7" x 11 3/4" x 9 3/4"
118mm x 182mm x 162mm 257mm x 118mm x 162mm 178mm x 299mm x 247mm
WEIGHT
Net
Shipping
FINISH
FEATURES
4.11b (1.9kg)/each
8.81b (4.0kg)/pair
Black Ash, White Textured
or Dark Cherry
Video Shielded
5-way Gold Plated
Binding Posts
Aluminum Grille
Keyhole Slot
'1.-20 Brass Insert
Clear Rubber Bumpers
5.91b (2.7kg)/each
6.71b (3.0kg)/each
Black Ash, White Textured
or Dark Cherry
Video Shielded
5-way Gold Plated
Binding Posts
Aluminum Grille
HorizontalNertical
Keyhole Slots
'1.-20 Brass Insert
Clear Rubber Bumpers
10.21b (4.6kg)/each
22.4lb (1 0.2kg)/pair
Black Ash or Dark
Cherry
Video Shielded
5·way Gold Plated
Binding Posts
Aluminum Grille
Keyhole Slot
'1.-20 Brass Insert
Clear Rubber Bumpers
All specifications are subject to change without notice. PSB' is a trademark of Lenbrook Corp .. used under licence by PSB Speakers'. a division of Lenbrook
Industries Limited. ©2006 PSB Speakers. All rights reserved.
8

VI. SPECIFICATIONS
Alpha C1
Center/Monitor
FREQUENCY RANGE (Anechoic Chamber)
Response
On Axis @ 0° ± 3dB 62-21,000Hz
Off Axis @ 30° ± 1.5dB 62-10,000Hz
LF cutoff - 10dB 52Hz
Alpha T1
Tower
55-21,000Hz
55-10,000Hz
34Hz
SENSITIVITY
Anechoic Chamber
Typical Listening Room
(1W (2.83V) @ 1m, IEC-filtered Pink Noise, C-weighted)
90dB 89dB
92dB 91dB
IMPEDANCE
Nominal
Minimum
INPUT POWER
Recommended
Program
ACOUSTIC DESIGN
Tweeter (Nominal)
Woofer (Nominal)
Crossover
Internal Volume
Design Type
SIZE (W xHx D)
WEIGHT
Net
Shipping
FINISH
FEATURES
8 Ohms
6 Ohms
(RMS, Clipping < 10% Time)
10-120 Watts
60 Watts
%" (19mm)
Aluminum Dome
with Ferrofluid
2x 5'I." (130mm)
Injection Molded Metalized
Polypropylene cone with
Rubber surround
3,000Hz, B3
0.46 cu ft (12.8 liters)
Bass Reflex
2" (50mm) Rear Port
177/8" x 7" x9 3/4"
453mm x 178mm x 247mm
15.91b (7.2kg)/each
17.3Ib (7.9kg)/each
Black Ash or Dark
Cherry
Video Shielded
5-way Gold Plated
Binding Posts
Aluminum Grille
HorizontalNertical
Keyhole Slots
'1.-20 Brass Insert
Clear Rubber Bumpers
80hms
6
Ohms
15-120 Watts
60 Watts
%" (19mm)
Aluminum Dome
with Ferrofluid
2x 5'I." (130mm)
Injection Molded Metalized
Polypropylene cone with
Rubber surround
3,000Hz, B3
1.19 cu ft (33.4 liters)
Bass Reflex
20/." (70mm) Rear Port
7" x 35 3/4" x 12 1/4"
178mm x 907mm x 310mm
291b (13.2kg)/each
72.21b (32.8kg)/pair
Black Ash or Dark
Cherry
Video Shielded
Dual, 5-way Gold Plated
Binding Posts
Aluminum Grille
Bi·wireable/Bi-ampable
Adjustable Spikes
and Rubber Levelers
All specifications are subject to change without notice. PSB® is a trademark of Lenbrook Corp., used under licence by PSB Speakers', a division of Lenbrook
Industries Limited. ©2006 PSB Speakers. All rights reserved.
9

PSB Speakers
633 Granite Court
Pickering, Ontario L1W
3K1
CANADA
www.psbspeakers.com
888-772-0000 (North America)
905-831-6555 (International)
Fax: [phone]
SPEAKERS

Un membre du groupe de societes Lenbrook
Enregistrez votre garantie sur Internet des maintenant
et courrez la chance de gagner des enceintes PSB.
Visitez Ie : www.psbspeakers.com/warranty
~
633 Granite Court, Pickering (Ontario)
Canada L1W 3K1
Telephone: [phone]
[phone]
Telecopieur: [phone]
www.psbspeakers.com
GARANTIE LlMITEE _
PSB Speakers, une division de Les Industries Lenbrook
Limitee, garantie les produits ci-apres pour la duree
indiquee.
Produits
Enceintes acoustiques et haut-parleurs d'extreme grave
asservis
Duree de la garantie
Taus les haut-parleurs PSB et les caissons de graves extremes
sont garantis 5 ans. Les amplificateurs PSB, y compris ceux
utilises dans nos « haut-parleurs actifs» (tels que les caissons
de graves extremes) sontgarantis 1 an.
Etendue de la garantie
Sous reserve des dispositions ci-apres, la presente garantie
couvre les pieces et la main-d'ceuvre en vue de corriger tout
vice de materiau et de fabrication. Sont exclus de la presente
garantie:
1. tout dommage, degradation, mauvais fonctionnement au
defaillance resultant des situations suivantes :
a, accident, cas de force majeure, mauvaise utilisation,
negligence au modification intempestive du produit ;
b. installation, enlevement out entretien incorrect et
manquement a se confirmer aux directives fournies
pour Ie produit;
c. reparation ou tentative de reparation par quiconque n'est
pas auto rise par PSB Speakers a reparer Ie produit ;
d. envoi du produit (Ia demande d'indemnisation doit etre
adressee au transporteur) ;
e. toute cause autre qU'une defectuosite du produit.
2. Ie nettoyage, I'installation initiale, une verification ne
permettant pas de detecter de dBfectuosite ou les frais
engages pour I'installation, I'enlevement ou la reinstallation
du produit.
3. les produits dont Ie numero de serie a ete efface, modifie au
enleve.
4. les accessoires, y compris, sans s'y limiter, les cables, les
accessoires d'installation et supports et les cordons
d'alimentation detachables.
5. les produits utilises a des fins commerciales au dans une
application industrielle au commerciale.
6. tout produit achete a I'exterieur du pays dans lequel la
reparation est demandee, y compris les possessions et les
territoires de ce pays.
7. tout autre probleme qui ne constitue pas un vice du produit.
8. Pour tout produit non achete au pres d'un revendeur agree
PSB Speakers. Si vous n'etes pas certain qU'un revendeur
est « agree ", verifiez sur notre liste de revendeurs ou
appelez PSB Speakers.
Conservez cet enonce de garantie, incluant la date
d'enregistrement et votre preuve d'achat, dans vos dossiers.
Titulaire de la presente garantie
La presente garantie est accordee uniquement a I'acheteur
initial.
Notre contribution
Nous payons tous les frais de main-d'ceuvre et de materiau
pour les articles couverts par la garantie ; les frais d'expedition
sont abordes dans la prochaine rubrique de la presente
garantie.
Pour obtenir Ie service apres-vente
1. Se votre produit doit etre repare, veuillez I'apporter a votre
depositaire PSB Speakers en prenant soit d'apporter
egalement votre facture ou acte de vente original. Si vous
avez besoin d'aide pour connaitre I'identite de votre
depositaire PSB Speakers, veuillez visiter Ie site web de PSB
Speakers au communiquez directement avec celle-ci.
2. Vous devez acquitter tous les frais d'expedition si votre
produit doit etre expedie en vue de Ie faire reparer.
Cependant, si les reparations necessaires sont couvertes
par la garantie, nous paierons tous les frais d'expedition de
retour vers n'importe quelle destination a I'interieur du pays
dans lequella reparation est demandee.
3. Lorsqu'une reparation sous garantie est demandee, vous
devez produire I'acte de vente original, la facture ou une
autre preuve d'achat date.
Limite des garanties implicites
Toutes les garanties implicites, y compris les garanties de
qualite marchande et d'aptitude a un but particulier, sont
limitees a la duree de la presente garantie.
Exclusion des dommages
La responsabilite de PSB Speakers a I'egard de tout produit
defectueux se limite a la reparation ou au remplacement du
produit, au gre de PSB Speakers. PSB Speakers ne peut etre
tenue responsable des dommages causes a tout autre produit
par suite de la defectuosite des produits PSB Speakers, ni des
dommages resultant des desagrements ou pertes d'utilisation
du produit, ni d'autres dommages, directs, indirects ou autres.
Les lois de I'etat (ou de la province) au regard de la
presente garantie
Certains etats et certaines provinces n'autorisent pas les
clauses limitant la duree des garanties tacites ou I'exclusion
des dommages indirects au accessoires, au I'une et I'autre.
Par consequent, il est possible que les clauses restrictives
ou exclusives ci-dessus ne s'appliquent pas a vous.
La presente garantie vous accorde des droits legaux precis; il
se peut que vous en ayez d'autres, qui peuvent varier d'un etat
(ou d'une province) a un autre.
La presente garantie ne s'applique que dans Ie pays oCJ Ie
produit a ete achete, incluant ses possessions etterritoires.
OM-010 Rev. 06/06

A Member of the Lenbrook Group of Companies
Register Your Warranty Online Now
for a chance to win PSB speakers.
Visit: www.psbspeakers.com/warranty
I!tl
633 Granite Court, Pickering, Ontario
Canada L1W 3K1
Phone: [phone]
[phone]
Fax: [phone]
www.psbspeakers.com
LIMITED WARRANTY _
PSB Speakers, a division of Lenbrook Industries Limited,
warrants the following products for the periods indicated:
Products
Loudspeakers and Powered Subwoofers
How Long Does the Warranty Last?
All PSB loudspeakers and subwoofer drivers have a 5-year
warranty. PSB amplifiers, including the amplifiers used in
our "powered speakers" (such as powered subwoofers)
have a1 year warranty.
What is Covered and What is Not Covered?
Except as specified below, this warranty covers parts and
labor to correct all defects in materials and workmanship.
The following are not covered by the warranty:
1. Damage, deterioration, malfunction or failure to meet
performance specifications resulting from:
a) Accident, acts of nature, misuse, abuse, neglect or
unauthorized product modification.
b) Improper installation, removal or maintenance, or failure
to follow instructions supplied with the product.
c) Repair or attempted repair by anyone not authorized by
PSB Speakers to repair the product.
d) Any shipment of the product (claims must be presented
to the carrier).
e) Any cause other than a product defect.
2) Cleaning, initial set-up, check-ups with no defects found, or
charges incurred for installation, removal or reinstallation of
the product.
3) Any product on which the serial number has been defaced,
modified, or removed.
4) Accessories, including but not limited to, cables, mounting
hardware and brackets, and detachable power cords.
5) Any product used in any trade or business or in an industrial
or commercial application.
6) Any product purchased outside the country of service, its
possessions orterritories.
7) Any problem other than a product defect.
8) Any product not purchased from an authorized PSB
Speakers Dealer. If you're not sure a dealer is "authorized",
check our dealer locator or call PSB Speakers.
Who May Enforce the Warranty?
This warranty may be enforced only by the original purchaser.
What We Will Pay For
We will pay for all labor and material expenses for items
covered by the warranty. Payment of shipping charges is
discussed in the next section ofthis warranty.
Keep this warranty statement including the registration date
with your proof of purchase for your records.
How You Can Get Service
1) If your unit needs service, please take your speaker with the
original invoice or bill of sale to your PSB Speakers dealer. If
you need assistance locating a PSB dealer please look on
PSB's internet website or contact PSB directly.
2) You must pay any shipping charges if it is necessary to ship
the product for service. However, if the necessary repairs
are covered by the warranty, we will pay the return shipping
charges to any destination within the country of service.
3) Wherever warranty service is required, you must present
the original dated sales receipt, invoice, or other proof of
purchase.
Limitation of Implied Warranties
All implied warranties, including warranties of merchantability
and fitness for a particular purpose, are limited in duration to
the length of this warranty.
Exclusion of Damages
PSB Speakers' liability for any defective product is limited to
repair or replacement of the product at PSB's option. PSB shall
not be liable for damage to other products caused by any
defects in PSB's prOducts, damages based upon
inconvenience or loss of use of the product, or any other
damages, whether incidental, consequential, or otherwise.
How State (Provincial) Law Relates to the Warranty
Some states do not allow limitations on how long in implied
warranty lasts and/or do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitations
or exclusions may not apply to you.
This warranty give you specific legal rights, and you may also
have other rights, which vary, from State (Province) to State
(Province) .
This warranty is enforceable only inside the county of
purchase, its possessions or territories.
OM-010 Rev. 06/06
