PST PST-QSG-3002-01 User manual
Line-Powered Oxygen Analyzer Quick Start Guide
First air calibration and measurement
2 ProcessSensing.com
Welcome to the Quick Start Guide for first air calibration and first measurement using your line-powered analyzer.
Here, you will find information covering first air calibration in section A, and connecting to your process gas in section B to make your first
measurement in section C. Please read the safety information below.
Start here
Safety information
•Avoid covering the vent for the test flow indicator when gas is flowing to
the sensor. This can pressurize the sensor causing damage.
•To remove moisture and particulates, open the sensor housing and either
blow on the sensing surface or gently wipe the surface with a damp cloth.
Ensure ppm sensors have minimal exposure to air.
•You must connect the analog signal output to a recording device in
accordance with local safety directives.
•If your analyzer is an AIS or IS model, power to the alarm contacts must not
exceed 24 V DC.
The first calibration is of utmost importance as all subsequent
calibrations are based on the initial one.
NOTE: We recommend you use certified span gas for calibration; if
this is not available to you, follow these instructions to carry
out an air calibration.
The GPR-series of line-powered oxygen analyzers is compliant with the
following safety approvals and directives:
User Interface (UI)
Button Function
Menu
Enter
Previous (decrement)
Next (increment)
ProcessSensing.com 3
Line-Powered Oxygen Analyzer Quick Start Guide
First air calibration and measurement
A. First air calibration
The GPR-1800 and GPR-2800 are delivered without the sensor installed to
preserve its operational life. To install the sensor:
1. Apply power to your analyzer (refer to Figure 3 on page 5).
2. Use and to navigate to Select Range.
3. Press to select 0-25% (Air Cal).
4. Using the two latches, open the front window.
5. Open the sensor housing (refer to Figure 2 on page 4 for guidance).
6. Loosen the star wheel then disengage the top sensor housing by turning it 90°
counter-clockwise. Refer to ‘b’ in Figure 2 on page 4.
7. Remove the sensor from its packaging, remove the shorting flags and
immediately place in the top sensor housing (refer to Figure 1 on page 4).
8. Hold the sensor in the top sensor housing away from any gas stream.
After 2...3 minutes the sensor is stable.
9. On your analyzer, press .
10. Use and , navigate to Calibration > Span Calibrate.
11. Now use and to enter the value 20.90 %.
Ensure the reading has stabilized before continuing.
NOTE: When a Span or Zero Cal starts, only "Abort" with is
shown until the reading is stable, then "Accept" with
appears.
12. Use to Accept, and to Abort.
13. Now place the sensor into the bottom sensor housing with the gold contact
plate facing upwards, (see Figure 1 on page 4 for guidance,) and replace the
top sensor housing by placing it on top of the sensor and turning 90°
clockwise.
14. Secure it with the star wheel at the bottom of the housing assembly (refer to
‘b’ in Figure 2 on page 4).
15. Quickly close your analyzer and continue immediately to section B.
B. Process gas connection
1. Connect your process gas line to the inlet on the flow meter (refer to Figure 4
on page 5).
NOTE: If you have an analyzer with a sample system connect your span
gas and sample gas lines to the appropriate ports. Once
connected, move the 3-way valve to the desired position for
Process gas.
2. Ensure the flow rate is at 1...2 SCFH and allow the span gas to flow for 2...3
minutes. This will purge the system.
3. Continue to section B.
Line-Powered Oxygen Analyzer Quick Start Guide
First air calibration and measurement
4 ProcessSensing.com
C. Making your first measurement
1. Observe the reading on your analyzer to ensure the O2 concentration is
trending downward.
2. When the O2 reading is in the desired sampling range, press on your
analyzer.
3. Use and to navigate to Select Range then press .
4. Use and to select your required operating range.
E.g. Response time: Sensor exposed to air for 2...3 minutes and installed in
<1 ppmV O2 sample gas:
NOTE: Response times are dependent on your analyzer model as
well as your sensor.
D. Figures
Figure 1 - Aligning your sensor
Figure 2 - Installing and uninstalling your sensor
Reading Recovery time
(Air to 0 ppm with N2 purge)
0.1 % 5 minutes
100 ppm 30 minutes
10 ppm 60 minutes
> 1 ppm 6-12 hours
Top sensor housing
Bottom sensor housing
90O
Loosen
Tighten
Star wheel a
b
Sensor
ProcessSensing.com 5
Line-Powered Oxygen Analyzer Quick Start Guide
First air calibration and measurement
Figure 3 - Wiring your analyzer
Figure 4 - Gas inlet (analyzer’s right side elevation)
E. Useful links
Scan below for more information:
= A and AIS models only
