HT HTB500 User manual

Copyright HT ITALIA 2020 Release EN 1.00 - 12/02/2020
ENGLISH
User manual

HTB500
EN – 1
TABLE OF CONTENTS
1.PRECAUTIONS AND SAFETY MEASURES ...............................................................2
1.1.Preliminary instructions ..................................................................................................... 2
1.2.During use......................................................................................................................... 2
1.3.After use............................................................................................................................ 2
2.GENERAL DESCRIPTION ...........................................................................................3
3.PREPARATION FOR USE ...........................................................................................3
3.1.Initial checks...................................................................................................................... 3
3.2.Instrument power supply ................................................................................................... 3
3.3.Storage.............................................................................................................................. 3
4.NOMENCLATURE........................................................................................................4
4.1.Description of the front part of the instrument ................................................................... 4
4.2.Description of the instrument’s side .................................................................................. 4
4.3.Description of the external probe ...................................................................................... 5
4.4.Description of function keys .............................................................................................. 6
4.4.1.Key ON/OFF............................................................................................................................... 6
4.4.2.Key Bright ................................................................................................................................... 6
4.4.3.Key (Zoom)............................................................................................................................ 6
4.4.4.Key (Rotate)......................................................................................................................... 6
4.4.5.Key RESET................................................................................................................................. 6
5.OPERATING INSTRUCTIONS.....................................................................................7
5.1.Using the instrument ......................................................................................................... 7
6.MAINTENANCE ...........................................................................................................8
6.1.General information........................................................................................................... 8
6.2.Battery recharge................................................................................................................ 8
6.3.Cleaning the instrument .................................................................................................... 8
6.4.End of life .......................................................................................................................... 8
7.TECHNICAL SPECIFICATIONS ..................................................................................9
7.1.Technical characteristics ................................................................................................... 9
7.2.General characteristics...................................................................................................... 9
7.3.Environment ...................................................................................................................... 9
7.3.1.Environmental conditions for use ............................................................................................... 9
7.4.Accessories....................................................................................................................... 9
7.4.1.Accessories provided ................................................................................................................. 9
7.4.2.Accessories provided ................................................................................................................. 9
8.ASSISTANCE.............................................................................................................10
8.1.Warranty conditions......................................................................................................... 10
8.2.Assistance....................................................................................................................... 10

HTB500
EN – 2
1. PRECAUTIONS AND SAFETY MEASURES
The instrument has been designed in compliance with the safety directive relevant to
electronic measuring instruments. In order to prevent damaging the instrument, please
carefully follow the procedures described in this manual and read all notes preceded by
symbol with the utmost attention. Before and after carrying out measurements,
carefully observe the following instructions:
Do not carry out any measurements in case gas, explosive materials or flammables are
present, or in humid or dusty environments.
Do not carry out any measurement in case you find anomalies in the instrument such
as deformation, substance leaks, absence of display on the screen, etc.
In this manual, and on the instrument, the following symbols are used:
Caution: observe the instructions given in this manual. Improper use may
damage the instrument or its components.
Make sure not to damage/interrupt the external probe in order to carry out
normal operations.
Make sure not to crush/squeeze the external probe in order to carry out normal
operations.
1.1. PRELIMINARY INSTRUCTIONS
We recommend following the normal safety rules devised to protect the user against
dangerous situations and the instrument against incorrect use.
Only the accessories provided together with the instrument will guarantee safety
standards. They must be used only if in good conditions and replaced with identical
models, when necessary.
Check that the battery is correctly inserted.
1.2. DURING USE
Please carefully read the following recommendations and instructions:
CAUTION
Failure to comply with the caution notes and/or instructions may damage
the instrument and/or its components or be a source of danger for the
operator.
Use the instrument and the external probe as instructed in this manual.
Should the instrument remain blocked and not function properly during use, please
press the RESET key (see § Fig. 2)
1.3. AFTER USE
When operations are complete, switch off the instrument.
If you expect not to use the instrument for a long period, remove the battery.

HTB500
EN – 3
2. GENERAL DESCRIPTION
Model HTB500 is a portable digital borescope which allows carrying out inspections inside
parts of objects not physically accessible (typically rotating equipment) and not visible to
the naked eye. The instrument uses a waterproof external probe with 4 LEDs with high
brightness and a camera, in order to obtain a high-resolution image on the display.
The instrument’s characteristics are the following:
Real-time display of the item
Waterproof flexible external probe (IP67)
Built-in white-light LEDs for operations in poorly lit environments
Image rotation (0° - 180°) on the display
Adjustment of brightness
Rechargeable Li-ION battery
USB input for battery recharge
Analog video output (PAL/NTSC) for the connection to external devices
Electronic image zoom
3. PREPARATION FOR USE
3.1. INITIAL CHECKS
Before shipping, the instrument has been checked from an electric as well as mechanical
point of view. All possible precautions have been taken so that the instrument is delivered
undamaged. However, we recommend generally checking the instrument in order to detect
possible damage suffered during transport. In case anomalies are found, immediately
contact the forwarding agent. We also recommend checking that the packaging contains
all components indicated in § 7.4.1. In case of discrepancy, please contact the Dealer. In
case the instrument should be returned, please follow the instructions given in § 8.
3.2. INSTRUMENT POWER SUPPLY
The instrument is powered by 1x3.7V rechargeable 2000mAh Li-ION battery included in
the package. The “” symbol appears on the display when the battery is flat. Recharge
the battery by following the instructions given in § 6.2.
3.3. STORAGE
In order to guarantee precise measurement, after a long storage time under extreme
environmental conditions, wait for the instrument to come back to normal operating
conditions (see § 7.3.1).

HTB500
EN – 4
4. NOMENCLATURE
4.1. DESCRIPTION OF THE FRONT PART OF THE INSTRUMENT
CAPTION:
1. LCD display
2. Key Bright
3. Key ON/OFF
4. Battery compartment
cover
5. Input terminal for
external probe
6. Key (Zoom)
7. Key (Rotate)
Fig. 1: Description of the front part of the instrument
4.2. DESCRIPTION OF THE INSTRUMENT’S SIDE
CAPTION:
1. Video output (TV)
2. Key RESET
3. USB input for battery
recharge
4. Battery compartment
cover
5. Input terminal for
external probe
Fig. 2: Description of the instrument’s side

HTB500
EN – 5
4.3. DESCRIPTION OF THE EXTERNAL PROBE
CAPTION:
1. Male terminal for the
connection of the
probe to the
instrument
2. Flexible external probe
3. Probe terminal with
built-in camera
4. Female terminal for
the connection of the
probe to the
instrument
5. White-light LEDs
6. Built-in photo camera
Fig. 3: Description of the external probe

HTB500
EN – 6
4.4. DESCRIPTION OF FUNCTION KEYS
4.4.1. Key ON/OFF
Pressing key ON/OFF allows turning on/off the instrument. Upon start-up, with
disconnected external probe, the instrument only shows an empty screen with the symbol
of the battery charge level.
4.4.2. Key Bright
Pressing key Bright allows adjusting the brightness of the white-light LEDs on the end of
the external probe (see Fig. 3 – part 5) up to 10 levels. The following screen appears on
the display for a moment.
Fig. 4: Setting of brightness levels of the probe’s LEDs
4.4.3. Key (Zoom)
Pressing key allows the zooming of the image on the display from 1.0x ÷ 2.0x by steps
of 0.2x. The following screen appears on the display:
Fig. 5: Setting of the display image zooming
4.4.4. Key (Rotate)
Pressing key allows rotating the image on the display, switching to a 180° view (see
Fig. 6).
Image 0° Image 180°
Fig. 6: Image rotation on the display
4.4.5. Key RESET
Pressing key RESET (see Fig. 2 – part 2) allows resetting the internal system by switching
the instrument off and on again.

HTB500
EN – 7
5. OPERATING INSTRUCTIONS
5.1. USING THE INSTRUMENT
CAUTION
Use the instrument in dry environments or with low humidity levels,
respecting the instructions given with the technical specifications in order
to avoid any damage.
Only the probe’s built-in photo camera is fully waterproof.
Do not expose the photo camera to sunlight or to external probes which
may reflect light onto it during operations.
Handle with care.
1. Insert the rechargeable battery into the relevant compartment (see Fig. 2 – part 4),
connecting it as shown in Fig. 7
Fig. 7: Connecting the battery to the instrument
2. Insert the external probe into the instrument (see Fig. 3 - parts 1 and 4) and fasten it by
screwing in the connector (see Fig. 2 – part 5).
3. Switch on the instrument using key ON/OFF. The white-light LEDs of the probe switch
on and the image of the framed item appears on the display. Move the probe to the
desired position.
4. To use the functions Bright, Zoom and Rotate, please refer to § 4.4
5. In case you want to use the instrument together with an external device, please
connect the TV video output (PAL/NTSC type) of the instrument (see Fig. 2 – part 1)
through a standard video cable. The instrument automatically recognizes the presence
of a PAL or NTSC system.
6. Switch off the instrument using key ON/OFF.

HTB500
EN – 8
6. MAINTENANCE
6.1. GENERAL INFORMATION
1. While using and storing the instrument, carefully observe the recommendations listed
in this manual in order to prevent possible damage or danger during use.
2. Do not use the instrument in environments with high humidity levels or high
temperatures. Do not expose to direct sunlight.
3. Always switch off the instrument after use.
6.2. BATTERY RECHARGE
When the display shows symbol “ ”, it is necessary to replace the battery.
CAUTION
Only expert technicians should perform this operation. Before carrying out
this operation, make sure you have removed the probe from the input
terminal.
1. Switch off the instrument and remove the probe from the input terminal.
2. Connect the provided USB cable to the USB input of the instrument (see Fig. 2 – part 3)
and the other end of the cable to a USB port of the PC, regularly switched on.
3. The recharging process starts and the following icons “” are shown in
a sequence on the display:
4. At the end of the recharging process, the icon “” appears fixed on the display.
5. When necessary, replace the battery. Do not discard the used one into the
environment. Use the relevant containers for battery disposal.
6.3. CLEANING THE INSTRUMENT
Use a soft and dry cloth to clean the instrument. Never use wet cloths, solvents, water, etc.
6.4. END OF LIFE
WARNING: this symbol found on the instrument indicates that the appliance, its
accessories and the battery must be collected separately and correctly disposed
of.

HTB500
EN – 9
7. TECHNICAL SPECIFICATIONS
7.1. TECHNICAL CHARACTERISTICS
External camera
Sensor size: ¼in (CMOS), 300.000pxl
Max sensor resolution: 640x480pxl
Max sampling frequency: 30FPS/S
Colour depth: 24bit
Image focusing: fixed (5cm ÷ 15cm) (2.0in ÷ 5.9in)
External probe length: 1m (39in)
Camera diameter: 6mm (0.2in)
Camera light: 4 white-light LEDs
Adjustment of brightness: 10 levels
7.2. GENERAL CHARACTERISTICS
Mechanical characteristics
Dimensions (L x W x H): 250 x 100 x 95mm (10 x 4 x 4in)
Weight (battery included): 345g (12 ounces)
Mechanical protection: IP54 (instrument), IP67 (external probe)
Power supply
Battery type: 1x3.7V rechargeable Li-ION battery, 2000mAh
Low battery indication: symbol “” on the display
Battery life: approx. 5 hours (stand-by)
Recharging time: approx. 8 hours (USB interface)
Interface
Video output: PAL/NTSC
Power supply input: mini USB (5VDC, 1000mA)
Display
Characteristics: colour, LCD-TFT, 3.5”, 640x320pxl
7.3. ENVIRONMENT
7.3.1. Environmental conditions for use
Operating temperature: 0°C ÷ 50°C (32°F ÷ 122°F)
Allowable relative humidity: <85%RH
Storage temperature: -20°C ÷ 60°C (-4°F ÷ 140°F)
Storage humidity: <85%RH
Max operating altitude: 2000m (6562ft)
This instrument complies with European Directive EMC 2014/30/EU
This instrument satisfies the requirements of European Directive 2011/65/EU
(RoHS) and 2012/19/EU (WEEE).
7.4. ACCESSORIES
7.4.1. Accessories provided
Flexible external probe, L=1m, D=6mm
Rechargeable Li-ION battery
USB cable for battery recharge
Carrying bag
User manual
7.4.2. Accessories provided
Flexible external probe, L=3m, D=6mm Cod: BP36

HTB500
EN – 10
8. ASSISTANCE
8.1. WARRANTY CONDITIONS
This instrument is warranted against any material or manufacturing defect, in compliance
with the general sales conditions. During the warranty period, defective parts may be
replaced. However, the manufacturer reserves the right to repair or replace the product.
Should the instrument be returned to the After-sales Service or to a Dealer, transport will
be at the Customer's charge. However, shipment will be agreed in advance. A report will
always be enclosed to a shipment, stating the reasons for the product's return. Only use
original packaging for shipment; any damage due to the use of non-original packaging
material will be charged to the Customer. The manufacturer declines any responsibility for
injury to people or damage to property.
The warranty shall not apply in the following cases:
Repair and/or replacement of accessories and batteries (not covered by warranty)
Repairs that may become necessary as a consequence of an incorrect use of the
instrument or due to its use together with non-compatible appliances.
Repairs that may become necessary as a consequence of improper packaging.
Repairs which may become necessary as a consequence of interventions performed
by unauthorized personnel.
Modifications to the instrument performed without the manufacturer's explicit
authorization.
Use not provided for in the instrument's specifications or in the instruction manual.
The content of this manual cannot be reproduced in any form without the manufacturer's
authorization.
Our products are patented and our trademarks are registered. The manufacturer
reserves the right to make changes in the specifications and prices if this is due to
improvements in technology.
8.2. ASSISTANCE
If the instrument does not operate properly, before contacting the After-sales Service,
please check the conditions of the battery and replace it, if necessary. Should the
instrument still operate improperly, check that the product is operated according to the
instructions given in this manual. Should the instrument be returned to the After-sales
Service or to a Dealer, transport will be at the Customer's charge. However, shipment will
be agreed in advance. A report will always be enclosed to a shipment, stating the reasons
for the product's return. Only use original packaging for shipment; any damage due to the
use of non-original packaging material will be charged to the Customer.
