PTN MMX6464 User manual

Modular Matrix Switcher 64x64
PTN Electronics Limited www.PTN-electronics.com
MMX6464
PTN Modular Matrix Switcher 64x64
USER MANUAL
Version: MMX64642013V1.1

Modular Matrix Switcher 64x64
PTN Electronics Limited www.PTN-electronics.com
NOTICE: Please read this user manual carefully before using this product.
Update History
Version
Date
Update Content
1.0
2012.12.22
First Version.
1.1
2013.05.24
Modified the system diagram.
This manual is for operation instruction only, not for any maintenance usage.
The functions described in this version are updated till May 2013. Any changes
of functions and parameters since then will be informed separately. Please
refer to the dealers for the latest details.
This manual is copyright PTN Electronics Limited. All rights reserved. No part
of this publication may be copied or reproduced without the prior written
consent of PTN Electronics Limited.
All product function is valid till 2013-05-24.

Modular Matrix Switcher 64x64
PTN Electronics Limited www.PTN-electronics.com
Table of Contents
1. Introduction ...............................................................................................................1
1.1. About MMX6464............................................................................................1
1.2. MMX Modular Matrix Switcher Models...........................................................1
1.3. MMX signal card (changeable cards).............................................................1
1.4. Package Contents..........................................................................................2
2. Features....................................................................................................................2
3. Specification..............................................................................................................3
3.1. Main Unit........................................................................................................3
3.2. Changeable Cards.........................................................................................3
4. Operations of the Front Panel...................................................................................6
5. External Connection..................................................................................................8
5.1. Introduction of the Input and Output Connectors ...........................................8
5.2. Changeable Cards Introduction & Installation................................................8
5.3. Connection of RS-232 Communication Port................................................13
5.4. Connection with Computer...........................................................................13
5.5. Connection of TCP/IP Communication Port (Optional Function)..................13
6. System Diagram......................................................................................................14
7. Communication Protocol and Command Codes .....................................................15
8. Safety Operation Guide...........................................................................................18
9. Troubleshooting & Maintenance..............................................................................19
10.After-sales Service..................................................................................................20

Modular Matrix Switcher 64x64
PTN Electronics Limited 1 www.PTN-electronics.com
1. Introduction
1.1. About MMX6464
MMX6464 is a high performance video and audio modular matrix switcher. Various
changeable cards make MMX matrix flexible and all-in-one solution for different projects.
It can support different video signals with cross switching.
There are two series of changeable cards work with MMX matrix, input card MMX-4I
series and output card MMX-4O series; all the cards support hot plug & play. Users can
choose the right card for different application. There are different signal card is used for
processing different video signal, including: HMDI, DVI, VGA, SDI and HDMI TP etc.
MMX6464 can be used for different project, because of its changeable card design. It is
the combo solution for multimedia conference rooms, control rooms, broadcasting
rooms, shopping center etc. It will handle all the audiovisual management, including the
switching, driving, scaling etc.
1.2. MMX Modular Matrix Switcher Models
Spec
Models
Height
Maximum Slot
Power
supplies
RS232
control
Network
control
MMX88A
2U
2 input card
slots & 2 output
card slots
Single
√
Optional
MMX1616
3U
4 input card
slots & 4 output
card slots
Dual
√
Optional
MMX3232
5U
8 input card
slots & 8 output
card slots
Dual
√
Optional
MMX6464
10U
16 input card
slots & 16
output card
slots
Dual
√
Optional
1.3. MMX signal card (changeable cards)
To meet different situation and users, the MMX6464 cards are classified into the
following models:

Modular Matrix Switcher 64x64
PTN Electronics Limited 2 www.PTN-electronics.com
S pec
Models
Inputs
Signal Format
MMX-4I-HD
4
HDMI
MMX-4I-DV
4
DVI
MMX-4I-VG
4
VGA
MMX-4I-SD
4
SDI
MMX-4I-TP
4
RJ45
Spec
Models
Outputs
Signal Format
MMX-4O-HD
4
HDMI
MMX-4O-DV
4
DVI
MMX-4O-SD
4
SDI
MMX-4O-TP
4
RJ45
1.4. Package Contents
1 x MMX6464
1 x Power Cord
1 x IR remote (The cell battery is not included)
4 x Plastic cushions
1 x RS232 cable
1 x User manual
2. Features
Modular chassis with configurable I/O slots, ranging from 4x4 to 64x64.
Various I/O cards, includes HDMI, HDBaseT, SD/HD/3G-SDI, DVI and VGA cards
(Compatible with YUV, YC & CVBC.) to configure any matrix.
Truly crosspoint switching, any input to any output, regardless signal format.
Advanced EDID management, 3 ways to guarantee maximum compatibility.
Support HDMI1.4a, support 3D.
Integrated HDBaseT technology.
I/O cards works directly with CATx extender.
Ultra-switching for instaneous display, ensures the transition runs smoothly.
Unique pixel accurate re-clocking technology, providing exceptional output
transmission and accurate timing.
Controllable via button, RS232 & TCP/IP, also compatible with 3rd parties control.
Field-upgradeable and hot-swappable, friendly to use and maintain.
HDCP compliant.
LCD display.
MMX input cards
MMX output cards

Modular Matrix Switcher 64x64
PTN Electronics Limited 3 www.PTN-electronics.com
3. Specification
3.1. Main Unit
Control parts
Serial control port
RS-232, 9-pin female
D connector
Pin
Configurations
2 = TX, 3 = RX, 5
= GND
Installation
Rack Mountable
Front panel
control
Buttons
Options
TCP/IP control by PTNET(PTN's programmable interface)
General
Power Supply
100VAC ~ 240VAC,
50/60Hz
Power
Consumption
200W
Temperature
-20 ~ +70℃
Humidity
10% ~ 90%
Case Dimension
W483 x H438 x
D320mm (10U high)
Product Weight
5Kg
3.2. Changeable Cards
3.2.1. MMX-4I-DV & MMX-4O-DV
Input
Output
Input
4 DVI
Output
4 DVI
Input Connector
Female DB24+5
Output
Connector
Female DB24+5
Input Level
T.M.D.S. 2.9V/3.3V
output Level
T.M.D.S. 2.9V/3.3V
Input Impedance
75Ω
Output
Impedance
75Ω
General
Gain
0 dB
Bandwidth
6.75 Gbit/s
Video Signal
DVI 1.0/HDMI 1.4a
full digital T.M.D.S
signal
Max
Time-delay
5nS (±1nS)
Switching Speed
200ns (Max.)
Crosstalk
<-50dB@5MHz
EDID and DDC
Supports Extended Display Identification Data (EDID) and
Display Data Channel (DDC) data using DVI and HDMI 1.4a
standards. EDID and DDC signals are actively buffered
HDCP
Compliant with HDCP using DVI and HDMI 1.4a standards

Modular Matrix Switcher 64x64
PTN Electronics Limited 4 www.PTN-electronics.com
3.2.2. MMX-4I-HD & MMX-4O-HD
Input
Output
Input
4 HDMI
Output
4 HDMI
Input Connector
Female HDMI
Output
Connector
Female HDMI
Input Level
T.M.D.S. 2.9V/3.3V
output Level
T.M.D.S. 2.9V/3.3V
Input Impedance
75Ω
Output
Impedance
75Ω
General
Gain
0 dB
Bandwidth
6.75 Gbit/s
Video Signal
DVI 1.0/HDMI 1.4a full
digital T.M.D.S signal
Max
Time-delay
5nS (±1nS)
Switching Speed
200ns (Max.)
Crosstalk
<-50dB@5MHz
EDID and DDC
Supports Extended Display Identification Data (EDID) and
Display Data Channel (DDC) data using DVI and HDMI 1.4a
standards. EDID and DDC signals are actively buffered
HDCP
Compliant with HDCP using DVI and HDMI 1.4a standards
3.2.3. MMX-4I-VG
Input
Input
4 VGA
Input Level
0.5 ~ 2.0Vp-p
Input
Connector
Female 15 pin HD
Input
Impedance
75Ω
General
Gain
0 dB
Bandwidth
350MHz (-3dB), fully
load
Video Signal
VGA-UXGA,RGBHV,RGBS, RGsB, RsGsBs, component video,
S-video & C-video .
Switching
Speed
200ns (Max.)
Crosstalk
<-50dB@5MHz
3.2.4. MMX-4I-SD & MMX-4O-SD
Input
Output
Input
4 SDI
Output
4 SDI
Input
Connector
Female BNC
Output
Connector
Female BNC
Input Level
0.8Vp-p ±10%
output Level
0.8Vp-p ±10%
Input
Impedance
75Ω
Output
Impedance
75Ω
General

Modular Matrix Switcher 64x64
PTN Electronics Limited 5 www.PTN-electronics.com
Gain
Unity
Maximum
Data Rate
2.97 Gbps
Transmission
Distance
300M (Max.)
Data rate Lock
Auto
Input Return
Loss
<-14 dB @ 1 MHz ~
1.5 GHz
Input Return
Loss
<-14 dB @ 1 MHz ~
1.5 GHz
Video
Standard
SMPTE 292M,
SMPTE 259M,
SMPTE 424M,
ITU-RBT.601,
ITU-RBT.1120
Data Type
8bit, 10bit
3.2.5. MMX-4I-TP & MMX-4O-TP
Video Input
Video Output
Input
4 RJ45, 4 IR & 4
RS232
Output
4 RJ45, 4IR&RS232
Input
Connector
Female RJ45
3.5mm mini jack for
IR
3 poles captive screw
connector for RS232
Output
Connector
Female RJ45
3.5mm mini jack for
IR
3 poles captive screw
connector for RS232
Input
Impedance
75Ω
Output
Impedance
75Ω
Video General
Gain
0dB ~
10dB@100MHz
Bandwidth
6.75Gbps
Resolution
range
800x600 ~
1920x1200
Transmission
Distance
70M(Max)
SNR
>70dB@
100MHz-100M
Return Loss
<-30dB@ 5KHz
THD
＜0.005%@1KHz
Min.～Max.
Level
＜0.3V ~ 1.45Vp-p
HDMI
Standard
Support HDMI1.4a
and HDCP
Differential
Phasic Erro
±10°@
135MHz_100M

Modular Matrix Switcher 64x64
PTN Electronics Limited 6 www.PTN-electronics.com
4. Operations of the Front Panel
There are two parts in the front panel.
1) System monitor: the system switching and status monitor.
2) Crystal buttons: with green back-light indicating, including I/O buttons and function
buttons.
Buttons
Function Description
INPUTS
Input buttons. It is the number of every input channel (64 channels
in total), ranging from "0" to "9".
OUTPUTS
Output buttons. It is the number of every output channel (64
channels in total), ranging from "0" to "9".
AV
AV synchronal button: To transfer video and audio signal
synchronously by the switcher.
Operation: Press buttons in this order “3”, “AV”, “4”.
,
Division button: to divide the output channels when switching to
more than one channel.
Example: To transfer input 1 to output 1,8,15, you need to press
this button between each two output channels.
ENTER
Confirmation button: Confirm the switching operation. The
operation will not be executed by the matrix without confirmation.
ALL
All button: To transfer an input channel to all output channels.
Example1: To transfer video and audio signals from input channel
No.12 to all output channels
Operation: Press buttons in this order “12”, “ALL”

Modular Matrix Switcher 64x64
PTN Electronics Limited 7 www.PTN-electronics.com
Example2: To transfer all input signals to the corresponding output
channels respectively. In another word, to switch to this status:
1->1, 2->2, 3->3, 4->4…64->64.
Operation: Press buttons in this order “ALL”, “THROUGH”
THROUGH
Through button: To transfer the signals directly to the
corresponding output channels
Example: To transfer the signals from input channel No. 3 to their
corresponding output channels
Operation: Press buttons in this order “3”, “THROUGH”
UNDO
Undo button: To resume to the status before the command just
performed
Backspace button: To backspace the latest input button
Switching Operation:
With the front control panel, the MMX matrix could be control directly and rapidly by
pressing the buttons under below format.
“Input Channel”+ “Switch Mode”+“Output Channel”+“Enter”
1) “Switch Mode”: Audio & Video synchronal or break away switching mode, which
includes button “AV”.
2) “Input Channel”: Fill with the number of input channel to be controlled.
3) “Output Channel”: Fill with the number of output channels to be control
4) MMX6464 needs to use “,” button to separate multiple outputs, and “ENTER”button
to confirm the operation.
5) The input/output channels on the rear panel are counting from left to right,
top to bottom. And if the input/output channel is two digits number, the input
delay time between two numbers must less than 5 seconds; otherwise the
operation will be cancelled.
