Pulsar PSA12005 User manual

1
Switch mode power supply adapters
PSA12005, PSA12010, PSA12015
EN
Edition: 1st from 09.07.2010
Supercedes edition:_ _ _ _ _
1. Technical description.
1.1. General description.
Stabilised DC power supply is intended for cameras installed in CC V industrial systems. he unit has a
cable with a DC5.5/2.1 pin. When connected to fuse blocks of the LB4/xx/xx or LB8/xx/xx family, the power supply
unit can feed more cameras (max. 4 or 8). he unit is protected against short-circuit and overload.
1.2. Technical parameters.
PSA12005 PSA12010 PSA12015
imensions (L x W x H) 59 x 39 x 65 mm 70 x 29 x 76 mm 71 x 46 x 68 mm
Net/Gross weight 70g/80g 80g/95g 100g/120g
C plug DC5,5/2,1 female
Cable length 145 cm
Supply voltage
110 V÷ 240 V AC 50/60 Hz
Output power
6W
MAX
12W
MAX
18W
MAX
Output voltage 12 V DC
Maximum output current
for t
AMB
<30°C 500mA* 1000mA* 1500mA*
Maximum output current
for t
AMB
=40°C 350mA* 700mA* 1000mA*
Short circuit protection SCP /
overload protection OLP Yes Yes Yes
Operation status indication Yes - LED diode No Yes - LED diode
Operation conditions
0
o
C ÷ 40
o
C , RH 10 ÷ 90 %, no condensation
* - output current of the power supply unit depending on ambient temperature. For temperature above 30°C
maximum output current is limited according to graph 1. he power supply operation life time is limited by
reliability of the electrolyte capacitors which strongly depends of an operation temperature. Avoid excessive
temperature rise of the power supply!
Graph 1 Relation between output current and ambient temperature.

2
1.3. Accessories.
Fallowing accessories are available for adapters:
- fuse blocks LB4/xx/xx (AWZ573, AWZ574, AWZ575, AWZ576)
Fuse block is intended for connect multiple loads to one power supply unit. Fuse block has four, independently
protected outputs. Each output is protected against: overvoltage (varistor) and short circuit / overload. Depends of
type of the fuse block, overload / short circuit protection is realized with fuse or resettable P C fuse.
AWZ573
LB4/0,3A/PTC
AWZ574
LB4/0,5A/PTC
AWZ575
LB4/1,0A/PTC
AWZ576
LB4/0,3-1,0A/FTA
Protections:
- short circuit SCP
- overload OLP
- 4 x 0,3A P C - 4 x 0,5A P C - 4 x 1,0A P C - 4 x F 0,3A or
- 4 x F 0,5A or
- 4 x F 1,0A
- fuse blocks LB8/xx/xx (AWZ577, AWZ578, AWZ579, AWZ580)
LB8/xx/xx module is similar to LB4/xx/xx with one exception: LB8/xx/xx has eight outputs.
AWZ577
LB8/0,3A/PTC
AWZ578
LB8/0,5A/PTC
AWZ579
LB8/1,0A/PTC
AWZ580
LB8/0,3-1,0A/FTA
Protections:
- short circuit SCP
- overload OLP
- 8 x 0,3A P C - 8 x 0,5A P C - 8 x 1,0A P C - 4 x F 0,3A or
- 4 x F 0,5A or
- 4 x F 1,0A
- adapter CABLE – DC 5,5/2,1 PLUG (ML109)
2. Installation.
2.1 Requirements.
he adapter shall be mounted by the qualified installer having appropriate (required and necessary for a
given country) permissions and qualifications for connecting (operating) low-voltage installations. he unit shall be
mounted in closed rooms, according to the environment class II, of the normal air humidity (RH=90% max. without
condensation) and the temperature within the range from 0°C to +40°C.
he adapter shall be mounted in a close casing (a cubicle, a terminal device) and in order to fulfill LVD and
EMC requirements the rules for power-supply, encasing and shielding shall be observed according to application.
2.2 Installation procedure.
1. Connect the DC output to the load/loads.
2. Connect the power supply unit to the AC line. he power supply has to by installed in such way to keep the air
flow around the supply unit.
3. After tests and operation control are performed, the casing (cubicle) shall be closed etc.
3. Maintenance.
he adapter does not require any specific maintenance procedures, however, in the case of significant
level of dust, it should be cleaned with the compressed air.

3
WEEE designation
The waste electric and electronic equipment worn out may not be disposed of
together with standard household waste. According to the WEEE directive,
applicable in the EU, the separate neutralization methods should be used for
electric and electronic equipment.
Pulsar K.Bogusz Sp.j.
Siedlec 150, 32-744 Łapczyca, Poland
el. ([phone], Fax. [phone]
e-mail: biur[email protected], sal[email protected]
http:// www.pulsar.pl
