Pulsar HPSDC Series User manual

1
USER MANUAL
EN
Edition: 1 from 06.09.2021
Supersedes edition:
Power supplies
HPSDC series
v1.0
Multi-output power supply units HPSDC series

2
Features:
supply voltage ~200 - 240 V
available versions with 4, 8 or 16 outputs
protected with fuses
high efficiency (up to 86%)
adjustable output voltage 12 - 15V DC
LED optical indication
FPS technical output of fuse activation indication
protections:
SCP short circuit protection
OVP overvoltage protection
surge protection
OLP overload protection
antisabotage protection: unwanted
enclosure opening
warranty –2 years from production date
TABLE OF CONTENTS:
1. Technical description.
1.1. General description
1.2. Block diagram
1.3. Description of PSU components and connectors
1.4. Specifications
2. Installation.
2.1. Requirements
2.2. Installation procedure
3. Operating status indication.
3.1. Optical indication
4. Technical output
5. Operation and use
5.1. Overload or short circuit of the PSU module output.
5.2. Operation of the PSU OVP system
6. Maintenance
1. Technical description.
1.1. General description.
HPSDC series stabilized power supplies are designed to supply power to HD cameras or other devices requiring
stabilized voltage of 12 V DC. Output voltage is adjusted with a potentiometer within the range of 12 - 15 V DC. The PSU
features 4, 8 or 16 outputs (depending on the model), protected independently by glass fuses.
A failure (an overload, a short circuit) in the output circuit will result in blowing of the fuse Fn and disconnection of the
corresponding AUXn output from the power supply. The power supplies are equipped with short-circuit, overload,
overvoltage and overcurrent protection. They are mounted inside a metal enclosure equipped with a signalling panel and
a microswitch indicating the opening of the door (lid).
Table 1. Parameters of power supplies:
Model
Number of
outputs
Output voltage AUX
Output current max.
HPSDC-12V4x1A
4
12 V
(12 –15 V)
4 A
HPSDC-12V8x1A
8
7 A
HPSDC-12V16x1A
16
15 A
.
1.2.Block diagram (Fig. 1).
Fig. 1. Block diagram of PSU.

3
1.3. Description of PSU components and connectors.
Table 2. Elements and connector of PSU (see Fig. 2a, 2b, 2c).
Element no.
Description
[1]
L1…Ln (green) LEDs (indicating presence of voltage at each output of the PSU)
[2]
F1…Fn glass fuse in AUX (+) circuits
[3]
AUX1…AUXn outputs
[4]
LED (red) indicating failure of one of the outputs (fuse activation) AUX1 - AUXn
[5]
FPS output indicating failure of one of outputs, relay type
[6]
L-N power supply connector 230 V AC, PE protection connector
[7]
Main fuse
[8]
Optical indication connector LED
[9]
VADJ potentiometer, output voltage adjustment 12 –15 V DC
Fig. 2a. View of power supply module HPSDC-12V4x1A
Fig. 2b. View of power supply module HPSDC-12V8x1A
Fig. 2c. View of power supply module HPSDC-12V16x1A

4
Table 3. View of PSU (see Fig. 3).
Element no.
Description
[1]
PSU module
[2]
Cable ellipse opening
[3]
TAMPER; microswitch of antisabotage protection (NC)
Fig. 3. View of PSU
1.4.Specifications.
- electrical parameters (tab. 4)
- mechanical parameters (tab. 5)
- operation safety (tab. 6)
- operating parameters (tab. 7)
Table 4. Electrical parameters.
Model
HPSDC-12V4x1A
HPSDC-12V8x1A
HPSDC-12V16x1A
Supply voltage
~ 200 –240 V
Current consumption
0,5 A
0,8 A
1,6A
Ripple voltage
50mV p-p max.
50mV p-p max.
100mV p-p max.
Power frequency
50/60 Hz
Inrush current
40 A
50A
60A
PSU power
48 W max.
84 W max.
180 W max.
Output current
4x1 A (Σ I = 4A max.)
8x1 A (Σ I = 7A max.)
16x1 A (Σ I = 15A max.)
Efficiency
86%
86%
85%
Output voltage (factory
setting)
12 V DC
Adjustment range UAUX
12 –15 V DC
Short circuit protection
SCP
4x F 1A glass fuse fast
blow
8x F 1A glass fuse fast
blow
16x F 1A glass fuse fast
blow
Type of glass fuse
F1A...F2A
Overload protection OLP
105 –150% PSU power, automatically recovered
Surge protection
varistors
Over voltage protection
OVP
>19V (activation requires disconnecting the load or
supply for about approx. 1 min.)
>19V (automatic recovery)

5
Protection in 230V circuit
Glass fuse T3,15A
Glass fuse T5A
LED operation indication
- LEDs on PCB of power supply unit
- LED indicators on power supply’s cover (see section 3.1)
Technical output FPS –
fuse failure
relay: 1 A@ 30 V DC /50 V AC,
Connectors
Power supply: 0,5 –2,5 mm2(AWG 26 –12)
AUX outputs and technical outputs: 0,5 –2,5 mm2(AWG 26 –12)
Notes
Convectional cooling
Forced cooling (fan)
Table 5. Mechanical parameters.
HPSDC-12V4x1A
HPSDC-12V8x1A
HPSDC-12V16x1A
Enclosure dimensions
(WxH) [±2mm]
270x200
270x200
300x258
Enclosure dimensions
(W1xH1xD1+D) [±2mm]
275x205x67+8
275x205x67+8
305x263x77+8
Mounting (WxH)
237x170
237x170
267x226
Net/gross weight
1,7 / 1,8 [kg]
1,8 / 1,9 [kg]
2,7 / 2,8 [kg]
Enclosure
Steel sheet DC01 0,7mm
Closing
screwed (at the front), (lock assembly possible)
Notes
Enclosure does not adjoin assembly surface so that cables can be led.
Table 6. Operation safety.
Protection class EN 62368-1
I (first)
Protection grade EN 60529
IP20
Electrical strength of insulation:
- between input and output circuits of PSU
- between input circuit and protection circuit
- between output circuit and protection circuit
2500 V AC min.
1500 V AC min.
500 V AC min.
Insulation resistance:
- between input circuit and output or protection circuit
100 MΩ, 500 V DC
Table 7. Operating parameters.
Operating temperature
-10ºC...+40ºC
Storage temperature
-20ºC...+60ºC
Relative humidity
20%...90%, without condensation
Vibrations during operation
unacceptable
Impulse waves during operation
unacceptable
Direct insolation
unacceptable
Vibrations and impulse waves during transport
According to PN-83/T-42106
2. Installation.
2.1. Requirements.
PSU is to be mounted by a qualified installer, holding relevant permits and licenses (applicable and required for a
given country) for 230 V in and low-voltage installations. Unit should be mounted in confined spaces, in accordance, with
normal relative humidity (RH=90% maximum, without condensing) and temperature from -10°C to +40°C. The PSU shall
work in a vertical position that guarantees sufficient convectional air-flow through ventilating holes of the enclosure.
As power supply is designed for a continuous operation and is not equipped with a power-switch, therefore, an
appropriate overload protection in power supply circuit should be provided. Moreover, the user shall be informed about
the method of unplugging (most frequently through separating and assigning an appropriate fuse in the fuse-box).
The electrical system shall follow valid standards and regulations.

6
LED green AC:
on –PSU is supplied with 230 V
off –no 230 V power
LED red FPS:
off –no failure
on –indicates fuse failure
2.2. Installation procedure.
CAUTION!
Before installation, cut off voltage in 230 V power-supply circuit. To switch power off, use an
external switch, in which distance between contacts of all poles in disconnection state is not less
than 3mm.
It is required to install an installation switch with a nominal current of min. 6 A in the power supply circuits
outside the power supply unit.
1. Mount the PSU in a selected location and connect the wires.
2. Connect power cables (~230 V AC) to L-N clips of PSU. Connect ground wire to clip marked by earth symbol .
Use a three-core cable (with a yellow and green protection wire ). Lead the power cables to the relevant terminals of
the power supply via an isolation conduit.
Shock protection circuit shall be done with a particular care: yellow and green wire coat of power
cable should be connected to terminal marked with the grounding symbol on PSU enclosure.
Operation of PSU without the properly made and fully operational shock protection circuit is
UNACCEPTABLE! It can cause damage to equipment or an electric shock.
3. Switch on 230 V supply. The LEDs on the PCB and on the lid of PSU should light up (see Section 3.1).
4. Check output voltage and adjust if necessary using potentiometer.
5. Disconnect the PSU from the mains and make the rest of the connections - connect wires to the AUX1...AUXn
connectors. If necessary, connect the wires from devices (control panel, controller, siren, etc.) to the PSU technical
outputs FPS (fuse failure indication output).
6. Once the tests and control operation have been completed, close the enclosure.
3. Operating status indication.
The power supply unit features LED status indication:
3.1 Optical indication.
The power supply unit features LED status indication. Presence of voltage at each output of the PSU is indicated
by the green LED nearby each outputs fuse. Failure (fuse damage) is indicated by shutting down green LED nearby
appropriate outputs fuse on the PSU module and illuminating the red LED FPS. Status of the PSU (fuse damage
AUX1 ÷ AUXn) can be remotely controlled via the FPS technical output.
In addition, there is an additional indication on the lid of the power supply:
4. Technical output.
The PSU features a relay type output indicating FPS fuse failure.
Caution! In Fig. 4 set of contacts shows a potential-free status of relay, which corresponds to power supply failure.
Fig. 4 Technical output diagram

7
5. Operation and use.
5.1. Overload or short circuit of the PSU module output.
The AUX1÷AUXn PSU outputs are protected against short circuit by glass fuses. Activation of the protection (glass fuse
blowing) is indicated by shutting down green LED nearby appropriate outputs fuse on the PSU module and illuminating the red
LED FPS. In case of damage, replace the fuse (compatible with the original). As a precaution, it is possible to use fuses with a
higher current (up to 2 A) and a fast blow characteristic (F), which will increase the current-carrying capacity of the given output.
However, this does not affect the overall current capacity of the power supply.
5.2. Operation of the PSU OVP system.
If the OVP system is activated, the output voltage is automatically cut off. Operation can be resumed after
disconnecting the PSU from 230 V after approx. 1 minute.
6. Maintenance.
Any and all maintenance operations may be performed following the disconnection of the PSU from the power
supply network. The PSU does not require performing any specific maintenance measures, however, in the case of
significant dust rate, its interior is recommended to be cleaned with compressed air.
WEEE MARK
According to the EU WEE Directive –It is required not to dispose of electric or electronic waste as
unsorted municipal waste and to collect such WEEE separately
Pulsar sp. j.
Siedlec 150, 32-744 Łapczyca, Poland
Tel. [phone], Fax. [phone]
e-mail: [e-mail], sal[email protected]
http:// www.pulsar.pl, www.zasilacze.pl
