Pulsar HPSDCSEP-12V4x1A User manual

1
USER MANUAL
EN*
Edition: 1 from 10.02.2022
Supersedes edition:
HPSDCSEP-12V4x1A
v1.0
HPSDCSEP 12V/4A/4x1A power supply with
4 separated outputs

2
Features:
Supply voltage ~100 - 240 V
Power supply output 4x 12VDC/1A
high efficiency (up to 82%)
4 independent, galvanic isolated outputs
independent output voltage adjustment 12 –15 V DC
4 independent outputs protected by 1A fuses
LED optical indication
protections:
SCP short circuit protection
OVP overvoltage protection
surge protection
OLP overload protection
antisabotage protection: unwanted
enclosure opening
warranty –2 years from production date
TABLE OF CONTENTS:
1. Technical description.
1.1. General description
1.2. Block diagram
1.3. Description of PSU components and connectors
1.4. Specifications
2. Installation.
2.1. Requirements
2.2. Installation procedure
3. Operating status indication.
4. Operation and use
4.1. Overload or short circuit of the PSU module output.
4.2. Operation of the PSU OVP system
5. Maintenance
1. Technical description.
1.1. General description.
The HPSDCSEP-12V4x1A stabilised power supply is intended for supplying power to cameras or other devices that
require stabilised voltage of 12 V DC. The PSU has 4 independent outputs with voltage adjustment within the range of 12-15V
DC/4x1A, ensuring compensation of voltage drops in CCTV installations. The outputs of the PSU are galvanic separated and
protected with fuses. A failure (a short circuit) in the output circuit makes a fuse blow and disconnects the circuit from the DC
power supply (+U). The PSU is mounted inside a metal enclosure equipped with a microswitch indicating unwanted opening of
the door (lid).
Table 1. Displaying parameters of the power supply:
Model
Number of
outputs
Output voltage AUX
Output current
HPSDCSEP-12V4x1A
4
12 V (12 –15 V)
4x 1 A
1.2.Block diagram
Fig. 1. Block diagram of PSU.

3
1.3.Description of PSU components and connectors
Table 2. Elements and connector of PSU (see Fig. 2)
Element no.
Description
[1]
Main fuse
[2]
L-N power supply connector 230 V AC, PE protection connector
[3]
VADJ potentiometer, output voltage adjustment 12 - 15 V DC
[4]
LED (green) indicating presence of voltage at output of the PSU
[5]
Fuse in AUX circuits
[6]
AUX2 output
[7]
AUX3 output
[8]
AUX4 output
Fig. 2. View of power supply module
Table 3. View of PSU (see Fig. 3).
Element no.
Description
[1]
PSU module
[2]
Cable ellipse opening
[3]
TAMPER; microswitch of antisabotage protection (NC)
Fig. 3. View of PSU
1.4.Specifications.
- PSU parameters (tab. 4)
- operation safety (tab. 5)
- operating parameters (tab. 6)

4
Table 4. PSU parameters.
Model
HPSDC-12V4x1A
Power supply
~ 100 –240 V; 1A; 50/60 Hz
Inrush current
40 A
PSU power
48 W max.
Output current
4x 1 A
Efficiency
82%
Output voltage (factory settings)
12 V DC
Adjustment range UAUX
independent for each output: 12 –15 V DC
Ripple voltage
50mV p-p max.
Short circuit protection SCP
4x F 1A glass fuse fast blow
Overload protection OLP
105 –150% PSU power, automatically recovered
Surge protection
varistors
Over voltage protection OVP
>19V (triggering automatic return)
Protection in 230 V circuit
glass fuse T5A
LED operation indication
- LEDs on PCB of power supply unit: The green L1...Ln LEDs indicate the power
supply status on the outputs: AUX1...AUX4
Enclosure dimensions
(WxH) [±2mm]
270x200
Enclosure dimensions
(W1xH1xD1+D) [±2mm]
275x205x67+8
Fixing (WxH)
237x170
Net/gross weight
1,8/1,9 [kg]
Connectors
Power supply: 0,5 –1,5 mm2(AWG 26 –16)
Notes
Convectional cooling
Table 5. Operation safety.
Table 6. Operating parameters.
2. Installation.
2.1. Requirements.
PSU is to be mounted by a qualified installer, holding relevant permits and licenses (applicable and required for a
given country) for 230 V in and low-voltage installations. Unit should be mounted in confined spaces, in accordance, with
normal relative humidity (RH=90% maximum, without condensing) and temperature from -10°C to +40°C. The PSU shall
work in a vertical position that guarantees sufficient convectional air-flow through ventilating holes of the enclosure.
As power supply is designed for a continuous operation and is not equipped with a power-switch, therefore, an
appropriate overload protection in power supply circuit should be provided. Moreover, the user shall be informed about
the method of unplugging (most frequently through separating and assigning an appropriate fuse in the fuse-box).
The electrical system shall follow valid standards and regulations.
2.2. Installation procedure.
Before installation, cut off voltage in 230 V power-supply circuit. To switch power off, use an
external switch, in which distance between contacts of all poles in disconnection state is not less
than 3mm.
It is required to install an installation switch with a nominal current of 6 A in power supply circuits outside
power supply unit.
Protection class EN 62368-1
I (first)
Electrical strength of insulation:
- between input and output circuits of the PSU
- between input circuits of the PSU
- between input circuit and protection circuit
- between output circuit and protection circuit
2500 V AC min.
2500 V AC min.
1500 V AC min.
500 V AC min.
Insulation resistance:
- between input circuit and output or protection circuit
100 MΩ, 500 V DC
Operating temperature
-10ºC...+40ºC
Storage temperature
-20ºC...+60ºC
Relative humidity
20%...90%, without condensation
Vibrations during operation
unacceptable
Impulse waves during operation
unacceptable
Direct insolation
unacceptable
Vibrations and impulse waves during transport
According to PN-83/T-42106

5
1. Mount the PSU in a selected location and connect the wires.
2. Connect power cables (~230 V) to L-N clips of PSU. Connect ground wire to clip marked by earth symbol .
Use a three-core cable (with a yellow and green protection wire) to make connection ). Lead the cables to the
appropriate clips through the insulating bushing of the PSU.
Shock protection circuit shall be done with a particular care: yellow and green wire coat of power cable
should be connected to terminal marked with the grounding symbol on PSU enclosure. Operation of PSU
without the properly made and fully operational shock protection circuit is UNACCEPTABLE! It can cause
damage to equipment or an electric shock.
3. Switch on 230 V supply. LEDs on power supply PCB should be ON.
4. Check output voltage and adjust if necessary using right potentiometer.
5. Disconnect the PSU from the mains and make the rest of the connections - connect wires to the AUX1...AUX4
connectors.
6. Once the tests and control operation have been completed, close the enclosure/cabinet.
3. Operating status indication.
The power supply unit features LED status indication. Presence of voltage at each output of the PSU is indicated by the
green LED nearby each outputs fuse. Failure (fuse damage) is indicated by shutting down green LED nearby appropriate
outputs fuse on the PSU module
4. Operation and use.
4.1. Overload or short circuit of the PSU module output.
The AUX1÷AUX4 PSU outputs are protected against short circuit by glass fuses. Activation of the protection (glass fuse
blowing) is indicated by shutting down green LED nearby appropriate outputs fuse on the PSU module. In case of damage,
replace the fuse (compatible with the original).
4.2. Operation of the PSU OVP system.
If the OVP system is activated, the output voltage is automatically cut off. Operation is resumed automatically.
5. Maintenance.
Any and all maintenance operations may be performed following the disconnection of the PSU from the power
supply network. The PSU does not require performing any specific maintenance measures, however, in the case of
significant dust rate, its interior is recommended to be cleaned with compressed air.
WEEE MARK
According to the EU WEE Directive –It is required not to dispose of electric or electronic waste as
unsorted municipal waste and to collect such WEEE separately
