Pulsar PSBEN 2024B/LCD User manual

PSBEN 2024B/LCD
v.1.1
PSBEN 27,6V/2A/2x7Ah/EN/LCD
Buffer, switch mode power supply unit.
EN**
Edition: 5 from 18.06.2014
Supercedes edition: 4 from 01.02.2013
LCD Version

www.pulsar.pl PSBEN2024B/LCD BLACK POWER
2
TABLE OF CONTENTS
1. PSU FEATURES. ................................................................................................................................................................4
2. FUNCTIONAL REQUIREMENTS OF THE PSU COMPLIANT WITH THE EN 50131-6 STANDARD. ..............5
3. TECHNICAL DESCRIPTION. .........................................................................................................................................6
3.1 GENERAL DESCRIPTION........................................................................................................................................................6
3.2 BLOCK DIAGRAM.................................................................................................................................................................6
3.3 DESCRIPTION OF PSU’S COMPONENTS AND CONNECTORS. ..................................................................................................7
4. INSTALLATION.................................................................................................................................................................9
4.1 REQUIREMENTS. ..................................................................................................................................................................9
4.2 INSTALLATION PROCEDURE. ................................................................................................................................................9
5. FUNCTIONS......................................................................................................................................................................11
5.1 CONTROL PANEL. ..............................................................................................................................................................11
5.2 FIRST RUN OF THE PSU –LANGUAGE SELECTION SCREEN..................................................................................................11
5.3 MAIN SCREEN OF THE LCD................................................................................................................................................12
5.4 INFORMATION DISPLAYED ON THE LCD PANEL. ................................................................................................................12
5.4.1 Preview menu. ..........................................................................................................................................................12
5.4.2 LCD screen –current parameters ....................................................................................................................14
5.4.3 LCD screen –current failures ..........................................................................................................................15
5.4.4 LCD screen –history of the parameters ...........................................................................................................15
5.4.5 LCD screen –history of events .........................................................................................................................16
5.4.6 List of failure codes and information messages........................................................................................................17
5.5 ACOUSTIC INDICATION. .....................................................................................................................................................19
5.6 TECHNICAL OUTPUTS.........................................................................................................................................................19
5.7 INPUT OF COLLECTIVE FAILURE EXT IN............................................................................................................................20
5.8 ENCLOSURE TAMPER INDICATION -TAMPER. .................................................................................................................21
5.9 OVERVOLTAGE PROTECTION OF THE PSU OUTPUT OVP....................................................................................................21
5.10PSU OVERLOAD.................................................................................................................................................................21
6. PSU SETTINGS.................................................................................................................................................................22
6.1 PASSWORD.........................................................................................................................................................................22
6.1.1 Entering the password..............................................................................................................................................22
6.1.2 Changing the password. ...........................................................................................................................................23
6.1.3 Disabling the password. ...........................................................................................................................................23
6.1.4 Resetting passwords. ................................................................................................................................................23
6.1.5 Keyboard lock...........................................................................................................................................................24
6.2 PSU...................................................................................................................................................................................25
6.2.1 Setting the battery presence......................................................................................................................................25
6.2.2 Battery test on/off. ....................................................................................................................................................26
6.2.3 Battery protection on/off...........................................................................................................................................27
6.2.4 Setting the delay time for EPS output indicating 230V AC power loss. ...................................................................27
6.2.5 Setting the communication address. applies to cooperation with PowerSecurity. ..........................................28
6.2.6 Setting the transmission parameters. applies to cooperation with PowerSecurity..........................................29
6.3 CONTROL PANEL................................................................................................................................................................30
6.3.1 Setting the display language.....................................................................................................................................30
6.3.2 Setting the date. ........................................................................................................................................................31
6.3.3 Setting the time. ........................................................................................................................................................31
6.3.4 Setting the backlight mode........................................................................................................................................32
6.3.5 Contrast setting. .......................................................................................................................................................32
6.3.6 Blinking light indicating failure................................................................................................................................33

www.pulsar.pl PSBEN2024B/LCD BLACK POWER
3
7. RESERVE POWER SUPPLY CIRCUIT........................................................................................................................34
7.1 RUNNING THE PSU FROM THE BATTERY............................................................................................................................34
7.2 DEEP DISCHARGE BATTERY PROTECTION UVP. .................................................................................................................34
7.3 BATTERY TEST...................................................................................................................................................................34
7.4 STANDBY TIME. .................................................................................................................................................................35
7.5 BATTERY CHARGING TIME.................................................................................................................................................35
7.6 OPERATION WITHOUT A BATTERY......................................................................................................................................35
8. REMOTE MONITORING (OPTIONS: WI-FI, ETHERNET, RS485, USB)..............................................................36
8.1 COMMUNICATION VIA THE USB-TTL INTERFACE. ............................................................................................................36
8.2 ETHERNET NETWORK COMMUNICATION.........................................................................................................................36
8.3 THE WI-FI WIRELESS COMMUNICATION.............................................................................................................................37
8.4 RS485 NETWORK COMMUNICATION. .................................................................................................................................38
8.5 „POWERSECURITY”PROGRAM...........................................................................................................................................39
9. TECHNICAL PARAMETERS. .......................................................................................................................................40
TABLE 16. ELECTRICAL PARAMETERS.......................................................................................................................................40
TABLE 17. MECHANICAL PARAMETERS.....................................................................................................................................41
TABLE 18. SAFETY OF USE. .......................................................................................................................................................41
10. TECHNICAL INSPECTIONS AND MAINTENANCE................................................................................................42
10.1BATTERY REPLACEMENT OF THE LCD PANEL....................................................................................................................42

www.pulsar.pl PSBEN2024B/LCD BLACK POWER
4
1. PSU features.
EN50131-6 compliance, 1÷3 grades and II
environmental class
mains supply of 230VAC
uninterrupted voltage of 27,6VDC
fitting battery: 2x7Ah/12V
high efficiency 81%
PSU current efficiency:
0,58A –for grades 1 , 2 *
0,23A –for grades 3 **
2A –for general use ***
(see: chapter 3.1)
low level of voltage ripple
microprocessor-based automation system
intelligent management of PSU’s output power level
‘SERIAL’ communication port with implemented
MODBUS RTU protocol
remote monitoring (option: Wi-Fi, Ethernet, RS485,
USB)
free program - ‘PowerSecurity’ for monitoring the
PSU operation parameters
load current control
output voltage control
output fuse status control
dynamic battery test
battery circuit continuity control
battery voltages control
battery fuse status control
battery charge and maintenance control
deep discharge battery protection (UVP)
battery overcharge protection
battery output protection against short circuit and
reverse polarity connection
jumper selectable battery charging current
0,2A/0,6A/1A/1,5A
remote battery test (additional module required)
START button for battery activation
STOP button for disconnecting during battery-assisted
operation
optical indication–LCD panel
electrical parameters reading, e.g.: voltage, current
failure indication
PSU settings adjusted from the panel’s level
3 levels of access, password-protected
PSU’s operation history
failure history
real-time clock, battery-backed
optical indication of PSU overload OVL
acoustic indication of failure
adjustable times indicating AC power failure
technical inputs/outputs with galvanic isolation
EXT IN input of collective failure
EPS technical output indicating AC power loss
PSU technical output indicating PSU failure
APS technical output indicating battery failure
internal memory of PSU operating status
protections:
SCP short circuit protection
OLP overload protection
OHP overheat protection
OVP over voltage protection
surge protection
against tampering: unwanted opening of the
enclosure or detachment from the mounting surface
convectional cooling
warranty –5 year from the production date

www.pulsar.pl PSBEN2024B/LCD BLACK POWER
5
2. Functional requirements of the PSU compliant with the EN 50131-6 standard.
Functional requirements
Requirements of
EN 50131-6
PSBEN2024B/
LCD
Grade 1
Grade 2
Grade 3
EPS network absence
YES
YES
YES
YES
Low battery voltage
YES
YES
YES
YES
Protection against complete battery
discharge
-
-
YES
YES
Battery failure
-
-
YES
YES
No battery charge
-
-
YES
YES
Low output voltage
-
-
YES
YES
High output voltage
-
-
YES
YES
PSU failure
-
-
YES
YES
Surge protection
-
-
YES
YES
Short circuit protection
YES
YES
YES
YES
Overload protection
YES
YES
YES
YES
Output fuse activation
-
-
-
YES
Battery fuse failure
-
-
-
YES
EPS technical output
YES
YES
YES
YES
APS technical output
YES
YES
YES
YES
PSU technical output
YES
YES
YES
YES
Input of collective failure
-
-
-
YES
Remote battery test
-
-
-
YES
Tamper indicating enclosure opening
YES
YES
YES
YES
Tamper indicating detachment from the
mounting surface
-
-
YES
YES

www.pulsar.pl PSBEN2024B/LCD BLACK POWER
6
3. Technical description.
3.1 General description.
The buffer power supply is designed in accordance with the requirements of the EN 50131-6
standard, grade 1÷3 and II environmental class. It is intended for an uninterrupted supply of alarm system devices
requiring stabilized voltage of 24VDC (+/-15%).
Depending on a required protection level of the alarm system in the installation place, the PSU efficiency
and the battery charging current should be set as follows:
* Grade 1, 2 - standby time 12h
Output voltage 0,58A + 1,5A battery charge
** Grade 3 - standby time 30h if the faults of the main power source are reported to the Alarm Receiving
Centre - ARC (in accordance with 9.2 –EN 50131-1 standard).
Output voltage 0,23A + 1,5A battery charge
- standby time 60h if the faults of the main power source are reported to the Alarm Receiving
Centre - ARC (in accordance with 9.2 –EN 50131-1 standard).
Output voltage 0,116A + 1,5A battery charge
*** General use –if the PSU is not mounted in an installation complaint with the EN-50131 standard, the
acceptable current efficiency amounts to:
1. Output voltage 2A + 0,2A battery charge
2. Output voltage 1,6A + 0,6A battery charge
3. Output voltage 1,2A + 1A battery charge
4. Output voltage 0,7A + 1,5A battery charge
Total current of the receivers + battery: 2,2A max.
In case of power decay, a battery back-up is activated immediately. The PSU is housed in a metal
enclosure (color: RAL 9005 - black) with battery space for a 2x7Ah/12V battery. It is fitted with micro switches
indicating unwanted door opening (front panel) and detachment from the mounting surface.
3.2 Block diagram.
The PSU is manufactured based on a high-duty system of DC/DC converter. The microprocessor system is
responsible for full diagnostics of the PSU and battery parameters.
Fig. 1. Block diagram of the PSU.

www.pulsar.pl PSBEN2024B/LCD BLACK POWER
7
3.3 Description of PSU’s components and connectors.
Table 1. Elements of the PSU pcb (see Fig. 2).
Element no
Description
PANEL –optical indication connector
PBAT –jumper; idle in this model
TAC –jumpers J1, J2; idle in this model
CAUTION. In this model, jumpers are operated from the LCD desktop’s level (see: chapter. 6.2).
IBAT –pin;battery charging current selection
J1= , J2= J3= IBAT =0,2 A
J1= , J2= J3= IBAT =0,6 A
J1= , J2= J3= IBAT =1,0 A
J1= , J2= , J3= IBAT =1,5 A
Caption: jumper on, jumper off
START –button (launching the PSU from a battery)
STOP –button (disconnection of the PSU during battery-assisted operation)
–pin; activation of the acoustic indication
- indication on
- indication off Caption: jumper on, jumper off
VADJ –potentiometer, DC voltage adjustment
BUZZER –acoustic indicator
FBAT –fuse in the battery circuit
Connectors:
~AC~ –AC power input
+BAT –DC power battery output
+AUX –DC power output (+AUX= +U, -AUX=GND)
EPS FLT –technical output of AC network absence indication
open = AC power failure
close = AC power - O.K.
PSU FLT –technical output of PSU failure
open = failure
close = PSU working correctly - O.K.
APS FLT –technical output of battery failure
open = battery failure
close = battery O.K.
EXT IN –output of collective failure
VEXT pin –polarization of EXT IN circuit
Communication connector
LEDs –optical indication:
AC –presence of the AC power
AUX –DC output voltage
OVL –PSU overload
PSU –PSU failure
APS –battery failure
EXT –EXT IN output’s status
LB –battery charge
OVP –optical indication for activating the over voltage system
TAMPER –connector for the micro switch tamper

www.pulsar.pl PSBEN2024B/LCD BLACK POWER
8
Fig. 2. The view of the PSU’s PCB.
Table 2. PSU elements (see fig. 3).
Element no.
Description
Insolation transformer
PSU board (see Tab.1, fig.2)
TAMPER; micro-switch (contacts) of tamper resistance (NC)
FMAINS fuse in the supply circuit (230V/AC)
L-N power supply connector 230V/AC, PE protective connector
Battery connectors: positive: +BAT = red, negative: - BAT = black
Tamper grip
Fig.3. The view of the PSU.

www.pulsar.pl PSBEN2024B/LCD BLACK POWER
9
4. Installation.
4.1 Requirements.
The PSU is to be mounted by a qualified installer, holding relevant permits and licenses (applicable and
required for a given country) for 230V/AC in and low-voltage installations.
As the power supply is designed for a continuous operation and is not equipped with a power-
switch, therefore, an appropriate overload protection in the power supply circuit should be provided. Moreover, the
user should be informed how to disconnect the power supply unit from the mains supply (usually by assigning an
appropriate fuse in the fuse box). The electrical system shall be made in accordance with applicable standards
and regulations. The power supply should operate in a vertical position in order to provide free and
convectional air flow through ventilating holes of the casing.
The PSU is protected against access to the configuration menu through two-level passwords. If the
default settings should be changed, unlock access by entering the service password –see Table 4 and
section 6.1.
4.2 Installation procedure.
CAUTION!
Before installation, cut off the voltage in the 230V power-supply circuit.
To switch off power use an external switch in which the distance between the contacts of all poles in the
disconnection state is not less than 3mm.
1. Mount the PSU in a selected location. It is particularly important to bolt the tamper grip to the mounting surface.
The grip is located in the central part of the enclosure (see fig. 3 [7]) and guarantees indication in case of any
attempts of detaching the device from the mounting surface. Proper installation is one of the requirements of the
EN 50131-6 standard.
Fig. 4. Fixing a tamper grip.
2. Connect the power cables (~230VAC) to L-N terminals of the PSU. Connect the ground wire to the terminal
marked by the earth symbol: PE. Use a three-core cable (with a yellow and green PE protection wire) to make the
connection. Lead the cables to the appropriate terminals through the insulating bushing.
The shock protection circuit shall be performed with a particular care, i.e. the yellow and green wire coat
of the power cable shall stick to one side of the terminal - marked with the PE symbol on the PSU
enclosure. Operation of the PSU without the properly made and fully operational shock protection circuit
is UNACCEPTABLE! It can cause a device failure or an electric shock.
3. Connect the receivers’ cables to the +AUX, -AUX connectors of the terminal block on the PSU board.
4. If necessary, connect the device’s leads to the technical inputs and outputs:
- EPS FLT; technical output of AC power loss indication (alarm panel, controller, indicator, etc.)
- PSU FLT; technical output of the PSU failure.
- APS FLT; technical output of the battery failure.
- TAMPER; output indicating enclosure opening or detachment from the assembly surface.

www.pulsar.pl PSBEN2024B/LCD BLACK POWER
10
- EXT IN; input of collective failure.
5. With the IBAT jumper determine the maximum battery charging current, in accordance with the battery
parameters.
6. With the PBAT jumper determine if the discharged battery disconnection system U<20V (+/-5%) shall be on or off.
The battery protection is on when the PBAT jumper is off.
7. Switch on the ~230V AC supply (red AC diode and green AUX diode should be on).
8. Check the output voltage (the PSU voltage without load and without battery should amount to 27,5V ÷ 27,7V,
with a battery or during battery charging process: 22V÷27,6V). If the value of the voltage requires adjustment, it
should be set with use of the VADJ potentiometer, monitoring the voltage at the AUX output of the PSU.
9. Connect the batteries in accordance with the markings: +BAT red to 'plus', -BAT black to 'minus’. The LB diode
should be on during battery charging process.
10. Press the STOP button to activate or deactivate a dynamic battery test. Deactivating the test turns out the PSU
failure indication at the APS FLT output, but it does not affect the protection system against complete battery
discharge.
11. Check the current consumption of the receivers, taking into account the battery charging current, so as not to
exceed the total current efficiency of the PSU.
12. Once the tests are completed, close the PSU cover.
Table 3. Operation parameters.
Environmental class
II
Operating temperature
-10ºC...+40ºC
Storing temperature
-20ºC...+60ºC
Relative humidity
20%...90%, no condensation
Sinusoidal vibrations during operation
EN 50130-5
Surges during operation
EN 50130-5
Direct insolation
unacceptable
Vibrations and surges during transport
PN-83/T-42106
Table 4. Factory settings of the PSU.
Indication time of EPS network loss
5s
section 5.6
Battery charging current
0,6A
section 7.5
Battery presence
YES (battery present)
section 7.6
Battery test
ON
section 6.2.2
section 7.3
Deep discharge battery protection UVP
ON
section 7.2
Acoustic indication
ON
section 5.5
Communication address
1
section 6.2.5
Transmission
115.2k 8E1
section 6.2.6
Highlighting
Constant –50%
section 6.3.4
Blinking light indicating failure
ON
section 6.3.6
Passwords:
- user’s
- installer’s
- keyboard lock
1111
1234
NO
section 6.1

www.pulsar.pl PSBEN2024B/LCD BLACK POWER
11
5. Functions.
5.1Control Panel.
The PSU features a panel with buttons and LCD display, enabling reading of all the available electrical
parameters. The panel buttons are used to select and confirm the parameters, which should be displayed.
Fig. 5. Control panel.
Table 5. The description of the buttons and LEDs of the LCD panel.
- move the cursor on the display
- next screen selection
- selection approval
- leaving the editing mode without changing the values
- entering the overview menu mode
- red LED indicating the presence of AC voltage
- green LED indicating power at the AUX output of the PSU
- red LED indicating the PSU failure
5.2 First run of the PSU –language selection screen.
During the first run of the PSU, language selection screen will be displayed.
Use the „<” or „>” buttons to select the available languages. After selecting the appropriate language, confirm by
pressing the "SET" button. The main screen will be displayed.
Fig. 6. Language selection screen.
If the language selection is not done, language selection screen will be displayed on the next startup. If the
choice has already been made, language selection can be done as explained in section 6.3.1.

www.pulsar.pl PSBEN2024B/LCD BLACK POWER
12
5.3 Main screen of the LCD.
Main screen of the LCD displays the basic electrical parameters and indicates the current status of the
power supply.
Fig. 7. Main screen of the LCD.
The resolution of voltage and current measurement is 0.1V and 0.1A, respectively. The
displayed values of voltages and currents should be treated with caution; if a greater accuracy is
required, use a multimeter.
Table 6. The description of the main screen symbols.
Screen field
Operating status
Failure status
Blinking „FAIL”message
Information about the current voltage
and power consumption at the AUX
output.
The parameter, which value has been
exceeded, is blinking.
Information about the current state of
battery charge
Blinking icon.
The blinking warning symbol is displayed.
Fuse icon - blinking.
Clock
5.4 Information displayed on the LCD panel.
5.4.1 Preview menu.
Pressing the „ESC” button at the bottom of the display starts the preview menu, allowing to choose one of
the four available PSU screens.
Use the „<” or „>” buttons to choose a proper screen and press the „SET” button to confirm.
- current parameters of the PSU
(see section 5.4.2)

www.pulsar.pl PSBEN2024B/LCD BLACK POWER
13
- current failures of the PSU
(see section 5.4.3)
- parameters of the PSU stored in the memory
(see section 5.4.4)
- History of events
(see section 5.4.5)

www.pulsar.pl PSBEN2024B/LCD BLACK POWER
14
5.4.2 LCD screen –current parameters
To set the screen, press the „ESC” button, use the „<” or „>” buttons to choose the icon and press the
„SET” button to confirm.
The screen displays electrical parameters and the status of the technical outputs during operation.
Illumination of an element informs about an activation and reflects the status of LEDs on the PCB of the PSU (see
Table1, [12]).
Fig. 8. LCD panel –PSU parameters.
Table 7. The description of the screen symbols - current parameters of the PSU.
Screen field
Description
Additional
information
-230V AC power ON
(highlighted = AC power on)
Sections 6.2.4
- Battery charging indication
(highlighted = battery charging)
- PSU overload indication
(highlighted = PSU overload)
Sections 5.10
- PSU failure indication
(highlighted = PSU failure)
Sections:
- 5.4.6
- 5.6
- Battery failure indication
(highlighted = battery failure)
Sections:
- 5.4.6
- 5.6
- EXTi input status indication
(highlighted = EXTi input activated)
Sections:
- 5.4.6
- 5.7
The current settings of the PBAT, J1 and J2 jumpers.
TAMPER input status (highlighted = activated)
Sections 5.8
Current electrical parameters of the PSU:
UBAT –battery voltage
UAUX –AUX output voltage
IAUX –output current
Sections 5.4.4
The status of the technical outputs:
EPS - AC power indication
open= AC power failure
closed = AC power –O.K.
PSU –PSU failure indication
open= PSU failure
closed = PSU working correctly O.K.
APS –battery failure indication
open= battery failure
closed = battery O.K.
Sections:
5.4.6
5.6

www.pulsar.pl PSBEN2024B/LCD BLACK POWER
15
5.4.3 LCD screen –current failures
In case of abnormal electrical parameters during the operation, the PSU will indicate a failure by displaying a
message on the LCD, turning on the red LED on the panel, activating acoustic indication (if enabled)
and changing the status of a dedicated technical output.
Fig. 9. Message indicating blown fuse at the AUX output.
At a given time, multiple failures can occur. To check which faults are indicated, choose the current failures of
the PSU screen.
To do that, press the „ESC” button, use the „<” or „>” buttons to choose the icon and press the „SET”
button to confirm..
Fig. 10. LCD screen –current failures of the PSU.
The screen displays the codes and descriptions of failures. The display order of failures is arranged by priority
of importance. The first failures in the display order are of the highest priority.
If there are more than five failures at the same time, use the „<” or „>” buttons to display the next failure..
5.4.4 LCD screen –history of the parameters
To set the screen, press the „ESC” button, use the „<” or „>” buttons to choose the icon and press the
„SET” button to confirm..
Fig. 11. Screen of the history of PSU’s parameters.
During normal operation, the PSU records voltage and current parameters at the output circuits and saves
them in the internal non-volatile memory. The saving is repeated in 5 minutes intervals and the internal memory
can store up to about 6144 values. The memory works in a circular cycle - when the memory is full, the oldest
entries are replaced with the newest ones.
The screen of the parameters history enables reading of the stored parameters and scanning the values on
a chart. The screen features a time axis, located horizontally in the bottom part of the chart, and a
parameter axis, located vertically in the left. Use the „<” or „>” buttons to move the cursor into various time points
and read the value of the measurement..

www.pulsar.pl PSBEN2024B/LCD BLACK POWER
16
Fig. 12. Screen of the history of PSU’s parameters.
In order to change the displayed parameter, highlight its name by pressing the „SET” button and use the
„<” or „>” buttons to choose the requested parameter. Pressing the „SET” button again will highlight the time
range of the chart, which also can be changed with the „<” or „>” buttons. Pressing the „SET” button again will
enable moving the cursor (vertical dotted line on the chart) along the time line with the „<” or „>” buttons. The
values of current parameter and the recording time pointed by the cursor will also be highlighted.
Among the available positions on the chart, it is possible to view the following values:
- current - the value measured at the end of the measuring cycle
- minimum - the lowest value measured during 5 minutes
- maximum - the highest value measured during 5 minutes
of the following parameters:
- UAUX - AUX output voltage
- UAUX MIN - AUX output voltage - minimum
- UAUX MAX - AUX output voltage - maximum
- IAUX - output current
- IAUX MIN - output current, minimum
- IAUX MAX - output current, maximum
To optimally read and analyze the values shown in the chart, it is possible to change the time range on the
bottom axis of the chart. The following ranges are available:
<8h>
<24h>
<2days>
<week> (weekly)
5.4.5 LCD screen –history of events
In case of abnormal electrical parameters during the operation, the PSU will indicate a failure by displaying
a message on the LCD, periodically turning on and off the LCD backlight, turning on the red LED ALARM on the
panel, activating acoustic indication (if enabled) and changing the status of a dedicated technical outputs.
To choose the history of events screen, press the „ESC” button, use the „<” or „>” buttons to choose the
icon and press the „SET” button to confirm.
Fig. 13. The history of events screen.
The history of events screen enables overviewing the events recorded by the internal diagnostic system.
The internal memory can store up to 2048 events, carrying information about the fault type, time of occurrence and
the values of other electrical parameters. In addition, the diagnostic system assigns the failure code for a particular
event on the basis of the stored parameters.

www.pulsar.pl PSBEN2024B/LCD BLACK POWER
17
In order to preview the history of events, use the „<” or „>” buttons. It can be done in two modes: short
mode(date, time, code, fault description) or full mode - with additional information about electrical parameters and
status of inputs and outputs. To switch between the modes, press the „SET” button.
Fig. 14. Description of the history of events screen.
Section 5.4.6 lists all codes that may occur during the operation of the PSU. The individual codes are
accompanied by appropriate optical indication on the panel, acoustic indication and activation of a dedicated
technical output.
The memory of the new power supply remembers the events that are the result of the efficiency tests
carried out at the production stage.
5.4.6 List of failure codes and information messages.
The PSU indicates the operation status with the appropriate code. The codes are divided into two
groups,marked with the initial letters "F" or "I”.
The codes beginning with the letter "F" indicate a failure. The codes that begin with the letter "I" indicate the
correct operation of the PSU or repaired fault, involving, for example, fuse replacement: "I03 - BAT fuse replaced”.
Table 8. List of PSU failure codes.
Failure
code
Information
Technical
output
activation
Additional information
Additional
information
F01
AC power fail!
EPS FLT
- No AC mains supply
- FMAINS fuse failure
F02
AUX fuse fail!
PSU FLT
- Blown FAUX fuse
- AUX output overload
F03
BAT fuse fail!
APS FLT
- Blown FBAT fuse
- Short circuit in the battery circuit
- Short circuit in the AUX output circuit
F04
Output overload!
PSU FLT
- PSU overload
Section 5.10
F05
Battery fail!
APS FLT
- Worn out battery
- Undercharged battery
- Battery not connected
Section 5.6
Section 7
F06
High AUX voltage!
PSU FLT
- Output voltage over 29.4V
F07
High battery voltage!
PSU FLT
- Battery voltage >28V
F08
Charge circuit fail!
PSU FLT
- The output voltage of the PSU set too low ,
below 26V

www.pulsar.pl PSBEN2024B/LCD BLACK POWER
18
- Battery charging circuit failure
F09
Low AUX voltage!
PSU FLT
- Output voltage below 23,6V
(during buffer operation)
F10
Low battery voltage!
APS FLT
- the battery voltage has dropped below 23V
(during battery-assisted operation)
F11
Low battery volt. –
off!
APS FLT
- the battery voltage has dropped below 20V
(during battery-assisted operation)
F12
External input EXTi!
- Activation of the input of collective failure
EXT IN
Section 5.7
F13
PSU cover opened!
PSU FLT
F50-F54
Internal supply fail!
PSU FLT
- service codes
F60
No communication
PSU FLT
- no communication with LCD panel
F61-F64
Control panel fail
PSU FLT
- service codes
F65
Access unlocked
- passwords unlocked
Table 9. List of PSU message codes.
Message
code
Description
I00
Power supply start-up
I01
AC power back
I02
AUX fuse replaced
I03
BAT fuse replaced
I04
Battery OK
I05
Battery test –START
I06
PSU cover closed
Table 10. Optical indication of failure with the PSU LED on the PCB of the PSU.
The number of
flashes of the PSU
LED on the PCB of
the power supply
Failure
code
Failure description
1
F06
High AUX voltage!
2
F07
High battery voltage!
3
F08
Charge circuit fail!
4
F09
Low AUX voltage!
5
F50-F54
F60
Internal supply fail!
No communication
6
F13
PSU cover opened!

www.pulsar.pl PSBEN2024B/LCD BLACK POWER
19
5.5Acoustic indication.
Emergency situations are acoustically indicated. The frequency and the number of signals depend on an
event type (see chapter. 5.4.6). The acoustic indication is off after removing an appropriate jumper (fig. 2, [5]).
Table 11. Acoustic indication.
No.
Description
Event
1
1 signal per 10s, battery-assisted
operation
No 230V AC supply
2
1 signal per 10s, mains operation
Battery fault, undercharged battery
3
2 signals per 10s, battery-assisted
operation
Low level of battery charge
4
Fast signals, battery-assisted
operation
The PSU will be disconnected due to the battery discharge
5
Continuous indication
PSU failure [see chapter. 5.4.6]
6
1 signal
Breaking the battery test
7
2 signals
Activation of the battery test
5.6 Technical outputs.
The PSU feature indication outputs, with galvanic isolation, which change their state if any of the following
events occur:
EPS FLT - output indicating AC power loss.
The output indicates 230V AC power loss. Under normal status, with the 230V AC power on, the output
is closed. In case of power failure, the PSU will switch the output into the open position after a time lag
determined in the „ Delay time for EPS output” menu (see section. 6.2.4).
APS FLT - output indicating battery failure.
The output indicates a failure in the battery circuit. Under normal status (during correct operation) the
output is close. In case of a failure the PSU will switch the output into the open state. Any failures can be
triggered by the following events:
- a faulty or undercharged battery
- battery voltage below 23V during battery-assisted operation
- battery fuse failure
- no continuity in the battery circuit
PSU FLT - output indicating PSU failure.
The output indicates the PSU failure. Under normal status (during correct operation) the output is close.
In case of a failure the PSU will switch the output into the open state. Any failures can be triggered by the
following events:
- low output voltage Uaux<23,6V
- high output voltage Uaux>29,4V
- high battery voltage Uaku>28V (during battery test)
- polymer fuse PTC activation
- exceeding the PSU nominal current
- failure in the battery charging circuit
- activation of the over voltage protection OVP
- enclosure opening - TAMPER
- internal damage of the PSU
- EXT IN input activation
The technical outputs have been implemented with galvanic isolation between the PSU’s systems and the
attached devices.
Fig. 15. Electrical diagram of the technical outputs.

www.pulsar.pl PSBEN2024B/LCD BLACK POWER
20
5.7 Input of collective failure EXT IN.
The EXT IN (external input) technical input indicating a collective failure is intended for additional, external
devices that generate the failure signal. The voltage at the EXT IN input will save information about an incident in
the internal memory of the power supply and sending the signal about the failure to the PSU FLT output.
The EXT IN technical input has been implemented with galvanic isolation between the PSU’s systems
and the devices attached.
Fig. 16. Electrical diagram of the EXT IN input.
The electrical diagram below shows the way of connecting external devices to the EXT IN input. Outputs
such as: OC (open collector), relay may be used as a source of the signal.
Fig. 17. Examples of connections.
In the option with tamper switches, the VEXT jumper must be on. It polarizes the EXT IN input circuit
therefore is required in such configuration.
The EXT IN input has been adjusted to cooperate with fuse modules that generate a failure signal in case
of a fuse fault in any of output sections (e.g. AWZ535, AWZ536). To guarantee a correct cooperation between the
module and the EXT IN input, the VEXT jumper must be on and the connections are to be made accordingly to the
diagram below.
Fig. 18. Example of a connection with the fuse module: AWZ535 or AWZ536.
