Pulsar PSB-12V5A User manual

1
PSB-12V5A
PSB 13,8V/5A enclosed switch
mode buffer power supply
Edition: 1 from 28.04.2020
Supercedes the edition: ------------
EN
Features of the power supply:
DC 13,8 V/5 A uninterruptible power supply
high efficiency 87%
controlling of battery charging and maintaining
protecting of battery against excessive discharging
(UVP)
battery charging current 0,5 A/1 A, changed by
jumper
optional equipment: set of external LED indicators:
PKAZ168, mounting plate DIN2
battery output is full protected against short-
circuit and reverse connection
LED optical signalisation
protections:
short-circuit protection SCP
over voltage protection OVP
surge protection
overload protection OLP
warranty –2 years from production date
1. Technical description.
1.1.General description.
Buffer-type power supply units are intended for continuous power supply to devices that require stabilised voltage
of 12 V DC (+/-15%). The power supply provides a voltage of U=13,8 V DC with an output current of:
1. Output current of 5 A + 0,5 A battery charging
2. Output current of 4,5 A + 1 A battery charging
Total device current + battery: 5,5 A max.
In case of power voltage decay, prompt switching to battery supply occurs. The power supply unit is protected
against a short circuit, an overload, a surge or over voltage protection.
1.2.Technical parameters.
Supply voltage
~ 200 –240 V; 0,8 A; 50 Hz
Inrush current
40 A
Supply power
76 W
Efficiency
87%
Output voltage (factory settings)
11-13,8 V DC –buffer operation
9,5-13,8 V DC –battery operation
Output current
5,5 A
Battery charging current
0,5 A / 1 A jumper selectable
Voltage adjustment range
13,5 –14,4 V DC
Current consumption by PSU during battery-
assisted operation
approx. 10 mA
Ripple voltage
100mV p-p max.
Short-circuit protection SCP
electronic, automatic recovery
Overload protection OLP
105-150% PSU power, automatically recovered
Overload protection (battery) OLP
melting fuse T6,3 A
Surge protection
varistors
Overvoltage protection OVP
>19 V (activation requires disconnecting the load or supply
for about approx. 1 min)
Excessive discharge protection UVP
U<9,5 V (± 5%) –disconnection of battery
Optical signalisation
LED green –indicates DC voltage at the power
LED optical indication output (intended for optional
indication set PKAZ168)
LED AC –presence of AC voltage
LED DC –presence of DC voltage on power supply output
LED CHARGE –battery charging process
Optional equipment
A set for optical indication LED PKAZ168
Operation conditions
Temperature: -10oC ÷ +40oC relative humidity 20%...90%,

2
without condensation
Dimensions
L=129, W= 98, H=40 [±2mm]
Net/gross weight
0,32 / 0,36 [kg]
Protection class electric shock protection
I (first) - requires a protective conductor
Connectors
I/O PCB: 0,5 –2,5 mm2(AWG 26 –12)
output of optical signalization: 4 pins micromatch socket
Additional accessories
Battery wires 6,3F –45cm, ML062 angle muff (hole
5,2mm)
Electrical strength of insulation:
- between input (network) circuit and output circuits
of power-supply
- between input circuit and protection circuit
- between output circuit and protection circuit
2500 V AC min.
1500 V AC min.
500 V AC min.
Insulation resistance:
- between input circuit and output or protection
circuit
100 MΩ, 500 V DC
Storage temperature
-20ºC...+60ºC
Vibrations and impulse waves during transport
according to PN-83/T-42106
1.3. Description of terminals.
Elements/connectors [Fig.1]
Description
[1]
LED for DC output voltage
[2]
Potentiometer - output voltage adjust
[3]
Connector of optical signalization LED
[4]
Power supply output (V+, V-)
[5]
Battery connector (B+, B-)
[6]
Jumper -battery charging current configuration:
Ibat =0,5 A
Ibat =1,0 A
Legend: jumper installed, jumper removed
[7]
L-N –input voltage connectors 230 V,
–protective conductor connector
1.4.Dimensions and fitting of the PSB-12V5A power supply.

3
2. Installation.
2.1. Requirements.
PSU is to be mounted by a qualified installer, holding relevant permits and licenses (applicable and required for a
given country) for low-voltage installations. The device shall be mounted in closed rooms of the normal air humidity
(RH=90% max. without condensation) and the temperature within the range from -10°C to +40°C.
The power supply shall be mounted in a close casing (a cubicle, a terminal device) and in order to fulfill LVD and EMC
requirements the rules for power-supply, encasing and shielding shall be observed according to application.
Due to the power supply design, the protection wire has to be connected to the corresponding connector of the
supply unit. Before installation, prepare a PSU load balance with point 1.1.
2.2. Installation procedure.
Before installation, make sure that the voltage in the 230 V power-supply circuit is cut off. To switch off
power use an external switch in which the distance between the contacts of all poles in the
disconnection state is not less than 3mm.
1. Mount the PSU in a selected location and connect the wires.
2. Connect the power cables (~230 V) to L-N clips of the PSU.
The shock protection circuit shall be performed with a particular care, i.e. the yellow and green wire
coat of the power cable shall stick to one side of the ‘ ’ terminal - in the PSU enclosure. Operation of
the PSU without a properly made and fully operational shock protection circuit is UNACCEPTABLE! It
can cause a device failure or an electric shock.
3. Connect the ground wire to the clip marked by the earth symbol (connector of power supply module). Use a three-
core cable (with a yellow and green protection wire) to make the connection. Lead the cables to the appropriate clips of
the subplate through the insulating bushing.
4. Check the PSU output voltage, if needed correct the setting it should by the potentiometer.
5. Connect load / loads to proper output connectors of the power supply (positive end is marked as +V, negative
end as V-)
6. Screw the battery cables to the BAT connector (black B-, red B +).
7. Connect the battery paying attention to polarity.
8. Connect the PKAZ168 external optical signalling (optional equipment)
9. Once the tests and control operation have been completed, close the enclosure/cabinet.
3. Maintenance.
All maintenance procedures can be performed after the disconnection of the power supply from the electrical
grid. The power supply does not require any special maintenance procedures, but in the case of significant dust
accumulation, dusting using compressed air is recommended.
Pulsar sp. j.
Siedlec 150, 32-744 Łapczyca, Polska
Tel. [phone], Fax. [phone]
e-mail: [email protected], [email protected]
http:// www.pulsar.pl, www.zasilacze.pl
WEEE MARKING
According to the EU WEE Directive –It is required not to dispose of electric or electronic waste as unsorted municipal waste and to collect such
WEEE separately.
