PulseAudio PA-SS4V User manual

pulseaudio1.com | vanco1.com | 800.626.6445
Two Source, Four Pair Stereo Speaker
SELECTOR BOX
PART NUMBER PA-SS4V
with Volume Control

2
1. Do not install or place this unit
in a built-in cabinet, or other
confined space without adequate
ventilation.
2. To prevent risk of electrical shock
or fire hazard, due to overheating
do not obstruct unit’s ventilation
openings.
3. Do not install near any source of
heat, including other units that
may produce heat.
4. Do not place unit near flames.
5. Only clean unit with a dry cloth.
6. Unplug unit during lightning
storms or when not used for an
extended period of time.
7. Protect the power cord from being
walked on or pinched, particularly
at the plugs.
8. Use unit only with accessories
specified by the manufacturer.
9. Refer all servicing to qualified
personnel.
WARNING
THIS PRODUCT IS 100% INSPECTED AND TESTED IN THE
UNITED STATES TO VERIFY PERFORMANCE PARAMETERS.
Thank you for purchasing this product. For optimum
performance and safety, please read these instructions
carefully before connecting, operating or adjusting this
product. Please keep this manual for future reference.
DEAR CUSTOMER

3
Thank you for your purchase of a PA-SS4V Two Source, Four Pair Speaker
Selector Box with Volume Control. The PA-SS4V is a low-profile speaker
distribution system which features:
• An independent On/O switch for each zone of audio
• Impedance matching volume control for each audio zone
• The ability to select either of the two stereo speaker-level signals to 4
audio zones
Dual-Source Four Pair Stereo Speaker Selector with
Volume Control
Part # PA-SS4V
• Distributes high level stereo signals from 2 sources to up to 4 zones
• Easy selectable impedance matching to protect amplifiers and equipment
• Spring loaded speaker terminals accepts up to 14 gauge speaker wire
• 12 step volume control settings
• Independent ON/OFF button for each zone
• Rack mounting accessories included
• Rated up to 100W RMS per channel
• Dimensions: 16.7” x 7.1” x 1.7”
FEATURES
PACKAGE CONTENTS
• PA-SS4V Speaker Selector
• Product Manual

4
SS4V PANEL DESCRIPTIONS
CONNECT AND OPERATE
1
3
2
1
2
1. Speaker Zone ON/OFF Button
2. Volume Control Dial
3. Zone Source Selection Button (A/B)
4. Unit ON/OFF Button
The “+/-“ polarity connections for the inputs and outputs are clearly marked
on the rear panel and use spring loaded speaker terminals. Make sure that
the system and all source components are powered down before making any
connections.
4
3
1. Spring Loaded Inputs
2. Impedance Switch - 1 for each zone (see chart below)
3. Spring Loaded Speaker Outputs
Front Panel
Back Panel

5
ZONE 2 ZONE 1
ZONE 4
AMP A
AMP B
ZONE 3
ZONE 2 ZONE 1
ZONE 4
AMP A
AMP B
ZONE 3
1. With any and all amplifiers and sources turned o, connect the speaker
wire to the appropriate “+/-“ terminals of each speaker
2. Route the speaker wires from amplifier or receiver to the speaker selector.
The terminals on the speaker selector accepts up to 14 gauge wire
3. Strip ¼” insulation from the end of the speaker wire and slightly twist to
avoid fraying
4. Press to open the appropriate spring-loaded speaker selector terminal
(INPUT) and insert the striped end of the wire into the proper terminal.
Make sure the proper “+/-“ polarity is maintained when connecting the
speaker wires
5. Next, with your source amplifier powered o, strip ¼” insulation from the
end of the cable. Make sure the + and – terminals are correctly identified.
6. To connect the speakers to the PA-SS4V press to open the appropriate
spring-loaded terminal (OUTPUT) and insert the striped end of the wire
into the proper terminal. Make sure the proper “+/- polarity is maintained
when connecting the input wires
7. Once everything is connected, you can begin testing. Turn on the sound
system and set the amplifier’s volume control to a moderate level. If each
zone is turned on, check each zone for audio and balance. If you are
having multiple sources connected, test each zone’s source switching

6
1. Determine the amplifiers minimum impedance capabilities. This is found
in the amplifier’s specifications. Please refer to the manufacturer’s manual
for this information
2. Identify the correct impedance matching from the charts below based
on whether you are using 8 ohm or 4 ohm amplifiers. If your amplifier is 6
ohm stable, refer to the 8 ohm chart
3. Determine the total number of 4 ohm pairs of speakers and 8 ohm pairs of
speakers
4. Follow the chart to apply the correct setting
SAFETY AND NOTICE
The PA-SS4V has been tested for conformance to safety regulations and
requirements, and has been certified for international use. However, like all
electronic equipment, the PA-SS4V should be used with care. Please read and
follow the safety instructions to protect yourself from possible injury and to
minimize the risk of damage to the unit.
• Follow all instructions and warnings marked on this unit.
• Do not attempt to service this unit yourself, except where explained in this manual.
• Provide proper ventilation and air circulation and do not use near water.
• Keep objects that might damage the device and assure that the placement of this
unit is on a stable surface.
• Use only the power adapter and power cords and connection cables designed for
this unit.
• Do not use liquid or aerosol cleaners to clean this unit.
• Always unplug the power to the device before cleaning
SETTING THE IMPEDANCE
The impedance in the speaker selector is set to the factory default position
of X4 which is proper for most applications. If certain applications require the
impedance setting to change, simply switch the position of the Impedance for
that specific zone or for all zones that require dierent impedance.

7
TECHNICAL SUPPORT
In case of problems, please contact Vanco Technical Support by dialing
1-800-626-6445. You can also email technical support issues to techsupport@
vanco1.com. When calling, please have the Model Number, Serial Number
(axed to the bottom of the unit) and Invoice available for reference during
the call. Please read this Instruction Manual prior to calling or installing this
unit, since it will familiarize you with the capabilities of this product and its
proper installation. All active electronic products are 100% inspected and
tested to insure highest product quality and trouble-free installation and
operation. The testing process utilizes the types of high-definition sources and
displays typically installed for entertainment and home theatre applications.
For additional information please visit www.vanco1.com.
LIMITED WARRANTY
With the exceptions noted in the next paragraph, Vanco warrants to the
original purchaser that the equipment it manufactures or sells will be free from
defects in materials and workmanship for a period of two years from the date
of purchase. Should this product, in Vanco’s opinion, prove defective within
this warranty period, Vanco, at its option, will repair or replace this product
without charge. Any defective parts replaced become the property of Vanco.
This warranty does not apply to those products which have been damaged
due to accident, unauthorized alterations, improper repair, modifications,
inadequate maintenance and care, or use in any manner for which the product
was not originally intended. Items integrated into Vanco products that are
made by other manufacturers, notably computer hard drives and liquid
crystal display panels, are limited to the term of the warranty oered by the
respective manufacturers. Such specific warranties are available upon request
to Vanco. A surge protector, power conditioner unit, or an uninterruptible
power supply must be installed in the electrical circuit to protect against
power surges. If repairs are needed during the warranty period the purchaser
will be required to provide a sales receipt/sales invoice or other acceptable
proof of purchase to the seller of this equipment. The seller will then contact
Vanco regarding warranty repair or replacement.
LIABILITY STATEMENT
Every eort has been made to ensure that this product is free of defects. The
manufacturer of this product cannot be held liable for the use of this hardware
or any direct or indirect consequential damages arising from its use. It is
the responsibility of the user and installer of the hardware to check that it is
suitable for their requirements and that it is installed correctly. All rights are
reserved. No parts of this manual may be reproduced or transmitted by any
form or means electronic or mechanical, including photocopying, recording
or by any information storage or retrieval system without the written consent
of the publisher. Manufacturer reserves the right to revise any of its hardware
and software following its policy to modify and/or improve its products where
necessary or desirable. This statement does not aect the legal rights of the
user in any way.
