Flepcher FLP-ZS-1012 User manual

Function Descriptions
345
P0WER LED 3 4 5
5 6 7
23 4
6 7
1
12
P0WER 2
1 2 3 4
1
5
1.This unit is powered by external stabilized voltage supply of DC 24V current 1A.≥
2.This selector can switch on/off manually through pressing the zone buttons on front panel,
and the zones also can be controlled by the zones button on the panel of digital paging
console FLP-PMC-1001,and the control mode adopts 485 signal control.
3.Each unit has individual address code, and with RJ45 8-core network ports which include one
group 485 signal, one group balanced audio signal, one group DC24V.
4.There is an emergency alarm short-circuit activation signal input terminal. Once a
short-circuit signal is input, all zones can be switched on automatically . After the
short-circuit signal is removed, the original state is restored automatically
5.12 channel constant 100V input signals, correspond with 12 output signals.
Front Panel
Zone select buttons ALL ON button ALL OFF button
Rear Panel
Address code DC24V input Communication output link Communication input
Short-circuit signal output Short-circuit signal input Zone input and output ports
Operation
1 Set the unit with correct address code. If only one unit is connected to the system,.
the address code must be set to "1". If there are multiple units, the order must be set
to "1,2,3,4 ... 8 ", and can only connect up to 8 units.
2 Connect the network cable according to the correct connection method (please refer to.
the network cable port wiring definition diagram).
3 Connect the corresponding amplifier and speaker group to the corresponding ports.
( : -according to the correct wiring method Note The total power to the single channel
≤ ).250W
4 When plugging and unplugging the network cable, you must ensure that other devices.
connected to this device are powered off.
5 When connecting DC24V power supply the current must be 1A to the DC input.( ≥ )
terminal pay attention that the positive and negative cannot be connected in reverse, .
Connection Schematic
To amplifier
To speaker
8 core network cable-
Technical Specification
≤1 3 W
DC /1024V 00m A
485*155*500mm
L P -F - Z S 1 0 1 2
2 0Kg.
Single channel output ≤
≤3000W
250W
Model
Channels 12 channels
All channels output
total power
power
Power consumption
Power Supply
Dimension
Weight
Communication Port Interface Definition
Wiring Definition Diagram
