PULSE+ STAGEPAR-108 User manual

www.pulse-audio.co.uk
STAGEPAR-108
(Black order code: STAGEPAR-108B)
(Polished order code: STAGEPAR-108S)
User Manual

3
Index
1SafetyInstruction............................................................................................................5
2 Introduction ....................................................................................................................6
2.1 Supported function modes....................................................................................7
2.1.1 Modes which supportDMX input or DMX output...........................................7
2.1.2 Stand alone modes...........................................................................................8
3Overview ........................................................................................................................9
3.1 Back view...............................................................................................................9
3.2 DMX operation....................................................................................................10
3.2.1 Building a serial chain...................................................................................10
3.2.2LEDPARoperates as a DMXmaster............................................................10
3.2.3LEDPARoperates as a DMX slave ..............................................................10
4Function Selection ........................................................................................................11
5 Auto change mode ........................................................................................................12
5.1 Mode setting ........................................................................................................12
5.2 Speed setting........................................................................................................12
5.3 Colour pattern setting.........................................................................................13
6 Auto fade mode ............................................................................................................14
6.1 Mode setting ........................................................................................................14
6.2 Fadespeed ...........................................................................................................14
6.3 Colour pattern setting.........................................................................................15
7 Manual mode ................................................................................................................16
7.1 Mode setting ........................................................................................................16
7.2 Colour pattern setting.........................................................................................17
7.2.1Red Colour....................................................................................................17
7.2.2Green Colour.................................................................................................17
7.2.3Blue Colour...................................................................................................18
8DMX slave 5ch mode ...................................................................................................19
8.1 Mode setting ........................................................................................................19
8.2 Speed setting........................................................................................................19
8.3 DMX usage for 5ch control.................................................................................20
8.4 Set up of thefirst DMX receiving channel .........................................................21
8.5 Examples .............................................................................................................22
8.5.1 Example A, firstDMXreceive channel is 1 ...................................................22
8.5.2 Example B, firstDMXreceive channel is 22 .................................................22
8.5.3 Example C, firstDMXreceive channel is 272 ...............................................22
8.5.4 Example D, firstDMXreceive channel is 508 ...............................................22
9DMXmaster 5ch mode .................................................................................................23
9.1 Mode setting ........................................................................................................23

4
9.2 Speed setting........................................................................................................23
9.3 DMX usage for 5ch control.................................................................................24
9.4 Colour pattern setting.........................................................................................25
9.4.1 Colour patterns..............................................................................................25
9.4.2 Fading in out colour patterns.........................................................................25
9.4.3 Fading over colour patterns...........................................................................26
9.4.4 Chaser colour patterns...................................................................................26
9.5 Examples .............................................................................................................28
9.5.1 Example A ....................................................................................................28
9.5.2 Example B.....................................................................................................29
10 DMX slave 3ch.........................................................................................................31
10.1 Mode setting ........................................................................................................31
10.2 DMX usage ..........................................................................................................31
10.3 Set up of thefirst DMX receiving channel .........................................................32
10.4 Examples .............................................................................................................33
10.4.1 Example A, firstDMXreceive channel is 1 ...................................................33
10.4.2 Example B, firstDMXreceive channel is 22 .................................................33
10.4.3 Example C, firstDMXreceive channel is 272 ...............................................33
10.4.4 Example D, firstDMXreceive channel is 510 ...............................................33
11 DMXmaster 3ch.......................................................................................................34
11.1 Mode setting ........................................................................................................34
11.2Speed setting........................................................................................................34
11.3 DMX usage for 3ch control.................................................................................34
11.4Colour pattern setting.........................................................................................35
11.5 Examples .............................................................................................................36
11.5.1 Example A ....................................................................................................36
11.5.2 Example B.....................................................................................................37
12 Technical Specifications ...........................................................................................38
36 LEDs, 3W................................................................................................. 38
...........................

5
1Safety Instruction
 Keep this device away from rain and moisture!
 Unplug mains lead before opening the housing!
 Never look directly into the light source (sensitive persons may suffer an epileptic
shock).
 Never leave this device running unattended.
 Keep away children.
 When installing the device, make sure there is no highly inflammable material within
a distance of 0.5m.

6
2Introduction
Main feature of this LED PAR is, that it can be used as a 4ch DMX controller.
In this mode 4 LED PARs are connected with XLR cables on their DMX In-/Outputs.
The first LED PAR is set to DMX master mode. Now the LED PAR in master mode sent
control signals to the connected slaves. There are different patterns available e.g. all
connected LED PARs do the same, each shows different patterns, chaser programs, fade in –
fade out patterns and fade over patterns. The steps of the patterns can be controlled by music
beat or by a potentiometer. The music sensitivity is controllable. The colour patterns offers a
100% colour mode, a 100% / 50% colour mode, and a 100% / 75% / 50% /25% colour mode.
The colours are shown by random.
A 3ch DMX slave mode is supported, for easy connection in a DMX system. All 512channels
are supported.
Stand alone modes colour change, fading patterns and fixed colour settings are supported.

7
2.1 Supported function modes
2.1.1 Modes which support DMX input or DMX output
2.1.1.1 5 channel master mode
In this mode the LED PAR is used as a 4 channel DMX master.
The 5channel master mode is offered to be compatible to the first revision of the LED PAR.
The 5channel master mode uses build in functions of the LED PARs. Which will be
controlled by the DMX signal.
There are different patterns available e.g. all connected LED PARs do the same, each shows
different patterns, chaser programs, fade in – fade out patterns and fade over patterns. The
steps of the patterns can be controlled by music beat or by a potentiometer. The music
sensitivity is controllable. The colour patterns offers a 100% colour mode, a 100% / 50%
colour mode, and a 100% / 75% / 50% /25% colour mode. The colours are shown by random.
2.1.1.2 3 channel master mode
In this mode the LED PAR is used as a 4 channel DMX master.
The 3channel master mode is offered for less consumption of DMX channels e.g. in case of
connected DMX power packs or other DMX receivers.
There are different patterns available e.g. all connected LED PARs do the same, each shows
different patterns, chaser programs, fade in – fade out patterns and fade over patterns. The
steps of the patterns can be controlled by music beat or by a potentiometer. The music
sensitivity is controllable. The colour patterns offers a 100% colour mode, a 100% / 50%
colour mode, and a 100% / 75% / 50% /25% colour mode. The colours are shown by random.
2.1.1.3 5 channel slave mode
In this mode the LED PAR is used as a DMX slave.
The 5channel slave mode is supported if the LED PAR is in use with the first revision of the
LED PAR. The 5channel slave mode uses build in functions, which be controlled by the
DMX signal. An external DMX controller controls the Led PAR.
2.1.1.4 3 channel slave mode
The 3channel slave mode is for use with a standard DMX controller. The LED PAR can be
controller with all 512 channels. Each colour is controlled by one DMX channel. All 512
DMX channels can be used.

8
2.1.2 Stand alone modes
2.1.2.1 Auto fade mode
There is an auto fade mode available with different fade in/fade out patterns and fade over
patterns. Even here a compatible mode is offered for use with the first revision of the LED
PAR. The fade in/fade out and fade over time can be set accurate by 9 time settings.
The auto fade mode supports different colour change patterns:
The colour patterns offers a 100% colour mode, a 100% / 50% colour mode, and a 100% /
75% / 50% /25% colour mode. The colours are shown by random.
The compatible mode is for use with the first revision of the LED PAR
2.1.2.2 Auto change mode
The auto change mode supports different colour change patterns.
The colour patterns offers a 100% colour mode, a 100% / 50% colour mode, and a 100% /
75% / 50% /25% colour mode. The colours are shown by random.
The compatible mode is for use with the first revision of the LED PAR
The change speed can be controlled by music or potentiometer.
2.1.2.3 manual mode
In the manual mode each colour can be set to on in steps of ~14%.

9
3Overview
3.1 Back view
This picture shows the backside of the LED PAR.
DMX-Input:
In case of external DMX control, the DMX cable is connected here.
DMX-Input pin Signal
1Ground
2Signal “-”
3Signal “+”
DMX-Output:
Connect here the DMX cable for next unit.
DMX-Output pin Signal
1Ground
2Signal “-”
3Signal “+”
Function:
This 4 pin dipswitch sets, the function mode of the LED PAR.
Pattern:
The function of this 10 pin dipswitch depend on the selected mode, e.g. in chaser mode the
chaser patterns are selected here.
Speed:
Manual speed setting.
Music:
Sensitivity control for the build in microphone.

10
3.2 DMX operation
3.2.1 Building a serial chain
Connect the DMX-output of the first unit in the DMX-chain with the DMX-input of the next
fixture. Always connect one output with the input of the next unit until all fixtures are
connected.
The last unit of the DMX chain has to be terminated with a resistor. Connect a 120 Ohm
resistor between Signal “-“ and Signal “+” to DMX-output-socket of the last unit .
3.2.2 LED PAR operates as a DMX master
In the DMX master mode, the LED operates as a DMX controller to the connected units in the
DMX chain.
If the LED PAR is used as a DMX master, it must be the first unit in the DMX chain. Unplug
the DMX input cable of the LED PAR which operates as a DMX master.
3.2.3 LED PAR operates as a DMX slave
In the DMX slave mode the LED PAR operates as a normal DMX receiver. It is controlled by
an external DMX controller.

11
4Function Selection
The LED PAR modes may be set by the 4pin dipswitch on the backside of the LED PAR
according to the this table:
SW4 SW3 SW2 SW1 mode
X 0 0 0 auto change
X 0 0 1 auto fade
X 0 1 0 manual mode
X 0 1 1 DMX slave 5ch
X 1 0 0 DMX master 5ch
X 1 0 1 DMX slave 3ch
X 1 1 0 DMX master 3ch
X 1 1 1 No new mode (DMX master 3ch is used)
0 X X X speed control by potentiometer, if selected mode support it
1 X X X speed control by music, if selected mode support it
0 = dipswitch is set to off
1 = dipswitch is set to on
X = see information below/above

12
5Auto change mode
The LED PAR shows different colours depending on speed selection.
In this mode the LED PAR is used stand alone, the DMX output/input is not used.
5.1 Mode setting
To enable the auto change mode, set the 4 pin dipswitch on the backside of the LED PAR
according to the this table:
SW4 SW3 SW2 SW1 Mode
X 0 0 0 auto change
0 = dipswitch is set to off
1 = dipswitch is set to on
X = see information below
5.2 Speed setting
SW4 setup the speed source. Choose the speed source according this table
SW4 SW3 SW2 SW1 mode
0 X X X speed control by potentiometer
1 X X X speed control by music
0 = dipswitch is set to off
1 = dipswitch is set to on
X = see information above

13
5.3 Colour pattern setting
The colour modes may be set by the 10pin dipswitch on the backside of the LED PAR
according to the this table:
SW10 SW9 SW8 SW7 SW6 SW5 SW4 SW3 SW2 SW1 Colour pattern selection
0 0 0 0 0 0 0 0 0 0 compatible mode -old pattern style
0 0 0 0 0 0 0 0 0 1 100% colour change
0 0 0 0 0 0 0 0 1 0 100%, 50% colour change
0 0 0 0 0 0 0 0 1 1 100%, 75%, 50%, 25% colour change
0 = dipswitch is set to off
1 = dipswitch is set to on
If another colour pattern is set, always patterns “0000000011” is used.

14
6Auto fade mode
The LED PAR shows different fading colours depending on speed selection.
In this mode the LED PAR is used stand alone, the DMX output/input is not used.
6.1 Mode setting
To enable the auto change mode, set the 4pin dipswitch on the backside of the LED PAR
according to the this table:
SW4 SW3 SW2 SW1 mode
X 0 0 1 auto fade
0 = dipswitch is set to off.
1 = dipswitch is set to on.
X = in this mode there is no speed control by potentiometer or music supported
6.2 Fade speed
The fading speed may be set by the 10pin dipswitch on the backside of the LED PAR
according to the this table:
SW10 SW9 SW8 SW7 SW6 SW5 SW4 SW3 SW2 SW1 Fading speed selection
0 0 0 X X X 0 0 0 0 10:30min
0 0 0 X X X 0 0 0 1 2,5s
0 0 0 X X X 0 0 1 0 5s
0 0 0 X X X 0 0 1 1 10s
0 0 0 X X X 0 1 0 0 20s
0 0 0 X X X 0 1 0 1 40s
0 0 0 X X X 0 1 1 0 80s
0 0 0 X X X 0 1 1 1 160s
0 0 0 X X X 1 0 0 0 320s
0 = dipswitch is set to off.
1 = dipswitch is set to on.
X = see table below
If another timing pattern is set, always patterns “000xxx1000” is used.
No speed control by potentiometer or music is supported in this mode.

15
6.3 Colour pattern setting
The fading patterns may be set by the 10pin dipswitch on the backside of the LED PAR
according to the this table:
SW10 SW9 SW8 SW7 SW6 SW5 SW4 SW3 SW2 SW1 Colour pattern selection
0 0 0 0 0 0 X X X X compatible mode -old pattern style
0 0 0 0 0 1 X X X X 100% colour change, fade in and out
0 0 0 0 1 0 X X X X 100%, 50% colour change, fade in and out
0 0 0 0 1 1 X X X X 100%, 75%, 50%, 25% colour change, fade in
and out
0 0 0 1 0 0 X X X X 100% colour change, fade in
0 0 0 1 0 1 X X X X 100%, 50% colour change, fade in
0 0 0 1 1 0 X X X X 100%, 75%, 50%, 25% colour change, fade in
0 = dipswitch is set to off.
1 = dipswitch is set to on.
X = see table above
If another colour pattern is set, always pattern 000110xxxx is used.

16
7Manual mode
The LED PAR shows different fixed colours.
In this mode the LED PAR is used stand alone, the DMX output/input is not used.
7.1 Mode setting
To enable the manual mode, set the 4pin dipswitch on the backside of the LED PAR
according to the this table:
SW4 SW3 SW2 SW1 mode
X 0 1 0 manual mode
0 = dipswitch is set to off
1 = dipswitch is set to on
X = in this mode there is no speed control by potentiometer or music supported

17
7.2 Colour pattern setting
7.2.1 Red Colour
The red colour may be set by the 10pin dipswitch on the backside of the LED PAR according
to the this table:
SW10 SW9 SW8 SW7 SW6 SW5 SW4 SW3 SW2 SW1 Red colour brightness
0 X X X X X X 0 0 0 0%
0 X X X X X X 0 0 1 14%
0 X X X X X X 0 1 0 28%
0 X X X X X X 0 1 1 42%
0 X X X X X X 1 0 0 57%
0 X X X X X X 1 0 1 71%
0 X X X X X X 1 1 0 85%
0 X X X X X X 1 1 1 100%
0 = dipswitch is set to off
1 = dipswitch is set to on
X = see table below
7.2.2 Green Colour
The green colour may be set by the 10pin dipswitch on the backside of the LED PAR
according to the following table:
SW10 SW9 SW8 SW7 SW6 SW5 SW4 SW3 SW2 SW1 Green colour brightness
0 X X X 0 0 0 X X X 0%
0 X X X 0 0 1 X X X 14%
0 X X X 0 1 0 X X X 28%
0 X X X 0 1 1 X X X 42%
0 X X X 1 0 0 X X X 57%
0 X X X 1 0 1 X X X 71%
0 X X X 1 1 0 X X X 85%
0 X X X 1 1 1 X X X 100%
0 = dipswitch is set to off.
1 = dipswitch is set to on.
X = see table above or below

18
7.2.3 Blue Colour
The blue colour may be set by the 10pin dipswitch on the backside of the LED PAR
according to the this table:
SW10 SW9 SW8 SW7 SW6 SW5 SW4 SW3 SW2 SW1 Blue colour brightness
0 0 0 0 X X X X X X 0%
0 0 0 1 X X X X X X 14%
0 0 1 0 X X X X X X 28%
0 0 1 1 X X X X X X 42%
0 1 0 0 X X X X X X 57%
0 1 0 1 X X X X X X 71%
0 1 1 0 X X X X X X 85%
0 1 1 1 X X X X X X 100%
0 = dipswitch is set to off.
1 = dipswitch is set to on.
X = see table above

19
8DMX slave 5ch mode
The item is controlled by 5 DMX channels according the table below.
With Dipswitch 1 to 9 the first DMX channel to receive is set.
8.1 Mode setting
To enable the DMX slave 5ch mode, set the 4pin dipswitch on the backside of the LED PAR
according to the this table:
SW4 SW3 SW2 SW1 mode
X 0 1 1 DMX slave 5ch
0 = dipswitch is set to off
1 = dipswitch is set to on
X = see information below
8.2 Speed setting
SW4 setup the speed source. Choose the speed source according this table
SW4 SW3 SW2 SW1 mode
0 X X X speed control by potentiometer, if selected function support it
1 X X X speed control by music, if selected mode support it
0 = dipswitch is set to off
1 = dipswitch is set to on
X = see information above

20
8.3 DMX usage for 5ch control
The table shows the DMX value which need to be sent to the LED PAR by an external DMX
controller:
Channel 1 value Function
0 - 63 RGB control, CH2 = red, CH3 = green, CH4 = blue
64 – 127 7 colour fade, CH5 = speed control
128 – 191 7 colour change, CH5 = speed control
192 – 255 3 colour change, CH5 = speed control
Channel 2 value Function
0 – 255 Red colour 0% – 100%
Channel 3 value Function
0 – 255 Green colour 0% – 100%
Channel 4 value Function
0 – 255 Blue colour 0% – 100%
Channel 5 value Function
0 - 10 no function – no speed
11 - 100 value 11 to 100, fast speed to low speed
101 - 150 no function – no speed
151 - 255 speed control by unit, by music or potentiometer

21
8.4 Set up of the first DMX receiving channel
The value of dipswitch 1 to 9 is binary coded. To set a wished DMX receiving channel add
the different values (see example below of the table):
SW10 SW9 SW8 SW7 SW6 SW5 SW4 SW3 SW2 SW1 First DMX receive channel
0 0 0 0 0 0 0 0 0 1 1
0 0 0 0 0 0 0 0 1 0 2
0 0 0 0 0 0 0 1 0 0 4
0 0 0 0 0 0 1 0 0 0 8
0 0 0 0 0 1 0 0 0 0 16
0 0 0 0 1 0 0 0 0 0 32
0 0 0 1 0 0 0 0 0 0 64
0 0 1 0 0 0 0 0 0 0 128
0 1 0 0 0 0 0 0 0 0 256
0 = dipswitch is set to off.
1 = dipswitch is set to on.
Remarks:
In case of all dipswitches 1 to 9 are set to zero, the first DMX receive channel is 1.
I case of only dipswitch 1 is set to on, the first DMX receive channel is 1.
The maximum first receive channel is channel 508.
In case of chosen first receive channel bigger than 508, the maximum receive channel is still
508.
