Pure-Pro RO600 User manual

RO600
PRO
P
URE
DRINKING WATER SYSTEM
REVERSE OSMOSIS SYSTEM
19
PURE-PRO REVERSE OSMOSIS SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
RO600 600GPD Light Commercial
Type of product
Date of purchase
Name Tel
Address
Memo
01 Introduction of RO600
02 What is Reverse Osmosis
03 Components& Selections
04 Cartridge filters
05 The parts of RO600
08 Installation diagram
13 Change filters
14 Change RO membrane
15 Operation regulations
17 FAQ
18 Maintenance checking list
19 Memo
07 Tubing connection diagram
USER'S MANUAL
Thank you very much for selecting Pure-Pro Water Corp.
In order to bring the best use of your system, please read
the user's manual carefully before installation and follow
the regulations.

01
PURE-PRO REVERSE OSMOSIS SYSTEM
18
PURE-PRO REVERSE OSMOSIS SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
RO600 600GPD Light Commercial RO600 600GPD Light Commercial
Introduction of RO600
Date
Filters
1st stage 2nd stage 3rd stage 4th stage 7th stage Other items
Maintenance checking list
6th stage
~
¨RO600
This system is economical and designed for commercial and residential
application. Provide safe, pure water. It is suitable for manufacturing, restaurants,
food processing industries, shopping centers, schools and hotels.
RO600 improves both the taste and quality of your water. It reduces up to +99% of
the chlorine, as well as objectionable odors and sediment. RO600 also reduces
the following hard water contaminants that may be present in your water: lead,
cooper, barium, chromium, mercury, sodium, cadmium, fluoride, nitrite, nitrate,
and selenium.
Production: 600gpd
Water Tank (Include) : 20 gallons.
Operation Pressure : 10 - 125 psi
Available in : 110 volt, 220volt, 240volt. ( 50 / 60 Hz )
Weight (System & Tank) : 49 kg
Dimensions: 50.0 (L) x 24.0 (W) x 80.0 (H) cm
56.0 (L) x 56.0 (W) x 88.0 (H) cm
- system
- tank
¨Features
20 Gallons Standards Water Storage Tank With Tank Ball Valve.
FDAApproved Polypropylene Made Flat Cap Housings.
3 high rejection membranes, Each membrane is 200GPD at 100psi.
Build in electrical shut off valve to prevent any damage of the membrane.
Self Piercing Saddle Valve & Feed water quick connector.
Drain Saddle Valve.
1 Year Warranty.
30 Days Money Back Guarantee.
Completely Assembled, 100% Factory Tested and Sterilized Ready for
Installation.
¨Specifications

17
PURE-PRO REVERSE OSMOSIS SYSTEM
02
PURE-PRO REVERSE OSMOSIS SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
RO600 600GPD Light Commercial RO600 600GPD Light Commercial
Reverse osmosis was originally designed to make sea water drinkable for the
navy. It is ideal for anyone on a low sodium diet. An R.O. membrane has a pore
size much smaller than bacteria virus, or the cryptosporidium parasite. When
functioning properly it will remove all microorganisms from tap water and produce
sterile water. Reverse osmosis is the reversal of the natural flow of osmosis. In a
water purification system, the goal is not to dilute the salt solution, but to
separate the pure water from the salt and other contaminants. When the natural
osmotic flow is reversed, water from the salt solution is forced to pass through the
membrane in the opposite direction by application of pressure-thus the term
REVERSE OSMOSIS. Through this process, we are able to produce pure water
by screening out the salts and other contaminants.
What is reverse osmosis
Reverse Osmosis
Pressure
Membrane
Water flow
Q: What is the guarantee on the PurePro system ?
Q: What factors affect the quantity and the quality of the water production?
Pressure
Temperature
Total Dissolved Solids (TDS)
Membrane
Q:
Q:
The PurePro System (excluding filters) is guaranteed for 1 year for material and
workmanship. All defective parts will be replaced free within the first year under
natural breakdown. The membrane has one year pro-rated guarantee.
There are four major variables to consider:
1. -The greater the water pressure, the better water quantity and
quality it produced. Water pressure of 60 PSI is ideal.
2. -76 F is the ideal water temperature for R.O. 40 F water will
cause the production of R.O. water to fall to half of that at 76 F. The maximum
water temperature recommended is 85 F.
3. -The higher the amount of dissolved
contaminants in the water, the lower the quantity of water produced. A high
level of TOTAL DISSOLVED SOLIDS can be overcome with additional water
pressure.
4. -Different membranes have different characteristics. Some
produce more water than others; some have better contaminant rejection
capabilities; some have greater resistance to chemical abrasion for longer life.
PurePro system includes TW30-1812-200 The Thin Film Composite (TFC)
membranes combine the best of these characteristics and are considered the
finest membrane in the world.
0 0
0
0
My RO system is not making any water. What should I do?
1.Make sure you plug in electricity.
2.Check the water supply. Make sure it's on.
3.Check if pumps work well.
If none of above occur, please contact a technician at the nearest shop for
assistance.
1.Switch off the water supply and turn on the faucet.
2.Check the water flow from the faucet. If water stop coming out, check the
water storage tank.
Water tank still has water: the tank water pressure is under regular water
pressure give pressure to the tank.
Why can't my water storage tank make enough water?
FAQ

03
PURE-PRO REVERSE OSMOSIS SYSTEM
16
PURE-PRO REVERSE OSMOSIS SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
RO600 600GPD Light Commercial RO600 600GPD Light Commercial
Components & Selections
¨Components
¨Selections
A.With everything connected, turn on the water check for leaks.
B.Make sure the storage tank shut-off valve is "OFF". Open the sink
top faucet.
C.Within a few minutes (up to 15) the water will start to run from the
faucet slowly.
D.Let the water run for at least 30 minutes. This flushes the carbon
filters on first time use.
E.After initial flushing, open the shut-off valve on the tank and close
the sink top faucet.
F.Tank will now full of water (usually 2 to 3 hours) after the tank has
filled. Open the sink top faucet and drain all water until the storage
tank is empty and there is only a small flow from the sink top
faucet.*** DO NOT USE FIRST TANK OF WATER.***
G.Close the sink top faucet. The system is now ready for use.
H.Change filters regularly every 6 to 12 months and have the
membrane checked annually.
Caution
1.Do not use hot water (over 45 C)!
2.Do not freeze the machine!
3.Switch off electricity and water source if away for more than 5 days,
and drain out pure water.
0
Operation regulation
1. 6/8 hot &cold water
deliver-valve
2. standing faucet
bracket
3. 3/8 extended RO
tubing white
Deliver-valve
20G water storage tank
Housing wrench C-type
Feed water connector
Tubing white
RO membrane x 3
Standard faucet
Tank ball valve

15
PURE-PRO REVERSE OSMOSIS SYSTEM
04
PURE-PRO REVERSE OSMOSIS SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
RO600 600GPD Light Commercial RO600 600GPD Light Commercial
3 Months
1 Year
1 Year
Stage 1
Stage3
Stage 2
Stage 4~6
200GPD TFC
membrane 3 pcs
Stage 7
12" Inline Post
Carbon Filters
Cartridge Filters Filter Description
3 Months
3 Months
This 5micron sediment filter is made of 100%
pure polypropylene fibers. High capacity filter
removes dusts, particles and rusts.
This granular activated carbon filter is composed
of high-performance activated carbon that
removes free chlorine, odor, organic
contaminants, pesticides and chemicals that
contributed to taste and odor.
This block carbon filter is composed of high-
performance carbon that removes free chlorine,
odor, organic contaminants, pesticides and
chemicals that contributed to taste and odor.
Made in USA. High rejection TFC type membrane
with the capacity of producing 200 gallons per day.
This membrane removes the following hard water
contaminants that may be present in your water:
lead, cooper, barium, chromium, mercury, sodium,
cadmium, fluoride, nitrite, nitrate, and selenium.
NSF approved. This post carbon filter is designed
to improve taste. It removes any residual
impurities and odors from the tank and provides a
finer conditioning of pure water.
20" length Block
Carbon Filter
Service Life
Cartridge Filters
20" length 5 micron
Spun-polypropylene
Sediment Filter
20" length
Granular Activated
Carbon Filter
Operation regulation
5For the first time operation when
changing the filters, water should
run for at least 20 minutes before
drinking it.
1Plug in electricity. 2Turn on water source.
To RO system
Booster
pump x 2
4Pumps start to function.
3Turn on water tank supply.

05
PURE-PRO REVERSE OSMOSIS SYSTEM
14
PURE-PRO REVERSE OSMOSIS SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
PRO
RE
NG WATE R SYSTEM
O
RO600 600GPD Light Commercial RO600 600GPD Light Commercial
ThepartsofRO600 Change membrane
5Open the RO membrane housing
anti-clockwise.
6Take out the old RO membrane with
a handy tool.
7Insert a new RO membrane.
1Unplug electricity.
To RO system
2Turn off water source.
Post carbon filter
RO membrane housing
Input water
1st stage filter housing
2nd stage filter housing
3rd stage filter housing
RO system main
housing bracket
High pressure switch
Flow restrictor
Jaco nuts
4Loose the Jaco fitting anti-clockwise.
3Turn off water tank
supply.

4Unplug electricity. 5Open the housings
clockwise.
6Insert new filter.
06
PURE-PRO REVERSE OSMOSIS SYSTEM
13
PURE-PRO REVERSE OSMOSIS SYSTEM
8After changing filters, let water run
for about 15 minutes to clear the
filters.
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
RO600 600GPD Light Commercial RO600 600GPD Light Commercial
ThepartsofRO600
Change filters
1Have a C-type
housing wrench
ready.
Be sure the
rubber gasket
is attached
on the housing
To RO system
2Turn off water source.
To tankTo faucet
7Loose the fitting nuts at point 1,2,3.
Take out the jaco fittings, and seal
it up with the Teflon tape again.
Replace the new pre-filters.
FLOW
12
3
Booster pump
Transformer
Solenoid valve
3Turn off water tank
supply.

PURE-PRO REVERSE OSMOSIS SYSTEM
07 12
PURE-PRO REVERSE OSMOSIS SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
11.Take tubing white. Wear the concave type screw on tubing white and insert the
tubing shroud as shown in the picture. Connect the tubing top with the faucet
end. Then connect the tubing end to the last stage filter (as point 4 on page 07)
12.Make sure that you complete No. 1 to No. 11. If so, switch on water supply and
plug in electricity.
PS. Do not use drink water from the first made water in the tank.
RO600 600GPD Light Commercial RO600 600GPD Light Commercial
Tubing connection diagram
1
2
3
4
In
To water storage tank
Drain out
To faucet
Installation diagram
4
2
1
Faucet
Tank
Drain out
Input water
3

10.Take out the faucet and its components. Install the faucet and the rubber
gasket to the kitchenware table. Install the rest of component as shown in the
picture.
PRO
P
URE
DRINKING WATER SYSTEM
1.Loosen the fitting nuts and the cap from the RO membrane housing as shown in
the picture. Unpack the RO membrane and insert to its housing (rubber gasket
towards to the open end). When completed, tighten up the cap with the RO
membrane housing and the jaco fittings.
2.Turn off the water supply. Loosen the stainless steel pipe connector.
PRO
RE
NG WATER SYSTEM
3.Get feed water connector and connect it to the stainless steel pipe as in the
picture 2.
PRO
P
URE
DRINKING WATER SYSTEM
PURE-PRO REVERSE OSMOSIS SYSTEM
11 08
PURE-PRO REVERSE OSMOSIS SYSTEM
RO600 600GPD Light Commercial RO600 600GPD Light Commercial
Jaco nuts
Cold
Installation diagramInstallation diagram
Faucet
Kitchenware table
Twisted plastic locker
Rubber gasket
Flat metal piece
Screw locker
PS. To suit your kitchenware table, you can choose to have twisted plastic locker
or screw locker to be installed for your faucet.

8.Take tubing white again, connect it with the drain out (as point 3 on page 07)
4.Get deliver valve and seal it with Teflon tape for 14 circles. Then connector it
with the feed water connector.
5.Get tubing white, connect it with deliver valve and the inlet water supply (as
point 1 on page 07)
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
7.Take tubing white, connect it to the deliver valve and the inlet water to storage
tank (as point 2 on page 07)
PURE-PRO REVERSE OSMOSIS SYSTEM
09 10
PURE-PRO REVERSE OSMOSIS SYSTEM
RO600 600GPD Light Commercial RO600 600GPD Light Commercial
9.Use an electric drill and drill an approximately 1 cm hole through the
kitchenware table.
Installation diagramInstallation diagram
6.Screw in ball valve connector as shown in the picture.
Before jointing the tank ball valve, seal ball valve connector with Teflon tape.
Now put tank ball valve and its connector together.
Note: Teflon tape is required for every joint point.
