Puregas Altec AIR P8400W User manual

P017585 – Rev. A
P8400W Air-dryer
User’s Guide

Altec AIR P8400W Air-dryer User’s Guide
Page 3 of 110 P017585 – Rev. A
1. Welcome & Congratulations
Congratulations on your purchase of a new ALTEC AIR P8400W Air-dryer! We here at
ALTEC AIR are very proud of our products and we are committed to providing you with
the best value and service possible.
We are sure that you will be satisfied with your new air-dryer and would like to thank
you for choosing ALTEC AIR for your air-dryer requirements. We also hope that you
will continue to choose us for your future air pressure and related product purchases.
For information about this and other ALTEC AIR products, please visit us on the web at:
www.AltecAIR.com
2. Introduction
PLEASE READ THIS USER’S GUIDE THOROUGHLY AND SAVE FOR
FUTURE REFERENCE.
This User’s Guide is provided for the benefit of our customers and contains information
and direction specific to the ALTEC AIR P8400W Air-dryer. It will cover topics
including: safety, specifications, installation, registration, operation, testing, maintenance,
replacement parts, service, and troubleshooting issues. Observation and compliance with
this User’s Guide will ensure the maximum life and efficiency of your air-dryer.
This User’s Guide should be read thoroughly prior to installing, operating, or servicing
the air-dryer in order to become familiar with the recommended procedures. This will
minimize the possibility of personal injury or damage to the unit due to improper
operation or handling.

Altec AIR P8400W Air-dryer User’s Guide
Page 4 of 110 P017585 – Rev. A
3. Table of Contents
1. Welcome & Congratulations .......................... 3
2. Introduction ..................................................... 3
3. Table of Contents............................................. 4
4. Safety & Warning Information...................... 6
5. Overview & Specifications.............................. 8
5.1 Product Description.................................... 8
5.2 Key Features............................................... 9
5.3 Technical Specifications............................. 9
5.4 Dryer Function Overview......................... 10
6. Installing Your Dryer.................................... 11
6.1 Safety & Warning Information................. 11
6.2 Before You Begin..................................... 12
6.3 Included Contents..................................... 13
6.4 Required Tools and Materials................... 13
6.5 Installation Steps....................................... 13
6.6 Installation Checklist................................ 23
7. Registering Your Dryer................................. 24
8. Operating Your Dryer .................................. 25
8.1 Safety & Warning Information................. 25
8.2 Connecting Air Lines to the Dryer ........... 26
8.3 Powering the Dryer ON & OFF................ 26
8.4 Using the Front Panel Display.................. 27
8.5 Identifying Dryer Alarms ......................... 30
8.6 Accessing the Setup Menu........................ 34
8.7 Using the System Setup Menu.................. 35
8.8 Using the Alarm Setup Menu ................... 42
8.9 Using the Network Setup Menu................ 48
8.10 Opening Panels....................................... 53
8.11 Depressurizing the Dryer........................ 54
8.12 Setting the System Pressure.................... 54
8.13 Setting the Static Pressure....................... 55
8.14 Setting the Outlet Pressure...................... 55
8.15 Engaging the Boost Transformer............ 56
8.16 Connecting via Web Browser................. 56
8.17 Using the Status Screen .......................... 59
8.18 Using the Setup Screen........................... 60
8.19 Using the Event/Alarm Screen................ 62
8.20 Using the Firmware Screen..................... 63
8.21 Connecting via SNMP ............................ 64
9. Testing Your Dryer ....................................... 65
9.1 Safety & Warning Information................. 65
9.2 Measuring Compressor Amp Draw .......... 66
9.3 Measuring Voltage to Compressor ........... 67
9.4 Measuring Incoming Voltage ................... 68
9.5 Measuring Voltages at Solid State Relay.. 69
9.6 Testing Consistent Heatless Dryer
Cycling............................................................ 70
9.7 Testing Unloader Valve............................ 71
9.8 Measuring Heatless Dryer Solenoid
Voltage............................................................ 72
9.9 Testing Precooler Fans.............................. 73
9.10 Testing Safety Relief Valve.................... 73
9.11 Testing Compressor ON/OFF Cycling ... 74
9.12 Testing Compressor Excessive Run
Time Alarms................................................... 75
9.13 Testing Humidity Alarm and System
Shutdown........................................................ 76
9.14 Testing High Outlet Pressure Alarm....... 78
9.15 Testing Low Outlet Pressure Alarm........ 79
9.16 Testing Air Fittings & Hoses for Leaks.. 81
10. Maintaining Your Dryer............................. 82
10.1 Safety & Warning Information............... 82
10.2 Six Month Maintenance.......................... 84
10.3 8,000 & 16,000 Hour Maintenance......... 85

Altec AIR P8400W Air-dryer User’s Guide
Page 5 of 110 P017585 – Rev. A
11. Replacement Parts & Accessories.............. 86
11.1 Top Section Parts.................................... 86
11.2 Middle Section Parts............................... 87
11.3 Heatless Dryer Assembly Parts............... 88
11.4 Lower Section Parts................................ 89
11.5 Frame Section Parts................................ 90
11.6 Accessories for Your Dryer.................... 91
11.7 Ordering Parts from ALTEC AIR .......... 92
12. Service & Repair.......................................... 93
12.1 Services Offered ..................................... 93
12.2 Initiating a Service Transaction.............. 93
13. Troubleshooting Your Dryer...................... 94
13.1 Before You Call ALTEC AIR................ 94
13.2 Safety & Warning Information............... 94
13.3 Air-dryer Won’t Power ON.................... 96
13.4 Display Screen Not Functioning............. 96
13.5 High Outlet Pressure Alarm.................... 96
13.6 Can’t Create a High Pressure Alarm....... 97
13.7 Low Outlet Pressure Alarm .................... 97
13.8 Can’t Create a Low Pressure Alarm ....... 98
13.9 High Flow Rate Alarm............................ 98
13.10 High Cabinet Temperature Alarm ........ 98
13.11 High Humidity...................................... 99
13.12 Can’t Create a High Humidity Alarm /
Shutdown...................................................... 100
13.13 Compressor Doesn’t Operate.............. 100
13.14 Compressor Won’t Build Pressure...... 101
13.15 Compressor Excessive AMP Draw..... 101
13.16 High Compressor Temperature........... 102
13.17 Compressor Excessive Run Time
Alarm............................................................ 102
13.18 Can’t Create a Compressor Excessive
Run Time Alarm........................................... 103
13.19 Compressor Rapid ON/OFF Cycling.. 103
13.20 Inconsistent Heatless Dryer Cycling... 103
13.21 Contacting ALTEC AIR Technical
Support.......................................................... 104
14. Appendix .................................................... 105
14.1 Wiring Diagram.................................... 105
14.2 Set Point Limits and Defaults ............... 106
15. Limited Warranty Agreement.................. 108
Registration Reminder.................................. 108
16. Contacting ALTEC AIR ........................... 109
16.1 General.................................................. 109
16.2 Sales...................................................... 109
16.3 Service .................................................. 109
16.4 Technical Support................................. 109
17. Notes............................................................ 110

Altec AIR P8400W Air-dryer User’s Guide
Page 6 of 110 P017585 – Rev. A
4. Safety & Warning Information
This section contains general information about safety and warning points to consider and
adhere to during installation, operation, and maintenance of your air-dryer. PLEASE
READ THIS SECTION BEFORE PERFORMING ANY OPERATION OR
PROCEDURE ON YOUR AIR-DRYER.
Additional warnings specific to an operation or procedure will also be presented
throughout the following sections. These will include the symbol as well as a label of
“WARNING!”, “CAUTION!”, or “IMPORTANT!”. Please be sure to pay close
attention for these warnings and read them as you encounter them.
WARNING!
For your safety, all the information in this User’s Guide must be
followed to minimize the risk of electrical shock and prevent
property damage or personal injury.
WARNING!
Extreme care should be exercised to avoid contact with live
electrical circuits. Many procedures performed during installation,
operation, testing, and maintenance of this air-dryer require the
equipment to be running, creating a situation for potential electrical
shock. It is highly recommended that you remove all jewelry before
performing any procedures.
WARNING!
Internal surfaces may be hot. Use care when contacting internal
components as there is a potential for some of these components to
become hot when in operation or standby.

Altec AIR P8400W Air-dryer User’s Guide
Page 7 of 110 P017585 – Rev. A
CAUTION!
Depressurizing the air-dryer may be necessary before performing
certain procedures. NEVER remove pressure sensing tubes from the
Control Board without depressurizing the air-dryer first, or damage to
the Control Board will occur.
IMPORTANT!
Performing procedures not described in this User’s Guide or installing
components not supplied by PUREGAS is NOT RECOMMENDED
AND MAY VOID THE
WARRANTY.
IMPORTANT!
Performing routine maintenance as outlined in the Maintaining Your
Dryer section will ensure optimal performance over the lifecycle of
yo
ur air
-
dryer.
CAUTION!
Incoming power to dryer must be 190 - 230 VAC, 1 Phase, 50 / 60 Hz
with minimum 20 amp service (3-wire, nub-out receptacle) with a 20 amp
circuit breaker. If hard-wiring directly, minimum of 12 AWG wire must be
used with an External Surge Protection Device (SPD).
CAUTION!
Proper Installation & Maintenance as outlined in this User’s Guide is
extremely important to ensure the reliability and longevity of the
equipment as well as prevent damage or personal injury.
WARNING!
High Noise. PUREGAS air-dryers are meant to be installed in an
unattended area.

Altec AIR P8400W Air-dryer User’s Guide
Page 8 of 110 P017585 – Rev. A
5. Overview & Specifications
5.1 Product Description
The P8400W Air-dryer from ALTEC AIR is designed to intake wet ambient air and
remove the moisture for delivery to applications requiring a constant, on-demand
source of dry, pressurized air. This process is fully automatic and will remain
consistent with minimal required periodic maintenance. This dryer is designed
specifically for indoor use.
The P8400W Air-dryer employs dual redundant systems that can be run
independently, interchangeably, or simultaneously depending on your pressurized air
requirement. Other features of the P8400W Air-dryer include a fully digital operating
platform offering the most accurate readings of dryer variables, removable access
panels allowing easier access for adjustment and maintenance, and ultra quiet
compressors with an industry leading maintenance interval of 8,000 hours.
CAUTION!
This Air-dryer does not contain an internal Surge Protection Device
(SPD). An SPD is required and must be supplied by the user.
CAUTION!
Observe precautions for handling Electrostatic Sensitive Devices.
IMPORTANT!
Installation of ALTEC AIR air-dryers are intended for network
telecommunication facilities (non-customer premises) only.

Altec AIR P8400W Air-dryer User’s Guide
Page 9 of 110 P017585 – Rev. A
5.2 Key Features
LCD display of all operating parameters
Precise humidity sensing within 0.1% RH
Redundant system for internal backup from one system to the other
Removable compressor tray for easy maintenance
Oil-less compressors with 8,000-hour maintenance interval
Remote alarm reset capabilities & access via HTML interface
SNMP communications capable
5.3 Technical Specifications
Output Capacity Normal:
6,500 SCFD both systems, 3,250 SCFD single system
Maximum:
8,
4
00 SCFD both systems, 4,
2
00 SCFD single system
Power Requirements 190 -230 VAC, 1 Phase, 50 / 60 Hz
Electrical Characteristics Running Amps: 15 (20 Amp service recommended)
Outlet Pressure Range 0 – 15 PSI (adjustable)
Outlet Air Humidity
Less than 2% RH
Compressor Type 2-cylinder, 3/4 HP, oil-less type compressor
Drying Method Heatless Desiccant
Operating Temperature
Range 40to 85F (5to 30C) Optimal
Noise Level 78.8 dBA
Heat Dissipation 6,000 BTU/hr
Alarms Standard alarms – complete readings of all critical
measurement points, individual alarm indication display
Outlet Connections Pressure Outlet: 1/2” NPT Female
Dimensions 21” D x 25.25” W x 49” H
(53.3 cm x 64.1 cm x 124.5 cm)
Net / Shipping Weight
265 lbs (120 kgs) / 318 lbs (144
kgs)

Altec AIR P8400W Air-dryer User’s Guide
Page 10 of 110 P017585 – Rev. A
5.4 Dryer Function Overview
# Component Description
1
Compressor
Compresses drawn in ambient air.
2
Pre
cooler
Cools
compressed air
prior to drying function
.
3
Unloader Valve
Relieves excess compressor head
pressure
.
4
Heatless Dryer
Removes moisture from compressed air.
5
Humidity Sensor
Measures the humidity of the
compressed
air
.
6 Capacity Control Valve Regulates system pressure and prevents air from
bleeding back through the heatless dryer.
7
Air
Tank
Stores dry
compressed air.
8 Static Pressure Regulator Regulates the static pressure (17 PSI).
Maintains constant pressure on the flow block for
accu
rate flow measuring
.
9
Flow Block
Measures the flow of compressed air.
10
Outlet
Pressure Regulator
Regulates the outlet pressure.
11 Pressure Outlet Outputs the pressure set by the Outlet Pressure
Regulator.

Altec AIR P8400W Air-dryer User’s Guide
Page 11 of 110 P017585 – Rev. A
6. Installing Your Dryer
6.1 Safety & Warning Information
.
WARNING!
Extreme care should be exercised to avoid contact with live
electrical circuits. Many procedures performed during
installation, operation, testing, and maintenance of this air-dryer
require the equipment to be running, creating a situation for
potential electrical shock. It is highly recommended that you
remove all jewelry before per
forming any procedures.
WARNING!
Internal surfaces may be hot. Use care when coming into contact
with internal components as there is a potential for some of these
components to become hot when in operation or standby.
CAUTION!
Proper Installation & Maintenance as outlined in this User’s Guide
is extremely important to ensure the reliability and longevity of the
equipment as well as prevent damage or personal injury.
WARNING!
High Noise. Air-dryers are meant to be installed in an unattended
area.
CAUTION!
This Air-dryer does not contain an internal Surge Protection Device
(SPD). An SPD is required and must be supplied by the user.

Altec AIR P8400W Air-dryer User’s Guide
Page 12 of 110 P017585 – Rev. A
6.2 Before You Begin
6.2.1 Carefully inspect the unit, including the shipping box as well as the air-
dryer, for ANY DAMAGE CAUSED BY SHIPPING. If any shipping
damage is detected, it is important to file a claim with the shipping
company prior to continuing the installation procedures.
6.2.2 Read the entire Installing Your Dryer section to familiarize yourself with
the components and procedures before performing the air-dryer installation.
6.2.3 Verify the installation location of the air-dryer:
6.2.3.1 Well ventilated and free from abrasive dust or chemicals.
6.2.3.2 Ambient temperature is between 40° and 85° F (optimal).
NOTE: Higher temperatures will decrease component lifespan.
6.2.3.3 Meets the following power requirements:
190 -230 VAC, 1 Phase, 50 / 60 Hz
Minimum 20 amp service circuit breaker
Outlet compatible with a HBL9965C plug
If hard-wiring directly, minimum of 12 AWG wire must be used
6.2.4 Notify the alarm center of the installation and potential for alarms during
the process (as necessary).
IMPORTANT!
Performing procedures not described in this User’s Guide or
installing components not supplied by PUREGAS is NOT
RECOMMENDED AND MAY VOID THE WARRANTY.
IMPORTANT!
Installation of PUREGAS air-dryers are intended for network
telecommunication facilities (non-customer premises) only.

Altec AIR P8400W Air-dryer User’s Guide
Page 13 of 110 P017585 – Rev. A
6.3 Included Contents
(1) P8400W Air-dryer
(1) Installation Guide (not shown)
Package located inside the dryer:
(1) User’s Guide (not
shown)
(2) Purge Mufflers
6.4 Required Tools and Materials
Large adjustable wrench
Medium adjustable wrench
7/16” wrench
Band cutters or snips
Lifting Straps
Pipe dope or pipe thread tape
Cup of soapy water
1-inch paint brush
(recommended)
6.5 Installation Steps
6.5.1 Remove all shipping materials.
NOTE: If ANY SHIPPING
DAMAGE is detected, file a
claim with the shipping
company prior to continuing
the installation procedures.
6.5.2 Place the dryer at the
operating location using lifting straps.

Altec AIR P8400W Air-dryer User’s Guide
Page 14 of 110 P017585 – Rev. A
6.5.3 Remove the front panel.
The front panel and top cover
are equipped with locking
latches if a higher level of
security is required.
6.5.4 Check for loose parts, hoses,
or wiring.
NOTE: If ANY SHIPPING
DAMAGE is detected, file a
claim with the shipping
company prior to continuing
the installation procedures.
6.5.5 Remove the shipping block
from under the compressor
plates.
Discard block and bolts.
6.5.6 Remove the ship-loose
contents package.

Altec AIR P8400W Air-dryer User’s Guide
Page 15 of 110 P017585 – Rev. A
On BACK of dryer:
6.5.7 Verify that the red orifice
plug is still installed where
shown.
6.5.8 Install the two (2) purge
mufflers (shipped loose).
6.5.9 Verify that the dryer is
powered OFF.
6.5.10 Plug the power cord into a
190 - 230 VAC, 1 phase,
50 / 60 Hz power outlet.
(HBL9965C Compatible)
6.5.11 Remove the Top Cover
from the dryer.

Altec AIR P8400W Air-dryer User’s Guide
Page 16 of 110 P017585 – Rev. A
6.5.12 Verify incoming voltage measurement:
6.5.12.1 Locate the Main
POWER Circuit
Breaker.
6.5.12.2 Use a Voltmeter to
measure the voltage by
placing the probes
between the Circuit
Breaker and terminal
insulation so that they
touch the metal contacts.
If the voltage measures between 210 – 230 VAC, skip to step 6.5.14 .
If the voltage measures less than 210 VAC, continue to the next steps to
engage the Boost Transformer.
6.5.13 Engage the Boost
Transformer:
6.5.13.1 Unplug the power cord
from the power outlet.

Altec AIR P8400W Air-dryer User’s Guide
Page 17 of 110 P017585 – Rev. A
6.5.13.2 Locate the Main Power
Lead quick disconnects in
the top section of the dryer.
6.5.13.3 Unplug the Main Power
Lead quick disconnects.
6.5.13.4 Plug both Boost
Transformer Lead
connectors into the Main
Power Lead connectors.
The incoming power wiring
should now look like this:

Altec AIR P8400W Air-dryer User’s Guide
Page 18 of 110 P017585 – Rev. A
6.5.13.5 Plug the power cord back into the power outlet.
6.5.14 Reinstall the Top Cover back
onto the dryer.
6.5.15 Turn the dryer power ON.
NOTE: Both system
compressors and heatless dryers
will start, creating air flow
through the red outlet pressure
orifice.
6.5.16 Set the System Pressures:
System 1 & System 2 are
adjusted and set independently.
Perform the following steps for
System 1 (left) and then repeat the steps for System 2 (right).
With Compressor running:
6.5.16.1 Pull the Capacity
Control Valve knob out.

Altec AIR P8400W Air-dryer User’s Guide
Page 19 of 110 P017585 – Rev. A
6.5.16.2 Turn the knob until
the reading on the
pressure gauge is 50
PSI.
6.5.16.3 Push the knob in to
lock.
6.5.17 Let the dryer run until the
Humidity drops under 2% on both
System 1 and System 2 (may take
up to 15 minutes).
NOTE: Press RESET if either System goes into SHUTDOWN.
6.5.18 Turn the dryer OFF.

Altec AIR P8400W Air-dryer User’s Guide
Page 20 of 110 P017585 – Rev. A
6.5.19 Connect the air supply line to
the dryer.
CAUTION: Be careful when
removing outlet plug. System may be
pressurized.
ALTEC AIR recommends using Installation Kit P011752 to connect your dryer to
the air supply line (See section 11.6 for detail).
6.5.20 Turn the dryer ON.
6.5.21 Set the Static Pressure:
6.5.21.1 Pull Static Pressure
Regulator knob out.
6.5.21.2 Turn knob until the
reading on the pressure
gauge is 17 PSI.
6.5.21.3 Push knob in to lock.
