PureLink HT-150 User manual

HT-150 Owner’s Manual
1 x 5 HDMI to HDBaseT Distribution Amplifier
PureLinkTM
535 East Crescent Avenue
Ramsey, NJ 07446
USA
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
www.purelinkav.com
For order support, please contact your local dealer.
For technical support, please contact us at [e-mail]

PureLink by Dtrovision
2
TABLE OF CONTENTS
Chapter 1. Product Overview
1.1 Safety Precautions --------------------------------------------------------------- 3
1.2 Product Description --------------------------------------------------------------- 4
1.3 Product Features --------------------------------------------------------------- 4
1.4 What’s in the Box --------------------------------------------------------------- 4
1.5 Common Application --------------------------------------------------------------- 5
1.6 Installation Guidelines --------------------------------------------------------------- 6
1.7 Matching Receiver Options -------------------------------------------------------------- 6
1.8 EDID Management ---------------------------------------------------------------- 7
1.9 IR Cable Connection Guide ------------------------------------------------------------- 8
Chapter 2. Product Specifications
2.1 HT-150 Specification --------------------------------------------------------------- 9
2.2 HCE II Rx Specification --------------------------------------------------------------- 9
2.3 HTR Rx Specification --------------------------------------------------------------- 11
2.4 HDMI Receptacle Pin Assignment -------------------------------------------------- 12
2.5 CATx (HDBaseT) Cable Termination ------------------------------------------------ 12
2.6 Mechanical Specification --------------------------------------------------------------- 14
2.7 Environmental Specification -------------------------------------------------------- 15
2.8 Troubleshooting --------------------------------------------------------------- 15
2.9 Maintenance --------------------------------------------------------------- 15
Chapter 3. Additional Information
3.1 Manufacturer’s Warranty (2-Year) ------------------------------------------------- 16
3.2 Customer Service ------------------------------------------------------------------- 16

PureLink by Dtrovision
3
Chapter 1. Product Overview
1.1 Safety Precautions
All safety instructions should be read and understood before the unit is operated.
The owner’s manual and safety instructions should be retained for future reference.
Unplug this unit from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp
cloth only.
Keep away from wet, magnetic, and flammable surfaces or substances.
Always use the correct external power supply (indicated on the product label) when operating this unit.
This unit may be equipped with a 3 wire grounding-type plug - a plug having a third (grounding) pin.
This pin will only fit in to a grounding type power outlet. If you are unable to insert the plug in to the
outlet, contact your electrician to replace your obsolete outlet.
Air vents should be kept clean and unobstructed at all times.
Please refrain from using frayed power cords and damaged wall outlets.
Do not place any heavy objects or equipment on top of the unit.
If you experience any malfunctioning of product or have any question as to operation of the
product, please contact our customer service center.
PureLinkTM
Tel: [phone]
Email: [e-mail]

PureLink by Dtrovision
4
Welcome!
Congratulations on your purchase of the PureLink HT-150 HDMI to HDBaseT distribution amplifier.
This manual contains information that will assist you in installing and operating the product.
1.2 Product Description
PureLink HT-150 HDMI to HDBaseT distribution amplifier is designed to distribute a single HD digital signal into
multiple displays over long distances without any degradation of original signal quality or distortion of the image.
HT-150 extends HD audio, video and IR control signals up to 330ft over a CATx cable. A dedicated IC chipset
makes HT-150 capable of amplifying and distributing highest quality of video signal and true HD digital contents.
In addition, HT-150 offers quick and easy plug and play installation for commercial and residential system.
1.3 Product Features
Distribute a single source to maximum five (5) displays
1 x HDMI input, 1 x HDMI output and 4 x CATx (HDBaseT) outputs
Extend a source at 1080p up to 330ft over single CATx cable with HTR HDBaseT extender receiver
(230ft with HCE II Rx)
HT-150’s CATx (HDBaseT) output can send signal directly to PureLink HDBaseT extender receiver,
eliminating the need of matching transmitter
Uncompressed high definition video up to 1080p@60Hz
HDMI 1.3 with 3D support
HDCP compliant
Local HDMI output for in room display, AVR, or cascading to another distribution amplifier
IR ports remote location AV devices control
High Quality Picture – No signal loss and digital noise free
1.4 What’s in the Box
HT-150 : One (1) unit
IR emitter : One (1) unit
IR receiver : One (1) unit
DC 12V 4.2A power supply adapter : One (1) unit
User’s Manual
Option Product: HCE II Rx (PureLink’s HDBaseT extender receiver)
HTR Rx (PureLink’s HDBaseT extender receiver)

PureLink by Dtrovision
5
TWC6 (PureLink’s certified CATx cable with TotalWire Technology)
PI (PureLink’s PureInstall HDMI cable with TotalWire Technology)
1.5 Product application notes
Figure 1 – Schematic Connection Diagram of HT-150

PureLink by Dtrovision
6
Figure 2 – Schematic Connection Diagram of HT-150
Figure 3 – Schematic Connection Diagram of HT-150

PureLink by Dtrovision
7
1.6 Installation
Important : Please use the installation procedure below. Improper or no operation may result if the start
up sequence is not correctly followed.
1. Carefully unpack the contents of the shipping group
2. Turn off the entire system before connecting
3. Connect your video source’s HDMI output port to the HT-150’s HDMI input port using a standard HDMI
cable (not included)
4. For local HD display, connect HT-150’s HDMI output port to your HD display’s HDMI input port
5. For remote location HD displays, connect HT-150’s CATx output port to PureLink HDBaseT extender
Rx’s CATx input port
6. Connect PureLink HDBaseT extender Rx’s HDMI output port to HD display’s HDMI input port
7. Plug the 12V power supply to HT-150
8. Plug the 12V wall mount power supply into the wall outlet
9. Turn power on the source and the display
1.7 HT-150’s matching receiver options ;
HCE II Rx : CATx (HDBaseT) to HDMI receiver. IR. 230ft (70m)
HTR Rx : CATx (HDBaseT) to HDMI receiver. IR. 330ft (100m)
* for detail specification information about HCE II Rx and HTR Rx, please go to pg 9-11.
Caution :
HT-150 is not designed to work in a network environment, do not connect it to network to avoid
damage
Do not place IR transmitter near from IR receiver to avoid mutual interference
The CATx wiring must be away from any elecromagnetic wave equipment, i.e : mobile phone,
microwave, radio, fluorescent lamp, high voltage power lines.
1.8 EDID Management
PureLink HT-150 provides Auto EDID management system; easy and fail safe way to handle EDID, via
pre-loaded factory default 1080p 2ch and EDID emulation.
What's EDID?

PureLink by Dtrovision
8
Extended Display Identification Data (EDID) is an information set that digital display provides to describe its
capabilities to a Video source. Video source will know what kinds of displays are connected and it will determine
which resolution to Output according to the EDID information received from the display.
The EDID normally includes manufacturer name and serial number, sets of capable resolution including native
resolution, supported timing, pixel mapping data (for digital displays only) and etc.
In a digital connectivity environment; in order to support the maximum resolution of connected monitor, EDID
handshake is a critical because improper EDID handshake between sources to the display will result in no image
on the display.
EDID handshake may sound simple; however, with multiple peripheral devices within the chain, display's EDID
information easily get lost or blocked while it is traveling to the source device.
HT-150 provides Auto EDID management system to meet today’s sophisticated digital connectivity integration
environment. There is an EDID setting DIP switch on the back of the unit;
EDID
SETTING
DIP Switch Position EDID function
Dip switch 1,2,3,4 “up” position Communicate EDID with factory default at 1080p 2ch
Dip switch 1, 2 "down" position & 3,4 "up" position Communicate EDID with output #1 (HDMI) connected display
Dip switch 2 "down" position & 1,3,4 "up" position Communicate EDID with output #2 (CATx) connected display
Dip switch 3 "down" position & 1,2,4 "up" position Communicate EDID with output #3 (CATx) connected display
Dip switch 4 "down" position & 1,2,3 "up" position Communicate EDID with output #4 (CATx) connected display
1.9 IR cable connection guide

PureLink by Dtrovision
9
There are two (2) IR ports on the HT-150 unit, 1 x IR Tx, and 1 x IR Rx.
IR Tx port is to send IR signals to remote location AV devices (mostly displays) via CATx (HDBaseT) cable
from a local source near HT-150 (ex. Blu ray player).
IR Rx port is to receive IR signals from remote locationAV devices (mostly displays) via CATx (HDBaseT)
cable to control a local source near HT-150 (ex. Blu ray player).
* Please note that HT-150 can only send same IR commands to all outputs. If more than one of the displays
Share the same IR codes, they will react to the commands simultaneously. To avoid this, please use different
brands or models of the displays.
Common IR cabling application would be like below diagram;
Figure 4 – Schematic IR Connection Diagram of HT-150

PureLink by Dtrovision
10
Chapter 2. Product Specifications
2.1 HT-150 Specification
Item Description
Model HT-150
Input type HDMI, 1 port
IR, 1 port
Output type
HDMI, 1 port
CATx, 4 ports
IR, 1 port
Graphic Resolution VGA / SVGA / XGA / UXGA / WUXGA
480i/p , 720i/p , 1080i/p
HDBaseT Output Distance 330ft (100m) with HTR Rx
230ft (70m) with HCE II Rx
HDBaseT IR Carrier Frequency 30 ~ 60 KHz
HDBaseT IR Emitter/Receive angle
HDBaseT IR Emitter/Receive distance 16 ft (5m)
Connector type
HDMI 19 Pin Female
RJ 45
3.5mm Phone Jack (for IR)
DC Power Jack
Supported format HDMI 1.3
HDCP Compliant Yes
Power Supply DC +12V , 4.2A
Dimension (W x D x H) 9.97” x 5.7” x 1.57” (253 x 145 x 40 mm)
Weight 1.9 lbs (0.86 kg)
2.2 HCE II Rx Specification
Item Description
Model HCE II Rx

PureLink by Dtrovision
11
Input type CATx (HDBaseT), 1 port
IR, 1 port
Output type HDMI, 1 port
IR, 1 port
Graphic Resolution VGA / SVGA / XGA / UXGA / WUXGA
480i/p , 720i/p , 1080i/p
HDBaseT Distance 230ft (70m) with HCE II Rx
HDBaseT IR Carrier Frequency 30 ~ 60 KHz
HDBaseT IR Emitter/Receive angle
HDBaseT IR Emitter/Receive distance 16 ft (5m)
Connector type
HDMI 19 Pin Female
RJ 45
3.5mm Phone Jack (for IR)
DC Power Jack
Supported format HDMI 1.4
HDCP Compliant Yes
Power Supply DC +5V , 2A
Dimension (W x D x H) 1.93” x 3.6” x 0.98” (48.6 x 92.3 x 24.8 mm)
Weight 0.61 lbs (0.28 kg)

PureLink by Dtrovision
12
2.3 HTR Rx Specification
Item Description
Model HTR Rx
Input type
CATx (HDBaseT), 1 port
IR, 1 port
Toslink optical in, 1 port
Output type
HDMI, 1 port
IR, 1 port
RS232, 1 port (bi-direction)
Ethernet, 1 port (bi-direction)
Graphic Resolution VGA / SVGA / XGA / UXGA / WUXGA
480i/p , 720i/p , 1080i/p
HDBaseT Distance 330ft (100m) with HTR Rx
HDBaseT IR Carrier Frequency 30 ~ 60 KHz
HDBaseT IR Emitter/Receive angle

PureLink by Dtrovision
13
HDBaseT IR Emitter/Receive distance 16 ft (5m)
Connector type
HDMI 19 Pin Female
RJ 45
3.5mm Phone Jack (for IR)
DC Power Jack
Serial
Toslink
Supported format HDMI 1.4
HDCP Compliant Yes
Power Supply DC +5V , 2A
Dimension (W x D x H) 3.5” x 4.7” x 1.2” (88.0 x 120.0 x 30.0 mm)
Weight 0.62 lbs (0.28 kg)
* Some of HTR’s features (RS232, Ethernet, and ARC) are not designed to use with HT-150.
2.4 HDMI Receptacle Pin Assignment
HDMI Connector Pin Assignment

PureLink by Dtrovision
14
Pin No. Signal Name Pin No. Signal Name
1 TMDS DATA 2+ 11 TMDS Clock Shield
2 TMDS DATA Shield 12 TMDS Clock -
3 TMDS DATA 2- 13 CEC
4 TMDS DATA 1+ 14 Reserved (HDMI 1.0–1.3c)
5 TMDS DATA Shield 15 SCL (I²C Serial Clock for DDC)
6 TMDS DATA 1- 16 SDA (I²C Serial Data Line for DDC)
7 TMDS DATA 01+ 17 DDC/CEC/HEC Ground
8 TMDS DATA Shield 18 +5 V (max 50 mA)
9 TMDS DATA 0- 19 Hot Plug detect (all versions)
10 TMDS Clock + 20
2.5 CATx (HDBaseT) cable Termination
HT-150 is designed based on TIA/EIA-566-B Standard. Please ensure that each PIN layout of
the cable is corresponding with the picture below before connecting the cable. Please note that CAT5e or
above level cable enables to deliver better quality and longer distance.
CATx cable
Link cable recommend use high quality CAT5, CAT5e, CAT6, CAT6a, CAT7 UTP/STP or FTP cable.
Transmission Distance
Pin
TIA/EIA-568B Signal
Wire color Digital RGB
1 Orange/ White TMDS Data2+
2 Orange TMDS Data2-
3 Green/ White TMDS Data1+
4 Blue TMDS Data0+
5 Blue/ White TMDS Data0-
6 Green TMDS Data1-
7 Brown/ White TMDS Clock+
8 Brown TMDS Clock-

PureLink by Dtrovision
15
The maximum transmission distance up to 330ft (100m), use lower resolution won’t extend longer than 330ft
(100m). If connection through the wall socket, the cable length must be less than 16ft (5m) between HT-150,
HDBaseT extender receiver and wall jack, as below drawing:
For HT-150 and HTR Rx setup:
For HT-150 and HCE II Rx setup:
2.6Mechanical Specification
Front Panel:

PureLink by Dtrovision
16
: Power On/Off indication (Green LED)
IN : HDMI input signal On/Off indication (Blue LED)
OUT 1 – 5 : Output signal On/Off indication (Blue LED)
Rear Panel :
IR Tx : IR port to send IR control signals to CATx (HDBaseT) outputs to remote location AV devices
IR Rx : IR port to receive IR control signals from CATx (HDBaseT) outputs from remote location AV
devices
IN : HDMI input port
OUT 1 – 5 : HDMI & CATx (HDBaseT) output ports
EDID : EDID management DIP switch
DC + 12V : Power Receptacle
2.7 Environmental Specification
Items Status
Operating Temperature 32˚F ~ 131˚F (0˚C ~ 55˚C)
Operating Humidity 10% ~ 80%, non-condensing
Storage Temperature -4˚F ~ 158˚F (-20˚C ~ 70˚C)
Storage Humidity 5% ~ 95%, non-condensing
2.8 Troubleshooting

PureLink by Dtrovision
17
The display shows only black screen.
- Ensure that all plugs and jacks used by external power supplies (both PureLink product and others) are firmly
connected. Ensure the all LEDs are ON.
- Ensure that the HDMI ports are firmly plugged in to the source and display.
- Ensure that the CATx cable is properly terminated.
- Ensure that the HT-150 and PureLink HDBaseT receiver are plugged correctly to the source and display,
respectively.
- Check if the source and display are powered on and properly booted.
- Reset the system by un-plugging and re-plugging the HT-150’s all input and output ports or PureLink HDBaseT
receiver’s CATx and HDMI ports, or by un-plugging and re-plugging the power cord plugs of HT-150 and
PureLink HDBaseT Rx modules.
- Re-boot up the system while connecting the optical HDMI extension module.
Screen is distorted or displays noises.
- Replace HDMI cables
- Replace CATx cables
- Ensure that the resolution sets less than 1920x1080 at 60Hz refresh ratio.
- Reset the system.
2.9 Maintenance
No special maintenance is required for the HT-150 HDMI to HDBaseT distribution amplifier. Ensure that the
HT-150 unit and power adapters are stored or used in a benign environment free from liquid or dirt
contamination. There are no user serviceable parts. Refer all service and repair issues to PureLink.
Chapter 3. Additional Information
3.1 Manufacturer’s Warranty (2-Year)
PureLink warrants this HT-150 HDMI to HDBaseT distribution amplifier to be free from defects in workmanship
and materials, under normal use and service, for a period of two (2) year from the date of purchase from
PureLink or its authorized resellers.

PureLink by Dtrovision
18
If the product does not operate as warranted during the applicable warranty period, PureLink shall, at its
option and expense, execute one of the following as necessary:
1. Repair the defective product or part
2. Deliver to customer and equivalent product or part to replace the defective item
3. Refund to customer the purchase price paid for the defective product
All products that are replaced become the property of PureLink. Replacement products may be new or
reconditioned. Repaired or replacement products or parts come with a 90-day warranty or the remainder of the
warranty period. PureLink shall not be responsible for any software, firmware, information, or memory data
loss of contained in, stored on, or integrated with any products returned to PureLink for repair under warranty.
3.2 Customer Service
Any customer service inquiries can be submitted electronically through the Q&A form on our website
( www.purelinkav.com ).
For immediate assistance please contact us at [phone] to reach our customer care or tech support
team.
