PureMate PM 210UV User manual

IONIC AIR PURIFIER
Model No: PM 210UV
INSTRUCTION MANUAL

Thank you for purchasing the efficient PureMate PM 210UV ionic air purifier. We
wish you many years of healthy indoor air with this innovative product.
Ensure that all safety precautions are followed when using electrical appliances for
the proper operation of the device.
This instruction booklet describes the safety precautions to be observed during
operation to prevent injuries to yourself, other persons and damage to the device. The
content not only is suitable for this product but also suitable for electrical appliances in
general.
- Read all instructions before using appliance.
- IMPORTANT - This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit in a polarized
outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it
still does not fit, contact a qualified electrician. Do not attempt to defeat this safety
feature.
- To avoid fire or shock hazard, plug the appliance directly into a right AC electrical
outlet.
- Keep the cord out of heavy traffic areas. To avoid fire hazard, NEVER put the cord
under rugs, near heat registers, radiator, stoves or heaters.
- To protect against electrical hazards, DO NOT immerse in water or other liquids. Do
not use near water.
- Children cannot recognize the hazards associated with the usage of electrical
appliances. For this reason, always supervise children when they are near the unit.
- Always unplug the air purifier before moving it, opening the grill, changing filters,
cleaning or whenever the air purifier is not in use. Be sure to pull by the plug and not
the cord.
- NEVER drop or insert any object into any openings.
- DO NOT run cord under carpeting.
- DO NOT cover cord with throw rugs, runners, or similar coverings.
- DO NOT route cord under furniture or appliances. Arrange cord away from traffic
area and where it will not be tripped over.
- DO NOT operate any appliance with a damaged cord or plug, if motor fan fails to
rotate, after the appliance malfunctions, or if it has been dropped or damaged in any
manner. Send to Customer Service for assistance.
- Use appliance only for intended household use as described in this manual. Any
other use not recommended by the manufacturer may cause fire, electric shock or
injury to persons.
- DO NOT use outdoors.
- DO NOT place anything on top of unit.
- NEVER block the air openings, grills/outlets or place on a soft surface such as a bed
or sofa, as this could cause the unit to tip over, blocking the air intake or outtake
opening.
English | 1
SAFETY OPERATION
SAFETY PRECAUTIONS

1. Negative Ionization. Negative ions magnetically attracts floating particles,
causing them to become too heavy to remain airborne. As a result, they settle out
of the air, so that they can no longer be inhaled. The negative ions also cause
particles to magnetically attract to the collector plates just inside the PM 210UV.
The unit uses 25 stainless steel, electrodes to produce a high density of negative
ions (60,000,000 per cm³).
2. Electrostatic Precipitation. The electrostatic charge created between the
negatively charged ionizer pins and the positively charged dust collection plates
causing undesirable particles and pollutants to become magnetically trapped on
the plates.
3. Germicidal UV Light. UV (ultraviolet light) is scientifically-proven to destroy a
large variety of microbial contaminates, such as viruses, germs, bacteria and
fungi (including mould). Ultraviolet light has been used for years by the medical
field (including hospitals) to sanitize rooms and equipment, in order to prevent the
spread of illness and disease. It is recommended by Centres for Disease Control
for its ability to destroy biological pollutants.
Where to put the PM 210UV
- Elevated Location. Optimal elevation is 5 feet (1.5 meter) or more o the ground,
although it is not absolutely necessary to place the unit high o the ground.
- Air Flow. If you can place the unit near a source of air ow for the room or area, such as
by a fan or supply vent, the negative ions will be distributed more eectively.
- Open Area. Place the unit where it’s output will achieve more eective distribution.
- Centralized Location. The more this air ionizer is centrally located, the more area it can
cover. Placing it in a corner or against a wall will typically suce for most rooms though.
- Near Source of Pollution. The closer the unit is placed to a source of pollution, the more
eective it will be.
NOTE: For people with respiratory problems.
- Individuals aected by respiratory problems such as asthma or allergies are the ones who
most need the pure and fresh air provided by the PureMate ionizers. We therefore
suggest putting the PM 210UV in the room where these individuals would spend most of
their time.
- DO NOT attempt to repair or adjust any electrical or mechanical functions on this
unit. Doing so will void your warranty. The inside of the unit contains no user
serviceable parts. All servicing should be performed by qualified personnel only
English | 2
HOW IT WORKS
PLACEMENT

- For individuals who have chronic respiratory problems, we recommend that the PM
210UV be set at low at night time, if the ionizer is in the bedroom, since respiratory
activities dier in sleep.
- Since the unit produces moderate levels of Active Oxygen (Ozone), it is not recommended
to breathe too closely in front of the grill. Maintain a distance of at least 19” (48 cm) from
the unit.
English | 3
COMPONENTS
1. Front Grill
2. Power On/Off Button
3. Power Indicator (Red Light)
4. Control Indicator - High (Green Light)
5. Control Indicator - Low (Yellow Light)
6. Low/High Adjusting Switch
7. Dust-Collection Plates
8. Removable Back Grill
9. Fan
10. Independent Control for Fan
11. DC Power Socket
12. Germicidal UV Lamp
1
2
654
12
8
11
10
7
9
3

English | 4
OPERATING INSTRUCTIONS
CLEANING & MAINTENANCE
- Insert the end (hollow plug) of the cable of the AC/DC adapter into the DC socket
(Marked as DC12V) on the back of the air purifier (The DC adapter is for vehicle
use only).
- Insert the adapter in the electric socket or the vehicle’s cigarette lighter socket.
- Press the power switch, which will activate the unit and the red LED light.
- The fan is independently controlled. The switch on the side of the PM 210UV turns
the fan “ON” for increased effectiveness, or “OFF” for virtually silent operation.
Please ensure unit is turned off and unplugged before performing any cleaning or
maintenance.
Cleaning the Dust Collection Plates:
- The dust collection plates should be cleaned about every 20-30 days, or when
covered with dirt and residue. Cleaning the dust collection plates is very simple.
- Twist the knob on the right hand side of the air purifier and pull the plates out.
- Wipe the plates off with a damp cloth. If there is difficult-to-remove residue on the
plate, you should use a mild household cleaner, such as detergent, to help remove it.
- Dry the plates.
- Reinsert the plates back into the air purifier. Twist the handle to lock them in place
and so that the unit will operate again. Please refer to the lock and unlock symbols
on the handle of dust collection plate.
Settings:
Power:
- “Hi” - runs at full capacity.
- “Lo”- Automatically runs in intervals of 35 seconds “on” and 60 seconds“o”.
- “ O  ”.
Fan:
(1)“O” - turns fan o, resulting in virtually silent, ionic air purication.
(2)“On”- increases air flow through unit, increasing eectiveness.
1. Removing the dust collection plates. 2. Wiping dust collection plates clean.

At the end of the product life cycle, you should not throw this machine
into the normal household garbage but ring the product to a collection
point for the recycling of electrical and electronic equipment.
DISPOSAL OF THIS DEVICE
English | 5
Note: When removing the collector plates for periodic cleaning, please note that it
must be returned to the unit in exactly the same position for a flush fit. Reversing the
position will result in an incomplete closure and the unit will not function properly.
SPECIFICATIONS
Rated Voltage: 220-240 V/50-60Hz, 12 V DC
Power: 8 Watts
Negative Ion Output: 60,000,000 / cm³
Ozone Output: 0.015-0.04 PPM
UV Lamp Wavelength: 30uW (Frequency : 254 nm)
Fan Speed: 0.4 m³ per minute
Room Coverage: 46 m²
Dimensions: 35 x 22 x 12.7 cm
Weight: 1.4 kg
