Purite SELECT HP User manual

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954
SELECT HP
OPERATING MANUAL
Issue A
1/9/09

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 2

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 3
CONTENTS
1DOCUMENT HISTORY .................................................................................5
2CONTACT DETAILS .....................................................................................5
3HEALTH AND SAFETY .................................................................................7
3.1 Explanation of symbols and references ..................................................7
3.2 Additional safety requirements ...............................................................7
3.3 Usage in accordance with intended purpose. .........................................7
3.4 Operating staff ........................................................................................8
3.5 Bringing the system to a stop in the event of an emergency ..................8
3.6 Safety information for maintenance tasks...............................................8
3.7 Disposing of system parts and operating materials ................................8
3.8 Unauthorised conversion and manufacturing replacement parts............9
3.9 Warranty claims and liability ...................................................................9
4ABOUT YOUR WATER PURIFIER .............................................................11
4.1 The Select HP range of units................................................................11
4.2 Key Components of the Select HP .......................................................11
4.2.2 Touch screen display..................................................................11
4.2.3 Close coupled tank .....................................................................12
4.2.4 Removable front cover................................................................12
5OPERATING YOUR WATER PURIFIER.....................................................13
5.1 Menu Structure .....................................................................................13
5.1.1 Power On screen ........................................................................13
5.1.2 Start Up Screen ..........................................................................13
5.2 Power On screen..................................................................................14
5.3 Menus...................................................................................................16
5.4 Clean routine menu ..............................................................................16
5.5 Dispense options menu ........................................................................19
5.6 Settings menu.......................................................................................19
5.7 Maintenance .........................................................................................24
5.8 Systems menu......................................................................................26
6MAINTENANCE...........................................................................................31
6.1 Replacing media packs.........................................................................31
6.2 Cleaning inlet screen filter ....................................................................31
6.3 Cleaning procedure. .............................................................................32
6.4 Replacing the filter................................................................................33
6.5 Maintenance and service spares ..........................................................34
6.6 Trouble shooting...................................................................................35
7Technical specification.................................................................................37
7.1 Product outputs ....................................................................................37
7.2 Treated water specification...................................................................37
7.3 Water storage .......................................................................................37
7.4 Fuse rating / type..................................................................................37

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 4
8INSTALLATION ...........................................................................................39
8.1 Installation Kit .......................................................................................39
8.2 Media Packs .........................................................................................39
8.3 Feedwater supply requirements ...........................................................40
8.4 Electrical Supply ...................................................................................40
8.5 Unit positioning .....................................................................................40
8.6 Drain connection...................................................................................42
8.7 Installation of media cartridge packs ....................................................42
9APPENDIX...................................................................................................43

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 5
1DOCUMENT HISTORY
Issue Date of
Change
Description of Change Approved by
A First Issue: 1/09/2009
2CONTACT DETAILS
We trust the system will meet all your expectations. However, should you have
any additional questions concerning the equipment please do not hesitate to
contact Purite Ltd at:
Purite Ltd
Bandet Way
Thame
Oxfordshire
OX9 3SJ
United Kingdom
For all spares and consumable enquiries contact:
Customer Services Department: Tel No. [phone]
For all service enquiries contact:
Service Department: Tel No. [phone]
For further sales enquires contact:
Sales Department: Tel No. [phone]

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 6

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 7
3HEALTH AND SAFETY
3.1 Explanation of symbols and references
This symbol refers to any immediate dangers. Failure to
follow the specified procedure could result in serious
personal Injury. Extreme caution should be observed when
conducting any activity where this symbol is shown. Work
should be completed by a trained competent person.
Danger
Electrical shock. Do not touch electrical components. Before
performing tasks on parts of the electrical system, disconnect the
system from the power supply.
Warning
This symbol refers to a possible danger. Failure to follow the
specified procedure could result in personnel injury. Caution
should be observed when conducting any activity where this
symbol is shown. It is recommended work should be completed
by a trained competent person.
This symbol refers to a possibly hazardous situation.
Failure to observe these references may result in minor injuries
and/or damage to property.
Caution
I This symbol points out important information for working with the
system in the proper manner. Failure to observe these references
may result in malfunctions in the system or impact on the
environment.
3.2 Additional safety requirements
Country-specific requirements standards and regulations must be observed.
3.3 Usage in accordance with intended purpose.
The units must only be operated with water supplied in accordance with the
quality described and the operating parameters specified in “installation
details”.
The units must not be operated unless in proper working order. Any
malfunctions must be rectified immediately.

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 8
3.4 Operating staff
Only persons who have read and understood this Operating Manual should
be permitted to operate the unit. When operating the units, it is important to
observe all safety information.
3.5 Bringing the system to a stop in the event of an
emergency
Switch off via the display.
Turn off the electrical supply.
Shut off the water supply.
After remedying the damage:
Open the water supply.
Turn on the electrical supply.
Restart the unit via the main display.
3.6 Safety information for maintenance tasks
The operator must take care to ensure that all maintenance, inspection and
assembly tasks are performed by authorised and qualified professionals who
have been sufficiently informed regarding the task at hand (via use of
Operating Manual).
The system must be shut down and be protected from further use until all
repair and maintenance tasks have been completed. It is essential to observe
the shutdown procedure as described in this Operating Manual.
Before beginning tasks relating to electrical equipment/components of this
system, a check must confirm that power has been disconnected from the
corresponding section of the system. In addition, the system must be secured
to prevent it from being turned on again unintentionally.
3.7 Disposing of system parts and operating materials
When they need to be discarded, consumables must be disposed of
according to local and National requirements.

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 9
3.8 Unauthorised conversion and manufacturing
replacement parts
Conversion or modification of the system is only permitted with the approval
of the manufacturer. The same applies to making changes in the
programming for the control system. Original replacement parts and
accessories authorised by the manufacturer enhance safety. Use of other
parts will void the warranty.
3.9 Warranty claims and liability
This product has been manufactured in accordance with ISO 9001:2008
procedures, after which it was subjected to a quality control process. If,
however, you are unsatisfied with the unit, please contact the manufacturer
(Purite Limited).

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 10

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 11
4ABOUT YOUR WATER PURIFIER
The Purite Select HP purifies potable water. Water fed into the unit is pumped
through a combination of filtration devices, ionic resin exchange units and
reverse osmosis modules. Purified water produced by the unit complies with
latest standards for laboratory grade water.
4.1 The Select HP range of units
GP: Generation unit (with no close coupled tank).
IT: Generation unit with close coupled 20 litre water storage
tank
GP BP: Generation unit with feed water boost pump
BP/IT: Generation unit with close coupled water storage tank and
feed water boost pump
Each of the above variants is available with 4 different output flow rates:
HP 40 6 litres per hour
HP 80 12 litres per hour
HP 160 24 litres per hour
HP 320 48 litres per hour
Please note that the above outputs are based on an 8 hour working day at
60psi (4 bar) inlet pressure, 25oC and maximum of 400 ppm total dissolved
solids.
The unit type is detailed on its serial plate which can be found on the reverse
side of the front cover.
The Select HP is provided with an installation kit for quick installation.
Both media packs are provided and packaged separately.
4.2 Key Components of the Select HP
4.2.2 Touch screen display
Operation of the Select HP is controlled solely through the touch screen
display. System schematics are displayed for easy understanding of the
unit’s process.

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 12
4.2.3 Close coupled tank
The close coupled tank holds 20 litres of purified water. To dispense water
a bib tap has been provided at the front of the tank.
Note: Generation units are NOT supplied with a water storage tank
4.2.4 Removable front cover.
The front cover is easily removed and provides access to the cartridge
media packs.

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 13
5OPERATING YOUR WATER PURIFIER
Your Select HP is operated via the touch screen display. Buttons are provided on
the display to access start menus and set up functions. The display also provides
a mimic of the system when in operation.
5.1 Menu Structure
5.1.1 Power On screen
PROCESSING 09/09/09 10.22
MENU
WELCOME
START
HP
When connected to an electrical supply the power on screen is displayed.
5.1.2 Start Up Screen
Start
→Stop
→Dispense
→Menu A
→Text bar display options
Menu
→Clean routine
→Are you sure
→Loop clean
→clean
→Dispense options
→Method
→Volume
→Manual Latched
→Manual hold
→Settings menu
→Language
→English
→Time and date
→Set Time
→Set date
→Set Format

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 14
→Alarms
→Audible alarm enable
→Set Quality Alarm
→Set Temperature alarm
→Maintenance
→PT pack date
→PP pack date
→System Menu
→Product information
→Engineer menu
→Enter Pin No.
→Set Unit ID
→Auto restart
→Enable
→Disable
→Data Transfer
5.2 Power On screen
To switch the unit on press the START button on the power on screen.
WELCOME
HP
START
MENU
PROCESSING 09/09/09 10.22
When start is pressed the following screen is displayed to show the unit is in
operation and processing water.

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 15
The mimic screen shown above features four buttons and displays the
process elements of the system. In normal operation they remain a fixed
colour. However, in the event an alarm is detected or a specific process
element goes into fault, the symbol on the display will flash red to indicate
maintenance or corrective action is necessary. In addition the text bar at the
top of the screen will alternate between showing an alarm is active and the
data normally displayed.
The mimic screen push buttons
STOP This stops the unit and returns you to the power on screen.
DISPENSE When pressed, water is dispensed from the dispense point. It
is not possible to dispense water from the unit until the tank is
filled to its mid level switch. This may take a few minutes
dependant upon model variant.
MENU This accesses a secondary menu to allow dispense settings to
be stored.
▼Scrolls through the text bar display on the top of the screen to
show
Alarms active
Temperature
Outlet quality
Outlet Quality Uncompensated
These are features for display only and cannot be adjusted or reset from this
screen.
If an alarm is active the text bar display will alternate between the active alarm
and the last required display feature.

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 16
5.3 Menus
WELCOME
HP
START
MENU
PROCESSING 09/09/09 10.22
Pressing the menu button on the POWER-ON screen leads to a sequence of
options, user definable parameters and information about your Select HP.
Menu screens feature buttons: BACK; UP; DOWN; ENTER.
UP and DOWN are used to move through the options available (or to increase
or decrease numerical vales). ENTER selects the option highlighted and
BACK returns to the previous screen.
5.4 Clean routine menu
Selecting the Clean Routine from the menu begins the cleaning process.
Prompts are provided to describe the insertion of the cleaning agents required
for the process. i.e. remove media pack and replace with disinfect pack
adaptor.
USER MENU 09/09/09 10.22
Clean Routine
Dispense Options
Settings Menu
ENTER
BACK

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 17
Selecting Clean routine commences the cleaning process. You will be
required to confirm you wish to commence cleaning with the following prompt.
Refer to maintenance section before commencing the cleaning process.
USER MENU 09/09/09 10.22
Are you sure?
If yes is confirmed you will be required to select one of two cleaning routines.
Two routines are available: Loop Clean and Full Clean
Loop Clean circulates the disinfectant around the recirculation loop and the
close coupled tank if one is fitted.
Full Clean circulates the disinfectant through the entire system.
YES
NO
USER MENU 09/09/09 10.22
Loop Clean
Full Clean
ENTER
BACK

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 18
During the a status bar displays progress.
Cleaning
Tank Filling
1%
DO NOT DISPENSE WATER !!
Loop Clean 09/09/09 10.22
If power to the device is interrupted during a the process it is imperative the
cleaning routine is completed.
When power is restored to the device it will start by displaying the screen
below. Press CLEAN to resume the clean routine at the point it was
interrupted
Failure to complete the clean routine may lead to chemicals
remaining in the dispensed water.
Restart
Clean Interrupted by
Power down
Press CLEAN to continue
CLEAN
Loop Clean 09/09/09 10.22

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 19
5.5 Dispense options menu
Method
Manual Latched
Manual Hold
ENTER

BACK
Dispense options enable different dispense methods to be set.
Manual latched
When the dispense button is pressed water is dispensed continuously until
the dispense button is pressed again.
Manual Hold
The dispense button must be pressed and held down to dispense water.
When the button is released water dispense is terminated.
5.6 Settings menu
System Menu
Language
Time and Date
Alarms
Maintenance
System menu
ENTER
BACK
The settings menu enables system parameters to be entered and storedettings menu enables system parameters to be entered and stored

SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 20
Language
Text displays can be set to be shown in one of two languages.
LANGUAGE 09/09/09 10.22
ENGLISH
FRENCH
BACK

ENTER
Highlight the appropriate tick box by pressing on it and then pressing enter.
Time and date
The system time and date can be set.
Time and Date menu
Set Time
Set Date
Set Format
ENTER
BACK
